Manufactured with high quality PC/ABS, the AERA 660 Panel Dock by AIRGIZMOS, maximizes its use by placing the GPS right in the aircraft  panel and hold securely in place without blocking any other instruments.  It makes GPS touch screen controls easier to navigate and matches the look and feel of the rest of the avionics stack, resulting in a pleasant, professional looking panel. Dimensions are 6.25" wide by 4.25" high.

Garmin has reduced the number of connectors on the AERA 660  by using a docking connector. This docking connector has been integrated in the design and nests into the back of AIRGIZMOS Panel Dock. For upgrades from an older Garmin GPS, this panel dock has been designed to fit the same opening as those for AERA 496 or 500 and uses the same hole layout for mounting.

The FLYdat has been specially developed by TL ELEKTRONIC for BRP-ROTAX® Aircraft Engines for indicating and storing of engine operation data. The unit  is furnished with 8 sensor input ports, which can be occupied variably according to engine type.

The operating data is permanently compared with the engine specific operating limit. If the signalled operating data exceeds the stored operating limit, the FLYdat will warn the pilot. In addition all the input ports are equipped with a maximum alarm, responding when picked-up value is equal or above the stored limit. The FLYdat keeps the pilot informed on the following actual readings. Besides the topical data, the FLYdat shows also the hours of operation.

•  Engine speed

•  Cylinder head temperature (CHT)

•  Exhaust gas temperature (EGT)

•  Ambient air temperature (not on engines 912 / 914)

•  Temperature of cooling water (only on engines 582 UL, 618 UL)

•  Oil temperature and oil pressure (only on engines 912 / 914)

The TL ELEKTRONIC FLYdat is supplied with a standard configuration. With the standard configuration all trigger levels for warning- and alarm system are set to the maximum of the measuring range.

Configuration is available for the following BRP-ROTAX® engine types: 447 UL SCDI, 503 UL DCDI, 582 UL DCDI, 618 UL DCDI, 912 DCDI series, 914 DCDI series, Standard

By configuration of the TL ELEKTRONIC FLYdat, the engine type, engine number, hour of operation, temperature unit and the respective engine limits are programmed.

The TL ELEKTRONIC FLYdat unit and parts are no longer offered as ROTAX Part Numbers. These part numbers are provided for reference only.  In addition, aircraft engine  parts are subject to changes from time to time. Some parts may be no longer available or replaced by others with different part numbers. Listed engine parts do not imply their current availability or suitability for your engine application. Always consult the most recent Illustrated Part Catalogs (IPCs) or other documentation available from the engine manufacturer for the correct part number before ordering.

GARMIN® GTX™ transponder product line includes Mode A/C and Mode S TSO'd panel mounted transponders offered in a‭ ‬wide variety of configurations to choose‭ ‬from‭, ‬depending on desired functions‭.‬ Different models are listed under separate product presentations.

GARMIN® GTX™ 325  is a Mode A/C panel-mounted full-featured, TSO'd certified transponder offering a simple, affordable replacement for standard Mode C transponders. It features aural alerts, total air temperature (TAT), pressure altitude readout, altitude monitor function, density altitude readout, built-in timers and automatic ALT/GND mode.  ‬It replaces the popular GTX™ 327 ‬and is essentially the same unit‮—‬but carries the GTX™ 335/345‭ ‬display and button layout‭. ‬It would be a meaningful ‬choice for the replacement of an older Mode C ADS-B‭ ‬Out transponder.

The R.A. MILLER (RAMI) TSO'd AV-74 (.425 Stud Length) & the AV-74-1 (.800 Stud Length) are broadband blade type antennas for transponders or DME applications. The antenna housing is constructed of an acrylonitrile-styrene-acrylic (ASA) shell. The white color allows maximum performance without losses due to color pigments or unseen dirt. The antennas are supplied with cellular neoprene mounting pad and hardware. Designed to operate at speeds up to 350 mph and altitudes up to 50,000 ft. They have a drag force of 0.09 lbs @ 250 mph. These antennas are direct replacements for the CI-105 antennas.

Product Specifications:

Application: Transponder/DME

Frequency: 960 - 1220 MHz

Impedance: 50 Ohms Nominal

VSWR: 1.5:1 Maximum

Polarization: Vertical

Pattern: Omni-Directional

Connector: "BNC" Female

Max Height: 3.4"

RF Power Capacity: 2.5 kW Peak

FAA TSO: C66c, C74c

The 730/830 Engine Monitoring Systems (EDM) from JP INSTRUMENTS revolutionize engine monitoring by the compact size integration of a full color graphical LCD display with the extremely popular EDM 700/800 series functionally. Both 730 and 830 EDMs feature: colourful graphics, larger data display for easy reading, parameters in full colour, annunciation of exceedances, less page swapping, more data per page. The units are "Plug and Play" compatible with existing EDM-700/800 units. Oil pressure has also been added to the entire EDM series line.  Both 730 and 830 are FAA approved for use as secondary engine monitors. However they CANNOT BE USED as a replacement for primary gauges which have to be maintained. Different options and accessories are also available at additional cost.

