EATON AEROQUIP® brand name represents quality and innovation for aerospace and other industrial applications with a wide range of hoses, fittings, couplings and connectors available to cover application requirements. Following the acquisition of Eaton’s hydraulics business by DANFOSS, EATON AEROQUIP® products form now part of DANFOSS product portfolio.

DANFOSS EATON AEROQUIP® 491 and 471 hose fittings consist of an AN818 style nut, an externally threaded 37 nipple and an internally threaded hose socket. Fittings of sizes 3 through 6 have nuts and nipples of cadmium plated steel. Nuts and nipples for size 8 and larger are of anodized aluminum. Fittings conform to MS24587. Available in different tube and thread sizes in inches.

For additional information please consult the supplied documentation or contact us.

The  PARKER HANNIFIN (Hose Products Divisionn) offers the following series of Medium & High Pressure hydraulic hoses compatible with No-Skive fittings.

- BCH Series braided and SX Series spiral hoses meeting international technical standards. More recently developed they are intended for demanding small and medium OEMs and general distribution,

- ELITE No-Skive braided and Parkrimp® No-Skive spiral hoses, exceeding the standards and highly appreciated in the very demanding MRO and OEM markets.

- GLOBALCORE™ State-of-the-art  hose product range, exceeding the newest ISO 18752 and providing technical and economical excellence to the most demanding customers.

Good, Better, Best classification system is used for easier hose and fitting understanding and selection with superior performance of Best hoses versus their Better and Good counterparts including:

- Bend radius up to 50% smaller

- Flexibility (bending force) up to 30% higher

- Weight up to 20% lower

- Dimensions up to 25% smaller area

- Impulse resistance and service life up to four times higher

- Working temperature up to 25% higher

Agriculture is one of the typical markets and applications where Good hoses and fittings are the preferred product selection.

For additional information please refer to the supplied documentation or contact us.

Range of special accessories by FRANZ AIRCRAFT ENGINES for use in BRP-ROTAX® aircraft engines and other applications.

EATON HANSEN HA 15000  Series couplings, now part of DANFOSS product portfolio,  are general purpose hydraulic and fluid transfer couplings conforming to the dimensional requirements of ISO 7241-1 Series A. Body sizes are 1/4", 3/8", 1/2", 3/4" and 1".

Standard Materials used in their manufacturing include:

• Zinc-plated steel construction

• Stainless steel springs, balls and retaining rings

• Buna-N (Nitrile) seals

Product Features:

• Ball lock

• Manual connect, disconnect

• Poppet valving

• Slim profile

• Zinc plated steel construction

• NPTF and BSPP end connections

• Available push-to-connect socket designed for bulkhead mounting (1/2" body size only)

Rated Pressure in PSI / BAR per Body Size

1/4" - 4,568 / 315

 3/8" - 4,568 / 315

 1/2" - 3,625 / 250

 3/4" - 3,625 / 250

 1" - 2,900 / 200

For additional information please refer to the supplied documentation or contact us.

Note: Special Order items. Non-Cancellable/Non-Returnable Upon Order Placement (NCNR).

The  PARKER HANNIFIN (Hose Products Divisionn) offers Push-Lok® Plus multipurpose hose lines featuring the widest fluid compatibility, application range and size range in the industry. At the same time they incorporate the highest working pressures in all sizes, making them the most versatile general-purpose hoses available. PARKER Push-Lok®  system is easy to use. No clamps or special tools are required during installation enabling assemblies in seconds, saving valuable time and cost. The unique seal of Push-Lok ensures reliable, durable, leak-free service while with PARKER:s exclusive color-code system hose inventories are identified and maintained easily and efficiently.

