UMA NON TSO'd Electronic Amp Meter Gauges (Ammeters) are available in different series for different measurement ranges and installation in different panel hole diameters. 1-1/4" series allow utilization of panel space without compromising readability. They can be powered from 14 or 28 volts. Signals are acquired from remote mounted sensors, processed and displayed on analog dials with easy to read markings. Each gauge uses rugged aircore meter movement for vibration resistance and repeatability. Each gauge can be placed in a 1-1/4” diameter hole and mounted behind the panel with (4) 6-32 screws. They can be cluster mounted as close as 11/2” centers. Also available as new manufacture electric with 2-1/4" dia. Other UMA series of electronic ammeters include 2-1/4" series with moving coil and 85° Sweep and 2-1/4" Dual Amp/ 0-30 volt meters with moving coil  and 85° sweep.

NOTES:

These ammeters come with the suitable shunt. Different shunts are used depending on ammeter part number.

All Part Numbers beginning with the letter "T" are TSO'd for Certified Aircraft.

For use with most GPS and TAWS systems. Works well with most of today's mode S transponders.

Accelerometers (aka G-Meters) are used extensively in a wide range of applications including Aviation, Marine, Automotive, Military, and others. They are also used  in inertial navigation and guidance systems in airplane and ship autopilots.They help in a better understanding of static, such as gravity, or dynamic forces due to motion or vibration acting on an object.

Original Mechanical and more recent Digital accelerometers, used on civil and military aircraft, measure the instantaneous acceleration (or G-force) of an aircraft and its occupants compared to Earth's standard gravitational pull, in units of "G" (e.g., 1G, 2G). They enable pilots to monitor flight conditions, maintain safety, or practice aerobatics or combat maneuvers. Made by different manufacturers, they are offered as non-certified instruments, for use on  experimental and homebuilt aircraft, or certified products, installed on civil transport an military aircraft.

Mechanical accelerometers, included in this listing, use traditional components like proof masses, springs, and damping to measure acceleration based on displacement, offering high accuracy and durability for specific applications like flight stabilization and weapons communication. They are often of larger size and more expensive. Digital accelerometers, separately listed, are often Micromachined Micro-electromechanical (MEMS) systems, integrating sensors with microelectronic circuits for smaller size, lower cost, and high precision, making them ideal for flight stabilization, AHARS, and autopilot systems.

The choice of an accelerometer depends on the application's need for accuracy, size, cost, and resistance to harsh environments.

Please consult the Product Description section and the supplied documentation for more information on different brands of our offered accelerometers.

Connectors are used on electrical wiring harnesses and are essentially enclosures (i.e., shells) which house contacts with wires. The electrical connection into the system at the contact termination is either a soldered or crimped connection (the latter removable from the connector with the use of a special tool). The shell and insert may be moisture resistant or a hermetic seal. The inserts in each connector must be oriented for correct mating, and the shell or insert usually contains a keying feature to prevent miss-mating that could damage the connector or result in an electrical problem.

Connectors can be of a Plug (“male”) or Receptacle (“female”) type. Receptables are also termed as sockets or jacks. Plugs have prolonged connecting pins which fit into the mating sockets. Receptables have mounting features such as a flange with holes. Connectors used in aircraft are mostly those complying with Military Standards (MIL-STD) and Military Specifications (MIL-SPEC).

Different connectors, structured in series, are offered as part of our own branded (AVIATIONEU NEW ERA) product lines to provide cost-effective solutions for a variety of applications. Sourced by quality suppliers, they are available in plug or receptable types.

AVIATIONEU NEW ERA MIL Standard MS5015 series connectors meet MIL-C-5015 specification. They ensure high electrical capability and durability at an acceptable cost and can be used for a range of applications including military ground support equipment, aircraft installations and others. Available in different case sizes (10SL,14S,16S,18,20,22,24,28 and 32) and  sold by the piece (pc.).

