WULTRAD INC. is a manufacturer of non-certified flight and engine instruments under FALCON GAUGE brand for experimental and homebuilt aircraft. Although their products are Non-TSO, they are made to TSO or MIL specifications for quality.

FALCON GAUGE Electrical Attitude Gyro is intended for use in experimental aircraft only. It provides a continuous visual display of the aircraft attitude with respect to the earth for maneuvering around the longitudinal (pitch), and lateral (roll) axes, and yaw. A precision AC brushless motor is featured in the electrical attitude gyro. The Power failure drops into view whenever the power is insufficient for operation of the gyro. Electrical gyro can be caged by pulling the "Pull to Cage" knob. It is offεred with or without internal lighting and is designed to work with a 12V system. Dimension: 3-3/8"X 6.46/164mm.

SAFE FLIGHT (SF) is the world's leading manufacturer of aircraft lift instrumentation and control systems. SAFE FLIGHT FAA certified Lift Detectors & Angle of Attack (AoA) Sensors are installed on hundreds of aircraft worlwide.

SF’s Lift Detector is the foundation of SAFE FLIGHT’s Stall Warning systems. This was the first and still the industry standard for stall warning in light aircraft. It  consists of a small tab or vane which senses the change of the stagnation point on the wing and an alerting device used for stall warning. The  detector warns by light and horn of any danger of an approaching stall regardless of the flight maneuver. It comes in different variations complete with installation kit & instructions.

SF’s SCc Angle of Attack (AoA) system meets FAA requirements by providing both flashing red LEDs and an unmistakable audio output to alert the pilot of increasing AoA and an impending stall. It consists of two key components, the Lift Transducer and the the Indexer Computer. Available for retro-fit. Including the Lift Transducer, the Indexer Computer, and all necessary wiring, connectors and installation hardware.

For additional information please refer to the Product Description section and the supplied documentation.

The AVIASPORT indicators (gauges) are reliable, accurate and solid, combining the accumulated experience of more than twenty years with the latest technology  They have been designed for ROTAX engines and their display areas are divided into red, green and yellow zones in line with Rotax limits. They use a pointer that turns 240º or 320º, providing high resolution. AVIASPORT range of gauges includes CHT, EGT, tachometers, oil and fuel pressure, oil and coolant temperature, fuel level, voltmeters & ammeters and offered with casings of different sizes: 80mm; 57mm and 52mm.

AVIASPORT Oil Pressure indicators (gauges) are designed specifically for ROTAX 912/914 aircraft engines with painted red, green, and yellow gauge markings. are available in two sizes: 52 and 57 mm. They are offered in two unit versions for readings in PSI or Bars. They work with different pressure sensors depending on these installed in ROTAX 912/914 engines: the VDO sensor (Before September 2008) or the 4..20mA sensor (after 2008).

The new OROLIA-KANNAD INTEGRA 406 GPS ELT is a major step forward in the development of ELT technology and aircraft safety. Major benefits over standard ELTs include  a fail-safe automatically activated system for transmission of both the unique identification and GPS position in case of ditching of the aircraft or a crash landing as well as the ability for the pilot/ crew to remove the ELT from a downed aircraft. In addition,it features internal 406MHz and GPS antennas saving significant cost on aircraft  installation without the need for an  external antenna (national authorities’ rules and regulations permitting) and additional external GPS interface.

The 406 INTEGRA fixed ELT(AF) transmits on both the international 406MHz satellite search and rescue system (min  24 hours from activation) and on 121.5MHz for local direction finding. Minimum operating temperature is -20°C. The internal battery life of the INTEGRA is 6 years. Complies with European and FAA standards.

406 INTEGRA ELT(AF) is designed for flat installation on fixed wing aircraft and can be connected to an outside antenna (sold separately).

This ELT comes with:

the COMPACT universal mounting bracket

RC200 remote control panel

DIN-12 connector

SUB-D 9 pts female connector

Note: Hazardous Material

The DIALIGHT 800/801-series MS25041 are high-quality Miniature press-to-test indicators with built-in bulb testing device and an adjustable dimmer (801 series). They use T 1 3/4 bulbs with midget flange base such as GE-330 (12V) or GE-327 (24V) bulbs but LED replacement bulbs can also be used (*).

