The analog and digital portable two-way radios (walkie talkies), manufactured by QUANZHOU YANTON ELECTRONICS CO., LTD., come in different models covering UHF or VHF and UHF frequency bands and different power outputs for communication over different distances. They have an ergonomic design and cover the needs of various operations. YANTON radios are approved by the Ministry of Information Industry in China and the European CE, RoHS and USA FCC certified/approved for use in other countries.

ETSO'd Slimline Panel Mounted 16 W VHF Radio with built in 2-place intercom with auxiliary inputs for stereo music and audio warnings. Available with 8.33 kHz or  25kHz frequency spacing options.

The MID CONTINENT® INSTRUMENT (MCI) 3" TSO'd Turn Coordinators are value priced  and engineered for reliability and a long service life. Depending on the model, they can be a direct replacements for most coordinators with 3-pin or 5-pin connectors.

These instruments show  a standard 2 minute turn when balance ball reaches either side of display. MCI turn coordinators feature a HEA non-glare glass screen for easy readings, an operating range of temperatures from -30 to +50 deg. C and altitude-1000 to 35000 ft and they can operate on a voltage range from 10-32 VDC for convenience. Power consumption is 0.28 A. They can be front or rear panel mounted in a 3 1/8" hole. Dimensions: 3 1/4"X3 1/4"X5". Max Weight: 1.4 lbs. Available in lighted and unlighted versions. FAA TSO certified to C3b.

The “B” models are equipped with a proven AC rotor powered by a solid-state inverter, creating less heat behind the panel. Utilizing a brushless rotor design, these models exhibit top industry ratings of 4,800 hours MTBF. They are ideal for use in high performance aircraft and cold-climate applications.

The TT31 is a power-efficient, inexpensive, Mode S transponder by TRIG AVIONICS  that meets the European elementary surveillance requirements. The TT31 fits in the same mounting tray as the BENDIX KING KT76A transponder, making it a great choice for either upgrades or new installations. The TT31 plug and play design minimises the cost and downtime for the upgrade. The TT31 is TSO approved for fitting to European and FAA registered aircraft. With a new software upgrade and a connection to an appropriate GPS, this will make the TT31 compliant with the FAA final rule on ADS-B Out (TSO C166b) for 2020.

Product Features:

European Mode S (*)

Low Power Consumption

No Cavity Tube

240 Watts Nominal Output

Plug and Play Installation

Backlit LCD Display

Easy to Use Rotary Knobs

Timer/Stopwatch Function

Altitude Monitor

Certified 1090ES/ADS-B Out (TSO C166b)

NOTE (*): All Mode S transponder upgrades for EASA certified aircraft must be carried out by a licensed engineer using a Minor Change approved by EASA.

Pre-approved Minor Changes for popular aircraft types may be available for this device. In this case no EASA fees for the issue of Minor Change approval apply. Contact us for more information.

This 2-1/4 inch flap indicator uses a resistance potentiometer as a flap position sensor. Transmitter is required. Wt: 9.8 oz.

The FLIGHTCOM 403MC is a 4-place panel mount, easy to use, voice-activated mono intercom with 3-position transmit capability designed to fit almost anywhere in the panel.

The RAY ALLEN (RAC) RP4 LED position indicator is designed to be installed in the cockpit providing an indication of the servo output shaft position. This indicator supercedes and it is a direct replacement for previous RAC RP3. The RP4 indicator uses ten LED lights to show the position of a actuator output shaft (or position sensor arm). There are also two amber colored LED's, one on each end of the indicator scale, to act as a reference for the green indicator light, especially in dark conditions. The 10 LEDs are the brightest available for superior visibility in sunlight, but can be dimmed for night flight. It can be installed horizontally or vertically.

