Flared sleeve fittings are cylindrical metallic parts designed to be used on tubing to back up the flared end and provide a bearing surface for the coupling nut, thereby reducing wear on the tubing flare. The inside diameter of the flanged end is countersunk to form a seat for the flare when assembled to a mating fitting.

Coupling sleeves conforming to SAE International, standard AS5176 standard replace respective MS20819/AN819 sleeves and they are offered as part of our own (AVIATIONEU NEW ERA) product lines. Sourced from quality producers these fittings are manufactured in different materials including 4130 Steel, Copper, Corrosion Resistant Steel (CRES) and Aluminum & Titanium Alloys. Material Code Letters in the part numbers indicate the composition of the fitting.

Depending on their Part Number they are sold in pieces but also in packs a with specified number of fittings indicated after the letters "PK" in the product reference number (SKU).

NAS1922/NAS1924 series clamps are light-weight, aircraft application clamps from 300-series stainless steel available with either a 1/4" round slotted screw or a 1/4" slotted hex-head screw.

NAS1922/NAS1924 series clamps are included as part of our own branded (AVIATIONEU NEW ERA) product lines. They are available in different sizes (NAS1924 clamps are available in sizes 48 & above). Both screw styles can be supplied with optional lock wire hole for tamper resistance. Black Oxide coated band versions (designated by the letter "L" in the part number) are also offered for increased wear resistance.

The following designators in the product reference number (SKU) indicate the different versions:

-1 Clamp with round slotted screw

-3 Clamp with slotted hex-head screw

-1H Clamp with round slotted screw & lock wire hole

-3H Clamp with slotted hex-head screw & lock wire hole

NAS1922/NAS1924 series clamps are sold in pieces or packs of specified number of pieces indicated after the letters "PK" in the product reference number (SKU).

Please refer to the attached documentation of the effective diameter range for different part numbers.

The  Parker Aerospace (Stratoflex Products Division) offers a broad array of PTFE, rubber and metal hose and hose assemblies, hose fittings, rigid tube assemblies, couplings, quick disconnects, swivel joints, fuel break-away valves, hydraulic fuses, and flow regulators, and specialty fittings including permanently swaged and welded fittings suitable for virtually any aerospace application. 676 Series are straight fittings  for use with Stratoflex 156 hoses. They come in different outside diameters (OD) and thread sizes in inches. Please refer to the attached Stratoflex catalog for offered hoses and fittings or contact us.

DANFOSS EATON SYNFLEX® subsea hoses and bundles are built to meet and exceed the most demanding industry requirements. Their rigorous hose qualification ensures long hose service life while their robust construction enables them to withstand high pressures. They are offered in long, continuous lengths to cover requirements of diverse applications all over the world.

At its core, SYNFLEX® High Pressure hose is a smooth, seamless, continuous extrusion of Nylon 11 Besno P40 TLO. The hose is reinforced with premium aramid fiber and jacketed with a highly UV resistant thermoplastic for long term aging and resistance to hydrolysis. Long continuous lengths are available for subsea bundles and single line applications. Available in 3,000, 5,000, 10,000, and 15,000 psi working pressures these hoses are lightweight, easy to install and assemble, and available in multiple sizes and long continuous lengths. Used in a wide range of applications including Hydraulic flying leads, workover umbilical components, hot lines, chemical, water and nitrogen injections and  subsea blow out prevention (BOP) bundles and hot lines enabling faster and more effective response to subsea events.

Like in other SYNFLEX® hoses, approved Eaton components are offered to ensure complete hose assembly systems.

Hoses are priced and sold by the foot unless otherwise specified. Fittings can be separately purchased in pieces.

For additional information on different products please consult the Product Description section, supplied documentation or contact us.

POLY-FLO tube is a flexible, economical thermoplastic tube fabricated from high molecular weight polyethylene for improved strength. The base resin has the greatest resistance to environmental stress cracking of all the regular polyethylenes. Used for instrument or pneumatic lines. Use Nylo-Seal fittings (259-N inserts are required), nylon or polyethylene hose fittings such as 0710-153. It meets A.S.T.M. D-1248-60T, Type 1, Class A, Grade 4 and Federal Specification LP- 590, Type 2, Grade 7. Color:- natural.

