SCINTEX complete kit with digital gauge and dual flow meters enabling monitoring of the engine's supply and return lines. It comes with 2 fittings for each flow meter (to be specified at the time of ordering) and clamps. For installation wiring between the flow meters and the display unit is required (not included). This kit is intended for use in vehicles, machinery, generators and boats / marine and other engine applications. The flow meters are precision cut from steel and aluminum and they are highly accurate, repeatable and suitable for use with diesel, biodiesel, unleaded petrol and other fuels. The display unit is a 1.8”, high resolution, sunlight readable, wide viewing angle, LCD colour display with a completely sealed and waterproof display front panel. The gauge enclosure is a common 52mm round size to fit many existing cutouts. Key features include highly accurate with good repeatability displays consumption in Litres per Hour or other units, fuel remaining in up to 2 tanks, connection capabilities to a NMEA enabled RS232 GPS receiver,  one or two fuel flow senders and fuel level senders and a single fuel pressure sender and display. It can be powered by 12V - 36V power supplies. Please refer to the additional information and specifications provided or contact us.

ROTAX® aircraft  engines form part of the product portfolio  of BRP-Powertrain GmbH & Co. KG which develops and manufactures engines for snowmobiles, watercrafts, boats, roadsters, all-terrain and side-by-side vehicles, motorcycles, carts, and aircrafts.

BRP-ROTAX® product range includes certified and non certified internal combustion engines, parts and accessories for light and ultralight aircraft.

Revolution Counters (Tachometers)/HOBBS meters are used in BRP-ROTAX® aircraft engines. They are offered as certified or non certified parts from BRP-ROTAX® but also from other manufacturers.  Non certified parts can be used in ultralights or other aircraft not requiring certification of parts for their installation. Certified parts are designated by the letters "CERT" after the part number in the product reference number (SKU).

Aircraft engine  parts are subject to changes from time to time. Some parts may be no longer available or replaced by others with different part numbers. Listed BRP-ROTAX® engine parts do not imply their current availability or suitability for your engine application. Always consult the most recent Illustrated Part Catalogs (IPCs) or other documentation available from the manufacturer for the correct part number before ordering.

A variety of special headsets, parts and accessories designed for specific aircraft, as well as other military communication applications are included in this listing, They are manufactured by DAVID CLARK CO., INC. and other companies. Other product lines of these manufacturers intended for use in General Aviation, Business/Corporate Aviation, Air Transport airplanes and helicopters as wel as other applications are separately listed. For additional information please consult the Product Description section, the supplied documentation or contact us.

AERO INSTRUMENTS® Company, now part of AEROCONTROLEX® Group, Inc., has been a supplier of Air Data Sensors for aircraft applications for over 85 years. AEROCONTROLEX® current manufacturing  of Air Data Sensors has been transitioned to AEROSONIC® Corporation which manufactures aviation instrumentation and avionics equipment including air data systems, standby displays, digital and mechanical standby instruments, sensors and probes.

Air data include total pressure of the airflow measured by pitot tubes, static pressure of the ambient air by static ports (or both pressures by pitot-static tubes), total temperature (higher than the actual air temperature due to friction and adiabatic compression) by TAT sensors, and angle of attack (i.e. angle between the airfoil and the airflow) by AoA sensors. All these data are vital for aircraft flight and in the case of large civil or military aircraft, once collected are fed to  an air data computer (ADC).

AEROSONIC® / AEROCONTROLEX® extensive portfolio of pitot probes, including pitot, pitot static and pitot/angle-of-attack probes, are designed and today in use  on a wide range of aircraft ranging from military and large commercial transports to helicopters and UAVs. Their product range  includes electrically heated pitot probes, pitot-static probes, static pressure ports, angle of attack, temperature sensors and flight test equipment for the aerospace and defense industries. They are designed to meet or exceed all applicable standards, including SAE AS393, DOD MIL-T-5421B, TSOC-16, AN5813 and BS2G.135 and feature heating elements to prevent ice accretion and water ingression for reliable operation in the most adverse environmental conditions. Probes may be configured as stand alone with pneumatic outputs to the Air Data Computer, or they may integrate the computing function and eliminate the pneumatic connection.