The AV-534 is a TSO'd heavy-duty stainless steel bent whip VHF communications antenna with porcelain insulators and mounting hardware. The AV-534L is same antenna as AV-534 but furnished with 96" lead of RG58 A/U cable with male BNC and ground strap with lugs.

Static ports are located on the side of an aircraft and function as small air inlets. Their purpose is to measure static air pressure, also known as barometric pressure. The pressure within the static port is collected and then utilized by the altimeter and the vertical speed indicator (VSI). Different static ports are offered, both certified and non certified (the latter with an intended use in homebuilt/experimental aircraft).

Several offered non certified static ports are briefly described below. For certified static ports plese refer to their separate product presentations.

Aluminum Cessna Type

Aluminum single engine Cessna type static port. Externally mounted through a 19/64” hole. Can be used on fabric, composite or aluminum. No need for rivets. 1-3/8” dia.x1” depth.

Aluminum 15160

Aluminum static port for external mounting through 1/4" diameter hole in side of the fuselage. Base has 1/8" NPT female port for connecting to static line (polyethylene fitting included). Installation with 3/32" diameter flush rivets.

Aluminum 15161

Aluminum static port for external mounting through 1/4" diameter hole in side of the fuselage. Base has 1/8" NPT female port for connecting to static line. Installation with 3/32" diameter flush rivets.

Aluminum 15176

Aluminum static port externally mounted in a 1-1/4" base OD outside of the fuselage through 5/16" ID hole. Installation with 4 countersunk 3/32" rivets to skin with pal nuts & lock washers on inside.

The new OROLIA-KANNAD INTEGRA 406 GPS ELT is a major step forward in the development of ELT technology and aircraft safety. Major benefits over standard ELTs include  a fail-safe automatically activated system for transmission of both the unique identification and GPS position in case of ditching of the aircraft or a crash landing as well as the ability for the pilot/ crew to remove the ELT from a downed aircraft. In addition,it features internal 406MHz and GPS antennas saving significant cost on aircraft  installation without the need for an  external antenna (national authorities’ rules and regulations permitting) and additional external GPS interface.

The 406 INTEGRA fixed ELT(AF) transmits on both the international 406MHz satellite search and rescue system (min  24 hours from activation) and on 121.5MHz for local direction finding. Minimum operating temperature is -20°C. The internal battery life of the INTEGRA is 6 years. Complies with European and FAA standards.

406 INTEGRA ELT(AF) is designed for flat installation on fixed wing aircraft and can be connected to an outside antenna (sold separately).

This ELT comes with:

the COMPACT universal mounting bracket

RC200 remote control panel

DIN-12 connector

SUB-D 9 pts female connector

Note: Hazardous Material

HONEYWELL BENDIX KING® Aviation Database Services are offered for database updates of different navigation BENDIX KING® devices. They cover different geographical areas and are available for use in single or multiple devices, as single (one cycle) or multiple scheduled annual update cycles per year. They can be distributed through media (database cards/cartridges) and/or internet downloads (eliminating media and shipping costs). Database upgrades are subject to copyright restrictions and are allowed for use only in the specific aircraft and devices specified at the time of ordering. Orders for HONEYWELL BENDIX KING® database updates are fulfilled by AVIATIONEU TRAINING SYSTEMS & SERVICES which offers aviation database services, in cooperation with respective database providers, on a simplified subscription-based ordering process saving man effort, time and costs for customers. Please refer to our listed services or contact us for additional information.

ETSO'd Slimline Panel Mounted 10 W VHF Radio with built in 2-place intercom with auxiliary inputs for stereo music and audio warnings. Available with 8.33 kHz or  25kHz frequency spacing options.

