KANARDIA diverse family of non-certified gauges for use in ultralight aeroplanes, autogyros and helicopters includes different RPM, CHT, EGT and oil/temperature engine gauges.

KANARDIA INDU Series round RPM gauges are offered as standalone (master) or as slave gauges. The slave version requires an engine monitoring unit (DAQU) to be present on the bus. KANARDIA INDU Series round RPM gauges are available for two standard panel hole diameters of 57 mm (2.25") and 80 mm (3.15"). They can be supplied in the following scales:

-RTX Rotax scale (7000) and markings (yellow, green, red)

-JAB Jabiru scale (3500). Markings must be specified at the time of ordering

-LYC Lycoming scale (3000). Markings must be specified at the time of ordering

-D D-motor scale (3100). Markings must be specified at the time of ordering

-CUS Custom made scale

KANARDIA INDU Series round standalone CHT and EGT indicators are offered for two standard panel hole diameters of 57 mm (2.25") and 80 mm (3.15"). Respecive sizes of these gauges are 62 x 62 x 45 mm and 82 x 82 x 45 mm. The 57 mm gauges weights 150 g and requires a 102 mA power.

KANARDIA INDU Series round standalone Fuel Pressure, Oil Temperature and Oil Pressure indicators are available for 57 mm (2.25") and 80 mm (3.15") standard panel hole diameters with same sizes and weight power characteristics as those of CHT/EGT gauges.

The AV-534 is a TSO'd heavy-duty stainless steel bent whip VHF communications antenna with porcelain insulators and mounting hardware. The AV-534L is same antenna as AV-534 but furnished with 96" lead of RG58 A/U cable with male BNC and ground strap with lugs.

Installation parts and accessories used in different GARMIN® GMA Audio Control Panels are offered, including connector kits, mounting trays, back plates, audio and USB cables and others. Parts and accessories come with a Certificate for Conformance as standard. For parts used in GARMIN® GMA certified Audio Control Panels, these can be accompanied by FAA Export 8130-3  Forms at additional cost whenever required. Please specify the needed certification at the time of ordering.

DAVTRON Μ475 Series 2-Function voltmeter/ammeter digital indicators are FAA-PMA approved and come in 475VA/475VAA models and versions, both with lighting capability. Model M485VA ls made primarily for remote shunts. They are both designed for low current drain ( .001 Amp) and are also used in standby and emergency battery packs. Other features include:

Plus Or Minus Amp Range: 150.0

Plus Volt D.C. Range: 100.0

Sunlight Readable Display

One Tenth Amp Resolution

One Tenth Volt Resolution

1.3" case depth

2-1/4" Standard mount

The PAI-700 TSO'd Vertical Card Compass is manufactured exclusively by Precision Aviation, Inc. This non-liquid (dry) type compass is magnet driven thus it is subject to lead and lag, however, these tendencies are greatly reduced due to the absence of pendulosity.  It is inherently stable due to the use of eddy current damping which is a natural phenomenon built into the basic design and as such has no overshoot. The PAI-700 has been designed to replace the float/liquid type compasses eliminating leaking fluid or backward azimuth readings. Available for Southern and Northern Hemisphere and different supply systems (5V, 14V and 28V). Precision Avionics Inc. also manufactures different compass brackets for overhead or glare shield mounting.

The Precision PAI-700  Vertical Card Compass consists of a 2" vertical rotating dial which is compared with a fixed miniature airplane (lubber line) to present the magnetic heading of the aircraft at all times. Heading information is more natural because the heading is read at the12 o'clock position and off the nose of the miniature aircraft. The compass card rotates and presents all quadrants in their true relation to line of flight. Requires no power (except for lighting) to operate. Installed in many current production aircraft & helicopters. Size: 2-7/8"H x 2-3/8"W x 2-1/8"D. Wt. 0.6 lb. After installing compass must be compensated using standard compensation procedures. Also used in sailplanes.

Note: Compass deviation card is included. A mount, sold separately, is required for installation with the unit.

