ZEFTRONICS Voltage Regulator with ground fault protection, trouble shooting light, black plastic connector & 16V over voltage protection built in.

AVIATIONEU NEW ERA air relief valves can be used in different industrial applications. They are made from different materials,  EN 1AL (free cutting steel), 1SMnPb30+C or SAE 12L13  and zinc plated. Available in the following sizes:

Metric: M10 x 1 ARV

British Standard Pipe (BSP): 1/8" BSP ARV

U.S. National Pipe Thread (NPT): 1/8" NPT ARV, 1/4" NPT ARV

Sold by the piece (pc.) with Minimum Order Quantity (MOQ) 1000 pcs.  Appearing price is for reference only per pc. Please contact us for a quotation.

A wide range of grease fittings (aka zerk fittings or grease nipples) are offered as part of our own labelled (AVIATIONEU NEW ERA) product lines. Sourced from quality manufacturers, they are competitively priced and can be furnished in different head types  (conical, button or flush head, drive-in or self-forming), straight or angled heads (30°, 45°, 65°, 67.5°, 90°) and thread sizes in metric or inch systems, depending on the selected fitting. Fittings are sold in pieces but mostly in packs a with specified number of fittings indicated after the letters "PK" in the product reference number (SKU). Fitting kits are also available with assortments of different fittings.

Our AVIATIONEU NEW ERA conical head grease nipples comply with DIN 71412, SAE J534 & IS 4009-2 standards. Hardness for nipple head: Min.550 HV. They are made from different materials,  EN 1AL(free cutting steel), 1SMnPb30+C,SAE 12L13 or stainless steel  303 & 316 with different surface finishes (clear/yellow/olive green zinc plated). Available with straight or angled nipples, tapered or parallel threads in different sizes:

Metric: from M5x0.8 to M16x1.5

British Standard Pipe (BSP): from 1/8"-28 to 3/8"-19

U.S. National Pipe Thread (NPT/PTF): from 1/8"-27 to 1/4"-18

U.S. ANSI/ASME B1.1 Unified National Thread - UNC Coarse series and UNF Fine series: from 1/4"-28 to 3/8"-24

Our AVIATIONEU NEW ERA button type round head grease fittings comply with DIN 3404 & IS 4009-1 standards.They are made from different materials,  EN 1AL(free cutting steel), 1SMnPb30+C,SAE 12L13 or stainless steel  303 & 316 with a galvanized surface treatment and different surface finishes (yellow/white zinc plated). Available with parallel threads in different head diameters (10, 16 & 22 mm head dia. )and sizes:

Metric: from M6x1 to M16x1.5

British Standard Pipe (BSP): 1/8", 1/4" & 3/8"

U.S. National Pipe Thread (NPT/PTF): 1/4"

Our AVIATIONEU NEW ERA flush head grease fittings comply with  DIN 3405 standard.They are made from different materials,  EN 1AL(free cutting steel), 1SMnPb30+C or SAE 12L13 and  zinc plated. Available with parallel threads in different sizes:

Metric: from M5x0.8 to M12x1.5

British Standard Pipe (BSP): 1/8", 1/4" & 3/8"

U.S. ANSI/ASME B1.1 Unified National Thread - UNC Coarse series and UNF Fine series: 1/4"-28

For additional information please contact us.

MONADNΟCK floating clip nuts  are high strength forged hex nuts suitable for structural and non-structural applications in metal, plastic and composite materials. Made of carbon steel, heat treated, cad plated per QQ-P-416, type II, class 2.

Used on most major civil and military programs, RADIALL™ DSX Series ARINC 404/SAE-AS81659 Connectors offer a proven solution to electrically connect equipment rack to avionics equipment. The DSX series are multipin, rack and panel style connectors designed to electrically connect equipment racks to avionics equipment. Typically the plug is installed on the avionics rack and the receptacle on the equipment box. Applications include commercial and military aircraft and helicopters, railway, radar systems, power circuits, in-flight electronic instrumentation and flight simulators.

Different DSX Series versions are outlined below:

DSX SAE AS81659, available in four shell sizes (1, 2, 3 & 4) with environmental and non-environmental versions as well as EMI/RFI options to improve shielding effectiveness. DSX SAE AS81659 connectors cover both civil and military applications.