PARKER's 801 general-purpose hoses with Push-Lok Plus technology are low-pressure, multipurpose synthetic rubber hoses featuring PARKER's exclusive color-coding system. Suitable for use with a wide range of media, 801 hoses are compatible with petroleum-based hydraulic fluid and lubricating oils, pneumatic power, antifreeze, and, when coupled with HY Series fittings, diesel fuel. These versatile hoses feature the unique Push-Lok® seal for easy assembly ensuring reliable, durable, and leak-free service. 801 hoses offer maximum working pressures ranging from 200 to 350 psi. The exclusive color-coding system enhances organization and assembly. Common uses include construction, utilities, machine tooling, ground support, industrial, and automotive applications.

For additional information please refer to the supplied documentation or contact us.

ROTAX® aircraft  engines form part of the product portfolio  of BRP-Powertrain GmbH & Co. KG which develops and manufactures engines for snowmobiles, watercrafts, boats, roadsters, all-terrain and side-by-side vehicles, motorcycles, carts, and aircrafts.

BRP-ROTAX® product range includes certified and non certified internal combustion engines, parts and accessories for light and ultralight aircraft.

Different hoses for water, heat, air intake, protection, form, connecting, low pressure and others & related fittings are used in BRP-ROTAX® aircraft engines. They are offered as certified or non certified parts from the manufacturer. Non certified parts can be used in ultralights or other aircraft not requiring certification of parts for their installation. Certified parts are designated by the letters "CERT" in the product reference number (SKU). ROTAX engine hoses are generally sold in meters and appearing prices are per meter but some hoses of specific dimensions and fittings are sold in pieces.

Aircraft engine  parts are subject to changes from time to time. Some parts may be no longer available or replaced by others with different part numbers. Listed BRP-ROTAX® engine parts do not imply their current availability or suitability for your engine application. Always consult the most recent Illustrated Part Catalogs (IPCs) or other documentation available from the manufacturer for the correct part number before ordering.

AVIATIONEU NEW ERA end hose banjo fittings are intended for use in hydraulic pipes in automotive fuel, oil and hydraulic systems. They are available with single or double ends from different materials, mild steel, EN 1AL(free cutting steel), 11SMnPb30, EN 8, stainless steel 202 & 304. Sourced by certified manufacturers these banjo fittings are competitively priced and offered in different Metric sizes (M10x5/16", M12x5/16", M14x5/16", M14x3/8", M16x3/8", M18x3/8", M18x1/2") and different surface treatments (clear /yellow zinc plated, olive green zinc plated, dacromet). Sold by the piece (pc.) with Minimum Order Quantity (MOQ) 500 pcs.  Appearing price is for reference only per pc. Please contact us for a quotation.

The  PARKER HANNIFIN (Stratoflex Products Division) offers a broad array of PTFE, rubber and metal hose and hose assemblies in different outside diameters (OD), hose fittings, rigid tube assemblies, couplings, quick disconnects, swivel joints, fuel break-away valves, hydraulic fuses, and flow regulators, and specialty fittings including permanently swaged and welded fittings suitable for virtually any aerospace application.

PARKER HANNIFIN Stratoflex rubber and PTFE hoses with various reinforcements and covers are briefly presented in the Product Description section with reference to their features and specifications. Offered in different sizes (tube and hose ODs) in inches and lengths in feet unless otherwise stated. Suitable fittings for use with Stratoflex hoses are separately presented. For additional information please refer to the attached Stratoflex catalogs for offered hoses, fittings and assemblies or contact us.

BAND-IT Junior® series smooth ID hose clamps come in a wide choice of widths, thicknesses and inside diameters in Imperial and Metric systems. They are made from different materials such as 201 austenitic chromium-nickel-manganese Stainless Steel, 316 Stainless Steel or Galvanized Carbon Steel (GCS). With their leak resistant design BAND-IT JS® clamps out-perform the other common clamping methods of hose sleeve clamping. They reduce the risk of leaks especially when used on thin walled hoses, ensuring that hose sleeving stays in place through the life of the sleeve. Their low profile buckle design reduces the clearance needed around the hose and has no sharp edges or tail that could cause injuries. Available for hose assemblies up to 8" outside diameter.

