SAE-AS1035/MS24402/AN824 series tee, flared tube fittings are available as part of our own labelled (AVIATIONEU NEW ERA) product lines in different materials, tube outer diameters and thread sizes in inches. The AN824 series tee fittings are superseded by the respective fittings of SAE-AS1035 series (SAE International, Standard SAE AS1035, FITTING, TEE, STANDARD AND REDUCER, FLARED). They are manufactured from Carbon Steel, Aluminum Alloy, Corrosion Resistant Steel (CRES), Titanium Alloy. The 2 digits after the series code indicate the tubing outer diameter (O.D.)  in inches. The following Material Code Letters in the part numbers indicate the composition of the fitting. Finish code “V” in the PN indicates high purity Aluminum coating for “W” or “D” fittings.

Depending on their Part Number they are sold in pieces but also in packs a with specified number of fittings indicated after the letters "PK" in the product reference number (SKU).

No code letter in part number for Carbon Steel

“D” for Aluminum Alloy (except 7075-T73)

“J” for CRES, type 304

“K” for CRES, type 316

“R” for CRES, type 321

“S” for CRES, type 347

“T” for Titanium Alloy 6AL-4V

“W” for Aluminum Alloy 7075-T73

For example, AS1035D in the PN of the fitting indicates that these are made from Aluminum Alloy.

Note: In SAE AS standards for new designs, aluminum fittings with material code letter D in their Part or Identifying Number (PIN) are replaced by those with material code letter W for Aluminum Alloy 7075-T73 providing a higher tensile strength. In addition CRES fittings with material code letter S can be used for replacement parts. For new designs use of CRES fittings with material code letter R is recommended for applications requiring higher temperature.

EATON AEROQUIP® brand name represents quality and innovation for aerospace and other industrial applications with a wide range of hoses, fittings, couplings and connectors available to cover application requirements. Following the acquisition of Eaton’s hydraulics business by DANFOSS, EATON AEROQUIP® products form now part of DANFOSS product portfolio.

DANFOSS EATON AEROQUIP® 816/8846/8891 series flared hose fittings can be used with DANFOSS EATON AEROQUIP® 601 hoses  and are available in different sizes. The 816 series straight hose fittings and 8891 series 90 Deg. hose fittings both consist of a pre-assembled nut/nipple assembly and an internally threaded hose socket. The size 4 fitting has a cadmium plated steel nut and nipple. Sizes 6, 8 and 10 nuts and nipples, and all sizes of sockets, are anodized aluminum. The 8846 series fittings are 45° hose fittings with swivel flared UNJF threads. They are noted for their outstanding performance as a result of a unique lipseal design concept. During assembly the nipple spur cuts a lip in the tube stock of the hose forming the fluid seal.

For additional information please consult the supplied documentation or contact us.

Note: DANFOSS EATON AEROQUIP® 816 fittings ARE NOT THE SAME as AN816 fittings. Please specify at the time of ordering.

AVIATIONEU NEW ERA end hose banjo fittings are intended for use in hydraulic pipes in automotive fuel, oil and hydraulic systems. They are available with single or double ends from different materials, mild steel, EN 1AL(free cutting steel), 11SMnPb30, EN 8, stainless steel 202 & 304. Sourced by certified manufacturers these banjo fittings are competitively priced and offered in different Metric sizes (M10x5/16", M12x5/16", M14x5/16", M14x3/8", M16x3/8", M18x3/8", M18x1/2") and different surface treatments (clear /yellow zinc plated, olive green zinc plated, dacromet). Sold by the piece (pc.) with Minimum Order Quantity (MOQ) 500 pcs.  Appearing price is for reference only per pc. Please contact us for a quotation.

Danfoss SEL brand includes a range of low, mid, and high pressure industrial and hydraulic rubber, thermoplastic, and PVC hoses that meet or exceed industry standards. Spanning a broad range of operating pressures, Danfoss SEL hoses are the perfect solution for maximum durability and long-lasting performance under even the toughest conditions. SEL product portfolio includes:

FORCESTREAM standard wire braided hydraulic hoses.

SUPERSTREAM and ULTRASTREAM premium wire braided hoses offering higher working pressures and improved flexibility.

POWERSTREAM spiral reinforced hydraulic hoses for high pressure applications.