Product Specifications:

Shock: 490 m/s2

Relative humility: 95+-4% at 40℃

Insulation resistance: 5.000 Mega ohms minimum (at 25°C)

Frequency Range: 10-2000Hz/147m/s2

Voltage Rating: 500VAC 700VDC

Mating Type: threaded coupling

Termination : Solder

Durability (mating) ≧ 500 cycles

Temprature Range:  -55°C ~ +125°C

The COBHAM Antenna Systems' COMANT product range includes aviation antennas focusing on GPS, Communications and Navigation products for General Aviation, light Jets and helicopters.COMANT antennas offer a wide variety of fit, form and function options that will fit nearly every need. Comant antennas are compatible with a number of varying applications and effective in a number of differing environments. The range includes Radiophone, DME, VHF, VOR, LOC, GS, DME, Transponder, FM, AM, UHF, L Band, ELT, and COMDAT antennas. COMANT Antennas have been re-tested and upgraded to the new RTCA DO-160D environmental requirements and offer the 118 to 137 MHz frequency associated with DO 186A MOPS. They no longer come with a gasket or template which must be ordered  order separately.

LONE STAR AVIATION manufactures multiple fans and blowers for OEM applications.

The CYCLONE 100 FAA-PMA approved 1 port blower is the smallest (1 x 2 x2 ), most efficient (brushless dc motor), and the most versatile cooling fan for avionics and or other electronics needing thermal cooling. Its universal mounting bracket makes it easy to set-up and install on on many make and model aircraft and or rotor-craft.  Also installed in Land-Mobile, Marine and Military Vehicles for many PED, radio, GPS applications. Offered in Input 12VDC/24VDC versions.

Lone Star Aviation's new FAA-PMA approved Cyclone 1 port blower is the smallest (1 x 2 x2 ), most efficient (brushless dc motor), and the most versatile cooling fan for avionics and or other electronics needing thermal cooling. Its universal mounting bracket makes it easy to set-up and install on on many make and model aircraft and or rotor-craft.  Also installed in Land-Mobile, Marine and Military Vehicles for many PED, radio, GPS applications.

The CYCLONE 21 FAA-PMA approved 3 port blower is a compact (3 x 3 x 1") aircraft electronics cooling fan that delivers 21 cubic feet per minute of forced air cooling to a variety of avionics equipment. It is the top FAA approved avionics blower for 14/28 volt aircraft with the smallest footprint and the highest output but also the number one choice for OEM and aftermarket sales world-wide for many make and model aircraft and rotor-craft.

For more information on the above products please consult the Product Description section and the supplied documentation.

WULTRAD INC. is a manufacturer of non-certified flight and engine instruments under FALCON GAUGE brand for experimental and homebuilt aircraft. Although their products are Non-TSO, they are made to TSO or MIL specifications for quality.

FALCON GAUGE  Electrical Turn Coordinator is used for displaying the angular rate and sideslip of turning in horizontal flying and turning. The inclinometer indicates the slip angle of the aircraft while in a turn. A power failure flag drops into view whenever the voltage drops below a level for proper operation. The Turn Coordinator incorporates a built-in voltage regulator so it can be used with either 14VDC or 28VDC power system. It is compact in size and light weight eliminating radio interference.

This small, lightweight unlighted turn coordinator is excellent for homebuilt aircraft. Works for 14 Volt or 28 Volt systems. Features, power out warning flag with a 0° Panel. Fits Standard 3-1/8" Cut Out, 3-3/4" long.

ETSO'd Slimline Panel Mounted 16 W VHF Radio with built in 2-place intercom with auxiliary inputs for stereo music and audio warnings. Available with 8.33 kHz or  25kHz frequency spacing options.

Automatic portable radio beacons (ELT(AP) АРМ-406П (ARM-406P), АРМ-406П1 (ARM-406P1) and АРМ-406АС1 (ARM-406AC1) are safety devices designed to transmit via satellite to the stations COSPAS-SARSAT distress radio signals with aircraft coordinates received from the onboard computer system.Such information facilitie identification of the aircraft and guidance of S&R facilities to the accident site. Located in the aircraft cabin these devices offer the possibility of quick use in an emergency.

The automatic portable radio beacon АРМ-406П1 (APM-406P1) includes:

- monoblock P, consisting of a double protective casing with shock absorbers installed in it, an overload sensor (DP) and an AC1A monoblock;

- remote control PDU-406 (ПДУ-406) installed in the cockpit;

- external antenna ANT-406VA (АНТ-406ВА), mounted on the aircraft body.