FLYBOX® brand  by MICROEL SRL relates to a wide range of avionics and flight instruments specialy designed and developed for ultralight and experimental aircraft. FLYBOX® product portfolio includes

My-EMS & Vigilus Engine Monitoring Systems

Engimaster EMS Engine Monitoring Systems

Oblò,  Oblò 2 and Eclipse NG Electronic Flight Instrument Systems (EFIS)

Omnia 57 and 80 Series of Legacy Instruments/Indicators

FLYBOX® Autopilot Systems

Flap & Propeller Controllers

For further information please refer to the Product Description section & the supplied documentation.

The AV-525 is a VOR/LOC/GS antenna similar in style to the AV-12 but utilizes an internal balun transformer. The antenna is rated at speeds up to 350 mph and altitudes up to 50,000 feet. It is a direct replacement for the CI 157P.

Product Specifications:

Model: AV-525

Application: VOR/LOC/GS Receive Only

Frequency: 108-118 MHz (VOR/LOC) -328-336 MHz (GS)

Impedance: 50 Ohms Nominal

VSWR: 3.0:1 Maximum 108-118 MHz - 2.0:1 Maximum 329-335 MHz

Polarization: Horizontal

Pattern: Omni-Directional

Connector: “BNC” Female

Max. Weight: 0.50 lbs.

Certification: FAA TSO C34e, C36e, C40c

KANARDIA INDU Series round altimeters are part of INDU diverse family of non-certified gauges for use in ultralight aeroplanes, autogyros and helicopters. They feature colour LCD display, one or two pointers  with possibility to personalise scales (in feet or meters) and LCD displays. They are offered as standalone (master) altimeters with internal pressure sensors or as slave instruments. The slave version requires some PFD like KANARDIA NESIS, EMSIS, AETOS or HORIS to be present on the CAN bus. KANARDIA INDU Series round altimeters are available for two standard panel hole diameters of 57 mm (2.25") with one pointer and 80 mm (3.15") with two pointers. They can also be ordered with integrated backup battery at additional cost. The backup battery can also handle and additional indicator, typically an airspeed indicator.

The GARMIN® GTN 650Xi (*) GPS/Nav/Comm/MFD panel-mount platform replaces discontinued GTN 650 (**) offering more pixels, processing power, speed and performance.  It’s approved for installation in many of makes and models of fixed-wing aircraft and helicopters providing high-resolution terrain mapping, graphical flight planning, traffic target surveillance, multiple weather options, taxiway diagrams and a host of other advanced navigation features. It comes with Americas or International Database (specified at the time of ordering).

The GARMIN® GTN 650Xi features:

- a brighter, faster, sharper, better Do-It-All intuitive touchscreen interface providing quick access to navigation, radio tuning, multifunction display features and more,

- powerful fast response dual-core processors boosting the GTN Xi series graphical display capabilities — with faster zooming, panning and map rendering on the display,

- high-resolution  4.9” display with almost double the pixel count of its predecessor and wider viewing angles,

- multi-function display cpability supporting multiple inputs of moving maps, terrain, traffic, weather, airport diagrams and more,

- easy data entry with the use the on-screen QWERTY keyboard or traditional concentric knobs to enter frequencies, waypoint identifiers, routings and more,

- Telligence™ voice control technology helping reduce pilot workload by responding to hundreds of spoken commands with the press of a button on the yoke,

- finger swipe gestures enabling pilots to pan across the map display or use a smartphone-like pinch-to-zoom motion to scale up or down on any map, traffic or terrain page.

GARMIN® GTN 650Xi Specifications

TSO applicability: C34e; 2C34f; C36e Class A; 2C36f Class A; C40c; 2C40c; C74d Class A; C112e; C128a; 2C128; C146e Class 3; C151d Class A, B; C157b Class 1, 2; 165b; C169a Class C, E, 3, 4, 5, 6; 2C169a Class C, E, H2, 3, 4, 5, 6; C194; C195b Class B1, B3, B5, B7; C209

Display size: 4.9" (125 mm) diagonal

Display resolution: 834 pixels (W) x 370 pixels (H)

Unit bezel height: 2.65" (67 mm)

Unit bezel width: 6.25" (159 mm)