The RAC RP4 position indicator is panel mounted using a faceplate and two countersunk, 2-56 x 7/16" screws (two spare finishing screws are included). The distance between the screw holes is identical to the older Ray Allen RP3 LED indicator. Although the faceplate dimensions are identical between the RP3 and RP4 indicators, the panel cutout size is slightly different between the RP3 and RP4. If you are replacing and older unit with a new RP4, you will only need to increase the size of your panel hole. The RP4 faceplate will cover the older RP3 panel hole.The RP4 faceplate measures 1.75"(45 mm) X .75"(19 mm) and it is 1.6"(41 mm) in depth. It is now the standard position indicator included in Ray Allen trim systems, or can be purchased separately for special applications such as a cowl or wing flap indicator.

The RP4 includes a RP4-L1 label (featuring Elev1, Elev2, Ail, Rudder, Flaps). A RP4-L2 label (featuring Cowl Flaps, < >, on/off) is also available and is sold separately.

NOTE: Labels can only be ordered together with . In ordering these high quality labels please be advised that rocker switches and needle indicators require a large label, LED indicators use a small label. Can be only included in orders of respective RP4 position indicator(s) (not separately).

Sourced from quality manufacturers, our own branded (AVIATIONEU NEA ERA) aviation (air crew) headsets are offered in two main families or series  (100 and 400) each with PNR and ANR models suited for use in fixed and rotary wing aircraft.

Two different plug types are offered, PJ-055/PJ-068 dual plugs widely used in General Aviation and other airplanes and Military grade U174 plug used on helicopters and military aircraft.

With their competitive prices, advanced design and features, quality materials and rigid construction, AVIATIONEU NEA ERA headsets combine performance, functionality and comfort to provide cost effective solutions for air crew communications.

ANR models (*) are offered with or without Bluetooth capability for music and mobile communications. All our headsets are accompanied by the Manufacturer and our Certificate of Conformance and come with a 12-months manufacturer warranty.

100 Series

AVIATIONEU NEA ERA 100 Series of aviation headsets includes PNR model 100 (GA) with dual plugs for airplanes and 100 (H) with U174 plug for military/helicopter operations. They feature  23dB and 24dB  noise reduction ratings respectively. 100 Series PNR headsets are Low cost, entry level headsets, ideal for General Aviation pilots and flight schools. Their ANR counterparts (Models 100A (GA) & 100A (H) are offered with a 29dB noise reduction rating and without or with Bluetooth capability, indicated by the letters "BT" in the product reference number (SKU). Pilots' style requirements are also covered through multiple colors, with Grey/Black (commonly stocked) and Green/Pink/Red/Yellow/Blue (On Demand as special order).

400C Series (Ultra Light Carbon Fiber Aviation Headsets)

Combining high performance, modern design, robust construction and an ultralight weight (only 9oz, 255g) the AVIATIONEU NEA ERA 400C series headsets are intended for use in air transport and military operations or by demanding pilots who seek high performance, functionality and confort headsets with an ultra light weight. Offered in carbon fiber black color. Various models include:

400C (GA) and 400C (H) PNR and 400AC (GA) and 400AC (H) ANR headsets offered with dual plugs and U174 single plug respectively and a noise reduction capability of 23dB (400C PNR) 29dB (400AC ANR).They come with or without Bluetooth capability.

AVIATIONEU NEA ERA 100 Series headsets are included in this listing while 400 Series headsets are separately listed. Please refer to the additional information and specifications provided or contact us.

(*) ANR function is powered by an AA battey in a supplied battery box with toggle switch. The headset will shut off automatically when unplugged from the battery box, manually turned off from the toggle switch or when the radio or avionics master switch is turned off.

SAFE FLIGHT (SF) is the world's leading manufacturer of aircraft lift instrumentation and control systems. SAFE FLIGHT FAA certified Lift Detectors & Angle of Attack (AoA) Sensors are installed on hundreds of aircraft worlwide.

SF’s Lift Detector is the foundation of SAFE FLIGHT’s Stall Warning systems. This was the first and still the industry standard for stall warning in light aircraft. It  consists of a small tab or vane which senses the change of the stagnation point on the wing and an alerting device used for stall warning. The  detector warns by light and horn of any danger of an approaching stall regardless of the flight maneuver. It comes in different variations complete with installation kit & instructions.

