AVIATIONEU NEW ERA Hexagon Socket Head Screws are made of Carbon Steel, Alloy Steel with a Black Oxide or Galvanized finish (depending on the P/N) and a strength class of 4.8 or other as specified by the letter "S" in the P/N. They are fully threaded, coarse type, and produced by certified manufacturers in accordance with DIN 7984 standard. They are offered in competitive prices in different diameters ("M" designated), indicating the screw's diameter in mm and lengths in mm. The thread pitch (the distance between threads measured along the length of the screw) expressed in mm is indicated by the "P" designation in the P/N. Sold in packs of 500, 250 or  50 pieces depending on the selected product. The number of pieces included in each pack is mentioned after "PK" designation.

AVIATIONEU NEW ERA Hexagon Bolts are made of Stainless Steel 304/316 (depending on the P/N) with a bright surface treatment and a strength class of A2-70 for SS 304 bolts and A4-70 for SS 316 bolts. They are fully threaded, coarse type, and produced by certified manufacturers in accordance with DIN 933 standard. They are offered in competitive prices in different diameters ("M" designated), indicating the bolt's diameter in mm and lengths in mm. The thread pitch (the distance between threads measured along the length of the bolt) expressed in mm is indicated by the "P" designation in the P/N. Sold in packs of 250, 100 or  25 pieces depending on the selected product. The number of pieces included in each pack is mentioned after "PK" designation.

AVIATIONEU NEW ERA air relief valves can be used in different industrial applications. They are made from different materials,  EN 1AL (free cutting steel), 1SMnPb30+C or SAE 12L13  and zinc plated. Available in the following sizes:

Metric: M10 x 1 ARV

British Standard Pipe (BSP): 1/8" BSP ARV

U.S. National Pipe Thread (NPT): 1/8" NPT ARV, 1/4" NPT ARV

Sold by the piece (pc.) with Minimum Order Quantity (MOQ) 1000 pcs.  Appearing price is for reference only per pc. Please contact us for a quotation.

Copper wires are conductors of electricity and they are used for a wide range of applications including power generation, power transmission, power distribution, telecommunications, electronics circuitry and others. Apart from the high conductivity copper features durability, tensile strength and corrosion resistance.

AVIATIONEU NEW ERA copper round wire product range includes bare copper, copper, paper insulated copper wires as well as double cotton covered and silver or tinned plated copper wires.

They are offered in rolls in different wire gauges (*). Sold in kilograms except the double cotton covered wire which is sold by the meter. Appearing prices is for reference only per UOM. Please contact us for a quotation.

Bare Copper Wire, Gauge 0-5

Paper Insulated Stranded Wire, Gauge 0-5

Tinned Plated Copper Wire (Temperature 120 deg. C), Gauge 0.2-2

Silver Plated Copper Wire (Voltage up to 1000 V, Flame Retardant), Gauge 0-5

Double Cotton Covered Copper Wire, Gauge 0-5

(*) Wire gauge is a measurement of wire diameter. This determines the amount of electric current a wire can safely carry, as well as its electrical resistance and weight. Please refer to the respective table.

In co-operation with aircraft manufacturers, AVIATIONEU NEW ERA Lease or Buy Programs have been developed for ultralight and light aircraft (*). They are generally offered as FACTORY NEW although used aircraft may be included. Depending on the selection, these can be used for recreational and business flying, pilot training, aeroclub operations or other missions (e.g surveillance or aerial photography). A range of support services are also offered (as required) depending on the leasing or buy option and the country of operations. These indicatively include initial airworthiness certification in the country of destination, user training on aircraft operations, supply of spare parts and consummables, aircraft maintenance, insurance etc. Some of these services are prerequisites in the leasing option. Please refer to the individual aircraft presentations or contact us for additional information and quotation.

(*) The term "Ultralight" is often used to denote different aircraft types across the world. In the U.S.,Ultralights are referred to as vehicles (not aircraft) and must be a single-place of very light weight. The term "Light Sport Aircraft (LSA)" is used in FAA regulations (FARs) for certification of aircraft complying with the ASTM standards and subject to specified limitations such as non-pressurised cabin, max seating capacity of two persons (including the pilot), a single reciprocating engine, a MTOW of not more than 1,320 pounds, a fixed-pitch or  ground-adjustable propeller, etc. In Europe, certification of Ultralights falling under Annex II of the European Union Aviation Safety Agency (EASA) Basic Regulation is handled under national rules. EASA has introduced a new certification process for the European Light Aeroplane (ELA) considered as a simple two-seater non-pressurised aircraft for "non-aerobatic" and "VFR day" operations only with a single, non-turbine engine fitted with a propeller and a maximum take-off weight of 600kg.

Structural screws are made of alloy steel, are properly heat treated, and can be used as structural bolts. Those commonly used in aircraft applications are manufactured to aerospace/military standards/specifications. They are offered as part of our own branded (AVIATIONEU NEW ERA) product lines in different materials and finishes, structured in different series based on the standard of their conformance.

AVIATIONEU NEW ERA MS27039 Series structural machine screws are pan head cross recessed screws equivalent to those of NAS 220 Series. MS27039 Series screws are fabricated from Alloy Steel and Cadmium plated per specification QQ-P-416A, Type II, Class 3, Anodized Aluminum Alloy 2024 or Stainless Steel Unplated  to MIL-S-6050 or MIL-8695 specifications. Those from are designated by the letters "DD" and their counterparts from stainless steel  by the letter "C" respectively in the product part number after MS27039 and before the size number. These screws have 125,000 to 145,000 psi tensile strength. Sourced from quality suppliers, they are offered in different thread sizes and lengths in inches and sold in pieces or convenient packs of specified number of screws per pack indicated after the letters "PK" in the product reference number (SKU).

Other structural screws of NAS204 through NAS235 and AN509/AN525 series are also available (see individual product presentations).

For more information, please refer to the supplied documentation or contact us.

Titanium fasteners are best known for their strength,  lightweight, and corrosion resistance. They feature an excellent strength to weight ratio and significant mechanical properties but perhaps their most notable attribute is their superior corrosion resistance to salt water / seawater operating conditions. Titanium fasteners are used in aerospace, automotive and motorsports but also in many other industries including chlor alkali, marine, off-shore oil & gas, desalination, medical, and pulp and paper. They come in different types (like bolts, screws and nuts), sizes, titanium grades and standards/specifications (e.g. ANSI/ASME, DIN/ISO, ASTM, ASME, MIL specifications etc.) to meet application requirements. Compared to respective fasteners made of steel and aluminum, as a rule of thumb, titanium fasteners are about half the weight of their steel counterparts while aluminum fasteners are about half the weight of titanium ones.

Sourced from quality producers, a wide range of titanium fasteners are offered as part of AVIATIONEU NEW ERA product lines (please refer to the individual product presentations).

AVIATIONEU NEW ERA Titanium nuts are available in both inch and metric systems. Their typicals uses include aerospace, marine, motorsports and many other applications. Manufactured from 6AL-4V grade titanium, CNC machined, heat treated with hexagonal heads and rolled threads these nuts come in diffrent types including locking and flange nuts(*), sizes, thread pitches, flange diameters and lengths. They are sold in pieces. For more information or unlisted fasteners please contact us.

(*) Appearing dimensions for Flange Nuts: Hex Size, Flange Diameter, Height (Hex or Total).

Aircraft washers used in airframe construction or repair works are either plain, lock, or special type washers.

AN960/AN960L series are aeronautical (Army-Navy) standard flat washers superseded by the respective washers in NAS1149/NAS1149L series. They come in regular thickness (NAS1149/AN960) or light thickness (NAS1149L/AN960L) indicated by the letter "L" in the dash number of the product reference number (SKU). They are made from different materials such as carbon steel, corrosion resistant steel (CRES) and aluminum alloys. These washers are used under hex nuts to provide a smooth bearing surface, as shims to obtain the correct grip length for a bolt and nut assembly, and to adjust the position of AN310 and AN320 castle nuts with respect to drilled cotter pin holes in bolts and clevis pins.

NAS1149/AN960 and NAS1149L/AN960L series washers are offered as part of our own labeled (AVIATIONEU NEW ERA) product lines. They can be furnished in different materials (such as carbon steel, CRES, anodized aluminum or aluminum alloy), different finishes and different inside, outside diameters and thicknesses in inches.  Letters in the part number of NAS1149/AN960 washers are used for material and finish specification. Please refer to the supplied documentation for information on available sizes, materials, finishes and cross reference between  AN960  and NAS1149 series washers.

Sold in packs with a specified number of washers per pack indicated after the letters "PK" in the product reference number (SKU).

Cotter pins are used to secure bolts, screws, nuts, and pins. Military standard MS24665 split cotter pins are made from cadmium plated steel, replacing those of AN380 series or passivated corrosion resistant steel (CRES), replacing those of AN381 series. The CRES cotter pins are more resistant to corrosion and also used where heatresisting attributes are desired, such as forward of firewall or  in locations where nonmagnetic material is required. Regardless of their shape or material, all cotter pins serve the same general purpose - safetying. MS24665 split cotter pins are superseded by respective part numbers of NASM24665 series.