Unit depth with connectors: 11.25" (286 mm) (measured from face of aircraft panel to rear of connector backshells)

Unit weight: 5.5 lbs (2.48 kg)

Input voltage range: 11 VDC - 33 VDC

Operating temperature range: -20° C to 55° C (-4° F to 131° F)

Number of GPS channels: 15 (12 GPS and 3 GPS/WAAS/SBAS)

LAT/LON position accuracy: <1.25 meter RMS horizontal, < 2 meter vertical, with WAAS

Maximum velocity: 1,166 knots

Position update Interval: 0.2 sec (5 Hz)

Notes:

(*) The GARMIN® GTN 650Xi can be supplied as kit with 4 feet pigtail wire harness without certification . If cerification is required installation must be done by a GARMIN® Authoried Service Center.

(**) The GARMIN® GTN 650 can be supplied as USED (Serviceable) Certified unit (FAA 8130-3 Form) with GPS antenna, rack, connector, existing Database, 6 nonth warranty.

FALCON GAUGE Magnetic Compasses are non certified  2" compasses available in liquid (MCDN) and non-liquid (dry) types (MCVC). The Liquid Type compasses provide an accurate reading at a low cost. They are fluid damped and incorporate a thermal expansion chamber and compensating magnet. Available in Panel or Pedestal Mount versions with or without lighting. Different models available: MCDN-2, MCDS-2, MCDN-2L, MCDS-2L. They can be ordered for Northern or Southern Hemisphere.

These compasses are very similar to the Airpath C2300 & C2400 style compasses, but are priced more economically.

The FALCON GAUGE Vertical Card Compasses are of a non-liquid type.  They are designed with a different concept which eliminates the disadvantages experienced with a liquid compass, namely leaking and back and forth motion of the compass card.  These compasses look like directional gyros and offer superior visibility.  A second vertical rotating dial, which is compared with a fixed miniature airplane (lubber line), presents the magnetic heading of the aircraft at all times making heading information more natural.  The easy to read presentation allows the pilot to see the complete 360 degree dial.  They also feature an internal LED light and a universal mounting bracket.

Used by airlines, corporate flight departments, and major avionics manufacturers in the world, JEPPESEN® NavData® Databases offer the most complete and accurate aeronautical information available with worldwide coverage and access to more than 7,000 airports (a database three times the size of any other provider). NavData® information provide vital knowledge of airport features, runway characteristics, communications information, waypoint features, SIDs, STARs, terminal approach procedure information, VORs, NDBs and a comprehensive set of boundaries for controlled/restricted airspace. They can also be combined with obstacle and terrain data, and customizable data services for many different platforms and manufacturers.

JEPPESEN®  NavData® services are distinct in terms of coverage, content, accuracy, FAA LOA 1 and EASA DAT compliant quality, configurability and high level service 24 hours a day.

JEPPESEN® NavData® services are offered  for different GARMIN® avionics listed below. Such services are included in separate product presentations.

G3X/G3X Touch

G300

G500/G500H/G500HTXi/G500TXi

G600/G600TXi/G700TXi

G900/G900X/G950

G1000/G1000H/G1000NXi/G1000H NXi

G2000/G3000

G5000H

GNC355/GNC355A

GNS175

GNS400/GNS400 WAAS Series

GNS500/GNS500 WAAS Series

GNX375

GPS Series

GTN600/GTN600Xi

GTN700/GTN700Xi

GX Series

Perspective

Prodigy

Portable/mobile devices supported (Jeppesen Electronic Charts only):GARMIN® Pilot, GPSMAP 696, AERA 795/796

JEPPESEN® NavData® services for GARMIN® Navigators GNC®/GNS™/GPS 400/500 Series are offered  in both WAAS and NON-WAAS versions, as single one time updates, annual subscriptions and bundled with other information. The NON-WAAS versions are intended for use on the GARMIN® GNS™, GNC® and  GPS units while the WAAS version can be used on the GARMIN® GNS™ 400W/500W WAAS units.

NavData® Annual Subscription Services include IFR NavData and are offered for either a single unit or dual units in the same cockpit. They are provided through downloaded updates every 28 days and are available in different coverage areas around the world.