COLDSTREAM  hydraulic hoses resistant to ambient temperatures down to -50 C, specifically designed for low temperature applications.

ULTIMATE hydraulic hoses supporting high temperature applications up to 135 C, or 150 C for short-term exposure.

ARMADILLO range of hydraulic hoses with specialized cover materials providing advantages like enhanced ozone or abrasion resistance. Ideal for demanding and dynamic applications, such as pit mining equipment.

SUPER ABRA hydraulic hoses offering an outer cover.

For additional information please refer to the supplied documentation.

I.M.M.® HYDRAULICS (part of INTERPUMP GROUP) is a multinational company that project manages, produces and distributes hydraulic hoses and hose fittings, as well as related assembly and test trial equipment.

I.M.M.® HYDRAULICS manufactures an extensive range of high and very high pressure rubber wire braided and wire multispiralled, thermoplastic and P.T.F.E. hoses for use in different industrial applications.

INTERPUMP/ I.M.M.® hose product range includes:

Double wire braid and four wire spiral hoses for marine and offshore applications,

Single/Double wire braid, four wire spiral, textile and suction line hoses conforming to different international standards,

High performance hoses including compressor, high and low temperature, HyOzone, HIPAC and others,

Thermoplastic and P.T.F.E. hoses

INTERPUMP/ I.M.M.® hoses are offered in desired cut lengths in meters but also in coils of specified meter lengths.

Different fittings, adapters, couplings and other components and accessories are offered for use with INTERPUMP/ I.M.M.® hoses.

Component compatibility, along with the use of quality components, insures the production of reliable hose assemblies when properly assembled. Use or intermixing of other components not specifically engineered and designed for use with INTERPUMP/ I.M.M.® hoses is not recommended and may result in the production of unsafe or unreliable hose assemblies.

Please refer to the supplied documentation or contact us for additional information or assistance on non listed products.

ROTAX® aircraft  engines form part of the product portfolio  of BRP-Powertrain GmbH & Co. KG which develops and manufactures engines for snowmobiles, watercrafts, boats, roadsters, all-terrain and side-by-side vehicles, motorcycles, carts, and aircrafts.

BRP-ROTAX® product range includes certified and non certified internal combustion engines, parts and accessories for light and ultralight aircraft.

Different hoses for water, heat, air intake, protection, form, connecting, low pressure and others & related fittings are used in BRP-ROTAX® aircraft engines. They are offered as certified or non certified parts from the manufacturer. Non certified parts can be used in ultralights or other aircraft not requiring certification of parts for their installation. Certified parts are designated by the letters "CERT" in the product reference number (SKU). ROTAX engine hoses are generally sold in meters and appearing prices are per meter but some hoses of specific dimensions and fittings are sold in pieces.

Aircraft engine  parts are subject to changes from time to time. Some parts may be no longer available or replaced by others with different part numbers. Listed BRP-ROTAX® engine parts do not imply their current availability or suitability for your engine application. Always consult the most recent Illustrated Part Catalogs (IPCs) or other documentation available from the manufacturer for the correct part number before ordering.

EATON products are known for their quality and innovation in aerospace and other industrial applications with a wide range of hoses, fittings, couplings and connectors available to cover application requirements. Following the acquisition of Eaton’s hydraulics business by DANFOSS, EATON hydraulic products form now part of DANFOSS product portfolio.

DANFOSS EATON WINNER® Series wire reinforced synthetic rubber hoses are constructed by a synthetic rubber tube with one or two wire braid reinforcement and a synthetic rubber cover. These hoses feature an operating temperature range of -40°C to +100°C / -40°F to +212°F. They can be used for a wide range of applications in hydraulic systems with petroleum and waterbased fluids as well as for general industrial uses. Available in different tubing sizes and internal diameters in inches. Priced and sold in meters unless otherwise stated.

EATON WINNER® Series include the following hoses:

The EATON WINNER® EC110 hoses which have one wire braid reinforcement and meet EN 853 1SN specification.

The EATON WINNER® EC115 hoses with one wire braid reinforcement and compliance with EN 857 1SC specification.

The EATON WINNER® EC210 hoses wiyh two wire braid reinforcement meeting EN 853 2SN specification.