POLY-FLO tubes are sold by the foot.

AVIATIONEU NEW ERA end hose banjo fittings are intended for use in hydraulic pipes in automotive fuel, oil and hydraulic systems. They are available with single or double ends from different materials, mild steel, EN 1AL(free cutting steel), 11SMnPb30, EN 8, stainless steel 202 & 304. Sourced by certified manufacturers these banjo fittings are competitively priced and offered in different Metric sizes (M10x5/16", M12x5/16", M14x5/16", M14x3/8", M16x3/8", M18x3/8", M18x1/2") and different surface treatments (clear /yellow zinc plated, olive green zinc plated, dacromet). Sold by the piece (pc.) with Minimum Order Quantity (MOQ) 500 pcs.  Appearing price is for reference only per pc. Please contact us for a quotation.

DANFOSS EATON SYNFLEX® 1300 Series composite wall tubes are designed for pneumatic instrument control systems. Their fully bonded polyethylene/aluminium construction combines the advantages of both metal and plastic tubing.

Their outer, high density polyethylene layer is impervious to most chemical environments and enables SYNFLEX® 1300 tubes to outperform practically all types of unprotected metal tubing.

Product Features:

• Combine the advantages of both metal and plastic tubing

• Very light (5 times lighter than a standard instrument control tubes)

• Provide neat looking bends without special bending tools

• Corrosion and chemical environment resistant

• Excellent chemical compatibility

• Tubing contents dry thanks to aluminum barrier

• Enable direct burial w ithout additional protection (whatever the installation)

• Connection with standard compression fittings

• 25, 75,100m standard lengths

• Standard color: black, other colours on request

• Also available with "Halogen free" jacket

Applications

• Pneumatic instrumentation and control lines located in very wet or moist environments

• Air and gas sampling

• Corrosive environments

• ID surface best suited for air

Construction

• Polyethylene/Aluminum composite

Temperature range

• -40 °C to 80 °C

Hose and tubing insert fittings are available in high density black polyethylene or white nylon. Polyethylene fittings can be used with tygon, nylon or soft rubber tubing to assemble low pressure instrument lines such as airspeed pitot and static lines. Nylon fittings can be used in gravity-feed fuel lines and engine breather lines.

EATON HANSEN HA 15000  Series couplings, now part of DANFOSS product portfolio,  are general purpose hydraulic and fluid transfer couplings conforming to the dimensional requirements of ISO 7241-1 Series A. Body sizes are 1/4", 3/8", 1/2", 3/4" and 1".

Standard Materials used in their manufacturing include:

• Zinc-plated steel construction

• Stainless steel springs, balls and retaining rings

• Buna-N (Nitrile) seals

Product Features:

• Ball lock

• Manual connect, disconnect

• Poppet valving

• Slim profile

• Zinc plated steel construction

• NPTF and BSPP end connections

• Available push-to-connect socket designed for bulkhead mounting (1/2" body size only)

Rated Pressure in PSI / BAR per Body Size

1/4" - 4,568 / 315

 3/8" - 4,568 / 315

 1/2" - 3,625 / 250

 3/4" - 3,625 / 250

 1" - 2,900 / 200

For additional information please refer to the supplied documentation or contact us.

Note: Special Order items. Non-Cancellable/Non-Returnable Upon Order Placement (NCNR).

Non-latching automatic self-sealing and Thread-Lok Quick Disconnect (QD) valved hose couplings are manufactured by the Stratoflex Products Division of Parker Hannifin Corporation.

Automatic couplings are recommended for use with today's advanced precision fluid systems for space flight, aircraft, ground and undersea applications. Stratoflex non-latching automatic self-sealing couplings are designed for use in diverse applications like electronic cooling systems, hydraulic accumulators/cylinders, brake systems, manifolds, vapor cycle and cryogenic systems. Automatic couplings are best utilized where space is limited, and hands off operation is required. Small envelope, high performance and unsurpassed reliability are key features of Stratoflex non-latching couplings. Available in different tube sizes, from sub-miniature to one inch in aluminum alloy, stainless steel, titanium and other exotic materials. They meet SAE Aerospace Standards AS4251,AS5072/1/2/3.