BAND-IT Junior® clamps are also offered as preformed clamps used in a wide array of agricultural and industrial applications. Preformed clamps are  made from Alloy 625, a nickel-chromium-molybdenum alloy known for its high strength, high toughness and excellent corrosion resistance. They are vibration resistant and require no hammering or crimping to complete installation. Clamps automatically lock in place under full tension in one simple level movement of the clamp tool(*).

BAND-IT JS® Clamp Features:

Vibration resistant lip lock design. No hammering or crimping

Unique buckle nest and smooth ID design reduces leak paths

Double wrapped steel bands for additional strength

Various materials for corrosive environments

Sold in packages with specified number of clamps per package indicated after the letters "PKG" in the product reference number (SKU).

For more information please refer to the product specifications or contact us.

(*) Note: BAND-IT Junior® Preformed Clamps should be installed using BAND-IT C001 Tool and J001 Junior® Adapter. 3/8" clamps can also be installed using the BAND-IT J020 POK-IT Tool.

Nylaflow®, Nylon Tubing is a high-quality pressure tubing, available in several types. Nylaflow® tubes are tough and durable, offering low friction and high flexibility. Offered by different producers, Nylaflow® tubing is suitable for applications that require toughness, resilience, a small bend radius and high burst strength. Nylaflow® tubing offers superior burst strength compared to vinyl, ethylene, and urethane tubing and it is a high performance, long-lasting alternative to copper, rubber, aluminum and other types of plastic tubing. Its high burst rating makes it a common solution pneumatic and hydraulic lines. Nylon has excellent chemical resistance and can withstand exposure to relatively high concentrations of harsh chemicals at elevated temperatures. Its extremely smooth inner surface resists abrasion and wear and makes for a low coefficient of friction. It is often used in corrosive environments because of its excellent resistance to harsh chemicals.

Nylaflow® tubing comes in different types.

Types T (Thin Wall) and H (Heavy Wall) are the most common Nylaflow general purpose tubing made from type 6/6 nylon. FDA compliant for use in food or beverage handling applications also meeting 3A sanitary standards. The High performance of this Nylon tubing makes it perfect for applications that require durability, resilience, a small bend radius, and high burst strength.

Type LM tubing is a premium high flex tubing available in two types: natural or black, which exhibits improved light stability. Type LM offers excellent chemical resistance and low moisture absorption. Often used in automotive fuel lines, lubrication lines, air lines, and vacuum environments.

Type LP tubing is a low pressure, general purpose type 6 nylon tubing with carbon added for UV stability.

Nylaflow® nylon tubing is available with custom markings, cut to length and custom packaging. It can be cut with a sharp knife and flared hot or cold. They are odorless, tasteless and noncorrosive.

Typical applications of Nylaflow® tubing include airlines, grease lines, vacuum lines, and hydraulic lines.

EATON AEROQUIP® brand name represents quality and innovation for aerospace and other industrial applications with a wide range of hoses, fittings, couplings and connectors available to cover application requirements. Following the acquisition of Eaton’s hydraulics business by DANFOSS, EATON AEROQUIP® products form now part of DANFOSS product portfolio.

DANFOSS EATON AEROQUIP® wire reinforced synthetic rubber hoses are offered in different series (types) described below to meet respective application requirements.

The AE701 hoses consist an upgraded version and a direct replacement for old 601 ones, widely used for aircraft fuel and oil lines where flexibility and light weight are prime considerations. They are made from specially formulated synthetic rubber  inner tube with two layers of stainless steel wire outer braid reinforcement.  Because of their lighter weight and lower operating pressure than type 303 hose, AE701 hoses are not recommended for hydraulic lines. The AE501 hoses are AE701 hoses overlaid with a blue braided chafeguard cover of tough polyester yarn. Both AE701 and  AE501 hoses meet MIL-H-83797, TSO C53a,Type A specification.

The AE401 series hoses are AE701 hoses with an integral cover of silicone rubber compound. They meet MIL-H-83797, TSO C53a,Type C specification.