DSX ARINC 404 shell type A and B are the original connectors, mainly dedicated today to commercial applications.

DSX-F and DSX-K receptacles, RADIALL™ solution for front release front removable (FR/FR) contacts to facilitate installation and maintenance. Fully intermateable with ARINC 404 type B and SAE AS81659 plugs, they offer the same characteristics as SAE AS81659 connectors.

Shell types are plugs and receptacles made from an aluminum alloy with cadmium yellow chromate or nickel plating options. Mismating is prevented by a polarizing system which provides 216 polarizing positions. For military part numbers, applicable polarizing position range goes from 00 through 99 only. Inserts are offered in various contact arrangements accommodating rear release, rear removable signal (size 22) power (sizes 5, 12, 16 & 20HD), coaxial (sizes 1, 3, 5, 7, 9 & 15), concentric twinax (sizes 5 & 9) triax (sizes 5 & 9) contacts in crimp, wire wrap or PC tail termination. Radiall’s 29504 fiber optic termini are also available. With numerous configurations and a wide variety of contacts and accessories, the  RADIALL™ DSX Series offers for both OEMs and aircraft manufacturers robust and high performance solutions fully compliant to SAE AS81659 specifications listed on the qualified product list (QPL)as well as ARINC 404 commercial connectors.

For additional information please refer to the supplied documentation.

Note: Special Order items. Non-Cancellable/Non-Returnable Upon Order Placement (NCNR). Minimum Order Quantities & long lead times usually apply. Contact us.

YAESU rechargable batteries are intended for use with YAESU handheld transceivers.

AVIATIONEU NEW ERA Brass plain washers are made of copper, nickel alloy with a natural color finish in accordance with DIN 125 standard. Sourced from certified manufacturers these washers are offered in competitive prices and they are available in different sizes on the basis of their Clearance (Hole) Diameter/Outer Diameter/Thickness in mm. Sold in packs of 250 or 50 pieces depending on the selected product. The number of pieces included in each pack is mentioned after "PK" designation.

KNITTER-SWITCH & CO.KG (KNITTER-SWITCH) manufactures  a wide range of professional switches including toggle,  pushbutton, tact, slide, dual-in-line, rotary coded, rotary, encoders and snap action switches.

KNITTER switches are available in different versions (configurations), Standard with silver or silver-plated contacts and terminals, Configuration B with gold-plated (over Nickel) contacts and terminals and Configuration G with gold-plated (over silver) contacts and terminals. All switches are sealed on the terminal side and meet CE regulations. Switches for SMT as well as most series for PCB mounting are generally fully washable.

Some KNITTER switches are ESD-resistant and have an approved IP 67 waterproof rating.

KNITTER range of toggle switches includes miniature, subminiature and microminiature toggle switches offered in different series and types. Depending on the selected series and type there are offered in one or multiple poles and switching functions.

 For additional information please consult the supplied documentation.

Surface Acoustic Wave (SAW) devices are components that make use of the ability of piezoelectric materials to convert acoustic (i.e. mechanical) waves into electromagnetic signals, and vice-versa. By far, the most common SAW devices are those which perform a filtering operation, also known as SAW filters. SAW Band Pass Filters (SAW BPF) sort signals by frequency the most widely used substrates being quartz (SiO2), lithium niobate (LiNbO3) and Lithium tantalite (LiTaO3) that are very brittle materials.

Usually SAW filters operate from 600 MHz to 2 GHz frequency range in mobile environment. Based on IF (Intermediate Frequency) and RF (Radio Frequency) filtering, there are two types of filters, IF SAW and RF SAW filters. In addition, based on construction, there are different  types of offered SAW filters such as IIDT, DMS and ladder.

Main advantages or benefits of SAW filters include:

• they allow electro-acoustic coupling via the transducer

• SAW velocity is 105 times less than that of Electromagnetic (EM) wave. As a result, SAW filters can be used in cases where EM wave based filter designs are impractical to be developed

• SAW filters are less expensive compared to BAW (Bulk Acoustic Wave) filters

• SAW filters are easy in fabrication due to easy access to their structure from the above surface of the filter.