The Parker Stratoflex’s Thread-Lok Quick Disconnect (QD) valved couplings provide a proven solution for fluid conveyance systems  for aerospace and derivative markets when envelope and weight are important and robust performance is critical. Applications range from hydraulic, fuel, and cooling systems to pneumatic, air data systems, landing gears, wheel and brakes hydraulic fluid motors, military ground vehicles and space applications. Their respective Thread-Lok Ground Service Equipment (GSE) Quick Disconnect (QD) couplings are intended for use with fluid conveyance systems providing a robust connection for ground service equipment to the aircraft flight systems. The Thread-Lok QD is used in a wide range of pressure and temperature applications.

They integrate a highly reliable and robust positive locking mechanism to ensure the performance needed in difficult aircraft system environments such as the engine nacelle, landing gear and brake systems, and other QD demanding installations . The Thread-Lok QD couplings can be used in a wide range of pressure and temperature applications while they provide a simple one-hand operation to thread the QD halves together with a visual confirmation of proper and full coupling to improve both time and safety.

The Thread-Lok QDs incorporate tang and slot design, with QDs engaging and locking in one position when the coupling halves are threaded together and fully connected, providing both visual and touch indication of the fully connected position. They use Parker’s efficient, self-sealing valve design that permits fluid flow with minimum pressure loss and turbulence.

Available in different tube sizes, from ¼ to one inch. Their stainless steel construction meets typical electrical bonding requirements.They meet or exceed MIL-C-25427 and AS1709 specifications.

For additional information please consult the Product Description section, the supplied documentation or contact us.

SAE100 R7 thermoplastic hydraulic hoses are commonly used with petroleum, fire-resistant, and water-base fluids, pneumatic, fuel, and lubricating systems. These hoses are poduced by different manufacturers such as KURT HYDRAULICS, DANFOSS EATON, PARKER and others they are offered as standard (conductive) and non-conductive (blocking electrical flow). They are generally composed of three parts: tube, reinforcement and cover. The tube and cover are made from high quality thermoplastic while reinforcement is made from suitable synthetic fiber.

KURT HYDRAULICS, part of KURT Manufacturing Group. manufactures and supplies a wide range of hydraulic fittings, hoses and couplings. The KURT HYDRAULICS thermoplastic hydraulic hoses are manufactured to the highest quality standards. Available in different grades for medium- to high-pressure applications in a range of sizes from 1/8” to 1”, depending on grade. Matching hydraulic fittings, quick crimpers, and more are also offered to create a complete hydraulic system.

KURT HYDRAULICS SAE100 R7 hoses feature a three-layer construction—nylon inner tubes, braided synthetic fiber reinforcements, and flexible, durable urethane outer sleeves. Offered in electrically conductive and non-conductive styles in most grades. They are rated up to 5000 PSI WP and 20000 PSI BP, varying by grade and diameter. All grades and sizes feature an operational temperature range from -40°F to +212°F.

Hoses are priced and sold by the foot unless otherwise specified. Fittings can be separately purchased in pieces.

For additional information on different products please consult the Product Description section, the supplied documentation or contact us.

SAE-AS5406/AN832 series union tube hydraulic fittings are available as part of our own labelled (AVIATIONEU NEW ERA) product lines in different materials, tube outer diameters and thread sizes in inches. The AN832 series fittings are superseded by the respective fittings of  SAE International standard  SAE-AS5406 series.

Like their SAE-AS5174/MS24392/AN815 union flared tube counterparts, SAE-AS5406/AN832 series fittings are manufactured from Carbon Steel, Aluminum Alloy, Corrosion Resistant Steel (CRES), Titanium Alloy. The 2 digits after the series code indicate the tubing outer diameter (O.D.)  in inches. The following Material Code Letters in the part numbers indicate the composition of the fitting.

No code letter in part number for Carbon Steel

Code letter “D” for Aluminum Alloy (except 7075-T73)

Code letter “J” for CRES, type 304

Code letter “K” for CRES, type 316

Code letter “S” for CRES, type 347

Code letter “T” for Titanium Alloy 6AL-4V

Code letter “W” for Aluminum Alloy 7075-T73

For example, AS5406D06 union fitting is made from Aluminum Alloy with a tubing outer diameter (O.D.) 3/8". The corresponding union fitting in AN832 series would be AN832-6D.