AEROSONIC® fuselage mounted static pressure ports are engineered to meet or exceed industry specifications to supply ambient static pressure measurements to air data computers, altimeters, airspeed indicators and vertical speed indicators in numerous types of aerospace applications. The Static Pressure Ports’ electrical heating elements prevent ice accretion and water ingestion ensuring the performance of primary flight instruments is not degraded even under the most severe atmospheric conditions.

For additional information please refer to the Product Description section.

EASA Certified VHF transceiver 57mm with 6W output power. Automatic selection of 8.33kHz/25kHz spacing and OLED display.

Designed to help the pilot determine altitude by measuring existing atmospheric pressure, the altimeter translates the measurement into “height above sea level.” This is indicated on the dial of the instrument in feet, which requires setting the barometric pressure in the Kollsman window.

UNITED INSTRUMENTS 5934 series are FAA TSO'd 3"/ 3-pointer altimeters, intended for use with most single engine, turbo/piston prop aircraft. They are offered in 5934 and 5934A models with respective maximum calibrated ranges  of -1.000 to 20.000 feet and  -1.000 to 35.000 feet respectively. All lighted instruments require a light tray sold separately.

Product Features:

Affordable, certified 3-1/8" case for half the cost of existing systems

United series 5934

All units approved to FAA TSO (C10b,C2b and C4c)

Anti-reflective glass enhances visibility and reduces pilot fatigue

Altimeter available with right-hand or left hand knob 20,000 or 35,000 ft. Hg or Mb

All instruments are made in the USA

One year limited warranty

Product Specifications:

Typical Weight: 13 oz

Number of Pointers: 3

Barometric Setting: 28.1 to 31.0 in HG / 946 to 1050 mb

Calibrated Ranges: -1,000 to +20,000 or +35,000 feet

Static Pressure Connection: 1/8-27 ANPT

Installation: Removable Spring Nuts and screws

For additional information please consult the supplied documentation.

Sourced from quality manufacturers, our own branded (AVIATIONEU NEA ERA) aviation (air crew) headsets are offered in two main families or series  (100 and 400) each with PNR and ANR models suited for use in fixed and rotary wing aircraft.

Two different plug types are offered, PJ-055/PJ-068 dual plugs widely used in General Aviation and other airplanes and Military grade U174 plug used on helicopters and military aircraft.

With their competitive prices, advanced design and features, quality materials and rigid construction, AVIATIONEU NEA ERA headsets combine performance, functionality and comfort to provide cost effective solutions for air crew communications.

ANR models (*) are offered with or without Bluetooth capability for music and mobile communications. All our headsets are accompanied by the Manufacturer and our Certificate of Conformance and come with a 12-months manufacturer warranty.

100 Series

AVIATIONEU NEA ERA 100 Series of aviation headsets includes PNR model 100 (GA) with dual plugs for airplanes and 100 (H) with U174 plug for military/helicopter operations. They feature  23dB and 24dB  noise reduction ratings respectively. 100 Series PNR headsets are Low cost, entry level headsets, ideal for General Aviation pilots and flight schools. Their ANR counterparts (Models 100A (GA) & 100A (H) are offered with a 29dB noise reduction rating and without or with Bluetooth capability, indicated by the letters "BT" in the product reference number (SKU). Pilots' style requirements are also covered through multiple colors, with Grey/Black (commonly stocked) and Green/Pink/Red/Yellow/Blue (On Demand as special order).

400C Series (Ultra Light Carbon Fiber Aviation Headsets)

Combining high performance, modern design, robust construction and an ultralight weight (only 9oz, 255g) the AVIATIONEU NEA ERA 400C series headsets are intended for use in air transport and military operations or by demanding pilots who seek high performance, functionality and confort headsets with an ultra light weight. Offered in carbon fiber black color. Various models include:

400C (GA) and 400C (H) PNR and 400AC (GA) and 400AC (H) ANR headsets offered with dual plugs and U174 single plug respectively and a noise reduction capability of 23dB (400C PNR) 29dB (400AC ANR).They come with or without Bluetooth capability.

AVIATIONEU NEA ERA 400 Series headsets are included in this listing while 100 Series headsets are separately listed. Please refer to the additional information and specifications provided or contact us.

(*) ANR function is powered by an AA battey in a supplied battery box with toggle switch. The headset will shut off automatically when unplugged from the battery box, manually turned off from the toggle switch or when the radio or avionics master switch is turned off.