MS24665 Series split cotter pins are offered as part of our own branded (AVIATIONEU NEW ERA) product lines in cadmium plated steel or passivated corrosion resistant steel and in different diameters and lengths. Sold in pieces. For more information, please refer to the supplied documentation or contact us.

Clevis pins are used as a quick and secure fastener in place of bolts and rivets. Clevis pins can be partially threaded or unthreaded. Unthreaded Clevis pins have a domed head at one end and a cross-hole at the other end. A Clevis pin is inserted through the holes at the pronged ends of a Clevis and is kept in place by a cotter pin. Threaded Clevis pins are partially threaded on one end with a formed head on the other.

MS20392 series Clevis pins are straight, headed pins with a drilled shank. They supersede those of AN392 to AN396 series and those of AN400, AN402, AN404, and AN406 series. MS20392 series Clevis pins are produced in different materials (steel alloy, corrosion resistant steel (CRES), titanium alloy) and surface finishes (cadmium plated, chrome plated, titanium alloy - aluminum coated) with a drilled hole for cotter pin. The following letters in the part number specify materials and finishes:

“C”  Steel alloy, 4037 4130 8630 or 8740 cadmium plated

“S”  Steel alloy, 8740 cadmium plated

“R” Corrosion resistant steel, PH13-8Mo chrome plated

“P” Corrosion resistant steel, PH13-8Mo cleaned descaled and passivated

“A” Titanium alloy Ti-6AI-4V, aluminum coated and lubricated with solid film lubricant

“T” Titanium alloy, Ti-6AI-4V, no finish

MS20392 series Clevis pins are offered as part of our own labelled (AVIATIONEU NEW ERA) product lines in different materials, head, shank diameters and effective lengths. They are used with clevis forks and in secondary controls which are not subjected to continuous operation. For more information, please refer to the supplied documentation or contact us.

NAS1922/NAS1924 series clamps are light-weight, aircraft application clamps from 300-series stainless steel available with either a 1/4" round slotted screw or a 1/4" slotted hex-head screw.

NAS1922/NAS1924 series clamps are included as part of our own branded (AVIATIONEU NEW ERA) product lines. They are available in different sizes (NAS1924 clamps are available in sizes 48 & above). Both screw styles can be supplied with optional lock wire hole for tamper resistance. Black Oxide coated band versions (designated by the letter "L" in the part number) are also offered for increased wear resistance.

The following designators in the product reference number (SKU) indicate the different versions:

-1 Clamp with round slotted screw

-3 Clamp with slotted hex-head screw

-1H Clamp with round slotted screw & lock wire hole

-3H Clamp with slotted hex-head screw & lock wire hole

NAS1922/NAS1924 series clamps are sold in pieces or packs of specified number of pieces indicated after the letters "PK" in the product reference number (SKU).

Please refer to the attached documentation of the effective diameter range for different part numbers.

Sourced from quality producers, AVIATIONEU NEW ERA general purpose brass check valves with nylon cover are suitable for use in hydraulic, heating, air conditioning and pneumatic installations in vertical, horizontal or oblique positions. They are manufactured in accordance with ISO 228 standard and they are available in different sizes. Sold in pieces.

AVIATIONEU NEW ERA TINNERMAN® NUT PACKS

 A. RAYMOND TINNERMAN® & PALNUT® (aka PAL) of TINNERMAN PALNUT ENGINEERED PRODUCTS, INC. are leading brands in specialty clip-type fasteners including the world's largest selection of spring steel, stainless steel, and plastic engineered fasteners. They consist innovative solutions to traditional fasteners combining aesthetics and functionality. They are quick and easy to install, and do not require mounting tools.

TINNERMAN® spring steel nuts (aka speed or sheet metal nuts) are self-retaining fasteners serving the functions of both a lock washer and a nut for an easy & fast attachment of mating panels. Offered in different shapes (e.g. Flat U, J) styles & finishes they can be used as both blind and front mounting attachments without required special tools, skills or equipment, removed and reused. Riveting, welding, clinching, staking and other secondary fastening devices are eliminated.

Sourced from quality suppliers, A.RAYMOND/TINNERMAN® popular OEM nuts or their equivalents (TINNERMAN® Style) are offered in convenient Nut Packs as part of our own labelled (AVIATIONEU NEW ERA) product lines to serve different aerospace, automotive, appliance assembly HVAC and other application requirements. They include U or Flat-Type and anchor nuts under different A.RAYMOND/TINNERMAN® brands.  Made from spring steel, resistant to vibrational loosening to prevent the need for a lock washer, these fasteners are available in a variety of finishes including: phosphate, zinc or plain. These packs are sold individually and include a specified number of fasteners of the respective TINNERMAN® part number per pack indicated after the letters "PK" in our product reference number (SKU).

Our current surplus stock of TINNERMAN® Nut Packs is now offered at discounted prices and available for immediate shipping till their stock exhaustion. Parts are accompanied by our Certificate of Conformance. Shipping to customer destination can be arranged at additional charge.

Surplus stock packs currently include the following nuts:

TINNERMAN® U-Type Nuts: A1348-8Z-1D/NAS395-17 (repl. D1274-8-1, A1758-10Z-1D/NAS395-24, A1784-6Z-1D/NAS395-6, A1785-6Z-1D/NAS395-7 (same as A1785-6Z1), A1786-8Z-1D/NAS395-12, A1787-8Z-1D/NAS395-18, A1787-10Z-1D/NAS395-22, A1789-8Z-1D/NAS395-16, D1274-8-1

TINNERMAN® Anchor Nuts: A06191-6Z-1D (repl. PN. A6191-6Z1D), A06191-8Z-1D (repl. PN. A6191-8Z1D), A06195-6Z-1D (repl. PN. A6195-6Z1D), A06195-8Z-1D (repl. PN. A6195-8Z1D)

TINNERMAN® SPEED NUTS® Flat Type Nuts of various screw sizes and finishes: #4A P.O (FN7-4A-PO), #6A P.O ( FN7-6A-PO), #8A P.O (FN7-8A-PO), #10A P.O (FN7-10A-PO), C8125-10-4  TINNERMAN Style Flat-Type Nut

For additional information please refer to the respective product presentations or contact us.

(*) TINNERMAN® is a registered trademark of A. RAYMOND & CIE. AVIATIONEU SUPPLIES & SERVICES DOES NOT manufacture these nuts. They are sourced from their respective suppliers.

Sourced from quality manufacturers, our own branded (AVIATIONEU NEA ERA) aviation (air crew) headsets are offered in two main families or series  (100 and 400) each with PNR and ANR models suited for use in fixed and rotary wing aircraft.

Two different plug types are offered, PJ-055/PJ-068 dual plugs widely used in General Aviation and other airplanes and Military grade U174 plug used on helicopters and military aircraft.

With their competitive prices, advanced design and features, quality materials and rigid construction, AVIATIONEU NEA ERA headsets combine performance, functionality and comfort to provide cost effective solutions for air crew communications.

ANR models (*) are offered with or without Bluetooth capability for music and mobile communications. All our headsets are accompanied by the Manufacturer and our Certificate of Conformance and come with a 12-months manufacturer warranty.

100 Series

AVIATIONEU NEA ERA 100 Series of aviation headsets includes PNR model 100 (GA) with dual plugs for airplanes and 100 (H) with U174 plug for military/helicopter operations. They feature  23dB and 24dB  noise reduction ratings respectively. 100 Series PNR headsets are Low cost, entry level headsets, ideal for General Aviation pilots and flight schools. Their ANR counterparts (Models 100A (GA) & 100A (H) are offered with a 29dB noise reduction rating and without or with Bluetooth capability, indicated by the letters "BT" in the product reference number (SKU). Pilots' style requirements are also covered through multiple colors, with Grey/Black (commonly stocked) and Green/Pink/Red/Yellow/Blue (On Demand as special order).

400C Series (Ultra Light Carbon Fiber Aviation Headsets)

Combining high performance, modern design, robust construction and an ultralight weight (only 9oz, 255g) the AVIATIONEU NEA ERA 400C series headsets are intended for use in air transport and military operations or by demanding pilots who seek high performance, functionality and confort headsets with an ultra light weight. Offered in carbon fiber black color. Various models include:

400C (GA) and 400C (H) PNR and 400AC (GA) and 400AC (H) ANR headsets offered with dual plugs and U174 single plug respectively and a noise reduction capability of 23dB (400C PNR) 29dB (400AC ANR).They come with or without Bluetooth capability.

AVIATIONEU NEA ERA 100 Series headsets are included in this listing while 400 Series headsets are separately listed. Please refer to the additional information and specifications provided or contact us.

(*) ANR function is powered by an AA battey in a supplied battery box with toggle switch. The headset will shut off automatically when unplugged from the battery box, manually turned off from the toggle switch or when the radio or avionics master switch is turned off.

