The R.A. MILLER (RAMI) TSO'd AV-74 (.425 Stud Length) & the AV-74-1 (.800 Stud Length) are broadband blade type antennas for transponders or DME applications. The antenna housing is constructed of an acrylonitrile-styrene-acrylic (ASA) shell. The white color allows maximum performance without losses due to color pigments or unseen dirt. The antennas are supplied with cellular neoprene mounting pad and hardware. Designed to operate at speeds up to 350 mph and altitudes up to 50,000 ft. They have a drag force of 0.09 lbs @ 250 mph. These antennas are direct replacements for the CI-105 antennas.

Product Specifications:

Application: Transponder/DME

Frequency: 960 - 1220 MHz

Impedance: 50 Ohms Nominal

VSWR: 1.5:1 Maximum

Polarization: Vertical

Pattern: Omni-Directional

Connector: "BNC" Female

Max Height: 3.4"

RF Power Capacity: 2.5 kW Peak

FAA TSO: C66c, C74c

GARMIN® GTX™ transponder product line includes Mode A/C and Mode S TSO'd panel mounted transponders offered in a‭ ‬wide variety of configurations to choose‭ ‬from‭, ‬depending on desired functions‭.‬ Different models are listed under separate product presentations.

GARMIN® GTX™ 330 is a panel-mounted IFR-certified 250 W, Mode S digital transponder with traffic datalink capability and dedicated pushbutton keys for squawk code selection. The GTX™ 330 series brings ATC aircraft surveillance to new levels of precision, reliability and performance. Optionally available with 1090 MHz extended squitter transmission, certified to TSO-C166b authorization, the GTX™ 330 ES (Extended Squitter) provides an affordable pathway to ADS-B compliance for the Next Generation airspace system. The extended squitter technology enables transponders to automatically transmit traffic surveillance data (including aircraft flight ID, position, altitude, velocity, climb/descent, and heading information) compared to traditional Mode S and Mode C transponders, which can only broadcast altitude, and thus require a ground-based radar to correlate and identify the aircraft's position. In addition, simultaneous broadcast of this information to TAS or TCAS equipped aircraft, enables them to essentially see the same traffic picture for their location that ATC is watching on the ground. The ‬“ES” upgrade provides a ADS-B‭ ‬Out‭ solution but an input from an approved position source is still needed as GTX™ 330 does not have a WAAS GPS.

GARMIN® GTX™ 330 is discontinued and replaced by GTX™ 335, an entry-level ADS-B Out model‭ with a version integrating an  internal WAAS GPS. If ADS-B‭ ‬In capability is required then the the GTX™ 345 transponder should be selected.

For additional information please refer to the Product Description section.

EASA Certified VHF transceiver in 160mm format with 6W output power. Automatic selection of 8.33kHz/25kHz spacing and OLED display.

The AV-534 is a TSO'd heavy-duty stainless steel bent whip VHF communications antenna with porcelain insulators and mounting hardware. The AV-534L is same antenna as AV-534 but furnished with 96" lead of RG58 A/U cable with male BNC and ground strap with lugs.

The LXNAV G–Meter  (accelerometer) is a standalone unit, designed to measure, indicate and log g–forces. The unit is offered in 57 mm or 80 mm diameters for installation into the aircraft instrument panel. It comes in two versions, standard and with flight recorder (FR).

The LXNAV G–Meter has an integrated high precision digital pressure sensor and inertial system. The sensors are sampled more than 100 times per second. Real Time Data is displayed on a QVGA 320x240 pixel 2.5″ high brightness color display. To adjust values and settings the LXNAV g–meter has three push buttons with fixed functions. The top button is ESC (CANCEL), the middle is to switch between modes and the lower button is the ENTER (OK) button.

The unit's inertial platform integrates a  ±8g accelerometer. Device is showing current g–load in navbox/needle and it’s min-max values in bar. Last flight min/max load navboxes are persistent till next flight. Min/Max limits with Warning zones can be defined.

Real Time Data is displayed on a QVGA 320×240 pixel 2.5-inch high brightness color display.

The Logbook menu displays the list of flights. If the RTC time is set properly the take-off and landing time shown will be correct. Each flight item consists of the maximum positive g–load, the maximum negative g–load from the flight and the maximum IAS. This function is available only with “FR” version.