The АС1А monoblock is  a portable radio beacon, including a PM-AC1A (ПМ-АС1А) transmitting module, an АРМ-043-01 autonomous power supply unit and an ANT-APM-01 (АНТ-АРМ-01) antenna. The emergency mode of operation of the AC1A monoblock can be switched on both from the remote control and from the DP, as well as manually when removing it from the protective casing when leaving the emergency aircraft.

Autonomous power supply (APS) units are also offered for use with the radio beacons. АРМ-043 (CDKT.436140.590) 14.4V are intended for use for beacons manufactured before 2013 while АРМ-043-01 (CDKT.436140.590-01) 10.8V for beacons manufactured after 2013. Unless otherwise specified their replacement frequency is once every 3 years with a 3-year self life.

For additional information please refer to the supplied documentation or contact us.

BENDIX KING KG 102A TSO'd Remote Mounted Directional Gyro can be used in in BK KCS 55A compass system  in conjunction with KMT 112 Magnetic Azimuth Transmitter to provide a gyro-stabilized magnetic heading to KI 525A HSI.

The RCA 56 Series of electric turn and bank indicators by KELLY MFG (RC ALLEN) are an all volt instrument, with a power warning flag, a black or white ball inclinometer and either lighted or non-lighted. These rate-of-turn pointer controlled instruments are powered by an electrically driven DC precision gyro with an inclinometer providing the pilot with turn and bank information.  They meet or exceed requirements of FAA TSO C3b. Made in the USA. Weight: 1.9 lbs.

Dimensions: Length: 6 1/4 in. Max, Width: 3 3/8 in. Max, Height: 3 3/8 in. Max

Mating Connector: MS3106A10SL-3S.

Connector Pin Out: A: +11-30 VDC, B: Ground, C: Spare

The GARMIN® GTR series COMM TSO'd panel mounted transceivers (please see separate presentation) together with the GARMIN® GNC series NAV/COMM radios are replacement products for the popular SL30 and SL40 models. They include new features to reduce pilot workload, while also offering an affordable solution to meet the requirements of the 8.33 kHz channel spacing European Union mandate under the Single European Sky (SES) initiative. They are more powerful than their SL-series predecessors with 10- or 16-Watt transmit power available versions.

The GARMIN® GNC series NAV/COMM radios are offered with either a 10 W (GNC 255A) or 16W (GNC 255B) COMM featuring a 25 kHz or 8.33 kHz spacing. Both come with a an internal VOR/LOC converter, a 40-channel glideslope (GS) receiver and include the rack, connector kit, and back plate. They are offered as units only or as kits with a 4ft harness to AUDIO Panel.  If purchased with the 4ft harness, they can only be used  in experimental aircraft.

4-Pin connector by AMPHENOL for use in all electrical gyros (DG or Horizon) including Falcon models.

The R.A. MILLER (RAMI) TSO'd AV-74 (.425 Stud Length) & the AV-74-1 (.800 Stud Length) are broadband blade type antennas for transponders or DME applications. The antenna housing is constructed of an acrylonitrile-styrene-acrylic (ASA) shell. The white color allows maximum performance without losses due to color pigments or unseen dirt. The antennas are supplied with cellular neoprene mounting pad and hardware. Designed to operate at speeds up to 350 mph and altitudes up to 50,000 ft. They have a drag force of 0.09 lbs @ 250 mph. These antennas are direct replacements for the CI-105 antennas.

Product Specifications:

Application: Transponder/DME

Frequency: 960 - 1220 MHz

Impedance: 50 Ohms Nominal

VSWR: 1.5:1 Maximum

Polarization: Vertical

Pattern: Omni-Directional

Connector: "BNC" Female

Max Height: 3.4"

RF Power Capacity: 2.5 kW Peak

FAA TSO: C66c, C74c

The PAI-700 TSO'd Vertical Card Compass is manufactured exclusively by Precision Aviation, Inc. This non-liquid (dry) type compass is magnet driven thus it is subject to lead and lag, however, these tendencies are greatly reduced due to the absence of pendulosity.  It is inherently stable due to the use of eddy current damping which is a natural phenomenon built into the basic design and as such has no overshoot. The PAI-700 has been designed to replace the float/liquid type compasses eliminating leaking fluid or backward azimuth readings. Available for Southern and Northern Hemisphere and different supply systems (5V, 14V and 28V). Precision Avionics Inc. also manufactures different compass brackets for overhead or glare shield mounting.