Sourced from quality manufacturers, our own branded (AVIATIONEU NEA ERA) aviation (air crew) headsets are offered in two main families or series  (100 and 400) each with PNR and ANR models suited for use in fixed and rotary wing aircraft.

Two different plug types are offered, PJ-055/PJ-068 dual plugs widely used in General Aviation and other airplanes and Military grade U174 plug used on helicopters and military aircraft.

With their competitive prices, advanced design and features, quality materials and rigid construction, AVIATIONEU NEA ERA headsets combine performance, functionality and comfort to provide cost effective solutions for air crew communications.

ANR models (*) are offered with or without Bluetooth capability for music and mobile communications. All our headsets are accompanied by the Manufacturer and our Certificate of Conformance and come with a 12-months manufacturer warranty.

100 Series

AVIATIONEU NEA ERA 100 Series of aviation headsets includes PNR model 100 (GA) with dual plugs for airplanes and 100 (H) with U174 plug for military/helicopter operations. They feature  23dB and 24dB  noise reduction ratings respectively. 100 Series PNR headsets are Low cost, entry level headsets, ideal for General Aviation pilots and flight schools. Their ANR counterparts (Models 100A (GA) & 100A (H) are offered with a 29dB noise reduction rating and without or with Bluetooth capability, indicated by the letters "BT" in the product reference number (SKU). Pilots' style requirements are also covered through multiple colors, with Grey/Black (commonly stocked) and Green/Pink/Red/Yellow/Blue (On Demand as special order).

400C Series (Ultra Light Carbon Fiber Aviation Headsets)

Combining high performance, modern design, robust construction and an ultralight weight (only 9oz, 255g) the AVIATIONEU NEA ERA 400C series headsets are intended for use in air transport and military operations or by demanding pilots who seek high performance, functionality and confort headsets with an ultra light weight. Offered in carbon fiber black color. Various models include:

400C (GA) and 400C (H) PNR and 400AC (GA) and 400AC (H) ANR headsets offered with dual plugs and U174 single plug respectively and a noise reduction capability of 23dB (400C PNR) 29dB (400AC ANR).They come with or without Bluetooth capability.

AVIATIONEU NEA ERA 400 Series headsets are included in this listing while 100 Series headsets are separately listed. Please refer to the additional information and specifications provided or contact us.

(*) ANR function is powered by an AA battey in a supplied battery box with toggle switch. The headset will shut off automatically when unplugged from the battery box, manually turned off from the toggle switch or when the radio or avionics master switch is turned off.

AVIATIONEU NEW ERA product range of multigrade motor oils (indicated by the letter  "W") aim to ensure proper operation of the engine, wear and damage protection of different types of petrol, gas and diesel engines installed in passenger cars, vans and trucks. They contain a low-viscosity motor oil as well as various polymer additives. The additives have little effect at low temperatures, but cause the oil to thin down in hot conditions more slowly than usual.They come in different viscocity (SAE) grades to cover respective oil viscosity needs in different temperature ranges. In addition to SAE, AVIATIONEU NEW ERA motor oils  comply with American Petroleum Institute (API) service rating classification system of passenger car and commercial automotive motor oils. API rating certifies that an oil meets certain Original Equipment Manufacturer (OEM) quality and performance standards. Depending on their API classification, AVIATIONEU NEW ERA  motor oils aim to provide improved high temperature deposit protection for pistons, more stringent sludge control, and seal compatibility. Oils are offered in different packing options. Please contact us for additional information.

Note: Supplied information is provided for reference only. For the selection of the suitable motor oil please observe the manufacturer's instructions.

Different engine oils for aviation and military applications can be supplied either as OEM parts under their respective brands or as part of our own branded (AVIATIONEU NEW ERA) product lines. They are offered in different types, (e.g. mineral or synthetic oils) and they conform to different US Military and Aerospace specifications or Russian specifications. Those meeting US Military and Aerospace as well as Russian specifications or their analogues are offered as brands of their respective producers (such as AEROSHELL®, EXXONMOBIL®, NYCO, LUKOIL®, ROYCO®, and others). Several Piston and Turbine Engine oils (abbreviated as PEOs and TEOs respectively) and other lubricants complying with Russian specifications are also offered as part of our own labelled (AVIATIONEU NEW ERA) product portfolio serving as cost effective alternatives. They can be used in a variety of applications in general aviation as well as commercial (transport) and military aircraft of Russian manufacturers, such as Ilyushin Mikoyan, Irkut, Sukhoi, Tupolev and Yakovlev (now merged and operating under a new company, United Aircraft Corporation), and others. Sourced from various quality producers, AVIATIONEU NEW ERA engine lubricants are offered in different packaging options (*) in liters or kilograms, depending on the lubricant and the producer.  Due to our continuously expanding network of co-operating suppliers, and the respective range of offered products, certain products may not be currently listed in our Web Platform for Supplies. In this case please contact us for additional information and assistance. An overview of offered AVIATIONEU NEW ERA AVIATION ENGINE OILS is included in the Product Description section serving as a Quick Guide. For AVIATIONEU NEW ERA ENGINE HYDRAULIC FLUIDS & PRESERVATIVES and GREASES please refer to the respective separate product presentations.

(*) Depending on the lubricant and the producer, AVIATIONEU NEW ERA aviation lubricants are offered in cans, pails, flanks, drums or other containers with the following indicative capacities:

 0.9kg/1L, 3.6kg /4L, 4.5kg /5L, 9kg /10L, 15.3kg, 27kg /30L, 54kg /60L, 91kg /100L, 182kg /200L.

Bias and radial aircraft tires and matching tire tubes are offered as part of our own labelled (AVIATION NEW ERA) product lines for use in main and nose wheel applications in general aviation, commercial, military aircraft and other projects.

Sourced from co-operating quality manufacturers holding ISO and other certifications, the AVIATION NEW ERA tires are available in Tube or Tubeless types in different ply ratings, tread patterns and sizes to meet respective rated load and pressure requirements of intended applications. For tube type tires, matching tire inner tubes with different types of valves are also offered. The AVIATIONEU NEW ERA aircraft tires and inner tubes are intended as cost-effective alternate parts to the respective known brands.

They are approved for use on the respective aircraft in their country of origin and other countries where they are exported depending on signed bilateral agreements between the respective Civil Aviation Authority of the producer and the export country.

All AVIATION NEW ERA tires and inner tubes are supplied with our standard Certificate of Conformance. If other certification is required, please specify at order placement as additional cost may apply.

Please refer to additional information  in the Product Description section for a better understanding of their construction and characteristics, our brief product brochure on aircraft tires and tubes or contact us for additional information.

MIL-spec were initially developed to standardize wires and cables used in military equipment. For many years, wires used in aircraft met MIL-W-5086  mil-spec and SAE-AS50861 standards superseeding them. They were manufactured with the use of tin-coated copper conductors rated at 600 volts and temperatures of 105°C and various insulating coatings including polyvinyl chloride (PVC). The PVC insulation provided resistance to abrasion, among many other things. Still in production, MIL-W-5086  cables in their various types of conductors and jacket constructions are used, apart from the aircraft in other applications that require resistance to abrasion, cut-through, impact, chemicals, and fuels. They are gradually replaced by those made in accordance with Mil-W-22759 standard due to toxic fumes generated by PVC insulation in the event of a fire. The Mil-W-22759 standard transitioned to SAE AS22759 in 2004. These two standards are essentially identical and cover a of wide range of single conductor wires (please refer to the Product Description section and supplied documentation for assistance).

Sourced from quality producers, AS22759/M22759 wires are offered as part of our own labelled (AVIATIONEU NEW ERA) product lines in different configurations, various AWG(*) sizes, in white or other color variations (depending on their selected product reference number). They are suitable for use in a range of applications in military and civilian aircraft, in harsh aircraft engine environments, for control surfaces as well as applications in areas subject to severe weather and moisture-prone (SWAMP).

Those commonly used are SAE AS22759/16  unshielded wires (replacing wires produced as per M22759/16 /17/18 and /19  specifications) but other configurations can be available. This specification uses stranded tin plated copper or silver plated high strength alloy conductors and extruded ethylene/tetrafluorbethylene (ETFE) insulation. Respective wire ratings are 150° C and 600 Volts.

The AVIATIONEU NEW ERA AS22759/M22759 wires are sold in pre-determined lengths in feet indicated in the product reference number (SKU). They are commonly packed in carousels, reels or spools. Cut-to-order lengths in 10 ft increments are also offered. Accompanied by our Certificate of Conformance (CoC) free of charge or Manufacturer Certificate of Conformance (CoC) if required at additional charge. Some of the offered wires are additionaly QPL listed(**) as specified in their product title.

(*) American Wire Gauge (AWG): Wire gauge is a measurement of wire diameter. This determines the amount of electric current a wire can safely carry, as well as its electrical resistance and weight.

(**) Included in U.S. DoD Qualified Products List (QPL) of products, components, or materials, often used in aerospace or military applications, examined, pre-tested & found to conform with all applicable standards or qualification requirements set by a certifying organization or government entity.