The selection of the right SAW filter for an intended application is based on significant parameters like those listed below. Such filters are produced by different manufacturers such as TAI-SAW, Qualcomm, API, Golledge Electronics, Oscilent, Amplitronix LLC, Vectron, Filtronetics, Microsaw, SAWTRON and others.

• RF or IF type

• RF center frequency

• Bandwidth

• Pass band ripple (dB)

• Power handling capability

• Insertion loss in pass band (dB)

• package type and dimension

Please refer to the specifications of offered SAW filters, the supplied documentation or contact us for additional information.

FLUITEK CORPORATION manufactures a wide range of industrial filter elements (filters) intended for use as replacements to respective OEM products. They are offered either per piece or in packs of specified number of filters indicated by the number after the letters "PK" in the product reference number (SKU). FLUITEK products are made to meet or exceed OEM specifications. For additional information on FLUITEK prodict portfolio please consult the Product Description Section or contact us.

Different aircraft engine firewall sealants are included in this presentation while other PPG AEROSPACE® products are separately presented.

PPG AEROSPACE® PR-812 is a high temperature primerless firewall sealant. It is a two-part, synthetic rubber compound designed for sealing firewall structures against the passage of air and vapours.

The uncured material is a low sag paste suitable for application by extrusion gun or spatula. It cures at room temperature to form a resilient sealant to common aircraft substrate. It has a service temperature range from -54°C (-65°F) to 204°C (400°F), and will withstand flash temperatures of 1093°C (2000°F). HAZARDOUS MATERIAL.

PPG AEROSPACE® Pro-Seal P/S 700 Firewall Sealant is a high temperature two-part, synthetic rubber compound primerless firewall sealant. It has a service temperature range from -65°F (-54°C) to 400°F (204°C, with withstand flash temperatures of 2000°F (1093°C). The material is designed for sealing firewall structures against the passage of air and vapors.The uncured material is a low sag paste suitable for application by extrusion gun or spatula. It cures at room temperature to form a resilient sealant to common aircraft substrates. Its storage life is at least 12 months when stored at temperatures below 80 °F ( 27 °C) in original, unopened containers. Meets MIL-S-38249 TYPE 1 and AMS3374 Type 4. Alternates with CS1900 and PRS12. Black color. Supplied in a two-part can kit and two-part SEMKIT® injection kits. HAZARDOUS MATERIAL.

Please refer to the attached documentation for additional information.

EATON AEROQUIP® brand name represents quality and innovation for aerospace and other industrial applications with a wide range of hoses, fittings, couplings and connectors available to cover application requirements. Following the acquisition of Eaton’s hydraulics business by DANFOSS, EATON AEROQUIP® products form now part of DANFOSS product portfolio. Made from different materials (S Steel, B Brass, C Stainless steel or D Aluminum alloy) DANFOSS EATON AEROQUIP® adapters & swivel Joints come in different types  and sizes. For additional information please consult the supplied documentation or contact us.

LENZ externally-mounted tank hydraulic suction line strainers are offered in different NPT and SAE series below to cover the needs of a range of applications.They do not require access to the tank interior for ease of servicing and feature perforated steel support tubes, cast iron bushings and 100 mesh stainless steel pleated screens as standard.

Part Numbers include subsections for the Series, the Size, the By-pass Option and the Mesh Oprion of the strainer.

Versions with by-pass options are designated by "-R" and PSI number after the size number of the strainer (e.g. -R3 and -R5 for 3 or 5 PSI by-pass options respectively).

Versions with mesh options, other than 100 mesh stainless steel pleated screen, are indicated by "-" and the number of the mesh option (i.e. -30, -60, -200  for 30, 60 or 200 mesh respectively).

LTF series are male NPT (MNPT) tank strainers designed for flows up to 50 GPM (200 LPM), with 2" X 2" MNPT steel nut. Offered with No by-pass or 5 PSI by-pass and 30, 60 and 200 mesh  options.

LTM series are male NPT (MNPT) to female NPT (FNPT) tank strainers designed for flows up to 200 GPM (750 LPM) with cast iron nut (stainless nut as option). Offered with No by-pass, 3 or 5 PSI by-pass and custom mesh  options.