SF’s SCc Angle of Attack (AoA) system meets FAA requirements by providing both flashing red LEDs and an unmistakable audio output to alert the pilot of increasing AoA and an impending stall. It consists of two key components, the Lift Transducer and the the Indexer Computer. Available for retro-fit. Including the Lift Transducer, the Indexer Computer, and all necessary wiring, connectors and installation hardware.

For additional information please refer to the Product Description section and the supplied documentation.

Range of special accessories by FRANZ AIRCRAFT ENGINES for use in BRP-ROTAX® aircraft engines and other applications.

The SIRS "Navigator" magnetic compass delivers extremely accurate readings due to its fully integrated, 4 magnet correction facility.  It has the same features as the "Pegasus", but is mounted with a fully adjustable bracket that allows attachment to a variety of positions including the glare-shield or the windshield. This allows the compass to be located away from magnetic influences. Available in different versions for Northern or Southern hemisphere, unlighted  or lighted 12/28V and has a 3-year warranty. Size: 203/8" H x 2-1/4" W. Product accessories such as installation kit, GS1 glareshield mount, SIRS MF1 short foot bracket and SIRS compass correction key are also available and sold separately.

White LED White LED Anti-Collision Head Light Assemblies by WHELEN AEROSPACE TECHNOLOGIES (WAT) consist of the Anti-Collision Light (P/N: 01-0771987-00) and the Flasher Assembly  (P/N: 01-0771985-17) sold separately. They are designed to replace the legacy strobe light (01-0770818-00) and power supply (01-0770006-12 and 01-0770006-17) system on Cessna single engine restart aircraft 1996 & newer. FAA/PMA Approved. When replacing either the 01-0770818-00 strobe assembly or 01-7000617 power supply, both 01-0771985-17 and 01-0771987-00 are needed to convert to LED.

Technical Specifications:

LED Color - Aviation White

Current Draw: 28 Volts 0.3 amps avg.

Dimensions:

01-0771987-00 Anti-Collision Light: L 3.17" (81mm) x W 1.42" (6mm) x H 1.18" (30mm)

01-0771985-17 Flasher Assembly:  L 3.93" (100mm) x W 3.10" (79mm) x H 1.38" (35mm)

Weight:

01-0771987-00 Anti-Collision Light: 0.14 pounds

01-0771985-17 Flasher Assembly: 0.48 pounds

MITCHELL AIRCRAFT PRODUCTS, Inc. is a well known manufacturer of tachometers, gauges, and instruments the general aviation industry, built under an FAA-approved quality system.

Their product range includes:

Mechanical 3-1/8″ Clockwise, & Counter-Clockwise, 2, 2-1/4″ Mechanical Recording & Electric Lighted Tachometers,

Electric Gauges (Ammeters, Cylinder Head Temperature, Exhaust Gas Temperature, Fuel Quantity Gauges, Outside Air Temperature, Pressure & Temperature Gauges, and Voltmeters,

Mechanical Pressure &Temperature Gauges

Modular Gauges (Ammeters, Blank, Fuel Quantity,Pressure, Temperature Gauges, and Voltmeters, Modular Gauge Frames. This line of FAA PMA  miniature square engine gauges is ideal for a wide variety of general aviation applications. They measure nearly 1-1/2″  and are stackable. The modular design allows them to be plugged from the front of the panel. The units are internally lighted. Complete standard panels are also available. If individual gauges are ordered, appropriate backplate with pigtail must be ordered to mount and connect the gauge. If more than one gauge are ordered to be mounted together, a special order clustering requires custom backplates.

Sending Units (CHT & EGT Thermocouples, Fuel Quantity & Pressure Senders, 1/8″ & 5/8″ Temperature Senders.

MITCHELL FAA PMA'd D1-211 Series  modular 1-1/2 " fuel quantity square  gauges can be stacked in horizontal and/or vertical rows in any position in the aircraft panel. These  modular gauges are internally lighted and are plug removable from the front of the panel for easy maintenance. Available in different sender resistances for the indication of fuel quantity in the aircraft's left or right fuel tank.