Extending our present product range, our new AVIATION NEW ERA extruded aluminum alloy angles are offered in Metric (mm) dimensions and cut to oder lengths in meters to cover a wide range of application requirements.These angles are sourced mostly from Asian producers with a ISO9001:2008 quality management system and production process control while some are also holders of Approved Supplier Certificates from major aerospace companies. They comply, according to the selected angle,  with SAE AMS-QQ-A-200/3  (*) or ASTM B211M specifications (**).

Like the other AVIATION NEW ERA extruded aluminum profiles, these angles are offered in different aluminum alloys and tempers and are competitively priced to provide aviation quality but also economical solutions to our angles in inches produceed as per SAE AMS-QQ-A-200/3 specifications (**).

Aluminum Alloy Options: 2011,2014,2017,2024,5052,5083,5086,5454,5754,6061, 6063,6082,7003,7022,7050,7055,7075.

Temper Options: T3,T351,T4,T451,T5,T6,T651,T6511,T7351,H111,H114,O.

Wide range of dimensions (mm). Custom dimensions also possible with an additional mold charge

Cut To Order (CTO) Lengths (m). Range: 1000mm - 6000mm.

Standard sizes in stock for quick deliveries. Custom dimensions also possible with an additional mold charge

 Manufacturer Test Reports (MTRs) can be supplied at additional charge

Applications: widely used to contain, protect, reinforce and support various surfaces whether in ceramic, glass, plaster, plastic, stone, wood or other metals.

For more information please refer to the supplied documentation or contact us.

(*) AMS stands for Aerospace Material Specifications established by the SAE International (formerly, the Society of Automotive Engineers or SAE). AMS specifications are compiled in a comprehensive database of individual directives that standardize procedures, equipment and processes related to aerospace material processing. These are continuously updated and revised to stay up-to-date with advances in material science and processes technologies.

(**) ASTM International is a standards organization developing and publishing “voluntary consensus technical standards for a wide range of materials, products, systems, and services.”ASTM’s aerospace material standards are instrumental in evaluating materials, components, and devices primarily used in aerospace and aircraft industries.

Steel alloy 4130 (ST4130), also known as Chrome Moly after the 2 key elements of its composition, chromium, and molybdenum, is a general-purpose alloy steel widely used by the aviation and motorsports industries due to its weldability, fabrication, and mild hardenability in all offered forms (tubes, bars, sheets and plates). They are available in two different material states (Normalized and Annealed) depending on the process of how the material is heated and cooled.

The Normalized condition (sometimes referred to as "Condition N") is the harder and stronger condition and is best used when forming is not needed. Normalizing relieves internal stress on steel and improves toughness in steels that may harden after the cold working process. The Annealed condition (sometimes referred to as "Condition A") is the softer and formable condition and is best used when forming is needed. Annealing relieves internal stresses, softens and makes the material more ductile.

4130 alloy steel (Chrome Moly) seamless round tubes are offered as part of our own branded (AVIATIONEU NEW ERA) product lines in Normalized (N )  or Annealed (A) conditions indicated by the letters "NRZ" and  "ANL" respectively in the product reference code (SKU). They have been for years the standard of the aircraft industry. These tubes offer good strength and weldability without compromising steel abrasion or impact resistance and can also be made even stronger through heat treatment. They are commonly used in in structural applications, gears, fasteners, and aircraft exteriors. Tensile Strength: 90,000 PSI. Available in a range of outer diameters, wall thicknesses and pre-cut lengths in inches or cut to order (CTO) lengths of 12 inches (1 foot)) or multiples. Apperating price of CTO tubes is per foot (12 inches). Depending on the supplier, they comply with different standards/specifications, such as MIL-T6736 standard or ASTM/A S1906 specifications. Unless otherwise mentioned, there is additional cost if manufacturing test reports are required. For additional information, please refer to the supplied documentation or contact us.

Anchor nuts (aka nutplates or anchor plates) are terms used interchangeably and relate to stamped sheet metal fasteners with an internally threaded tube and a plate with two clearance holes for rivets. They are used in blind mounted panel applications in aerospace and other industrial sectors where hex nuts cannot be used or an attached nut is required for ease of maintenance.

Anchor nuts can be Fixed or Floating, the latter being easier to use due to their built-in nut (threaded hole) able to "float" slightly thus providing a convenient connection point for threaded rods, such as bolts, from the backside. In the case of Fixed anchor nuts, the built-in nut is static (i.e. without the capability to “float”) and the threaded rod must be positioned perfectly over the hole. Self-locking anchor nuts are those with a built-in locking mechanism preventing them from loosening over time from vibrations. They are extensively used in aerospace, automotive, and construction industries.

Depending on their intended application, nutplates conform to different military, aerospace, ISO or other industrial standards such as the German DIN, U.S. (ASME & ASTM, IFI, ANSI), British BS, Japanese JIS and others. They are offered as OEM parts under their respective brands or under our own labelled (AVIATIONEU NEW ERA) product lines intended as cost-effective alternatives to the respective OEM products. Listed in accordance with their standard of compliance, Fixed and Floating nutplates come in different materials (such as steel or CRES & finishes),  in single/double lug configurations and Metric ISO οr Unified thread sizes. There is currently no U.S. Military Standard (MS) specification for Metric nutplates. Depending on the selected product and availability, nutplates can be supplied with a dry film lube specified by the letter "L" in the respective part number. Those with countersunk rivet holes are specified by the letter "K" at the end of the part number.

Sourced from quality manufacturers, AVIATIONEU NEW ERA MS21078 series nutplates are fixed self-locking, two-lug nutplates with elastic insert and plain rivet holes.  Made from cadmium plated steel they are available in different Unified thread sizes and replace respective AN366F series nutplates.  Sold in pieces but also in packs where the specified number of nuts per pack is indicated after the letters "PK" in the product reference number (SKU). Appearing prices are always for the units of measurement used each time. Matching rivets are sold separately.

For additional information please refer to the supplied documentation or contact us.

Countersinking is used to ensure that flat head screws or fasteners sit flush against the workpiece. Countersinks used in aerospace and industrial applications are made of durable materials such as High Speed Steel (HSS) known for its hardness, toughness, and ability to withstand high temperatures. High Speed Steel (HSS) countersinks are well suited for cutting aluminum sheet metals. When combined with Cobalt, an alloying agent in steels to improve the hardenability, strength, and wear resistance in machining applications but also due to its ability to resist wear at higher temperatures, the  respective countersinks are often used for cutting stainless steel and other aluminum alloys.

Sourced from quality suppliers, integral (fixed) pilot Microstop countersink cutters are offered as part of our own labeled (AVIATIONEU NEW ERA) product lines. Made from HSS or HSS Steel with Cobalt, they consist ideal tools for aircraft manufacturers, aircraft maintenance/ repair stations or  industrial manufacturers for precise and accurate countersinking, cost-effective alternatives to other OEM products and and stocked by our suppliers for fast deliveries.

Offered in different flutes, body and pilot diameters and sold  either separately (*) or in custom sets to address specific customer needs in machining applications.

Because of the difference in composition between HSS and Cobalt, main strengths of HSS countersinks are their high hardness and wear resistance. Therefore, as a general rule, they consist a better choice when you want your countersinks to retain their strength even when exposed to extreme wear or abuse. For higher hardenability, strength, and wear resistance and in applications when when countersinks are to be exposed to extremely high temperatures, cobalt countersinks should best be used.

AVIATIONEU NEW ERA countersinks can be used with popular adjustable or Microstop countersinking units utilizing a threaded shank drive (sold separately). For additional information please consult the supplied documentation or contact us.

(*) Minimum Order Quantities apply depending on the selected countersinks or their sets.

High-Speed Steel (HSS) is a metal alloy made up primarily of iron, tungsten, and carbon. It's known for its hardness, toughness, and ability to withstand high temperatures without losing its strength or shape. It also has excellent abrasion resistance properties, which make it useful for cutting tools. HSS drill bits are extremely hardwearing and particularly well designed for drilling into relatively hard metal surfaces and wood, as they are much more resistant to the heat generated from the fast speed operation. The front edges cut the material, whilst the spirals remove debris from the hole. Apart from HSS, Cobalt is often used as an alloying agent in steels to improve the hardenability, strength, and wear resistance in machining applications but also due to its ability to resist wear at higher temperatures while still maintaining its strength and shape. Cobalt-based alloys are typically harder than HSS alloys but are also more prone to cracking or chipping if not handled properly. Compared to HSS drill bits which are more elastic and, as such, don't break easily, those containing cobalt are more brittle and chip quickly.

Sourced from quality suppliers, threaded hex shank drill bits are offered as part of our own labeled (AVIATIONEU NEW ERA) product lines. Made from HSS or HSS Steel with Cobalt, these drill bits consist ideal tools for aircraft manufacturers, aircraft maintenance/repair stations or  industrial manufacturers, cost-effective alternatives to other OEM products and and stocked by our suppliers for fast deliveries. Offered in different types (stub, short or long), flute and overall lengths they are sold either separately (*) or in custom sets to address specific customer needs in machining applications.