The Precision PAI-700  Vertical Card Compass consists of a 2" vertical rotating dial which is compared with a fixed miniature airplane (lubber line) to present the magnetic heading of the aircraft at all times. Heading information is more natural because the heading is read at the12 o'clock position and off the nose of the miniature aircraft. The compass card rotates and presents all quadrants in their true relation to line of flight. Requires no power (except for lighting) to operate. Installed in many current production aircraft & helicopters. Size: 2-7/8"H x 2-3/8"W x 2-1/8"D. Wt. 0.6 lb. After installing compass must be compensated using standard compensation procedures. Also used in sailplanes.

Note: Compass deviation card is included. A mount, sold separately, is required for installation with the unit.

The LXNAV G–Meter  (accelerometer) is a standalone unit, designed to measure, indicate and log g–forces. The unit is offered in 57 mm or 80 mm diameters for installation into the aircraft instrument panel. It comes in two versions, standard and with flight recorder (FR).

The LXNAV G–Meter has an integrated high precision digital pressure sensor and inertial system. The sensors are sampled more than 100 times per second. Real Time Data is displayed on a QVGA 320x240 pixel 2.5″ high brightness color display. To adjust values and settings the LXNAV g–meter has three push buttons with fixed functions. The top button is ESC (CANCEL), the middle is to switch between modes and the lower button is the ENTER (OK) button.

The unit's inertial platform integrates a  ±8g accelerometer. Device is showing current g–load in navbox/needle and it’s min-max values in bar. Last flight min/max load navboxes are persistent till next flight. Min/Max limits with Warning zones can be defined.

Real Time Data is displayed on a QVGA 320×240 pixel 2.5-inch high brightness color display.

The Logbook menu displays the list of flights. If the RTC time is set properly the take-off and landing time shown will be correct. Each flight item consists of the maximum positive g–load, the maximum negative g–load from the flight and the maximum IAS. This function is available only with “FR” version.

Product Features:

• An extremely bright 2.5″ QVGA color display readable in all sunlight conditions with the ability to adjust the backlight.

• Three push buttons are used for input.

• RS232 input/output.

• Micro SD card

• 320x240 pixels color screen for additional information such as minimum and maximum g–force

• Built in RTC (Real time clock)

• Logbook

• 100Hz sampling rate for very fast response.

• Power supply cable included

TKM AVIONICS offers different NAV/COMM radios as slide-in replacements of legacy products from BENDIX KING and other manufacturers. The Michel MX-170 by TKM was introduced in early 1984 aiming to replace legacy BK radios such as KX-170A, KX-170B, KX-175, KX-175B type transceivers. The latest TSO'd MX170C with 760 VHF COMM channels and 200 NAV channels is designed to be electrically and mechanically interchangeable (slide in replacement) with the Bendix King KX170 and the Bendix King KX175 series of NAV/COMM radios. Like other TKM radios,the MX170C NAV/COMM has nice features and excellent performance. The dual color LED frequency displays are self-dimming, showing standby frequencies with red and active frequencies with yellow color. The channeling outputs are for 40-channel glide slope (King Glide Slope) and 200 channels (King Slip Code). The MX 170C operates on 13.75 Adc maximum current in transmit. Please refer to the attached owner manual for additional information.

ETSO'd Slimline Panel Mounted 10 W VHF Radio with built in 2-place intercom with auxiliary inputs for stereo music and audio warnings. Available with 8.33 kHz or  25kHz frequency spacing options.

Amphenol MS MIL-C-5015 Circular Plug Connectors are designed to meet the demanding performance requirements of military standards. These cable mount circular plug connectors have proven electrical capability for equipment applications where durability is important. The Amphenol plugs have threaded couplings and single key/keyway shell polarization for an accurate and reliable connection. The solid shells of these MS Series circular MIL-C-5015 connectors are made from high grade aluminium alloy. The shells are electrically zinc plated with an olive drab chromate finish which ensures a high resistance to corrosion. The inserts of these military circular connectors are made from resilient synthetic rubber which offers a high dielectric strength and resistance to vibration.

The MS3106A-10SL-3S plug can be used with Turn Coordinator TC02E-3-2 or Turn & Bank Indicator TB02E-2-1.