The RCA 56 Series of electric turn and bank indicators by KELLY MFG (RC ALLEN) are an all volt instrument, with a power warning flag, a black or white ball inclinometer and either lighted or non-lighted. These rate-of-turn pointer controlled instruments are powered by an electrically driven DC precision gyro with an inclinometer providing the pilot with turn and bank information.  They meet or exceed requirements of FAA TSO C3b. Made in the USA. Weight: 1.9 lbs.

Dimensions: Length: 6 1/4 in. Max, Width: 3 3/8 in. Max, Height: 3 3/8 in. Max

Mating Connector: MS3106A10SL-3S.

Connector Pin Out: A: +11-30 VDC, B: Ground, C: Spare

KANARDIA AETOS Basic EFIS Kit is a Non Certified complete navigation, flight and engine system for the ultralight airplanes, autogyros and helicopters. This self-contained state-of-the-art EFIS instrument is optimized for ultralight aircraft.

The AETOS Basic EFIS Kit comes with a large 7" sunlight-readable display with high contrast and integrated AHRS and GPS unit (AIRU), engine monitoring unit (DAQU), OAT probe, GPS antenna, cables & accessories. Engine sensors are not included in this kit. In contrast to NESIS EFIS, AETOS EFIS does not support flight maps. Options are available at additional cost to increase the functionality of this device.

MITCHELL AIRCRAFT PRODUCTS, Inc. is a well known manufacturer of tachometers, gauges, and instruments the general aviation industry, built under an FAA-approved quality system.

Their product range includes:

Mechanical 3-1/8″ Clockwise, & Counter-Clockwise, 2, 2-1/4″ Mechanical Recording & Electric Lighted Tachometers,

Electric Gauges (Ammeters, Cylinder Head Temperature, Exhaust Gas Temperature, Fuel Quantity Gauges, Outside Air Temperature, Pressure & Temperature Gauges, and Voltmeters,

Mechanical Pressure &Temperature Gauges

Modular Gauges (Ammeters, Blank, Fuel Quantity,Pressure, Temperature Gauges, and Voltmeters, Modular Gauge Frames. This line of FAA PMA  miniature square engine gauges is ideal for a wide variety of general aviation applications. They measure nearly 1-1/2″  and are stackable. The modular design allows them to be plugged from the front of the panel. The units are internally lighted. Complete standard panels are also available. If individual gauges are ordered, appropriate backplate with pigtail must be ordered to mount and connect the gauge. If more than one gauge are ordered to be mounted together, a special order clustering requires custom backplates.

Sending Units (CHT & EGT Thermocouples, Fuel Quantity & Pressure Senders, 1/8″ & 5/8″ Temperature Senders.

MITCHELL FAA PMA'd D1-211 Series  modular 1-1/2 " fuel quantity square  gauges can be stacked in horizontal and/or vertical rows in any position in the aircraft panel. These  modular gauges are internally lighted and are plug removable from the front of the panel for easy maintenance. Available in different sender resistances for the indication of fuel quantity in the aircraft's left or right fuel tank.

MITCHELL FAA PMA'd D1-211 Series  modular electric 12V (PN D1-211-5074) & 24V (P/N PE-111-4074) fuel quantity gauges are lighted and easily installed in a 2-1/4" panel hole. They feature a 2 year factory warranty.

The gauges and senders must be ordered separately.

For the 12V Fuel Quantity Gauge D1-211-5074 the matching sender is PS-211-8038, 10-180 Ohm. For 24V operation, P/N PE-111-4074  resistors for each instrument must be ordered.

MITCHELL Pressure Senders 80 PSI (PN PS-211-9002) and 150 PSI (PN PS-211-9040) are offered for use with D1-211-6089 and D1-211-6092 FAA PMA Pressure Gauges respectively. Both have 2 terminals (one terminal to be grounded).

MITCHELL EGT Gauge 0-1600 Deg. F, PN D1-211-6101 requires PN PS-211-8162 sender (probe).

The KANNAD 406 AS (P/N S1823502-03) is a aeronautical survival beacon. Thanks to its small size and light weight, the Kannad 406 AS fits easily inside a liferaft. It is supplied with a floating collar.

The KANNAD 406 AS is qualified by the French Civil Aviation in Europe with JTSO-2C91a & JTSO-2C126 and by FAA with TSO-C91a & TSO-C126 applied to “survival” beacons.

The ELT is programmed with either the aircraft tail number, a serial number or the aircraft operator designator. It can be installed inside an aircraft on a mounting bracket or in a carry-off bag (both on options).