The EATON WINNER® EC215 hoses with two wire braid reinforcement meeting  EN 857 2SC specification.

For additional information please refer to the supplied documentation ot contact us.

Thermoplastic hydraulic hoses are used in certain hydraulic control applications where low volumetric expansion properties are desired for more precise actions or control. Such applications include those for precision gauging, pilot lines, steering lines, grease systems, as well as other applications which cannot be subject to conductivity (use around power lines) or where moisture cannot be present, such as for spray foam. As with "rubber" hydraulic hose, not all brands of thermoplastic hydraulic hoses are built the same even though they may meet the same SAE specifications. Higher end brand hoses will typically be made to higher tolerances, better compounds, better resistance to various factors, added durability, enhanced engineering methods, and additional assurance of a proven system. With leading, innovative manufacturers such as Aeroquip, the market has seen improvements in hose design - such as more flexibility, lighter weight, higher temperature compounds, tougher covers, less manufacturing defects, and overall more durable products.

ΕΑΤΟΝ SYNFLEX® thermoplastic hose and tubing has been replacing rubber hose or metal tubing designs offering customers a number of benefits, including flexibility, durability, abrasion resistance, lighter weight materials, superior chemical resistance, variety of colors, high pressure capability and extended product performance.

Each component of the SYNFLEX® hose assembly system is compatible with other approved Eaton components to which it relates ensuring a complete hose assembly system. Component compatibility, along with the use of quality components, insures the production of reliable hose assemblies when properly assembled. Intermixing of fittings and hose not specifically engineered and designed for use with each other and Eaton equipment is not recommended and may result in the production of unsafe or unreliable hose assemblies. This can result in hose assembly leakage, hose separation or other failures which can cause serious bodily injury or property damage from spraying fluids, flying projectiles, or other substances. The ΕΑΤΟΝ warranty is limited to apply only when approved ΕΑΤΟΝ hose fittings and compatible ΕΑΤΟΝ SYNFLEX® hose are used with Eaton assembly equipment.

Hoses are priced and sold by the foot unless otherwise specified. Fittings can be separately purchased in pieces.

For additional information on different products please consult the supplied documentation or contact us.

AN822 90° Flared Tube & Pipe Thread Elbow Fittings are superseded by those of Military Standard MS20822 and these are superseded in turn by SAE-AS5195 standard. These fittings are made from different materials such as carbon steel, aluminum or corrosion resistant steel (stainless steel), sourced from quality manufacturers and offered as part of our own labelled (AVIATIONEU NEW ERA) product lines in different tube outer diameters and NPT thread sizes in inches. The fitting composition is designated by a code letter after the dash number in the part number as follows:

No letter for Carbon Steel

"B" for Copper Alloy

"D" for Aluminum Alloy

"J" for CRES, Class 304

"K" for CRES, Class 316

"S" for CRES, Class 347

"W" for Aluminum Alloy 7075-T73

For additional information please consult the supplied documentation or contact us.

GATES FLEXCORD PLUS Series lightweight straight coolant hoses have been designed to withstand today's severe conditions in automotive applications. They feature EPDM tube with Aramid reinforcement and EPDM cover.  Engineered to resist electrochemical degradation, the leading cause of hose failure they are very flexible hoses with a strong body to absorb vibrations and shock while their tubes and covers resist heat, ozone and coolant additives. Comply with SAE 20R4 class D2 and DIN 73411 class B1 norms.

GATES Type  4272 Flexcord Plus professional cooling water / heating hoses are offered in inner diameters 8-50mm and sold in pieces with a maximum length of 1 meter per piece.  Appearing prices are per piece of one meter each. For additional information please refer to the attached documentation.

Nylaflow®, Nylon Tubing is a high-quality pressure tubing, available in several types. Nylaflow® tubes are tough and durable, offering low friction and high flexibility. Offered by different producers, Nylaflow® tubing is suitable for applications that require toughness, resilience, a small bend radius and high burst strength. Nylaflow® tubing offers superior burst strength compared to vinyl, ethylene, and urethane tubing and it is a high performance, long-lasting alternative to copper, rubber, aluminum and other types of plastic tubing. Its high burst rating makes it a common solution pneumatic and hydraulic lines. Nylon has excellent chemical resistance and can withstand exposure to relatively high concentrations of harsh chemicals at elevated temperatures. Its extremely smooth inner surface resists abrasion and wear and makes for a low coefficient of friction. It is often used in corrosive environments because of its excellent resistance to harsh chemicals.