Orders for these databases and their updates are fulfilled by AVIATIONEU TRAINING SYSTEMS & SERVICES which offers aviation database services, in cooperation with respective database providers, on a simplified subscription-based ordering process saving man effort, time and costs for customers. Please refer to the offered listed services for various manufacturers, models, database versions and coverage areas.

The RAMI AV-10 COMM Antenna is designed for high-performance aircraft applications. It exhibits excellent electrical characteristics and incorporates an efficient aerodynamic 4-bolt mounting base. The antenna essentially matches the styling of the communication antennas currently used on most singles and light twins. The antenna is designed to operate at speeds up to 350 mph and altitudes up to 50,000 ft. It has a drag force of 2.70 lb @ 250 mph.

Product Specifications:

Application: Airborne Communications

Frequency: 118 to 137 MHz

Impedance: 50 Ohms Nominal

VSWR: 2.0 to 1 Maximum

Polarization: Vertical

Pattern: Omni-Directional

Connector: Type "BNC" Female

Max Weight: 8 oz

Max Height: 20-1/4"

RF Power Capacity: 25 Watts

Sourced from quality manufacturers, our own branded (AVIATIONEU NEA ERA) aviation (air crew) headsets are offered in two main families or series  (100 and 400) each with PNR and ANR models suited for use in fixed and rotary wing aircraft.

Two different plug types are offered, PJ-055/PJ-068 dual plugs widely used in General Aviation and other airplanes and Military grade U174 plug used on helicopters and military aircraft.

With their competitive prices, advanced design and features, quality materials and rigid construction, AVIATIONEU NEA ERA headsets combine performance, functionality and comfort to provide cost effective solutions for air crew communications.

ANR models (*) are offered with or without Bluetooth capability for music and mobile communications. All our headsets are accompanied by the Manufacturer and our Certificate of Conformance and come with a 12-months manufacturer warranty.

100 Series

AVIATIONEU NEA ERA 100 Series of aviation headsets includes PNR model 100 (GA) with dual plugs for airplanes and 100 (H) with U174 plug for military/helicopter operations. They feature  23dB and 24dB  noise reduction ratings respectively. 100 Series PNR headsets are Low cost, entry level headsets, ideal for General Aviation pilots and flight schools. Their ANR counterparts (Models 100A (GA) & 100A (H) are offered with a 29dB noise reduction rating and without or with Bluetooth capability, indicated by the letters "BT" in the product reference number (SKU). Pilots' style requirements are also covered through multiple colors, with Grey/Black (commonly stocked) and Green/Pink/Red/Yellow/Blue (On Demand as special order).

400C Series (Ultra Light Carbon Fiber Aviation Headsets)

Combining high performance, modern design, robust construction and an ultralight weight (only 9oz, 255g) the AVIATIONEU NEA ERA 400C series headsets are intended for use in air transport and military operations or by demanding pilots who seek high performance, functionality and confort headsets with an ultra light weight. Offered in carbon fiber black color. Various models include:

400C (GA) and 400C (H) PNR and 400AC (GA) and 400AC (H) ANR headsets offered with dual plugs and U174 single plug respectively and a noise reduction capability of 23dB (400C PNR) 29dB (400AC ANR).They come with or without Bluetooth capability.

AVIATIONEU NEA ERA 100 Series headsets are included in this listing while 400 Series headsets are separately listed. Please refer to the additional information and specifications provided or contact us.

(*) ANR function is powered by an AA battey in a supplied battery box with toggle switch. The headset will shut off automatically when unplugged from the battery box, manually turned off from the toggle switch or when the radio or avionics master switch is turned off.

R.A. MILLER INDUSTRIES (RAMI) aircraft antennas cover a wide range of functions including communications, NAV antennas, GPS, ADS-B, transponder, VOR localizer, glide slope antennas, and marker beacons. They are known for their streamlined aesthetics, quality, and reliable performance. Offered in different TSO models, RAMI wire whip and rod antennas ELT (Emergency Locator Transmitter) devices are intended for use on low-speed General Aviation aircraft.