The mounting bracket option includes a locking pin to avoid accidental activation before ELT removal. The locking pin can be ordered separately with the carry off version.

The ELT can be fitted with a "Water Switch Sensor" to be activated automatically when in contact with water. A buzzer and a led indicate activation.

An integrated “self test” checks the main functions of the beacon. The test result is given by the led flashing sequence.

Product Features:

Battery replacement is only every 6 years.

Precise pinpointing (<1NM) due to the unparalleled frequency accuracy of the 406 transmitter.

Three frequency transmitter (121.5 / 243 / 406 MHz)

Weight (including battery, auxiliary antenna and floating collar) 2.53 lbs (1150 g)

Options:

P/N S18 20 511-03 carry-off bag

P/N S1820511-02 Mounting bracket with locking pin

P/N S1820514-14 Water Switch Sensor

PS ENGINEERING has revolutionized audio control in general aviation airplanes. At that time, the original PMA6000 took the audio panel from a collection of switches added as an afterthought, to a multitalented intersystem focal point for cockpit audio.

Radio selection, cockpit communications and even music were seamlessly combined in the modern audio control panel. The PMA6000-series set a benchmark for all GA audio panels that followed.

The next generation PMA6000B benefits from PS Engineering's long experience of audio panel control design and manufacturing experiences. It is an excellent low cost audio panel alternative to the higher end systems that PS Engineering has become so famous for.

The PMA6000B combines an audio selector panel with a top-quality manually adjusted 4 place VOX mono intercom and a slew of features to enhance versatility and utility. The PMA6000B holds both FAA TSO as well as EASA ETSO and was designed to be made easier to install because of a single 44-pin Sub-d connector. Different PMA6000B models offered with or without marker beacon receiver.

Product Features:

Built-in 4 place mono intercom PS Engineering's ""Set-it and Forget-it"" manual VOX

Optional built-in marker beacon receiver

Split mode for dual audio capability

2 - Com Capability

3 - Intercom isolation modes - Pilot Isolate, All, and Crew

2 - Music inputs with Soft Mute™

2 - Unswitched inputs

6 - Switched inputs

A patented ""swap"" function allows selection of Com 1 or Com 2 from remote pushbutton

Fail-safe feature automatically hard-wires the pilot to Com1 in the case of an outage

Single 44-pin connector making installation easier

Certification: FAA TSO/EASA ETSO

Warranty: 24 months

TSO'd Electronic Fuel Quantity gauges from UMA INSTRUMENTS (indicated by the letter "T" in the PN) are offered in 1-1/4 in. and 2-1/4 in. sizes for installation in respective panel hole diameters and mounted with (4) 6-32 screws. Smaller 1-1/4 in. instruments can be cluster mounted as close as 11/2” centers utilizing panel space without compromising readability. They can be powered from 14 or 28 volts. Signals are acquired from remote mounted sensors, processed and displayed on black analog dials with white easy to read markings indicating empty to full fuel level. Each gauge uses rugged aircore meter movement for vibration resistance and repeatability. Available in different versions based on their sender type and range. UMA sensors are sold separately.

JPI FS-450 Fuel Scan is a top choice low price unit for fuel management of an aircraft, offeredin different versions with single transducer available for gravity, pressure and ROTAX engines or with a Flow Scan 201 or 231 transducer and harness for pressurized carb engines.

Sourced from quality manufacturers, our own branded (AVIATIONEU NEA ERA) aviation (air crew) headsets are offered in two main families or series  (100 and 400) each with PNR and ANR models suited for use in fixed and rotary wing aircraft.

Two different plug types are offered, PJ-055/PJ-068 dual plugs widely used in General Aviation and other airplanes and Military grade U174 plug used on helicopters and military aircraft.

With their competitive prices, advanced design and features, quality materials and rigid construction, AVIATIONEU NEA ERA headsets combine performance, functionality and comfort to provide cost effective solutions for air crew communications.

ANR models (*) are offered with or without Bluetooth capability for music and mobile communications. All our headsets are accompanied by the Manufacturer and our Certificate of Conformance and come with a 12-months manufacturer warranty.