Product Features:

• An extremely bright 2.5″ QVGA color display readable in all sunlight conditions with the ability to adjust the backlight.

• Three push buttons are used for input.

• RS232 input/output.

• Micro SD card

• 320x240 pixels color screen for additional information such as minimum and maximum g–force

• Built in RTC (Real time clock)

• Logbook

• 100Hz sampling rate for very fast response.

• Power supply cable included

AERA 510 is one of GARMIN older models of portable gps and availability is subject to remaining stocks. Please refer to other AERA gps offered. It is a dual duty portable gps combining the best in moving-map display features with intuitive, menu-driven touchscreen control. It features a 4.3-inch QVGA wide-format touchscreen and preloaded graphical mapping, support for NEXRAD imaging, SiriusXM satellite weather and optional SiriusXM Satellite radio with 170+ channels of digital music, news and other programming. The following navigation databases (ordered separately) can be used:

Americas - North, South and Central America (includes Alaska & Hawaii)

Atlantic International - Europe, Africa

Pacific International - Eastern Europe, Asia, Middle East and the South Pacific (includes Hawaii)

Discontinued. No longer available in NEW condition apart from existing stocks. Limited Availability.

1-1/4 inch TSO'd Electronic Fuel Pressure Gauges from UMA INSTRUMENTS. Black & White dial marking. Available in different pressure (PSI) ranges. Case: Aluminum. Weight: 4.0 oz. UMA sensors are sold separately.

HONEYWELL BENDIX KING® KNI-582 Radio Magnetic Indicator (RMI) provides bearing information to either ADF or VOR stations by means of two pointers each of which is read against compass card. The KNI-582 RMI requires inputs from ADF, HSI and NAV receivers and combines three data points on one indicator. The current aircraft heading from an HSI is shown on the card. The magnetic headings to VOR and NDB stations are shown by the twin needles. By combining all this information visually, less interpretation is required thus enhancing overall situational awareness, something especially helpful when the workload is high.

Product Features:

Dual pointer RMI

Accepts AC SIN/COS, DC SIN/COS, Serial, and VOR Composite inputs

Compatible with NAV Receivers such as KN-53, KNS-80, KNS-81, KX-155/165, KX-170B/175B, KNR-615, KNR-630, KNR-634, KNR-665, KNR-665A

Compatible with ADF receivers such as KR-85 (w/ KI-227 -01/04), KR-87, KDF-800/805/8000

Compatible with Compass Systems and NAV indicators such as KCS-305, KCS-55/55A, and KPI-550

Models available with 5 or 28 volt lighting

Models available with black or gray bezel

TACAN compatible and night vision goggle versions available

TSO'd

Specifications:

Altitude: To 50,000 feet

Operating Temperature: -20 to +55°C

Weight: 3.0 lbs. (1.4 kg)

Power Requirements: 28V 4A / 26VAC 6VA

TSO Compliance: Env. Cat. RTCA DO-160A A1D1/A/SKP/XXXXXSABAAA; TSO C6c (compass); TSO C41c Class A (ADF); TSO C40a (VOR)

Compass Heading Input: Operates from any slaved magnetic compass with ARINC X,Y,Z outputs.

UMA NON TSO'd Electronic Amp Meter Gauges (Ammeters) are available in different series for different measurement ranges and installation in different panel hole diameters. 1-1/4" series allow utilization of panel space without compromising readability. They can be powered from 14 or 28 volts. Signals are acquired from remote mounted sensors, processed and displayed on analog dials with easy to read markings. Each gauge uses rugged aircore meter movement for vibration resistance and repeatability. Each gauge can be placed in a 1-1/4” diameter hole and mounted behind the panel with (4) 6-32 screws. They can be cluster mounted as close as 11/2” centers. Also available as new manufacture electric with 2-1/4" dia. Other UMA series of electronic ammeters include 2-1/4" series with moving coil and 85° Sweep and 2-1/4" Dual Amp/ 0-30 volt meters with moving coil  and 85° sweep.

NOTES:

These ammeters come with the suitable shunt. Different shunts are used depending on ammeter part number.