The N16 split design remote-mount VHF Navigation Receiver by MGL AVIONICS belongs to a new generation of navigation receivers based on RF direct conversion technology. The N16 is identical in size to the V16 COMM radio and can be used in a simple configuration as combined NAV/COMM solution for both MGL EFIS systems using the MGL protocols or, if at least one MGL VEGA or RAZOR control head is used these heads can provide NAV/COMM data output on RS-232 that is compatible with most EFIS systems on the market. Like V16 COMM, it is a Non-TSO'd NAV receiver for use in experimental and light-sport aircraft. For stand-alone operation, at least one MGL RAZOR control head or two MGL VEGA heads are required. Using these heads a fully compliant solution is presented that provides both VOR CDI using a rotary control for OBS bearing entry as well as the familiar two bar ILS localizer and glideslope indication. The VOR provides a display for bearing to station and radial from station at the same time for up to two simultaneously-received VOR stations. For additional information please refer to the attached documentation.

The HONEYWELL BENDIX KING® KMT 112 is a Magnetic Azimuth Transmitter (aka Flux Detector or  Valve) which senses the direction of the earth’s magnetic field and continuously transmits this information through the slaving circuitry to a directional gyro (such as the HONEYWELL BENDIX KING® KG 102A or KSG 105 slaved directional gyros). This sensor is mounted remotely, usually in a wingtip, to eliminate the possibility of magnetic interference. The KMT 112 is typically used in HONEYWELL BENDIX KING® KCS 55A and KCS 305 compass systems. The KMT-112 flux valve is a sealed unit and cannot be serviced or have parts replaced. The unit must be replaced when/if it fails.

Like other KCS 55A compass system components, the  KMT 112 transmitter can be furnished in NEW condition or as USED in Serviceable or Overhauled conditions indicated respectively by the letters "SV" and "OH" in the product reference numbers (SKU and  accompanied by the relevant certification (e.g. yellow tag, 8130-3 form). They are also offered as exchanges / trade-ins  for returned customer owned units indicated by the letter "EX" in the SKU.  In the case of an exchange/trade-in option of a customer unit, the  full selling price of the ordered unit is charged and the core credit is refunded or credited towards future orders when our co-operating supplier verifies that the unit is in a reasonable, repairable condition. It is recommended that this option is selected by our customers mainly for upgrades and only in cases when their units are functioning properly at the time removal from the aircraft. In cases when customer units are found by our supplier to be non-repairable, the core deposit shall not be refunded and shipping charges shall apply if customers wish the return of these units to them.

Installation parts and manuals are sold separately.

For additional information and technical specifications please refer to the Product Desscription section, the product presentation of the HONEYWELL BENDIX KING® KCS 55A compass system or contact us.

Sigma-Tek 5000B Series Attitude Indicators (Artificial Horizons) are air-driven gyros that have a pictorial horizon mask and fixed airplane. The mask moves to indicate climb, dive, and bank. Bank and pitch attitudes are displayed so that the pilot’s sensing of the gyro indication is the same as the interpretation of the relation between the wings of the aircraft and the natural horizon during visual flight. These instruments are FAA certified (TSO-C4c), and can be used to replace the aircraft’s turn coordinator when equipped with an inclinometer. Different versions available mainly based on the layout, dispay colors, warning flag and lighting capabilities. Lighted indicators do not include lamp trays which are sold separately based on the aircraft voltage (14V or 28V).

ROTAX® aircraft  engines form part of the product portfolio  of BRP-Powertrain GmbH & Co. KG which develops and manufactures engines for snowmobiles, watercrafts, boats, roadsters, all-terrain and side-by-side vehicles, motorcycles, carts, and aircrafts.

BRP-ROTAX® product range includes certified and non certified internal combustion engines, parts and accessories for light and ultralight aircraft.

Revolution Counters (Tachometers)/HOBBS meters are used in BRP-ROTAX® aircraft engines. They are offered as certified or non certified parts from BRP-ROTAX® but also from other manufacturers.  Non certified parts can be used in ultralights or other aircraft not requiring certification of parts for their installation. Certified parts are designated by the letters "CERT" after the part number in the product reference number (SKU).

Aircraft engine  parts are subject to changes from time to time. Some parts may be no longer available or replaced by others with different part numbers. Listed BRP-ROTAX® engine parts do not imply their current availability or suitability for your engine application. Always consult the most recent Illustrated Part Catalogs (IPCs) or other documentation available from the manufacturer for the correct part number before ordering.