LTMA series are male SAE (MSAE) to female SAE (FSAE) tank strainers designed for flows up to  40 GPM (160 LPM). They come with Buna o-rings and steel zinc plated bushings. Offered with No by-pass , 3 or 5 PSI by-pass and 30, 60 and 200 mesh  options.

LTMAB series are male SAE (MSAE) to hose barbed tube externally-mounted tank strainers designed for flows up to 40 GPM (160 LPM). They come with 1" to 2" hose beads, Buna o-rings and forged Zinc plated fittings.  Offered with No by-pass, 3 or 5 PSI by-pass and 30, 60 and 200 mesh  options.

For additional information please refer to the supplied documentation.

The CONFOR™ foam family (formerly Temperfoam™) by Aearo Technologies LLC (E-A-R), are open cell elastomeric, ergonomic, urethane foams forming part of their specialty foams for comfortable seating, crash protection and noise and vibration control.

CONFOR™ foams offer enduring seating comfort, and absorb a much higher amount of impact shock compared to common polyfoam. They can be used for long period seating applications in aviation, automotive, recreational, office, in medical hospital bedding, sports equipment, wheelchair cushions, industrial operations, or as protective packaging for high value devices.

Standard CONFOR™ product line has been replaced by CONFOR™ M & AC RoHS compliant foams with the same slow recovery attributes as the replaced ones. They come in different sheet sizes (the most popular 16" x 18", 18" x 20", 18" x 24"),and densities, corresponding to different foam weights per cubic foot and denoted by a respective color code (Yellow/Very Soft (CF40 M/AC), Pink/Soft (CF42 M/AC), Blue Medium ((CF45 M/AC), and Green Firm (CF47 M/AC).

CONFOR™ M slow-recovery foams, offer a unique combination of physical characteristics, high energy absorption properties and temperature-softening behavior. They provide impact protection and isolation for dynamic loads, while maintaining consistent static load performance. Their unique combination of slow recovery and high energy absorption allows these materials to offer effective damping and vibration isolation. In addition, as open-celled foams, they are breathable, non-irritating in dermal contact, and thus suitable for highly diverse applications, for medical and body contact cushioning applications to electronics packaging. The respective CONFOR™ AC foams have been engineered for the aircraft market. They are flame resistant and comply with FAR 25.853(a) Appendix F Part I (a)(1)(ii)(12 sec) burn specification requirements, consisting an excellent choice for use on aircraft. CONFOR™ CF42AC & CF45AC foams  are softer and provide more comfort. CONFOR™ green firm density foam CF47AC provides the best energy absorption protection.

CONFOR™ AC foams are offered in different thicknesses, as solid pieces (e.g. in 1" thickness) or various pre-built  laminates resulting in higher thicknesses. DYNAFOAM is also often used as comfort foam on top of CF-47AC foams. Indicative offered laminations include:

- 1" thickness CF47AC sheet and 0.5" thickness DYNAFOAM sheet. Total laminate size - 16" x 18" x 1.5". Ideal balance for most pilots.

- 1" thickness CF45AC and 1" thickness CF47AC sheet. Total laminate size - 16" x 18" x  2". Ideal for maximizing safety providing comfort at the same time.

- 0.5" thickness CF47AC and 0.5" thickness DYNAFOAM sheet. Total laminate size - 16" x 18" x 1". Ideal for tall pilots with minimal head clearance.

Third party accessories, such as protective covers, are also available to maximize CONFOR™ foam life.

For additional information please consult the supplied documentation.

EXXONMOBIL® AVIATION Mobil Jet Oil 254 is a third-generation oil formulated to deliver exceptional high-temperature thermal stability  (HTS), excellent resistance to coking and deposit control as well as exceptional oxidation and corrosion protection. It meets the demanding requirements of latest technology  aircraft-type gas turbines operating over a wide range of severe operating conditions.  When compared to a typical Type II lubricant, Mobil Jet Oil 254 reduces bulk oil oxidation by up to 50 percent and shows deposit control capability 50 F higher.  These properties have been confirmed in various laboratory tests including; the Corrosion-Oxidation Stability Test,  Alcor Deposition Test, Vapor Phase Coker, Erdco High-Temperature Bearing Test, Ryder Gear and the Mobil Thin Film Oxidation Test.The closely controlled low-temperature viscosity of Mobil Jet Oil 254, along with its low pour point (below -54 ºC), ensure good low-temperature fluidity to permit starting and lubrication at temperatures as low as -40 ºC.  In extensive laboratory testing and in-flight experience, Mobil Jet Oil 254 also exhibits excellent bulk oil stability at temperatures up to 232 ºC (450 ºF) for extended periods.  The evaporation rate at these temperatures is low enough to prevent excessive loss of volume.  The load-carrying ability of Mobil Jet Oil 254 comes from its synthetic base stock viscosity and, therefore, is not subject to loss from viscosity index additive shear.