Because of the difference in composition between HSS and Cobalt, main strengths of HSS drill bits are their high hardness and wear resistance. Therefore, as a general rule, they consist a better choice when you want your drill bits to retain their strength even when exposed to extreme wear or abuse. For higher hardenability, strength, and wear resistance and in applications when when drill bits are to be exposed to extremely high temperatures, cobalt drill bits should best be used.

For additional information please consult the supplied documentation or contact us.

(*) Minimum Order Quantities apply depending on the selected drill bits or their sets.

Sourced from quality producers, the MIL-DTL-27500 shielded electical cables are offered as part of our own label (AVIATIONEU NEW ERA) product lines consisting cost-effective alternatives to the respective OEM products. Depending on the producer and specification, MS27500 cables come with stranded copper single or mltiple conductors (cores), nickel, silver or tin-plated and individually insulated, different number of strands, different chemically inert fluoropolymer insulation materials with good ozone and oxidation resistance as well as single or double shields. Their jackets are made of fluoropolymer, PTFE, glass, or polyamide tape.

The MIL-DTL-27500 shielded cables are used in a range of applications including avionics, military and civilian aerospace and airframe applications and ground support equipment and they are rated to a maximum voltage of 600 volts and maximum usable temperatures from 150 °C to 260 °C.

The AVIATIONEU NEW ERA MIL-DTL-27500 cables are offered in different configurations with single or multiple individually insulated conductors (cores) in various AWG sizes, insulation materials and shields to meet application requirements. Those commonly used include components listed below but other configurations can be available. For additional information on M27500 cables, please see our brief presenation in the Product Description section.

- Stranded tin-plated cooper single or multiple-conductor(s) (aka cores) comforming with MIL-W-22759/18 specification,

- Tefzel™(**) ETFE (ethylene-tetrafluoroethylene resin) insulation on each conductor

- tin- plated copper braided shield

- Tefzel™(**) ETFE jacket

The AVIATIONEU NEW ERA MIL-DTL-27500 cables are available in cut-to-order or pre-determined lengths in feet indicated in the product reference number (SKU) and packaged in rolls or spools. They are accompanied by our Certificate of Conformance (CoC). Due to their large variety of these cables, listed products shall continuously increase. If wanted cables cannot by found, please contact us.

(*) American Wire Gauge (AWG): Wire gauge is a measurement of wire diameter. This determines the amount of electric current a wire can safely carry, as well as its electrical resistance and weight.

(**) Tefzel™ and Teflon™ are registered trademarks of the DuPont Corporation.

The AVIATIONEU NEW ERA silicone insulated waterproof cables are available in different numbers of solid or stranded tinned copper conductors and AWG sizes (*) with silicon insulation jacket. Suitable for AC rated voltage 450/750V and all kinds of high temperature environment such as mobile motor, steel, aviation, power plant, petrochemical, etc. They feature a strong resistance to acids & alkali, oils, moisture and they are easy to peel and cut. They pass pass the UL VW - 1 and CSA FT1 flammability tests. Nominal Temperature : 200℃. Nominal voltage : 300/500V. Sold in rolls of 100 meters each, in increments of one roll and with a Minimum Order Quantity (MOQ) 3 rolls. Appearing price is for reference only. Contact us for a quotation.

(*) Wire gauge is a measurement of wire diameter. This determines the amount of electric current a wire can safely carry, as well as its electrical resistance and weight.

Aircraft braking systems serve a vital function during takeoff, landing and taxiing. Along with landing gear, aircraft wheels and brakes are critical to ensure safe and reliable aircraft ground operations under extreme forces, stress, as well as wear and tear from general operation and the environment. Commercial aircraft brakes are arranged in multiple disk pairs commonly referred to as Heat Sinks or Heat Packs (as they convert the kinetic energy of the moving airplane to heat energy). Initially made metal (steel) heat sinks are gradually replaced by those from carbon fibres (particularly on larger, long-haul commercial airplanes) due to their higher efficiency in braking applications, longer life-span, lower weight and resulting less fuel consumption and lower CO2 emission by the engines.

Carbon and steel heat packs and parts are offered as part of our own labelled (AVIATIONEU NEW ERA) product lines. Sourced from quality suppliers these heat packs  feature high quality, safety, improved design, significant cost savings and fast deliveries. They can be used as  cost effective alternatives in many commercial aircraft platforms equalling or exceeding standards of  respective OEM products by leading manufacturers such as Honeywell Aerospace, Collins Aerospace/Goodrich Wheels & Brakes, Parker Meggitt Aircraft Braking Systems and Safran Landing Systems (formerly Messier-Bugatti-Dowty). They are  PMA approved (*) parts by the Civil Aviation Administration of China (CAAC) for use on an extensive list of Western and Eastern commercial (civil ) aircraft platforms including Boeing, Airbus, McDonnell Douglas, Ilyushin and others and are currently installed in aircraft operating by different air transport operators in China and other countries in the Middle-East, South and Central Asia and Africa.

Typical Aircraft Applications for steel and carbon heat packs include Boeing 737 / 757, Airbus A318 / A319 / A320 / A330 , McDonnell Douglas: MD82 /MD90  Xian MA60 etc.

(*)  Parts Manufacturer Approval (PMA) is a combined design and production approval granted by a competent Civil Aviation Authority (CAA) to a manufacturer of aircraft parts for modification and replacement. Use of Civil Aviation Administration of China (CAAC) approved parts in other countries depends on existing bilateral agreements between CAAC and respective competent authorities in these countries.

For additional information please contact us.

Thermal fluids (aka thermal oils, thermic fluids, thermo fluids, heat transfer fluids, heat transfer oils, hot oils, thermic oils or thermo oils.) are specialized liquids used to transfer heat from one point to another in various industrial processes, including chemical processing, oil and gas refining, and power generation. Designed to operate at high temperatures they can provide efficient and reliable heat transfer, even under extreme conditions. Selecting the right transfer fluid depends on its thermal properties, which include its viscosity, heat capacity, the heating system it’s used in, and the application itself.  When dealing with complex applications that may have multiple heat transfer options and therefore specific calculations may be required. Factors such as the temperature and pressure requirements of the application, combined with the thermal properties of a fluid and the limitations of the heater need to be considered. There are different types of thermal fluids including water, glycol, organic (derived from petroleum) and synthetic (produced from advanced chemical processes) offered under respective brands of their producers such as Eastman (Therminol®/Marlotherm®), Dow Chemical (Dowtherm™), ExxonMobil (Mobiltherm™), and others.

Key properties of heat transfer fluids include thermal stability, low viscosity, high flash and fire points, and low toxicity helping to ensure safe and reliable operation of heat transfer systems. Their selection depends on various factors, including the operating temperature range, heat transfer efficiency requirements, system design, and safety considerations.

Sourced from quality producers, thermal fluids are offered as part of our own labelled (AVIATIONEU NEW ERA) product lines in different grades and packaging options including 210-Liter drums and 26-Liter pails. Based on different blends, AVIATIONEU NEW ERA heat transfer fluids can be used for heating and cooling processes in a variety of industrial applications resulting in economy, efficient operations, minimum maintenance, and precise temperature control.  Indicative industries of their application include: hydrocarbon processing (oil and gas, natural gas, refining, etc.), plastics processing, chemical processing, pharmaceuticals, food & beverage processing, renewable energies and many others. They exhibit similar characteristics, equivalent performance and consist cost effective alternatives to respective competitive brands. Depending on the selected product, they exhibit features and benefits outlined below:

Wide temperature operating ranges

Extended service life

Exceptional thermo-oxidative stability

Fast heat transfers

Excellent compatiblity

Low volatility

Cost savings

Appearing prices are per liter or kilogram depending on the product.

For additional information please refer to the Product Description section or contact us.

The NAS1581 Series screws  (also termed as bolts) are high strength, close tolerance, reduced (shear) head, countersunk screws offered as part of our own branded (AVIATIONEU NEW ERA) product lines. They come in different materials and finishes designated by the following letters in their product reference number (SKU) which is formed as a combination of the material, diameter, drive style, grip length and option of the screw:

Materials

(A) or (F) = Alloy Steel, 4140,4340 or 8740, Heat treated to 160-180ksi. Cad 2 plated. Material Code (A) has been superseded by Code (F)

(C) = Corrosion Resistant (A286) Steel, Heat treated to160-190ksi. Cad 2 (optional)

(V) = Titanium (6al-4v) Heat treated to 160-180ksi. No finish. Material Code (V) has been cancelled Dec.1991

Diameters: Numbers 3 to 10

Drive Styles

(R)= Offset Cruciform, (Torq-set) R, for diameters 3,4 & 5.

(T) = Offset Cruciform, (Torq-set) R for diameters 6 and up.