MGL AVIONICS XTreme full featured instrument series include an Electronic Flight Instrument System (XTreme-EFIS) with navigation/autopilot capabilities and anEngine Monitoring System (XTreme-EMS). Their light weight, small size and high level of functionality makes them an excellent choice for use in non-certified aircraft. Both instruments fit a standard 3 1/8” (80mm) instrument panel hole. All information is displayed in an easy to read format on a high resolution wide viewing angle 4.3” sunlight readable color display. The XTreme-EFIS includes all the functions of the XTreme-EMS version. It a compact, multifunction electronic flight information system intended as a main flight instrument in smaller aircraft or as a backup/secondary flight instrument in larger aircraft. It integrates all the necessary functionality to replace several flight and engine monitoring instruments.The XTreme-EMS is a compact universal engine monitor replacing several engine monitoring instruments. All engine sensors are connected to a RDAC (Remote data acquisition unit) normally mounted behind the aircraft firewall. A simple CAN communication link is then necessary to connect the XTreme-EMS to the RDAC.

DAVTRON M301 Series Outside Air Temperature (OAT) digital indicators are FAA-PMA approved and come complete with digital probe, in Fahrenheit or Celsius models and different versions. They require minimum panel space. Other features include: light weight, automatic dimming, miniature remote probe, sunlight readable display and a laser engraved faceplate. A 3-pin connector is installed on probe as an option for an additional charge.

LONE STAR AVIATION manufactures multiple fans and blowers for OEM applications.

The CYCLONE 100 FAA-PMA approved 1 port blower is the smallest (1 x 2 x2 ), most efficient (brushless dc motor), and the most versatile cooling fan for avionics and or other electronics needing thermal cooling. Its universal mounting bracket makes it easy to set-up and install on on many make and model aircraft and or rotor-craft.  Also installed in Land-Mobile, Marine and Military Vehicles for many PED, radio, GPS applications. Offered in Input 12VDC/24VDC versions.

Lone Star Aviation's new FAA-PMA approved Cyclone 1 port blower is the smallest (1 x 2 x2 ), most efficient (brushless dc motor), and the most versatile cooling fan for avionics and or other electronics needing thermal cooling. Its universal mounting bracket makes it easy to set-up and install on on many make and model aircraft and or rotor-craft.  Also installed in Land-Mobile, Marine and Military Vehicles for many PED, radio, GPS applications.

The CYCLONE 21 FAA-PMA approved 3 port blower is a compact (3 x 3 x 1") aircraft electronics cooling fan that delivers 21 cubic feet per minute of forced air cooling to a variety of avionics equipment. It is the top FAA approved avionics blower for 14/28 volt aircraft with the smallest footprint and the highest output but also the number one choice for OEM and aftermarket sales world-wide for many make and model aircraft and rotor-craft.

For more information on the above products please consult the Product Description section and the supplied documentation.

The TT31 is a power-efficient, inexpensive, Mode S transponder by TRIG AVIONICS  that meets the European elementary surveillance requirements. The TT31 fits in the same mounting tray as the BENDIX KING KT76A transponder, making it a great choice for either upgrades or new installations. The TT31 plug and play design minimises the cost and downtime for the upgrade. The TT31 is TSO approved for fitting to European and FAA registered aircraft. With a new software upgrade and a connection to an appropriate GPS, this will make the TT31 compliant with the FAA final rule on ADS-B Out (TSO C166b) for 2020.

Product Features:

European Mode S (*)

Low Power Consumption

No Cavity Tube

240 Watts Nominal Output

Plug and Play Installation

Backlit LCD Display

Easy to Use Rotary Knobs

Timer/Stopwatch Function

Altitude Monitor

Certified 1090ES/ADS-B Out (TSO C166b)

NOTE (*): All Mode S transponder upgrades for EASA certified aircraft must be carried out by a licensed engineer using a Minor Change approved by EASA.

Pre-approved Minor Changes for popular aircraft types may be available for this device. In this case no EASA fees for the issue of Minor Change approval apply. Contact us for more information.

SCINTEX complete kit with digital gauge and dual flow meters enabling monitoring of the engine's supply and return lines. It comes with 2 fittings for each flow meter (to be specified at the time of ordering) and clamps. For installation wiring between the flow meters and the display unit is required (not included). This kit is intended for use in vehicles, machinery, generators and boats / marine and other engine applications. The flow meters are precision cut from steel and aluminum and they are highly accurate, repeatable and suitable for use with diesel, biodiesel, unleaded petrol and other fuels. The display unit is a 1.8”, high resolution, sunlight readable, wide viewing angle, LCD colour display with a completely sealed and waterproof display front panel. The gauge enclosure is a common 52mm round size to fit many existing cutouts. Key features include highly accurate with good repeatability displays consumption in Litres per Hour or other units, fuel remaining in up to 2 tanks, connection capabilities to a NMEA enabled RS232 GPS receiver,  one or two fuel flow senders and fuel level senders and a single fuel pressure sender and display. It can be powered by 12V - 36V power supplies. Please refer to the additional information and specifications provided or contact us.