Depending on their Part Number they are sold in pieces but also in packs a with specified number of fittings indicated after the letters "PK" in the product reference number (SKU).

MIL-DTL 6000D Soft Flexible Aircraft Fuel (*), Oil, Water & Alcohol Rubber Hoses (superseeding MIL-DTL-6000C hoses) are offered as part of our own labeled (AVIATIONEU NEW ERA) product lines. They replace the respective MIL-DTL 6000C hoses.

These hoses are designed to handle oil, alcohol, coolant, and water.  The tube of these hoses is oil resistant with a black cover reinforced with high strength mildew resistant yarns. It withstands extreme temperature conditions from -40 deg. F to +250 deg. F.  Lightweight, flexible and easy-to-handle, they meet or exceed U.S. military specs and consist the right choice for hard-to-get-to spots in tight engine compartments. Their burst pressure is 1000 PSI (400 PSI for the hose with ID 2-1/2 in.).

AVIATIONEU NEW ERA MIL-DTL 6000D hoses are available in different internal and outer diameters in inches. Priced and sold in feet in one foot increments. The last part of our product reference code (SKU) indicates the inner diameter of the hose in inches.

For additional information please refer to the supplied documentation or contact us.

(*) MIL-DTL 6000D hoses are not recommended for use as fuel lines.

The AN6298 bulkhead nuts are plain, hexagon nuts used in various aerospace applications. These have been superseded by respective part numbers of SAE International standard  SAE-AS5178. Typically made from high-strength steel or corrosion-resistant alloys they are designed for use in  high-stress environments such as aircraft assemblies. Sourced from quality manufacturers they are offered as part of our own labelled (AVIATIONEU NEW ERA) product lines in different materials and thread sizes. The fitting composition is designated by a code letter in the part number of the fitting (No code letter for Steel, “D” for Aluminum Alloy, “J” for 304 Stainless Steel (CRES), “K” for 316 Stainless Steel or “T” for Titanium Alloy. Depending on their Part Number they are sold in pieces but mostly in packs a with specified number of fittings indicated after the letters "PK" in the product reference number (SKU).

SAE-AS5174/MS24392/AN815 series union, flared tube male to male hydraulic fittings are available as part of our own labelled (AVIATIONEU NEW ERA) product lines in different materials, tube outer diameters and thread sizes in inches. The AN815 series fittings are superseded by the respective fittings of Military Standard MS24392 which in turn are superseded by SAE International standard  SAE-AS5174 series. Materials include: Carbon Steel, Aluminum Alloy, Corrosion Resistant Steel (CRES), Titanium Alloy. The 2 digits after the series code indicate the tubing outer diameter (O.D.)  in inches. The following Material Code Letters in the part numbers indicate the composition of the fitting. Finish code “V” in the PN indicates high purity Aluminum coating for “W” or “D” fittings.

Depending on their Part Number they are sold in pieces but also in packs a with specified number of fittings indicated after the letters "PK" in the product reference number (SKU).

No code letter in part number for Carbon Steel

“D” for Aluminum Alloy (except 7075-T73)

“J” for CRES, type 304

“K” for CRES, type 316

“R” for CRES, type 321

“S” for CRES, type 347

“T” for Titanium Alloy 6AL-4V

“W” for Aluminum Alloy 7075-T73

“Z” for Carbon Steel, Zinc plated

For example, AS5174D0606 union fitting is made from Aluminum Alloy with a tubing outer diameter (O.D.) 3/8" and a 0.5625-18 UNJF thread. The corresponding union fitting in AN832 series would be AN815-6D.

Note: In SAE AS standards for new designs, Aluminum fittings with material code letter D in their Part or Identifying Number (PIN) are replaced by those with material code letter W for Aluminum Alloy 7075-T73 providing a higher tensile strength. In addition CRES fittings with material code letter S can be used for replacement parts. For new designs use of CRES fittings with material code letter R is recommended for applications requiring higher temperature.