Product Features & Benefits:

Excellent thermal and oxidation stability reducing the formation of carbon (carbon coking) and sludge deposits. Helps operators reduce shop visits and maintenance costs. Maintains engine efficiency and extends engine life. Reduces bulk oil oxidation by 50% and increases deposit control by 50 ºF

Excellent wear and corrosion protection extending seal, gear and bearing life. Reduces engine maintenance.

Viscosity and shear stability across wide temperature range providing effective lubrication at high operating temperatures

Chemically stable at high operating temperatures reducing evaporation losses and lowering oil consumption

Excellent resistance to foaming maintaining film strength under rigorous operating conditions

Good low temperature fluidity permiting start-up and ensuring effective lubrication of critical components at temperatures as low as -40 °F.

SHELL® TURBO® Turbine oils are premium quality lubricating oils designed to provide excellent lubrication of precision turbines and many other industrial applications. Made from severely hydroprocessed (API Group II) base oils carefully selected to provide satisfactory viscosity/temperature characteristics, low foaming tendencies and good water separation properties. In addition, they contain proven additives to protect equipment against rusting and to resist oxidation for long service life.

From high-temperature gas turbine systems to combined-cycle systems with integral gearing, the SHELL® TURBO® range of turbine mineral and  GTL (gas-toliquids) technology (*) oils are designed to protect the equipment from the effects of corrosion and to minimise the build-up of deposits and lacquer in turbine bearings and control valves.

Shell Turbo Oils T meet the American Standards Institute (ANSI)/American Gear Manufactures Association (AGMA) 9005-D94 requirements for R&O oils. They also coply with STLE Standards for machine tool lubrication include a classification for Hydraulic Fluid and General Purpose Lubricants.

The SHELL® TURBO® includes:

SHELL® Turbo T Mineral Turbine oils featuring reliable performance and protection. Available in ISO 32, 46, 68 and 100 viscosities.

SHELL® Turbo J Mineral Turbine oils  satisfying requirements of MHPS steam and gas turbines. Available in ISO 32 viscosity.

SHELL® Turbo S4 X and S4 GX GTL Turbine oils.The Turbo S4  X exhibits extended oil life and efficiency. Available in ISO 32 viscosity. The Turbo S4 GX is specifically formulated to provide additional protection for gearboxes in turbine systems that require enhanced anti-wear performance from oil . Available in ISO 32 and 46 viscosities.

For additional information please refer to the Product Description section and the supplied documentation.

(*) Shell gas-to-liquids (GTL) technology offering various benefits over traditional group II/III base oils such as a lower sulphur content than fluids derived from crude oil, a more uniform chemical structure, contributing to reliable performance and others.

The KLIXON® 7277 series circuit breakers are the commercial grade version of the 7274 series circuit breakers  which are small, lightweight, low amperage devices that are specifically designed to protect aircraft/aerospace cable and components in airborne vehicles and equipment. The KLIXON® 7277 series circuit breakers are physically and electrically identical to the 7274-2 military grade circuit breakers, with the exception that the 7277 series has wider calibration limits.  Klixon® 7277 series breakers have been designed for applications that do not require the tighter performance characteristics and approvals of 7277-2 series military circuit breakers.

Originally developed as an alternative to slow blow fuses, the trip–free 7277 series breakers are used extensively as primary electrical circuit protection on general aviation aircraft. The wider calibration limits of the 7277 has also resulted in applications including protection for data processing and telecommunications equipment, computers, flight simulators, construction, material handling and other industrial,electronic equipment. Suitable for use on trainer / simulator applications where all breakers are operated on low ampere control current, different ampere rating inserts (amp ratings on top of push button) can be ordered.