Product Features:

Flexibility

Light weight

Non-age sensitive (no shelf life)

Fluid temperatures: -65°F (-54°C) to +300°F (+149°C)

TSO C53a, Type A and Type C approvals (with fire sleeve)

Mil-Spec Approvals: MIL-H-83796/1 through MIL-H-83796/9 Assemblies & MIL-H-83797 Hose, MIL-F-83798 Fittings

Field attachable fittings

Applications:  fuel, engine oil and coolants.

Available in different tubing sizes and internal diameters in inches. Priced and sold by the foot.

For additional information please refer to the supplied documentation ot contact us.

Flared tube coupling nuts conforming SAE International standard AS5175 are used for a leak-free solution on aircraft and other applications replacing respective AN818 parts. They are offered  as part of our own (AVIATIONEU NEW ERA) product lines in different materials and grades and multiple thread sizes to suit application needs. Material Code Letters in the part numbers indicate the composition of the fitting (No code for Steel 1137 or 4130, "D" for Aluminum alloys (except 7075-T73), "J" for 304 Stainless Steel (CRES 304), "K" for 316 Stainless Steel (CRES 316), "T" for Titanium 64AI-4V or "W" for Aluminum 7075-T73. These nuts are designed to be used with AS5176 and MS20819 sleeves. The 2 digits after the series code indicate the tubing outer diameter (O.D.)  in inches. Finish code “V” in the PN indicates high purity Aluminum coating for “W” or “D” fittings. Depending on their Part Number they are sold in pieces but also in packs a with specified number of fittings indicated after the letters "PK" in the product reference number (SKU).

Note: In SAE AS standards for new designs, aluminum fittings with material code letter D in their Part or Identifying Number (PIN) are replaced by those with material code letter W for Aluminum Alloy 7075-T73 providing a higher tensile strength.

DANFOSS EATON SYNFLEX® 1300 Series composite wall tubes are designed for pneumatic instrument control systems. Their fully bonded polyethylene/aluminium construction combines the advantages of both metal and plastic tubing.

Their outer, high density polyethylene layer is impervious to most chemical environments and enables SYNFLEX® 1300 tubes to outperform practically all types of unprotected metal tubing.

Product Features:

• Combine the advantages of both metal and plastic tubing

• Very light (5 times lighter than a standard instrument control tubes)

• Provide neat looking bends without special bending tools

• Corrosion and chemical environment resistant

• Excellent chemical compatibility

• Tubing contents dry thanks to aluminum barrier

• Enable direct burial w ithout additional protection (whatever the installation)

• Connection with standard compression fittings

• 25, 75,100m standard lengths

• Standard color: black, other colours on request

• Also available with "Halogen free" jacket

Applications

• Pneumatic instrumentation and control lines located in very wet or moist environments

• Air and gas sampling

• Corrosive environments

• ID surface best suited for air

Construction

• Polyethylene/Aluminum composite

Temperature range

• -40 °C to 80 °C

GATES FLEXCORD PLUS Series lightweight straight coolant hoses have been designed to withstand today's severe conditions in automotive applications. They feature EPDM tube with Aramid reinforcement and EPDM cover.  Engineered to resist electrochemical degradation, the leading cause of hose failure they are very flexible hoses with a strong body to absorb vibrations and shock while their tubes and covers resist heat, ozone and coolant additives. Comply with SAE 20R4 class D2 and DIN 73411 class B1 norms.

GATES Type  4272 Flexcord Plus professional cooling water / heating hoses are offered in inner diameters 8-50mm and sold in pieces with a maximum length of 1 meter per piece.  Appearing prices are per piece of one meter each. For additional information please refer to the attached documentation.

AN823 45° Flared Tube & Pipe Thread Elbow Fittings are superseded by those of Military Standard MS20823 and these are superseded in turn by SAE-AS5196 standard. These fittings are  offered as part of AVIATIONEU NEW ERA product lines in steel or aluminum in different tube outer diameters and thread sizes in inches. Aluminum fittings are designated by the letter "D" after the suffix number.