MITCHELL FAA PMA'd D1-211 Series  modular electric 12V (PN D1-211-5074) & 24V (P/N PE-111-4074) fuel quantity gauges are lighted and easily installed in a 2-1/4" panel hole. They feature a 2 year factory warranty.

The gauges and senders must be ordered separately.

For the 12V Fuel Quantity Gauge D1-211-5074 the matching sender is PS-211-8038, 10-180 Ohm. For 24V operation, P/N PE-111-4074  resistors for each instrument must be ordered.

MITCHELL Pressure Senders 80 PSI (PN PS-211-9002) and 150 PSI (PN PS-211-9040) are offered for use with D1-211-6089 and D1-211-6092 FAA PMA Pressure Gauges respectively. Both have 2 terminals (one terminal to be grounded).

MITCHELL EGT Gauge 0-1600 Deg. F, PN D1-211-6101 requires PN PS-211-8162 sender (probe).

In addition to their panel mounted VHF transceivers, ICOM RADIOCOMMUNICATIONS offers handheld transceivers for aviation & marine applications. Their ICOM A25 series are powerful air band handheld transceivers offered in communications only (A25C) or NAV/COM versions (A25N) with 6 watts of power and an IP57 waterproof rating. They include a large 2350mAh Li-ion battery, providing a long operating time. The easy-to-use interface and large 2.3-inch LCD display combine to provide stress-free programming and in-flight operation. Built-in Bluetooth®, GPS and VOR navigation. ICOM A25 transceivers come with Antenna, Belt Clip, Handstrap, Battery Case, Battery Pack, Headset Adapter, Power Adapter and Battery Charger. ICOM IC-M25 VHF Marine transceiver is a slim depth light weight floating marine radio, floatable into the water with  flash and sound alarms. With its IPX7 waterproof construction, the 700 mW audio output, 11 hours of battery life, buoyancy in water and many other features it can effectively serve a wide range of marine applications. For additional information please consult the Product Description section.

The HONEYWELL BENDIX KING® KY 196A/197A series of TSO'd VHF COMM transceivers have a flatpack design, measure 1.3" x 6.3", weight just 2.8 pounds and have the same capabilities except that the 28-volt KY 196A delivers 16 watts and the 14-volt KY 197A 10 watts minimum transmit output power. Both incorporate solid-state construction and feature 9 pilot-programmable memory channels (11 including those in "USE" and "STBY"), flip-flop frequency transfer between active and standby frequencies, a 118.00MHz to 136.975MHz operating range and a digital frequency synthesizer generating 760 COMM frequencies. Despite their wide range of capabilities, KY 196A/197A radios were designed to be easy to read and logical to operate. An audio leveling feature automatically amplifies weak audio signals and mutes strong signals. Racks & connectors (for new installations) and manuals are sold separately.

The HONEYWELL BENDIX KING® KY 196A/197A  VHF COMM transceivers are available in different versions  including those with Silver Crown Plus faceplates. They can be furnished in NEW condition or as USED in Serviceable or Overhauled conditions indicated respectively by the letters "SV" and "OH" in the product reference numbers (SKU and  accompanied by the relevant certification (e.g. yellow tag, 8130-3 form). They are also offered as exchanges / trade-ins  for returned customer owned units indicated by the letter "EX" in the SKU.  In the case of an exchange/trade-in option of a customer unit, the  full selling price of the ordered unit is charged and the core credit is refunded or credited towards future orders when our co-operating supplier verifies that the unit is in a reasonable, repairable condition. It is recommended that this option is selected by our customers mainly for upgrades and only in cases when their units are functioning properly at the time removal from the aircraft. In cases when customer units are found by our supplier to be non-repairable, the core deposit shall not be refunded and shipping charges shall apply if customers wish the return of these units to them. Please refer to the Product Description section for technical specifications and information on USED avionics.