KLIXON® 7277 series circuit breakers' features include:

• Miniature size

• Light weight

• Trip–free design

• Current rating: 0.5 to 20 amps

• High vibration resistance

• Options include: dust boot (part #14500-1 fits 15/32 bushing, part #14500-5 fits 7/16 bushing), auxiliary switch, terminal hardware, longer push button.

For additional information please consult the supplied documentation.

AEROSHELL® 100 Series SAE 50 Grade Aviation Piston Engine Oils are  straight mineral oils blended from selected high viscosity index base oil. They are offered as AEROSHELL® 100 mineral break in oil with no additives, AEROSHELL® W100 mineral ashless dispersant oil for normal use and  AEROSHELL® W100 PLUS mineral ashless dispersant oil with a friction modifier/anti-wear additive package.

The specially blended high viscosity index base oil in AEROSHELL® 100 oils has been designed to provide effective protection to engine components compared to conventional mineral oils. Intended for use when an oil without a dispersant additive is required during the break-in of  new aviation piston engines or those recently overhauled.They meet the SAE specification J-1966 Grade 50.

AEROSHELL® W oils were the first non-ash dispersant oils to be used in aircraft piston engines. They combine nonmetallic additives with selected high viscosity index base stocks to give exceptional stability, dispersancy and anti-foaming performance. These additives leave no metallic ash residues that can lead to deposit formation in combustion chambers and on spark plugs, which can cause pre-ignition and possible engine failure.AEROSHELL® W100 oil includes very small amounts of pour point depressant to improve fluidity at very low temperatures and an anti-oxidant. This helps ensure complete confidence and peace of mind knowing that your aircraft will perform reliably in between scheduled overhauls. Approved to SAE specification J-1899 Grade 50.

AEROSHELL® W100 Plus single grade oils combine the single grade, ashless dispersant performance found in AEROSHELL® Oil W100 and the anti-wear/anti-corrosion additives of AEROSHELL® Oil W15W-50 Multigrade. They are approved for all aviation civil aircraft piston engines. Approved to SAE specification J-1899 Grade 50.

AEROSHELL® 100 Series oils have military qualification approvals. Common packing options include 1 US Quart bottles, cases of 6  or 12 1 US Quart bottles, jugs of 5 liters, pails of 5 US Gallons, and drums of 55 US Gallons. Please also refer to the attached documentation.

 NOTE: Other AEROSHELL® piston engine and turbine oils, greases and fluids are also offered through our Web Platform for Supplies or can be furnished through our network of co-operating suppliers. Due to our continuously expanding list of suppliers and their respective range of offered products, certain AEROSHELL® products may not be currently listed in our Platform. Please refer to our AEROSHELL® Aviation Lubricants Product Overview presentation or contact us for additional information or assistance on non listed products.

The  PARKER HANNIFIN (Hose Products Divisionn) offers Push-Lok® Plus multipurpose hose lines featuring the widest fluid compatibility, application range and size range in the industry. At the same time they incorporate the highest working pressures in all sizes, making them the most versatile general-purpose hoses available. PARKER Push-Lok®  system is easy to use. No clamps or special tools are required during installation enabling assemblies in seconds, saving valuable time and cost. The unique seal of Push-Lok ensures reliable, durable, leak-free service while with PARKER:s exclusive color-code system hose inventories are identified and maintained easily and efficiently.

PARKER's 801 general-purpose hoses with Push-Lok Plus technology are low-pressure, multipurpose synthetic rubber hoses featuring PARKER's exclusive color-coding system. Suitable for use with a wide range of media, 801 hoses are compatible with petroleum-based hydraulic fluid and lubricating oils, pneumatic power, antifreeze, and, when coupled with HY Series fittings, diesel fuel. These versatile hoses feature the unique Push-Lok® seal for easy assembly ensuring reliable, durable, and leak-free service. 801 hoses offer maximum working pressures ranging from 200 to 350 psi. The exclusive color-coding system enhances organization and assembly. Common uses include construction, utilities, machine tooling, ground support, industrial, and automotive applications.

For additional information please refer to the supplied documentation or contact us.