Hydraulic  & pneumatic fittings (also called compressed air connectors)  are used today in a wide range of applications as a connection for conductors such as hoses, tubes, pipes and machinery carrying fluids or gas and compressed air respectively to maintain their pressure without leakage. Whether their intended use is for fluids (hydraulic) or gas/compressed air (pneumatic) they are manufactured in a range of materials from plastic and aluminum to steel and stainless steel for maximum corrosion and chemical resistance. They come in different specifications (for military,aerospace or industrial uses), different thread types, such as British Standard Pipe (BSP) or U.S. National Pipe Thread (NPT/PTF) and sizes in inch or metric systems. Depending on the specific conductor/fitting application requirement different fittings are selected. Push-in fittings are quick and easy to install, connect and disconnect, even multiple times. Compressed air couplings,consisting of a socket and plug combination are self-sealing connecting components traditionally used for pneumatic tools, hall installations and laboratory equipment.  Compressed air distributors are the ideal choice whenever distribution of compressed air to different systems is required. Different types can be used to direct the compressed air from one access point to several  outputs at the required location.

Hydraulic  & pneumatic fittings are offered as OEM parts from well known manufacturers or as part of our own labelled (AVIATIONEU NEW ERA) product lines. They are included in different product presentations throughout our Web Platform. In addition, a comprehensive range of tools and accessories (separately presented) are also offered ranging from connecting and disconnecting pliers, tubing and pipe cutters to union nuts, sealing caps, hollow bolts, hose clips, tubing straps and others.

Extending our range of offered fittings for hydraulic systems and fluid power applications, JIC (Joint Industry Council) 37° flare fittings can be supplied as part of AVIATIONEU NEW ERA product porffolio. JIC fittings share the same 37° flare angle as AN (Army-Navy) fittings, listed separately but they exhibit significant differences in materials, design tolerances, and intended applications. Typically made from carbon steel, stainless steel, or brass, JIC 37° flare fittings are commonly used in agricultural equipment, construction, and general hydraulic industrial applications unlike AN fittings which were originally designed, developed and still widely used for military and aerospace applications meeting their strict performance requirements. Although JIC fittings are often interchangeable with AN fittings and also a cost-effective alternative for less demanding applications, AN fittings should be a prefered choice for aerospace,  military or critical applications in high-pressure or high-precision environments.

Please consult the supplied documentation or contact us for non listed items.

SAE100 R7 thermoplastic hydraulic hoses are commonly used with petroleum, fire-resistant, and water-base fluids, pneumatic, fuel, and lubricating systems. These hoses are poduced by different manufacturers such as KURT HYDRAULICS, DANFOSS EATON, PARKER and others they are offered as standard (conductive) and non-conductive (blocking electrical flow). They are generally composed of three parts: tube, reinforcement and cover. The tube and cover are made from high quality thermoplastic while reinforcement is made from suitable synthetic fiber.

KURT HYDRAULICS, part of KURT Manufacturing Group. manufactures and supplies a wide range of hydraulic fittings, hoses and couplings. The KURT HYDRAULICS thermoplastic hydraulic hoses are manufactured to the highest quality standards. Available in different grades for medium- to high-pressure applications in a range of sizes from 1/8” to 1”, depending on grade. Matching hydraulic fittings, quick crimpers, and more are also offered to create a complete hydraulic system.

KURT HYDRAULICS SAE100 R7 hoses feature a three-layer construction—nylon inner tubes, braided synthetic fiber reinforcements, and flexible, durable urethane outer sleeves. Offered in electrically conductive and non-conductive styles in most grades. They are rated up to 5000 PSI WP and 20000 PSI BP, varying by grade and diameter. All grades and sizes feature an operational temperature range from -40°F to +212°F.

Hoses are priced and sold by the foot unless otherwise specified. Fittings can be separately purchased in pieces.