Nylaflow® tubing comes in different types.

Types T (Thin Wall) and H (Heavy Wall) are the most common Nylaflow general purpose tubing made from type 6/6 nylon. FDA compliant for use in food or beverage handling applications also meeting 3A sanitary standards. The High performance of this Nylon tubing makes it perfect for applications that require durability, resilience, a small bend radius, and high burst strength.

Type LM tubing is a premium high flex tubing available in two types: natural or black, which exhibits improved light stability. Type LM offers excellent chemical resistance and low moisture absorption. Often used in automotive fuel lines, lubrication lines, air lines, and vacuum environments.

Type LP tubing is a low pressure, general purpose type 6 nylon tubing with carbon added for UV stability.

Nylaflow® nylon tubing is available with custom markings, cut to length and custom packaging. It can be cut with a sharp knife and flared hot or cold. They are odorless, tasteless and noncorrosive.

Typical applications of Nylaflow® tubing include airlines, grease lines, vacuum lines, and hydraulic lines.

Flared sleeve fittings are cylindrical metallic parts designed to be used on tubing to back up the flared end and provide a bearing surface for the coupling nut, thereby reducing wear on the tubing flare. The inside diameter of the flanged end is countersunk to form a seat for the flare when assembled to a mating fitting.

Coupling sleeves conforming to SAE International, standard AS5176 standard replace respective MS20819/AN819 sleeves and they are offered as part of our own (AVIATIONEU NEW ERA) product lines. Sourced from quality producers these fittings are manufactured in different materials including 4130 Steel, Copper, Corrosion Resistant Steel (CRES) and Aluminum & Titanium Alloys. Material Code Letters in the part numbers indicate the composition of the fitting.

Depending on their Part Number they are sold in pieces but also in packs a with specified number of fittings indicated after the letters "PK" in the product reference number (SKU).

The EATON AEROQUIP FC300 are AQP elastomer hoses with a blue, abrasion-resistant fabric cover with single wire braid reinforcement over a synthetic rubber inner tube for longer life. The FC300 hoses are designed for high pressure fluid applications such as power steering, hydraulics, air, fuel, lubricating oils, fire resistant hydraulic fluids and other industrial fluids. They are also suitable for biodiesel use up to B20 and max temperature of 212°F (100°C). Available in different internal diameters in inches and for use in different maximum operating pressures (psi). Priced and sold by the foot.

Indicative Applications:

Power steering lines

Hydraulics

Air

Gasoline

Fuel

Lubricating oils

Over the wall air tool

Dot-approved air brake

Max operating pressure is 2250 psi

Operating Temperature Range

-55°F to +302°F (-49°C to +150°C)

Air not to exceed +250°F [+121°C]

Notes:

(1) The FC300 Hose only works with FC300 steel fittings (to be ordered separately). Easily assembles with a bench vise and/or wrenches.

(2) FC300-32 and FC300-40 hoses DO NOT meet SAE 100R5 pressure with reusable fittings. FC300-32 is rated to 350 psi with crimp fittings.

VENA® HT Series flexible  hoses (SCAT equivalent) are  made of one layer of glass fabric silicone coated and visible steel wire  spiral inside. For use in conducting extremely cold or hot air (temperature range: -65°F to +550°F). Available in different internal diameters in inches. Sold by the foot.

EATON AEROQUIP® brand name represents quality and innovation for aerospace and other industrial applications with a wide range of hoses, fittings, couplings and connectors available to cover application requirements. Following the acquisition of Eaton’s hydraulics business by DANFOSS, EATON AEROQUIP® products form now part of DANFOSS product portfolio.

DANFOSS EATON AEROQUIP® BLIND-MATE quick disconnect couplings are utilized in advanced liquid cooled electronics and avionics thermal management systems. These couplings are used between removable cold plates and fixed manifolds to allow for quick leak free removal and replacement of both evaporative and liquid flow through systems. Blind-mate couplings provide unequaled performance in pressure drop, radial misalignment, and envelope. In addition, these couplings incorporate a patented integral thermal relief feature that prevents pressure buildup when the liquid cooling module is disconnected. Like other EATON AEROQUIP® quick disconnect couplings, they can be ordered as separate halves. Available in different sizes.