Danfoss SEL brand includes a range of low, mid, and high pressure industrial and hydraulic rubber, thermoplastic, and PVC hoses that meet or exceed industry standards. Spanning a broad range of operating pressures, Danfoss SEL hoses are the perfect solution for maximum durability and long-lasting performance under even the toughest conditions. SEL product portfolio includes:

FORCESTREAM standard wire braided hydraulic hoses.

SUPERSTREAM and ULTRASTREAM premium wire braided hoses offering higher working pressures and improved flexibility.

POWERSTREAM spiral reinforced hydraulic hoses for high pressure applications.

COLDSTREAM  hydraulic hoses resistant to ambient temperatures down to -50 C, specifically designed for low temperature applications.

ULTIMATE hydraulic hoses supporting high temperature applications up to 135 C, or 150 C for short-term exposure.

ARMADILLO range of hydraulic hoses with specialized cover materials providing advantages like enhanced ozone or abrasion resistance. Ideal for demanding and dynamic applications, such as pit mining equipment.

SUPER ABRA hydraulic hoses offering an outer cover.

For additional information please refer to the supplied documentation.

AVIATIONEU NEW ERA air relief valves can be used in different industrial applications. They are made from different materials,  EN 1AL (free cutting steel), 1SMnPb30+C or SAE 12L13  and zinc plated. Available in the following sizes:

Metric: M10 x 1 ARV

British Standard Pipe (BSP): 1/8" BSP ARV

U.S. National Pipe Thread (NPT): 1/8" NPT ARV, 1/4" NPT ARV

Sold by the piece (pc.) with Minimum Order Quantity (MOQ) 1000 pcs.  Appearing price is for reference only per pc. Please contact us for a quotation.

AN823 45° Flared Tube & Pipe Thread Elbow Fittings are superseded by those of Military Standard MS20823 and these are superseded in turn by SAE-AS5196 standard. These fittings are  offered as part of AVIATIONEU NEW ERA product lines in steel or aluminum in different tube outer diameters and thread sizes in inches. Aluminum fittings are designated by the letter "D" after the suffix number.

VENA® HT Series flexible  hoses (SCAT equivalent) are  made of one layer of glass fabric silicone coated and visible steel wire  spiral inside. For use in conducting extremely cold or hot air (temperature range: -65°F to +550°F). Available in different internal diameters in inches. Sold by the foot.

Nylaflow®, Nylon Tubing is a high-quality pressure tubing, available in several types. Nylaflow® tubes are tough and durable, offering low friction and high flexibility. Offered by different producers, Nylaflow® tubing is suitable for applications that require toughness, resilience, a small bend radius and high burst strength. Nylaflow® tubing offers superior burst strength compared to vinyl, ethylene, and urethane tubing and it is a high performance, long-lasting alternative to copper, rubber, aluminum and other types of plastic tubing. Its high burst rating makes it a common solution pneumatic and hydraulic lines. Nylon has excellent chemical resistance and can withstand exposure to relatively high concentrations of harsh chemicals at elevated temperatures. Its extremely smooth inner surface resists abrasion and wear and makes for a low coefficient of friction. It is often used in corrosive environments because of its excellent resistance to harsh chemicals.

Nylaflow® tubing comes in different types.

Types T (Thin Wall) and H (Heavy Wall) are the most common Nylaflow general purpose tubing made from type 6/6 nylon. FDA compliant for use in food or beverage handling applications also meeting 3A sanitary standards. The High performance of this Nylon tubing makes it perfect for applications that require durability, resilience, a small bend radius, and high burst strength.

Type LM tubing is a premium high flex tubing available in two types: natural or black, which exhibits improved light stability. Type LM offers excellent chemical resistance and low moisture absorption. Often used in automotive fuel lines, lubrication lines, air lines, and vacuum environments.

Type LP tubing is a low pressure, general purpose type 6 nylon tubing with carbon added for UV stability.

Nylaflow® nylon tubing is available with custom markings, cut to length and custom packaging. It can be cut with a sharp knife and flared hot or cold. They are odorless, tasteless and noncorrosive.

Typical applications of Nylaflow® tubing include airlines, grease lines, vacuum lines, and hydraulic lines.