For additional information on different products please consult the Product Description section, the supplied documentation or contact us.

Flared sleeve fittings are cylindrical metallic parts designed to be used on tubing to back up the flared end and provide a bearing surface for the coupling nut, thereby reducing wear on the tubing flare. The inside diameter of the flanged end is countersunk to form a seat for the flare when assembled to a mating fitting.

Coupling sleeves conforming to SAE International, standard AS5176 standard replace respective MS20819/AN819 sleeves and they are offered as part of our own (AVIATIONEU NEW ERA) product lines. Sourced from quality producers these fittings are manufactured in different materials including 4130 Steel, Copper, Corrosion Resistant Steel (CRES) and Aluminum & Titanium Alloys. Material Code Letters in the part numbers indicate the composition of the fitting.

Depending on their Part Number they are sold in pieces but also in packs a with specified number of fittings indicated after the letters "PK" in the product reference number (SKU).

Danfoss SEL brand includes a range of low, mid, and high pressure industrial and hydraulic rubber, thermoplastic, and PVC hoses that meet or exceed industry standards. Spanning a broad range of operating pressures, Danfoss SEL hoses are the perfect solution for maximum durability and long-lasting performance under even the toughest conditions. SEL product portfolio includes:

FORCESTREAM standard wire braided hydraulic hoses.

SUPERSTREAM and ULTRASTREAM premium wire braided hoses offering higher working pressures and improved flexibility.

POWERSTREAM spiral reinforced hydraulic hoses for high pressure applications.

COLDSTREAM  hydraulic hoses resistant to ambient temperatures down to -50 C, specifically designed for low temperature applications.

ULTIMATE hydraulic hoses supporting high temperature applications up to 135 C, or 150 C for short-term exposure.

ARMADILLO range of hydraulic hoses with specialized cover materials providing advantages like enhanced ozone or abrasion resistance. Ideal for demanding and dynamic applications, such as pit mining equipment.

SUPER ABRA hydraulic hoses offering an outer cover.

For additional information please refer to the supplied documentation.

EATON AEROQUIP® brand name represents quality and innovation for aerospace and other industrial applications with a wide range of hoses, fittings, couplings and connectors available to cover application requirements. Following the acquisition of Eaton’s hydraulics business by DANFOSS, EATON AEROQUIP® products form now part of DANFOSS product portfolio.

DANFOSS EATON AEROQUIP® BLIND-MATE quick disconnect couplings are utilized in advanced liquid cooled electronics and avionics thermal management systems. These couplings are used between removable cold plates and fixed manifolds to allow for quick leak free removal and replacement of both evaporative and liquid flow through systems. Blind-mate couplings provide unequaled performance in pressure drop, radial misalignment, and envelope. In addition, these couplings incorporate a patented integral thermal relief feature that prevents pressure buildup when the liquid cooling module is disconnected. Like other EATON AEROQUIP® quick disconnect couplings, they can be ordered as separate halves. Available in different sizes.

AEROQUIP® BLIND-MATE  couplings have been tested to meet or exceed SAE AS5072 for modular style couplings. These requirements include:

• Ability to operate within a temperature range of –65°F to +160°F (-54°C to +71°C)

• Capable of enduring 1000 connect/disconnect cycles without evidence of malfunction, leakage or damage

• Standard operating pressure of 150 PSI, proof pressure of 225 PSI, and burst pressure of 375 PSI

• Ability to tolerate proof and burst pressure without rupture or loss of fluid

• Ultra-low spillage during disconnection

• Integral thermal relief valve

• Minimal air inclusion during connection

Applications: Ethylene Glycol Water, Propylene Glycol Water, Polyalphaolefin (PAO) per MIL-C-87252

For additional information please refer to the supplied documentation or contact us.

Note: Special Order items. Non-Cancellable/Non-Returnable Upon Order Placement (NCNR). Minimum Order Quantities & long lead times usually apply. Contact us.