100 Series

AVIATIONEU NEA ERA 100 Series of aviation headsets includes PNR model 100 (GA) with dual plugs for airplanes and 100 (H) with U174 plug for military/helicopter operations. They feature  23dB and 24dB  noise reduction ratings respectively. 100 Series PNR headsets are Low cost, entry level headsets, ideal for General Aviation pilots and flight schools. Their ANR counterparts (Models 100A (GA) & 100A (H) are offered with a 29dB noise reduction rating and without or with Bluetooth capability, indicated by the letters "BT" in the product reference number (SKU). Pilots' style requirements are also covered through multiple colors, with Grey/Black (commonly stocked) and Green/Pink/Red/Yellow/Blue (On Demand as special order).

400C Series (Ultra Light Carbon Fiber Aviation Headsets)

Combining high performance, modern design, robust construction and an ultralight weight (only 9oz, 255g) the AVIATIONEU NEA ERA 400C series headsets are intended for use in air transport and military operations or by demanding pilots who seek high performance, functionality and confort headsets with an ultra light weight. Offered in carbon fiber black color. Various models include:

400C (GA) and 400C (H) PNR and 400AC (GA) and 400AC (H) ANR headsets offered with dual plugs and U174 single plug respectively and a noise reduction capability of 23dB (400C PNR) 29dB (400AC ANR).They come with or without Bluetooth capability.

AVIATIONEU NEA ERA 100 Series headsets are included in this listing while 400 Series headsets are separately listed. Please refer to the additional information and specifications provided or contact us.

(*) ANR function is powered by an AA battey in a supplied battery box with toggle switch. The headset will shut off automatically when unplugged from the battery box, manually turned off from the toggle switch or when the radio or avionics master switch is turned off.

The COBHAM Antenna Systems' COMANT product range includes aviation antennas focusing on GPS, Communications and Navigation products for General Aviation, light Jets and helicopters.COMANT antennas offer a wide variety of fit, form and function options that will fit nearly every need. Comant antennas are compatible with a number of varying applications and effective in a number of differing environments. The range includes Radiophone, DME, VHF, VOR, LOC, GS, DME, Transponder, FM, AM, UHF, L Band, ELT, and COMDAT antennas. COMANT Antennas have been re-tested and upgraded to the new RTCA DO-160D environmental requirements and offer the 118 to 137 MHz frequency associated with DO 186A MOPS. They no longer come with a gasket or template which must be ordered  order separately.

TKM AVIONICS offers different NAV/COMM radios as slide-in replacements of legacy products from BENDIX KING and other manufacturers. The Michel MX-170 by TKM was introduced in early 1984 aiming to replace legacy BK radios such as KX-170A, KX-170B, KX-175, KX-175B type transceivers. The latest TSO'd MX170C with 760 VHF COMM channels and 200 NAV channels is designed to be electrically and mechanically interchangeable (slide in replacement) with the Bendix King KX170 and the Bendix King KX175 series of NAV/COMM radios. Like other TKM radios,the MX170C NAV/COMM has nice features and excellent performance. The dual color LED frequency displays are self-dimming, showing standby frequencies with red and active frequencies with yellow color. The channeling outputs are for 40-channel glide slope (King Glide Slope) and 200 channels (King Slip Code). The MX 170C operates on 13.75 Adc maximum current in transmit. Please refer to the attached owner manual for additional information.

YAESU rechargable batteries are intended for use with YAESU handheld transceivers.

AN5771-4A style 2-1/4 inch hydraulic pressure gauge with steel case connecting directly to the aircraft's hydraulic system. Fits in a 2-1/4" dia. panel opening and has a threaded 1/4"  connection for a fitting. Range: 0-2000 PSI. Only available in Overhauled Condition. Certified with fresh Matte-white dial. Yellow-tagged. Limited availability.

For new design projects and applications please refer to the presentations of alternative TSO'd and non TSO'd electronic hydraulic pressure gauges and pressure senders offered.

Pressure Transducers (Senders) whenever required, ARE NOT INCLUDED in the prices of hydraulic pressure gauges. They are sold separately.

Note: A yellow tag is similar to a FAA 8130-3 Serviceable tag both denoting the "Serviceable" condition of the product i.e. it has been  repaired as needed, tested according to the manufacturer's procedure, meet the manufacturer's performance specifications and ready to return to service. Yellow tags are issued and widely accepted in North America while a FAA 8130-3 Serviceable tag is is accepted worldwide. The acceptance of yellow tags by national Civil Aviation Authorities should be checked by potential buyers prior to ordering.