All Part Numbers beginning with the letter "T" are TSO'd for Certified Aircraft.

SAFE FLIGHT (SF) is the world's leading manufacturer of aircraft lift instrumentation and control systems. SAFE FLIGHT FAA certified Lift Detectors & Angle of Attack (AoA) Sensors are installed on hundreds of aircraft worlwide.

SF’s Lift Detector is the foundation of SAFE FLIGHT’s Stall Warning systems. This was the first and still the industry standard for stall warning in light aircraft. It  consists of a small tab or vane which senses the change of the stagnation point on the wing and an alerting device used for stall warning. The  detector warns by light and horn of any danger of an approaching stall regardless of the flight maneuver. It comes in different variations complete with installation kit & instructions.

SF’s SCc Angle of Attack (AoA) system meets FAA requirements by providing both flashing red LEDs and an unmistakable audio output to alert the pilot of increasing AoA and an impending stall. It consists of two key components, the Lift Transducer and the the Indexer Computer. Available for retro-fit. Including the Lift Transducer, the Indexer Computer, and all necessary wiring, connectors and installation hardware.

For additional information please refer to the Product Description section and the supplied documentation.

Stratus ESG digital transponders by APPAREO have been designed with non-glass panel aircraft in mind. Different models are offered for non certified and certified aircraft. Stratus ESG transponders feature 1090 ES (Mode-S extended squitter), 310 W nominal power output, a built-in WAAS GPS, compliance with global mandates for ADS-B Out transponders, push-button operation with modern keypad makes entering a squawk code easy, easy-to-use interface and pressure altitude monitor. Their form-factor enables easy replacement for existing transponders.

Version for non certified aircraft is offered as unit only or together with wire pigtail.

The version for certified aircraft is TSO'd and can be used to replace existing transponders in a wide range of aircraft models from different aircraft manufacturers like Cessna, Piper, Beechcraft, Mooney, Diamond and others. Certified units can only be shipped to a certified Appareo installer.

Product Specifications:

Bezel Height: 1.69 in. (43 mm)

Bezel Width: 6.38 in. (162 mm)

Depth: 10.75 in. (273 mm) front of panel to connector backshell

Weight: 3.29 lbs. (1.49 kg) including rack and connectors

Operating Temperature: -20°C to 55°C

Storage Temperature: -55°C to 85°C

Power Input: 9.0 to 36.0 VDC, 15 W typical

Cooling Input: No fan required

Environmental Compliance: DO-160G

Software Compliance: DO-178B Level C

Hardware Compliance: DO-254 Level C

TSO Compliance: C112e (Level 2els, Class 1), C145d (Class Beta 1 GPS/WAAS), C166b (Class B1S)

Display: OLED

Transmitter Power: 310 W

GARMIN® GTX™ transponder product line includes Mode A/C and Mode S TSO'd panel mounted transponders offered in a‭ ‬wide variety of configurations to choose‭ ‬from‭, ‬depending on desired functions‭.‬ Different models are listed under separate product presentations.

GARMIN® GTX™ 327  is a TSO-certified Mode C digital transponder. Its innovative features, proven performance and reliability bring a whole new level of transponder utility to your aircraft. Features include a solid state design, and with no warm up time, lower power consumption and much lower heat emissions for a longer service life. It provides 200 watts nominal power output and has an easy-to-read DSTN liquid crystal display which reverses the numbers out of black for optimal viewing. An innovative keypad facilitates entering a squawk code while a dedicated VFR button allows for quick-and-easy VFR squawking. Similar to the GTX™ 330 Mode S transponder, the GTX™  327 also offers several timing and display functions, including flight time, count-up and count-down timers, as well as current pressure altitude.

GARMIN® GTX™ 327 Specifications:

Solid State Digital Transmitter

Mode: A/C

Display: DSTN LCD Display

Nominal Output Power: 200 watts

Dimensions: 6.25"W x 1.65"H x 8.73"D (15.9 x 4.2 x 22.2 cm)

Weight: 3.1 lbs. (1.4 kg)

Product includes: GTX 327 Transponder, Installation kit, Pilot's guide

PS ENGINEERING has revolutionized audio control in general aviation airplanes. At that time, the original PMA6000 took the audio panel from a collection of switches added as an afterthought, to a multitalented intersystem focal point for cockpit audio.