AEROQUIP® BLIND-MATE  couplings have been tested to meet or exceed SAE AS5072 for modular style couplings. These requirements include:

• Ability to operate within a temperature range of –65°F to +160°F (-54°C to +71°C)

• Capable of enduring 1000 connect/disconnect cycles without evidence of malfunction, leakage or damage

• Standard operating pressure of 150 PSI, proof pressure of 225 PSI, and burst pressure of 375 PSI

• Ability to tolerate proof and burst pressure without rupture or loss of fluid

• Ultra-low spillage during disconnection

• Integral thermal relief valve

• Minimal air inclusion during connection

Applications: Ethylene Glycol Water, Propylene Glycol Water, Polyalphaolefin (PAO) per MIL-C-87252

For additional information please refer to the supplied documentation or contact us.

Note: Special Order items. Non-Cancellable/Non-Returnable Upon Order Placement (NCNR). Minimum Order Quantities & long lead times usually apply. Contact us.

SAE-AS5406/AN832 series union tube hydraulic fittings are available as part of our own labelled (AVIATIONEU NEW ERA) product lines in different materials, tube outer diameters and thread sizes in inches. The AN832 series fittings are superseded by the respective fittings of  SAE International standard  SAE-AS5406 series.

Like their SAE-AS5174/MS24392/AN815 union flared tube counterparts, SAE-AS5406/AN832 series fittings are manufactured from Carbon Steel, Aluminum Alloy, Corrosion Resistant Steel (CRES), Titanium Alloy. The 2 digits after the series code indicate the tubing outer diameter (O.D.)  in inches. The following Material Code Letters in the part numbers indicate the composition of the fitting.

No code letter in part number for Carbon Steel

Code letter “D” for Aluminum Alloy (except 7075-T73)

Code letter “J” for CRES, type 304

Code letter “K” for CRES, type 316

Code letter “S” for CRES, type 347

Code letter “T” for Titanium Alloy 6AL-4V

Code letter “W” for Aluminum Alloy 7075-T73

For example, AS5406D06 union fitting is made from Aluminum Alloy with a tubing outer diameter (O.D.) 3/8". The corresponding union fitting in AN832 series would be AN832-6D.

Depending on their Part Number they are sold in pieces but also in packs a with specified number of fittings indicated after the letters "PK" in the product reference number (SKU).

Flared tube coupling nuts conforming SAE International standard AS5175 are used for a leak-free solution on aircraft and other applications replacing respective AN818 parts. They are offered  as part of our own (AVIATIONEU NEW ERA) product lines in different materials and grades and multiple thread sizes to suit application needs. Material Code Letters in the part numbers indicate the composition of the fitting (No code for Steel 1137 or 4130, "D" for Aluminum alloys (except 7075-T73), "J" for 304 Stainless Steel (CRES 304), "K" for 316 Stainless Steel (CRES 316), "T" for Titanium 64AI-4V or "W" for Aluminum 7075-T73. These nuts are designed to be used with AS5176 and MS20819 sleeves. The 2 digits after the series code indicate the tubing outer diameter (O.D.)  in inches. Finish code “V” in the PN indicates high purity Aluminum coating for “W” or “D” fittings. Depending on their Part Number they are sold in pieces but also in packs a with specified number of fittings indicated after the letters "PK" in the product reference number (SKU).

Note: In SAE AS standards for new designs, aluminum fittings with material code letter D in their Part or Identifying Number (PIN) are replaced by those with material code letter W for Aluminum Alloy 7075-T73 providing a higher tensile strength.

Hoses and fittings most suited to naval and marine applications are included in this listing. They are offered by DANFOSS EATON AEROQUIP® brand and other manufacturers, such as HYDRASEARCH or REPUBLIC BRASS SALES. Made from different materials & reinforcements they are available in different internal tube diameters (I.D.) in inches and lengths in feet. Depending on the hose, they can be used within their maximum operating pressure with a range of fluids (e.g. gasoline, crude, fuel and lubricating oils, air, water or hydraulic fluids) and conform to different Military specifications mentioned below.