RAMI AV-100 FAA TSO C126a Airborne ELT Antenna is a passive two frequency (121.5 & 406 MHz) whip antenna, designed for speeds up to 250 knots. Impedance 50 Ohms Nominal, VSWR (Maximum):121.5 MHz 2.0:1 / 406 MHz 1.5:1, Polarization Vertical, Pattern Omni-Directional, Connector BNC Female, Weight: 3 oz. Maximum, Color: Black.

RAMI AV-200 FAA TSO C126a Airborne ELT Antenna is a passive two frequency (121.5 & 406 MHz) whip antenna, designed for speeds up to 250 knots. It meets DO-160G, Section 8, Category U requirements for robust vibration and is qualified for installation on helicopters with unknown related rotor frequencies. Impedance 50 Ohms Nominal, VSWR (Maximum):121.5 MHz 2.0:1 / 406 MHz 1.5:1, Polarization Vertical, Pattern Omni-Directional, RF Power Capacity 10 Watts CW, Connector BNC Female, Weight: 0.19 lbs. Maximum, Max Height 24″.

RAMI AV-300 FAA TSO Airborne ELT Antenna is a passive three frequency (121.5, 243 & 406 MHz) fiberglass rod antenna, designed for speeds up to 350 knots. Impedance 50 Ohms Nominal, VSWR: 2.0:1 max at 121.5 MHz,2.0:1 max at 243 MHz, 1.5:1 max. at 406 MHz,  Polarization Vertical, Pattern Omni-Directional, RF Power Capacity 10 Watts CW, Connector BNC Female, Max Weight 9 oz, Max Height 14″.

Solid State Cockpit Voice Recorders (SSCVR) and Flight Data Recorder (FDR), aka "black boxes", are required by Civil Aviation Authorities to be installed in large commercial aircraft and some smaller commercial, corporate, and private aircraft used to help reconstruct the events leading to an aircraft accident. Manufactured by various manufactuers such as HONEYWELL AEROSPACE, UNIVERSAL™ AVIONICS and others they are offered in different models, as CVR, FDR or combined systems, certified by FAA, EASA and other CAAs and available in NEW Condition but also as USED (OVERHAULED) units for straight purchase or exchange. For additional information please consult the Product Description section, the supplied documentation or contact us for a quotatin.

The GARMIN® GTR series COMM TSO'd panel mounted transceivers (please see separate presentation) together with the GARMIN® GNC series NAV/COMM radios are replacement products for the popular SL30 and SL40 models. They include new features to reduce pilot workload, while also offering an affordable solution to meet the requirements of the 8.33 kHz channel spacing European Union mandate under the Single European Sky (SES) initiative. They are more powerful than their SL-series predecessors with 10- or 16-Watt transmit power available versions.

The GARMIN® GNC series NAV/COMM radios are offered with either a 10 W (GNC 255A) or 16W (GNC 255B) COMM featuring a 25 kHz or 8.33 kHz spacing. Both come with a an internal VOR/LOC converter, a 40-channel glideslope (GS) receiver and include the rack, connector kit, and back plate. They are offered as units only or as kits with a 4ft harness to AUDIO Panel.  If purchased with the 4ft harness, they can only be used  in experimental aircraft.

The KANNAD 406 AS (P/N S1823502-03) is a aeronautical survival beacon. Thanks to its small size and light weight, the Kannad 406 AS fits easily inside a liferaft. It is supplied with a floating collar.

The KANNAD 406 AS is qualified by the French Civil Aviation in Europe with JTSO-2C91a & JTSO-2C126 and by FAA with TSO-C91a & TSO-C126 applied to “survival” beacons.

The ELT is programmed with either the aircraft tail number, a serial number or the aircraft operator designator. It can be installed inside an aircraft on a mounting bracket or in a carry-off bag (both on options).

The mounting bracket option includes a locking pin to avoid accidental activation before ELT removal. The locking pin can be ordered separately with the carry off version.

The ELT can be fitted with a "Water Switch Sensor" to be activated automatically when in contact with water. A buzzer and a led indicate activation.