Radio selection, cockpit communications and even music were seamlessly combined in the modern audio control panel. The PMA6000-series set a benchmark for all GA audio panels that followed.

The next generation PMA6000B benefits from PS Engineering's long experience of audio panel control design and manufacturing experiences. It is an excellent low cost audio panel alternative to the higher end systems that PS Engineering has become so famous for.

The PMA6000B combines an audio selector panel with a top-quality manually adjusted 4 place VOX mono intercom and a slew of features to enhance versatility and utility. The PMA6000B holds both FAA TSO as well as EASA ETSO and was designed to be made easier to install because of a single 44-pin Sub-d connector. Different PMA6000B models offered with or without marker beacon receiver.

Product Features:

Built-in 4 place mono intercom PS Engineering's ""Set-it and Forget-it"" manual VOX

Optional built-in marker beacon receiver

Split mode for dual audio capability

2 - Com Capability

3 - Intercom isolation modes - Pilot Isolate, All, and Crew

2 - Music inputs with Soft Mute™

2 - Unswitched inputs

6 - Switched inputs

A patented ""swap"" function allows selection of Com 1 or Com 2 from remote pushbutton

Fail-safe feature automatically hard-wires the pilot to Com1 in the case of an outage

Single 44-pin connector making installation easier

Certification: FAA TSO/EASA ETSO

Warranty: 24 months

The PS ENGINEERING PMA7000 series of TSO'd audio panels offer a very affordable upgrade for existing BENDIX KING KMA24 units while providing a a great set of capabilities. The PMA7000B with built in Marker Beacon is KMA24 pin compatible. Existing wiring to the KMA24 can be maintained making the cost of the upgrading less expensive. In addition, it is plug and play with the original PMA7000M-S, the PMA6000M-S, and the KMA28 audio panels. PMA7000 series audio panels feature  6-place IntelliVox® automatic Voice Operated Relay (VOX) hi-fi stereo intercom system with Soft Mute™. The PMA7000B provide 3-com capability with the option to easily convert Com 3 to a full duplex cellular telephone interface  and "Split Mode" allowing the pilot to be on Com 1 while the copilot is on Com 2.

Product Features (depending on model selected):

IntelliVox® automatic VOX system with individually gated microphones

6 - Place hi-fi stereo intercom with Soft Mute™

Bluetooth(R) Interface (Model PMA7000BT) allowing music streaming as well as interconnect to an iPhone, iPad, iPod, or any other Bluetooth(R) enabled device that has the Handsfree or A2DP profile.

2 - music mute modes: Mute On and Mute Off

Built-in Marker Beacon Receiver

Cellular telephone input with dedicated On/Off hook switches for unprecedented flexibility

Split mode for dual audio panel capability

2 Hi-fidelity stereo music source inputs

3 - Isolation modes - Pilot Isolate, All, and Crew

4 - Unswitched inputs

Selectable music muting for passengers

Selectable special intercom mode with ""Alternate Intercom Mode""

RAM (Radio Active Mute) eliminates constant back ground noise from radio static

The only knob that is on the panel is a concentric volume control for the Crew and Passengers intercom volume. The all push button controls of the PMA7000B allows for easy selection of Coms and other Nav aids.

Certification: FAA Export 8130-3

Warranty: 24 months

EASA Certified VHF transceiver with 6W output power and 8.33kHz frequency spacing.

UMA Electronic Hydraulic Pressure Gauges are offered in TSO'd and Non TSO'd models and 1-1/4"  or 2-1/4" diameters to fit respective aircraft panel openings. They are housed in aluminium or Valox 420 plastic cases (depending on the model) and connect to  precision, high pressure transducers which mount directly to the aircraft's hydraulic system. Standard markings are black and white. Recommended for new design projects and applications.

Note: Pressure Transducers (Senders) ARE NOT INCLUDED in the prices of the pressure gauges. They are sold separately and are not TSO'd.

Sigma-Tek Light tray to connect lighting to Sigma-Tek 5000B Attitude Gyro and other avionics and instruments. Available in 14V or 28V versions.