HONEYWELL BENDIX KING® manufactures a range of TSO'd VOR/LOC/Glidescope indicators. These navigation instruments include VOR/LOC left-right needles, To-From indicator, VOR/LOC warning flag, glideslope deviation needle, glideslope warning flag and 30Hz OBS resolver. Depending on the model, the feature rectilinear instead of pendulum type meter movements for more precise indicator readings, 14/28 volt internal lighting, metal bezel with glass lens and course datum synchro for autopilot use.

These indicators are commonly used with BENDIX KING® remote mounted VOR/LOC converters such as KN-72 or KN-77, remote mounted Glideslope Receivers such as KN-73 or KN-75, KNS-80, KNS-81 nav systems and KX-155/KX-165 NAV/COMM transceivers.

The KI203 model features an internal VOR/ LOC converter and it is compatible with the BENDIX KING® KX155 transceiver. It has a rectilinear meter movement. Compatible with the BENDIX KING KX155 NAV/COMM transceiver.

The KI 204 VOR/LOC/Glideslope Indicator features a built-in VOR/LOC converter and scallop rejection filter, rectilinear needle movement and an optically coated glass lens. Requires input from external glideslope receiver. Compatible with the BENDIX KING® KX 155 or KX 155A NAV/COMMs. Requires input from external glideslope receiver.

The KI 206 VOR/LOC/Glideslope Indicator is rectilinear and internally lighted. It is used with the KNS 80/81 units, KX 165  transceiver and the KNR 634 VOR/LOC/GS/MB receiver. It is available with course datum synchro.

The KI208 model features a built-in VOR/ LOC converter and it is compatible with the BENDIX KING® KX 155 or KX 155A NAV/COMMs. It has a  pivoted needle action and a plastic lens.

The KI209 model features an internal VOR/ LOC converter and it is compatible with the BENDIX KING® KX155 transceiver. It features a pivot needle action.  The KI209 model includes GPS interface capability.

EASA Certified VHF transceiver with 6W output power and 8.33kHz frequency spacing.

SWIFT AIRCRAFT manufactures Swift two-seater low wing composite aircraft with striking elliptical wings and double curvature surfaces. Comfortable, safe and environmentally sound they are designed and manufactured entirely in the UK, and available globally,

The company also manufactures Swift aircraft gauges specializing in precision-engineered gauges, including Exhaust Gas Temperature (EGT) and Cylinder Head Temperature (CHT) gauges, commonly used in aviation.

PS ENGINEERING has revolutionized audio control in general aviation airplanes. At that time, the original PMA6000 took the audio panel from a collection of switches added as an afterthought, to a multitalented intersystem focal point for cockpit audio.

Radio selection, cockpit communications and even music were seamlessly combined in the modern audio control panel. The PMA6000-series set a benchmark for all GA audio panels that followed.

The next generation PMA6000B benefits from PS Engineering's long experience of audio panel control design and manufacturing experiences. It is an excellent low cost audio panel alternative to the higher end systems that PS Engineering has become so famous for.

The PMA6000B combines an audio selector panel with a top-quality manually adjusted 4 place VOX mono intercom and a slew of features to enhance versatility and utility. The PMA6000B holds both FAA TSO as well as EASA ETSO and was designed to be made easier to install because of a single 44-pin Sub-d connector. Different PMA6000B models offered with or without marker beacon receiver.

Product Features:

Built-in 4 place mono intercom PS Engineering's ""Set-it and Forget-it"" manual VOX

Optional built-in marker beacon receiver

Split mode for dual audio capability

2 - Com Capability

3 - Intercom isolation modes - Pilot Isolate, All, and Crew

2 - Music inputs with Soft Mute™

2 - Unswitched inputs

6 - Switched inputs

A patented ""swap"" function allows selection of Com 1 or Com 2 from remote pushbutton

Fail-safe feature automatically hard-wires the pilot to Com1 in the case of an outage

Single 44-pin connector making installation easier

Certification: FAA TSO/EASA ETSO

Warranty: 24 months