(H) = Dovetail Slot

Grip Lengths

The grip length  for Countersunk Head Fasteners (T in the supplied table) includes the head and extends to the full cylindrical portion of the shank. The Grip Length for NAS1581 Series screws is measured in 1/16ths of an inch. + or - .010

AVIATIONEU NEW ERA NAS1581 Series screws are offered in pieces or kits for convenience and economy.

For more information, please refer to the supplied documentation or contact us.

RG 400 (aka M17/128*) cables are high temperature coaxial cables used in a wide variety of military and commercial applications.

Sourced from quality suppliers, these cables are offered as part of our own label (AVIATIONEU NEW ERA) product lines and are intended for use in tactical operations and aerospace applications. They are are double shielded and made from dielectric PTFE (Polytetrafluoroethylene) material and fluorinated ethylene propylene (FEP) Type IX sheath with a solid copper stranded wire silver-plated conductor. They feature an impedance of 50 +/-2 ohms and an operating temperature range -55 °C ... +200 °C. They are priced and sold in feet. They come with Certificate of Conformance (CoC) and test reports. For additional information please refer to the supplied documentation

(*) M17/128 is a military part number used as equivalent to the RG400 cable. The the specifications and testing of military coaxial cables, including RG400, are very rigorous requiring their manufacturers to test attenuation and structural return loss by sweeping 22 different 50-ohm cables over the frequency band for which their use is recommended.

AN hex head bolts in different series are offered under AVIATIONEU NEW ERA product series. Sourced from quality vendors, these bolts are manufactured to the US Army-Navy (AN) standard, predecessor to Mil-Spec (MS), superseded by the National Aerospace Standard (NAS). Commonly used in aviation for either tensile/shear load applications. Made from high-strength type 4037 or 8740 alloy steel or 431 Stainless Steel (CRES) and cadmium plated for superior corrosion resistance (compared to commercial grade zinc plated bolts) they are offered with shank drilled for cotter pin or undrilled for stop nut application, and with a drilled head for safety wire or without. Minimum Tensile Strength (Steel and CRES) - 125,000psi. The length of AN aircraft bolts is measured from under the head to the end of the shank. The "grip" is the unthreaded portion of the shank. Threads are pressed into the steel, not cut, thus maintaining strength throughout the entire shank. The surface under the head of AN bolts is designed to be a bearing surface to reduce non-uniform stress as the bolt is torqued thus reducing premature fatigue. The following letters are used in the product part  numbers.

"A" after the dash number for bolts with undrilled shank

"C"  for bolts made of 431 Stainless Steel (CRES)

"H" after the AN number for bolts with drilled head (eg. AN3H-15)

 AN3 through AN20 Series bolts are superseded by NASM3 through 20 Series. The part numbers in both series have not been changed.

Specification Details:

AN3 through AN20 (REV. 12), Military Specification Sheet: Bolt -Machine, Aircraft [superseded by NASM3 through 20]. This specification covers aircraft machine bolts part numbers, AN3, AN4, AN5, AN6, AN7, AN8, AN9, AN10, AN14, AN16, AN17, AN18, and AN20. AN3 THRU AN20  is canceled and superseded by NASM3 THRU NASM20. The Part Identification Number (PIN) for AN3 THRU AN20 REV. 12 and the part number for NASM3 THRU NASM20 are identical. The part numbers have not been changed.

AN hex head bolts in different series are offered under AVIATIONEU NEW ERA product series. Sourced from quality vendors, these bolts are manufactured to the US Army-Navy (AN) standard, predecessor to Mil-Spec (MS), superseded by the National Aerospace Standard (NAS). Commonly used in aviation for either tensile/shear load applications. Made from high-strength type 4037 or 8740 alloy steel or 431 Stainless Steel (CRES) and cadmium plated for superior corrosion resistance (compared to commercial grade zinc plated bolts) they are offered with shank drilled for cotter pin or undrilled for stop nut application, and with a drilled head for safety wire or without. Minimum Tensile Strength (Steel and CRES) - 125,000psi. The length of AN aircraft bolts is measured from under the head to the end of the shank. The "grip" is the unthreaded portion of the shank. Threads are pressed into the steel, not cut, thus maintaining strength throughout the entire shank. The surface under the head of AN bolts is designed to be a bearing surface to reduce non-uniform stress as the bolt is torqued thus reducing premature fatigue. The following letters are used in the product part  numbers.

"A" after the dash number for bolts with undrilled shank

"C"  for bolts made of 431 Stainless Steel (CRES)

"H" after the AN number for bolts with drilled head (eg. AN4H-15)

 AN3 through AN20 Series bolts are superseded by NASM3 through 20 Series. The part numbers in both series have not been changed.

Specification Details:

AN3 through AN20 (REV. 12), Military Specification Sheet: Bolt -Machine, Aircraft [superseded by NASM3 through 20]. This specification covers aircraft machine bolts part numbers, AN3, AN4, AN5, AN6, AN7, AN8, AN9, AN10, AN14, AN16, AN17, AN18, and AN20. AN3 THRU AN20  is canceled and superseded by NASM3 THRU NASM20. The Part Identification Number (PIN) for AN3 THRU AN20 REV. 12 and the part number for NASM3 THRU NASM20 are identical. The part numbers have not been changed.

AN hex head bolts in different series are offered under AVIATIONEU NEW ERA product series. Sourced from quality vendors, these bolts are manufactured to the US Army-Navy (AN) standard, predecessor to Mil-Spec (MS), superseded by the National Aerospace Standard (NAS). Commonly used in aviation for either tensile/shear load applications. Made from high-strength type 4037 or 8740 alloy steel or 431 Stainless Steel (CRES) and cadmium plated for superior corrosion resistance (compared to commercial grade zinc plated bolts) they are offered with shank drilled for cotter pin or undrilled for stop nut application, and with a drilled head for safety wire or without. Minimum Tensile Strength (Steel and CRES) - 125,000psi. The length of AN aircraft bolts is measured from under the head to the end of the shank. The "grip" is the unthreaded portion of the shank. Threads are pressed into the steel, not cut, thus maintaining strength throughout the entire shank. The surface under the head of AN bolts is designed to be a bearing surface to reduce non-uniform stress as the bolt is torqued thus reducing premature fatigue. The following letters are used in the product part  numbers.

"A" after the dash number for bolts with undrilled shank

"C"  for bolts made of 431 Stainless Steel (CRES)

"H" after the AN number for bolts with drilled head (eg. AN5H-15)

 AN3 through AN20 Series bolts are superseded by NASM3 through 20 Series. The part numbers in both series have not been changed.

Specification Details:

AN3 through AN20 (REV. 12), Military Specification Sheet: Bolt -Machine, Aircraft [superseded by NASM3 through 20]. This specification covers aircraft machine bolts part numbers, AN3, AN4, AN5, AN6, AN7, AN8, AN9, AN10, AN14, AN16, AN17, AN18, and AN20. AN3 THRU AN20  is canceled and superseded by NASM3 THRU NASM20. The Part Identification Number (PIN) for AN3 THRU AN20 REV. 12 and the part number for NASM3 THRU NASM20 are identical. The part numbers have not been changed.

AN hex head bolts in different series are offered under AVIATIONEU NEW ERA product series. Sourced from quality vendors, these bolts are manufactured to the US Army-Navy (AN) standard, predecessor to Mil-Spec (MS), superseded by the National Aerospace Standard (NAS). Commonly used in aviation for either tensile/shear load applications. Made from high-strength type 4037 or 8740 alloy steel or 431 Stainless Steel (CRES) and cadmium plated for superior corrosion resistance (compared to commercial grade zinc plated bolts) they are offered with shank drilled for cotter pin or undrilled for stop nut application, and with a drilled head for safety wire or without. Minimum Tensile Strength (Steel and CRES) - 125,000psi. The length of AN aircraft bolts is measured from under the head to the end of the shank. The "grip" is the unthreaded portion of the shank. Threads are pressed into the steel, not cut, thus maintaining strength throughout the entire shank. The surface under the head of AN bolts is designed to be a bearing surface to reduce non-uniform stress as the bolt is torqued thus reducing premature fatigue. The following letters are used in the product part  numbers.

"A" after the dash number for bolts with undrilled shank

"C"  for bolts made of 431 Stainless Steel (CRES)

"H" after the AN number for bolts with drilled head (eg. AN6H-15)

 AN3 through AN20 Series bolts are superseded by NASM3 through 20 Series. The part numbers in both series have not been changed.

Specification Details:

AN3 through AN20 (REV. 12), Military Specification Sheet: Bolt -Machine, Aircraft [superseded by NASM3 through 20]. This specification covers aircraft machine bolts part numbers, AN3, AN4, AN5, AN6, AN7, AN8, AN9, AN10, AN14, AN16, AN17, AN18, and AN20. AN3 THRU AN20  is canceled and superseded by NASM3 THRU NASM20. The Part Identification Number (PIN) for AN3 THRU AN20 REV. 12 and the part number for NASM3 THRU NASM20 are identical. The part numbers have not been changed.