MIL-DTL-3992 Air brake hose

MIL-DTL-8794 Medium-pressure wire-braid hose

MIL-DTL-13444 Rubber fuel and oil hose

MIL-DTL-13531 Rubber hydraulic hose

MIL-DTL-52471 Rubber hydraulic hose

MIL-H-24135 Wire-reinforced rubber hose

MIL-H-24595 Wire-reinforced rubber hose

MIL-H-24136 Fiber-reinforced rubber hose

For additional information please consult the supplied documentation or contact us.

DANFOSS EATON SYNFLEX® subsea hoses and bundles are built to meet and exceed the most demanding industry requirements. Their rigorous hose qualification ensures long hose service life while their robust construction enables them to withstand high pressures. They are offered in long, continuous lengths to cover requirements of diverse applications all over the world.

At its core, SYNFLEX® High Pressure hose is a smooth, seamless, continuous extrusion of Nylon 11 Besno P40 TLO. The hose is reinforced with premium aramid fiber and jacketed with a highly UV resistant thermoplastic for long term aging and resistance to hydrolysis. Long continuous lengths are available for subsea bundles and single line applications. Available in 3,000, 5,000, 10,000, and 15,000 psi working pressures these hoses are lightweight, easy to install and assemble, and available in multiple sizes and long continuous lengths. Used in a wide range of applications including Hydraulic flying leads, workover umbilical components, hot lines, chemical, water and nitrogen injections and  subsea blow out prevention (BOP) bundles and hot lines enabling faster and more effective response to subsea events.

Like in other SYNFLEX® hoses, approved Eaton components are offered to ensure complete hose assembly systems.

Hoses are priced and sold by the foot unless otherwise specified. Fittings can be separately purchased in pieces.

For additional information on different products please consult the Product Description section, supplied documentation or contact us.

Non-latching automatic self-sealing and Thread-Lok Quick Disconnect (QD) valved hose couplings are manufactured by the Stratoflex Products Division of Parker Hannifin Corporation.

Automatic couplings are recommended for use with today's advanced precision fluid systems for space flight, aircraft, ground and undersea applications. Stratoflex non-latching automatic self-sealing couplings are designed for use in diverse applications like electronic cooling systems, hydraulic accumulators/cylinders, brake systems, manifolds, vapor cycle and cryogenic systems. Automatic couplings are best utilized where space is limited, and hands off operation is required. Small envelope, high performance and unsurpassed reliability are key features of Stratoflex non-latching couplings. Available in different tube sizes, from sub-miniature to one inch in aluminum alloy, stainless steel, titanium and other exotic materials. They meet SAE Aerospace Standards AS4251,AS5072/1/2/3.

The Parker Stratoflex’s Thread-Lok Quick Disconnect (QD) valved couplings provide a proven solution for fluid conveyance systems  for aerospace and derivative markets when envelope and weight are important and robust performance is critical. Applications range from hydraulic, fuel, and cooling systems to pneumatic, air data systems, landing gears, wheel and brakes hydraulic fluid motors, military ground vehicles and space applications. Their respective Thread-Lok Ground Service Equipment (GSE) Quick Disconnect (QD) couplings are intended for use with fluid conveyance systems providing a robust connection for ground service equipment to the aircraft flight systems. The Thread-Lok QD is used in a wide range of pressure and temperature applications.

They integrate a highly reliable and robust positive locking mechanism to ensure the performance needed in difficult aircraft system environments such as the engine nacelle, landing gear and brake systems, and other QD demanding installations . The Thread-Lok QD couplings can be used in a wide range of pressure and temperature applications while they provide a simple one-hand operation to thread the QD halves together with a visual confirmation of proper and full coupling to improve both time and safety.

The Thread-Lok QDs incorporate tang and slot design, with QDs engaging and locking in one position when the coupling halves are threaded together and fully connected, providing both visual and touch indication of the fully connected position. They use Parker’s efficient, self-sealing valve design that permits fluid flow with minimum pressure loss and turbulence.

Available in different tube sizes, from ¼ to one inch. Their stainless steel construction meets typical electrical bonding requirements.They meet or exceed MIL-C-25427 and AS1709 specifications.

For additional information please consult the Product Description section, the supplied documentation or contact us.