An integrated “self test” checks the main functions of the beacon. The test result is given by the led flashing sequence.

Product Features:

Battery replacement is only every 6 years.

Precise pinpointing (<1NM) due to the unparalleled frequency accuracy of the 406 transmitter.

Three frequency transmitter (121.5 / 243 / 406 MHz)

Weight (including battery, auxiliary antenna and floating collar) 2.53 lbs (1150 g)

Options:

P/N S18 20 511-03 carry-off bag

P/N S1820511-02 Mounting bracket with locking pin

P/N S1820514-14 Water Switch Sensor

HONEYWELL BENDIX KING® Panel-Mounted KLN 35A VFR GPS & KLX 135A VFR GPS/COMM with moving map. These products are DISCONTINUED and NO LONGER AVAILABLE IN NEW CONDITION.

The KLN 35A VFR GPS receiver combines satellite derived GPS worldwide navigation system with moving map graphics, a high-visibility display and and a choice of customized Jeppesen Nav Data databases, including coverage for Americas, Atlantic and Pacific areas. The KLX 135A offers even greater capability, incorporating all the same GPS performance and features as the KLN 35A also integrating a TSO'd, 760-channel, very-high frequency (VHF) communications radio with its navigation functions.

Limited Availability exists in USED devices which can be furnished in Serviceable or Overhauled conditions indicated respectively by the letters "SV" and "OH" in the product reference numbers (SKU and  accompanied by the relevant certification (e.g. yellow tag, 8130-3 form). In addition, they may be offered as exchanges / trade-ins  for returned customer owned units indicated by the letter "EX" in the SKU.  In the case of an exchange/trade-in option of a customer unit, the  full selling price of the ordered unit is charged and the core credit is refunded or credited towards future orders when our co-operating supplier verifies that the unit is in a reasonable, repairable condition. It is recommended that this option is selected by our customers mainly for upgrades and only in cases when their units are functioning properly at the time removal from the aircraft. In cases when customer units are found by our supplier to be non-repairable, the core deposit shall not be refunded and shipping charges shall apply if customers wish the return of these units to them.

Installation parts (for new installations) and manuals are sold separately.

Please refer to the Product Description section for technical specifications and information on USED avionics.

AN5771-4A style 2-1/4 inch hydraulic pressure gauge with steel case connecting directly to the aircraft's hydraulic system. Fits in a 2-1/4" dia. panel opening and has a threaded 1/4"  connection for a fitting. Range: 0-2000 PSI. Only available in Overhauled Condition. Certified with fresh Matte-white dial. Yellow-tagged. Limited availability.

For new design projects and applications please refer to the presentations of alternative TSO'd and non TSO'd electronic hydraulic pressure gauges and pressure senders offered.

Pressure Transducers (Senders) whenever required, ARE NOT INCLUDED in the prices of hydraulic pressure gauges. They are sold separately.

Note: A yellow tag is similar to a FAA 8130-3 Serviceable tag both denoting the "Serviceable" condition of the product i.e. it has been  repaired as needed, tested according to the manufacturer's procedure, meet the manufacturer's performance specifications and ready to return to service. Yellow tags are issued and widely accepted in North America while a FAA 8130-3 Serviceable tag is is accepted worldwide. The acceptance of yellow tags by national Civil Aviation Authorities should be checked by potential buyers prior to ordering.

Amphenol MS MIL-C-5015 Circular Plug Connectors are designed to meet the demanding performance requirements of military standards. These cable mount circular plug connectors have proven electrical capability for equipment applications where durability is important. The Amphenol plugs have threaded couplings and single key/keyway shell polarization for an accurate and reliable connection. The solid shells of these MS Series circular MIL-C-5015 connectors are made from high grade aluminium alloy. The shells are electrically zinc plated with an olive drab chromate finish which ensures a high resistance to corrosion. The inserts of these military circular connectors are made from resilient synthetic rubber which offers a high dielectric strength and resistance to vibration.

The MS3106A-10SL-3S plug can be used with Turn Coordinator TC02E-3-2 or Turn & Bank Indicator TB02E-2-1.