AN hex head bolts in different series are offered under AVIATIONEU NEW ERA product series. Sourced from quality vendors, these bolts are manufactured to the US Army-Navy (AN) standard, predecessor to Mil-Spec (MS), superseded by the National Aerospace Standard (NAS). Commonly used in aviation for either tensile/shear load applications. Made from high-strength type 4037 or 8740 alloy steel or 431 Stainless Steel (CRES) and cadmium plated for superior corrosion resistance (compared to commercial grade zinc plated bolts) they are offered with shank drilled for cotter pin or undrilled for stop nut application, and with a drilled head for safety wire or without. Minimum Tensile Strength (Steel and CRES) - 125,000psi. The length of AN aircraft bolts is measured from under the head to the end of the shank. The "grip" is the unthreaded portion of the shank. Threads are pressed into the steel, not cut, thus maintaining strength throughout the entire shank. The surface under the head of AN bolts is designed to be a bearing surface to reduce non-uniform stress as the bolt is torqued thus reducing premature fatigue. The following letters are used in the product part  numbers.

"A" after the dash number for bolts with undrilled shank

"C"  for bolts made of 431 Stainless Steel (CRES)

"H" after the AN number for bolts with drilled head (eg. AN8H-15)

 AN3 through AN20 Series bolts are superseded by NASM3 through 20 Series. The part numbers in both series have not been changed.

Specification Details:

AN3 through AN20 (REV. 12), Military Specification Sheet: Bolt -Machine, Aircraft [superseded by NASM3 through 20]. This specification covers aircraft machine bolts part numbers, AN3, AN4, AN5, AN6, AN7, AN8, AN9, AN10, AN14, AN16, AN17, AN18, and AN20. AN3 THRU AN20  is canceled and superseded by NASM3 THRU NASM20. The Part Identification Number (PIN) for AN3 THRU AN20 REV. 12 and the part number for NASM3 THRU NASM20 are identical. The part numbers have not been changed.

Solid shank rivets are relatively low-cost,  permanently installed fasteners used as structural parts in aircraft and other applications where reliability and safety consist a priority.  These rivets are produced in accordance with military and other international standards such as US Army-Navy (AN) standard and Mil-Spec (MS) that followed. AN426/MS20426 and AN470/MS20470 Series rivets are solid aluminum rivets with countersunk head or universal head respectively. Sourced from quality suppliers they are offered as part of our own labelled (AVIATIONEU NEW ERA) product lines. They are  available in different diameters and lengths and sold by the pound (lb). Those designated by the letter "A" in their part numbers are "soft" rivets fabricated from 1100-grade aluminum with a tensile strength of 16,000 PSI while rivets designated by the letters "AD" are fabricated from 2117 aluminum and heat treated to the T4 condition. They have a shear strength of 26,000 PSI and a tensile strength of 38,000 PSI. For additional information please refer to the article on an overview of our fasteners, other supplied documentation, the individual product presentations or contact us.

Solid shank rivets are relatively low-cost,  permanently installed fasteners used as structural parts in aircraft and other applications where reliability and safety consist a priority.  These rivets are produced in accordance with military and other international standards such as US Army-Navy (AN) standard and Mil-Spec (MS) that followed. AN426/MS20426 and AN470/MS20470 Series rivets are solid aluminum rivets with countersunk head or universal head respectively. Sourced from quality suppliers they are offered as part of our own labelled (AVIATIONEU NEW ERA) product lines. They are  available in different diameters and lengths and sold by the pound (lb). Those designated by the letter "A" in their part numbers are "soft" rivets fabricated from 1100-grade aluminum with a tensile strength of 16,000 PSI while rivets designated by the letters "AD" are fabricated from 2117 aluminum and heat treated to the T4 condition. They have a shear strength of 26,000 PSI and a tensile strength of 38,000 PSI. For additional information please refer to the article on an overview of our fasteners, other supplied documentation, the individual product presentations or contact us.

Structural screws are made of alloy steel, are properly heat treated, and can be used as structural bolts. Those commonly used in aircraft applications are manufactured to aerospace/military standards/specifications. They are offered as part of our own branded (AVIATIONEU NEW ERA) product lines structured in different series based on the standard of their conformance. Some of the screws commonly used include NAS204 through NAS235 and AN509/AN525 series.

AN525/AN525R Series high-strength structural washer head (AN525) and cross-recessed (Phillips) head (AN525R) screws, fabricated from alloy steel per specification QQ-S-689. Tensile strength 125,000 PSI. Cadmium plated per QQ-P-416A, Type II, Class 3.

The AN525 washer head structural screws provide a large contact area. The AN509R (100° countersunk) Phillips head screws are used in countersunk holes where a flush surface is necessary. These have been replaced by MS24694 Series structural screws of the respective materials and finishes.

Structural screws have a definite grip and the same shear strength as a bolt of the same size. Shank tolerances are similar to AN hex head bolts, and the threads are National Fine. Structural screws are available with round, brazier, or countersunk heads. The recessed head screws are driven by either a Phillips or a Reed and Prince screwdriver. Sourced from quality suppliers, these structural screws are offered as part of our own labelled (AVIATIONEU NEW ERA) product lines in different thread sizes and lengths in inches and sold in pieces. For more information, please refer to the individual product presentations, the supplied documentation or contact us.

Machine screws are one of the more widely used products among dozens of standard fastener types. They can be either coarse-threaded or fine-threaded, and are usually available with a wide range of head types. Usually stronger than many other screw types, they are used for fastening metal parts and panels securely together in a range of construction and other applications including aerospace, machinery, vehicles, engines, tool assemblies, electronic devices, and large-scale industrial equipment.

Sourced from quality producers,  machine screws are offered as part of our own labelled (AVIATIONEU NEW ERA) product lines conforming to aerospace/military or industrial standards/specifications.  They come in different sizes, head types, materials and thread gradings.

AVIATIONEU NEW ERA AN526 series screws are mil spec truss-head non-structural machine screws made of carbon steel and cadmium plated. Minimum tensile strength 55,000 psi. Available in slot head or Phillips recessed head indicated by the letter "R" in the product part number. They are available in different sizes and lengths in inches and sold in packs. The number of screws per package is indicated after the letters "PK" in the product reference number (SKU). For more information, please refer to the individual product presentations, the supplied documentation or contact us.

Tapping screws eliminate the need for drilled holes, as they are designed to cut their own hole as it is screwed into the materials. They are commonly used  in cases when the material is too thin (e.g. sheet metals), there is no rear access for installation of  a nut or when disassembly is required at a later stage and therefore blind rivets can not be an alternative. Sourced from quality producers, tapping screws are offered as part of our own labelled (AVIATIONEU NEW ERA) product lines conforming to aerospace/military or industrial standards/specifications.

AVIATIONEU NEW ERA AN530 series screws are mil spec tapping screws offered in different sizes and sold in packs. Those with a Philips recessed head are indicated by the letter "R" in the product part number. Tapping screws conforming to ASME specifications are also available as part of AVIATIONEU NEW ERA product portfolio (see separate product presentation). The number of screws per package is indicated after the letters "PK" in the product reference number (SKU). For more information, please refer to the individual product presentations, the supplied documentation or contact us.

Machine screws are one of the more widely used products among dozens of standard fastener types. They can be either coarse-threaded or fine-threaded, and are usually available with a wide range of head types. Usually stronger than many other screw types, they are used for fastening metal parts and panels securely together in a range of construction and other applications including aerospace, machinery, vehicles, engines, tool assemblies, electronic devices, and large-scale industrial equipment.

Sourced from quality producers,  machine screws are offered as part of our own labelled (AVIATIONEU NEW ERA) product lines conforming to aerospace/military or industrial standards/specifications.  They come in different sizes, head types, materials and thread gradings. Countersunk screws allow the head of the screw to sit flush with or below the surface of the surrounding material. They may also be used to remove the burr left from a drilling or tapping operation thereby improving the finish of the product and removing any hazardous sharp edges.

AVIATIONEU NEW ERA AN507 series screws are mil spec threaded 100 degree countersunk non structural screws with Phillips head. They have been replaced by the respective screws of MS24693 series of materials and finishes. These screws are made of carbon steel and cadmium plated, stainless steel unplated or brass with chemical black finish. They are sold in pieces and offered in different sizes in the following materials and finishes with the corresponding notations after MS24693 and before the size number:

Carbon Steel Cadmium plated (letter "S")

300 Series Stainless Steel unplated (letter "C")

Brass with chemical black finish, (letter "BB")

For more information, please refer to the individual product presentations, the supplied documentation or contact us.

AN316/NASM316 Series hexagonal steel cadmium plated  thin non-locking check nuts are Military Specification versions of non-locking jam nuts used typically to lock in adjustments where a male threaded part screws only partway into a female threaded part (rod ends, grub screws, bulkhead fittings, etc). AN316/NASM316 Series jam nuts are thinner than the AN315 specification nuts for use in tighter installations but the AN316/NASM316 hex check nuts can carry half the tension load of the AN315 nuts.

Sourced from quality producers, the AN316/NASM316 Series check nuts are offered as part of AVIATIONEU NEW ERA product lines in steel cadmium plated or corrosion resistant steel (CRES) passivated (indicated by the letter "C" replacing the dash number) in different thicknesses and thread sizes in inches.  Letters "R" and "L" after the dash number indicate a Right or Left Hand thread respectively. For additional information please consult the supplied documentation or contact us.

Certification Details:

AN316 (REV. 11)., AIR FORCE-NAVY AERONAUTICAL STANDARD: Nut, Jam, Hexagon (25 Feb 1991). Superseded by NASM316. The Part Identification Number (PIN) for AN316 and the part number for NASM316 are identical. The part numbers have not been changed.

AN315/NASM315 Series hex plain nuts are manufactured from steel and cadmium plated per QQ-P-416A, Type II, Class 3, corrosion resistance steel or aluminum alloys. The AN315 nuts have been superseded by NASM315 Series. Similar to common nuts  but with a rugged construction they are designed and built with aviation grade materials and to specific aviation design specifications. They can carry the same high tension load as the AN310 castle nuts and require an auxiliary locking device such as a check nut or lock washer.

Sourced from quality producers, the AN315/NASM315 Series hex plain nuts are offered as part of AVIATIONEU NEW ERA product lines in different thicknesses and thread sizes in inches. The following letters are used to designate specific types of airframe nuts:

"C" before dash number for corrosion resistance steel nuts

"D" before dash number for aluminum-alloy nuts

"L" after dash number for left-hand thread

"R" after dash number for right-hand thread

For additional information please consult the supplied documentation or contact us.

Certification Details:

AN315 (REV. 10) (NOTICE 2)., AIR FORCE-NAVY AERONAUTICAL STANDARD: Nut, Plain, Castellated, Airframe (23 SEP 2002) [S/S BY NASM315]., AN315 REV. 10, dated 29 DECEMBER 1972, is hereby canceled and superseded by NASM315. The Part Identification Number (PIN) for AN315 REV. 10 and the part number for NASM315 are identical. The part numbers have not been changed.

AN hex head bolts in different series are offered under AVIATIONEU NEW ERA product series. Sourced from quality vendors, these bolts are manufactured to the US Army-Navy (AN) standard, predecessor to Mil-Spec (MS), superseded by the National Aerospace Standard (NAS). Commonly used in aviation for either tensile/shear load applications. Made from high-strength type 4037 or 8740 alloy steel or 431 Stainless Steel (CRES) and cadmium plated for superior corrosion resistance (compared to commercial grade zinc plated bolts) they are offered with shank drilled for cotter pin or undrilled for stop nut application, and with a drilled head for safety wire or without. Minimum Tensile Strength (Steel and CRES) - 125,000psi. The length of AN aircraft bolts is measured from under the head to the end of the shank. The "grip" is the unthreaded portion of the shank. Threads are pressed into the steel, not cut, thus maintaining strength throughout the entire shank. The surface under the head of AN bolts is designed to be a bearing surface to reduce non-uniform stress as the bolt is torqued thus reducing premature fatigue.  AN3 through AN20 Series bolts are superseded by NASM3 through 20 Series. The part numbers in both series have not been changed. The following letters are used in the product part  numbers.

"A" after the dash number for bolts with undrilled shank

"C"  for bolts made of 431 Stainless Steel (CRES)

"H" after the AN number for bolts with drilled head (eg. AN10H-15)

AN10 bolts have a 5/8-18 thread with a 5/8" shank diameter. All AN10 bolts have a 0.955 thread length regardless of grip length. They can be torqued  to 92-108 lb-ft with AN365 or AN310 full-height nuts, or 50-65 lb-ft with AN364 or MS21042 half-height nuts. Indicated lengths are UHL: Under Head Length (aka Full Shank Length or Overall Length not including bolt head).

Anchor nuts can be Fixed or Floating, the latter being easier to use due to their built-in nut (threaded hole) able to "float" slightly thus providing a convenient connection point for threaded rods, such as bolts, from the backside. In the case of Fixed anchor nuts, the built-in nut is static (i.e. without the capability to “float”) and the threaded rod must be positioned perfectly over the hole. Self-locking anchor nuts are those with a built-in locking mechanism preventing them from loosening over time from vibrations. They are extensively used in aerospace, automotive, and construction industries.

Depending on their intended application, nutplates conform to different military, aerospace, ISO or other industrial standards such as the German DIN, U.S. (ASME & ASTM, IFI, ANSI), British BS, Japanese JIS and others. They are offered as OEM parts under their respective brands or under our own labelled (AVIATIONEU NEW ERA) product lines intended as cost-effective alternatives to the respective OEM products. Listed in accordance with their standard of compliance, Fixed and Floating nutplates come in different materials (such as steel or CRES & finishes),  in single/double lug configurations and Metric ISO οr Unified thread sizes. There is currently no U.S. Military Standard (MS) specification for Metric nutplates. Depending on the selected product and availability, nutplates can be supplied with a dry film lube specified by the letter "L" in the respective part number. Those with countersunk rivet holes are specified by the letter "K" at the end of the part number.

Sourced from quality manufacturers, AVIATIONEU NEW ERA MS21069/MS21070 series nutplates are fixed self-locking, two-lug, reduced rivet spacing low height miniature anchor nuts.  MS21069 series nutplates are made from cadmium plated steel while those of MS21070 series from corrosion resistant steel (CRES). They come in different Unified Thread sizes with plain or countersunk rivet holes on each side,  with or without a dry film lube. Sold in pieces but also in packs where the specified number of nuts per pack is indicated after the letters "PK" in the product reference number (SKU). Appearing prices are always for the units of measurement used each time. Matching rivets are sold separately.

For additional information please refer to the supplied documentation or contact us.

AN310/NASM310 and AN320/NASM320 Series castlellated nuts are manufactured from steel and cadmium plated. AN310/320 nuts have been superseded by NASM310/320 Series.  The Part Identification Numbers (PIN) for AN310/AN320 and those for NASM310/NASM320 are identical.

Castellated nuts are of similar style and shape as castle nuts but they are not as thick (deep) as the castle nuts (they consist the thin version of standard castle nuts). The thin design makes castlellated nuts weaker than the castle nuts and are used only where shear stress forces are encountered. Fabricated from steel and cadmium plated per QQ-P-416A, Type II, Class 3. AN310/NASM310 castle nuts are used with drilled-shank bolts, clevis bolts, eye bolts and studs. The slots in the nut accommodate a cotter pin for safety purposes. The thinner AN320/NASM320 series castellated shear nuts, with half the tensile rating of the AN310/NASM310 series nuts, are used with clevis bolts and threaded taper pins which are subject to shearing stress only.

Both AN310/NASM310 and AN320/NASM320 Series castlellated nuts are sourced from quality producers and offered as part of AVIATIONEU NEW ERA product lines. For additional information please consult the supplied documentation or contact us.

The AN363 series regular height all-metal stop nuts are similar to those of MS21042 series except that MS21042 nuts are shorter than the AN363 but develop the same tensile strength. The AN363 series nuts are fabricated from carbon steel & cadmium plated as per specification QQ-P-416C or stainless steel, in which case the letter "C" is included after the series number (e.g. AN363 cadmium plated steel, AN363C stainless steel). Both are designed for use in high temp installations (AN363 up to 450°F, AN363C up to 800°F).  The AN363/ AN363C series nuts have been replaced by those of MS21045/MS21046C respectively which in turn are superseded by NASM21045/NASM21046C.  The Part Identification Number (PIN) for MS21045/MS21046C  and the part number for NASM21045/NASM21046C nuts are identical. The part numbers have not been changed (eg. AN363-1032 to MS21045-3 to NASM21045-3).

Sourced from quality producers, MS21045/MS21046C all-metal stop nuts are offered as part of AVIATIONEU NEW ERA product lines which also include nuts from other AN, MS/NASM series (please refer to the individual product presentations). Sold in pieces. Please refer to product specifications or contact us.

Note: Depending on availability,these parts part may be supplied without or with Dry-Film Lubricant indicated by letter "L" in the SKU.

NASM21083/MS21083/AN364 series hexagonal low height self-locking  nuts with elastic insert are intended for use in structural applications. Sourced from quality producers and offered as part of our AVIATIONEU NEW ERA product lines, they are fabricated from different materials and finishes (cadmium plated steel, corrosion resistant steel passivated, aluminum alloy anodized) indicated by the following letters after their series number:

Letter “A” after dash number for nuts having non-metallic inserts

Letter "C" corrosion resistance (stainless) steel CRES passivated

Letter "B" brass

Letter "D" aluminum alloy anodized

Letter "N" cadmium plated steel

Cad plated nuts are furnished to military specifications while stainless steel nuts are furnished to military specification and commercial grade. AN364 nuts have been repaced by MS21083 which in turn are superseded by NASM21083. The Part Identification Number (PIN) for MS21083 and the part number for NASM21083 nuts are identical. The part numbers have not been changed.