With their sleek design and easy installation, and their availability in different vibrant colors they are  the perfect accessories for providing a stunning, uniform glow and enhancing the appearance and functionality of indicators in the panel.

Crafted with durability in mind and made from top-grade materials for excellent protection against weather elements and long-lasting performance,  both 800 and 801 series indicators feature a T-1 3/4 midget flange for 15/32" mounting hole with solder termination, black anodized mounting bushing, aluminum mounting and flange nuts hardware. The push-to-test marking is die-stamped and filled on all lens cap assemblies used with 3 terminal units. They are is compatible with various LED bulb models and ensure a secure and precise fit. Bulbs are NOT INCLUDED. They can be ordered separately.

(*) PNs 800-1030-0337-504, 800-1030-0331-504, and 800-1030-0333-504 of  DIALIGHT 800 Series and PNs 801-1030-0337-504, 801-1030-0331-504, and 801-1030-0333-504 of DIALIGHT 801 Series and PTT indicators can be used with Based LED Replacement Lamps.

Sourced from quality manufacturers, our own branded (AVIATIONEU NEA ERA) aviation (air crew) headsets are offered in two main families or series  (100 and 400) each with PNR and ANR models suited for use in fixed and rotary wing aircraft.

Two different plug types are offered, PJ-055/PJ-068 dual plugs widely used in General Aviation and other airplanes and Military grade U174 plug used on helicopters and military aircraft.

With their competitive prices, advanced design and features, quality materials and rigid construction, AVIATIONEU NEA ERA headsets combine performance, functionality and comfort to provide cost effective solutions for air crew communications.

ANR models (*) are offered with or without Bluetooth capability for music and mobile communications. All our headsets are accompanied by the Manufacturer and our Certificate of Conformance and come with a 12-months manufacturer warranty.

100 Series

AVIATIONEU NEA ERA 100 Series of aviation headsets includes PNR model 100 (GA) with dual plugs for airplanes and 100 (H) with U174 plug for military/helicopter operations. They feature  23dB and 24dB  noise reduction ratings respectively. 100 Series PNR headsets are Low cost, entry level headsets, ideal for General Aviation pilots and flight schools. Their ANR counterparts (Models 100A (GA) & 100A (H) are offered with a 29dB noise reduction rating and without or with Bluetooth capability, indicated by the letters "BT" in the product reference number (SKU). Pilots' style requirements are also covered through multiple colors, with Grey/Black (commonly stocked) and Green/Pink/Red/Yellow/Blue (On Demand as special order).

400C Series (Ultra Light Carbon Fiber Aviation Headsets)

Combining high performance, modern design, robust construction and an ultralight weight (only 9oz, 255g) the AVIATIONEU NEA ERA 400C series headsets are intended for use in air transport and military operations or by demanding pilots who seek high performance, functionality and confort headsets with an ultra light weight. Offered in carbon fiber black color. Various models include:

400C (GA) and 400C (H) PNR and 400AC (GA) and 400AC (H) ANR headsets offered with dual plugs and U174 single plug respectively and a noise reduction capability of 23dB (400C PNR) 29dB (400AC ANR).They come with or without Bluetooth capability.

AVIATIONEU NEA ERA 100 Series headsets are included in this listing while 400 Series headsets are separately listed. Please refer to the additional information and specifications provided or contact us.

(*) ANR function is powered by an AA battey in a supplied battery box with toggle switch. The headset will shut off automatically when unplugged from the battery box, manually turned off from the toggle switch or when the radio or avionics master switch is turned off.

GARMIN AERA 660 Portable GPS provides affordable feature-rich navigation, stunning display and streamlined database updating. It features a 5-inch capacitive touchscreen display, Connext® wireless capabilities for database updating , Garmin WireAware™ wire-strike avoidance technology, 3D Vision of rising terrain near the aircraft, while overlaying GPS-derived airspeed, altitude and vertical speed alongside flight plan information and more. Offered with different navigation databases.

The GARMIN® GTR series COMM TSO'd panel mounted transceivers (please see separate presentation) together with the GARMIN® GNC series NAV/COMM radios are replacement products for the popular SL30 and SL40 models. They include new features to reduce pilot workload, while also offering an affordable solution to meet the requirements of the 8.33 kHz channel spacing European Union mandate under the Single European Sky (SES) initiative. They are more powerful than their SL-series predecessors with 10- or 16-Watt transmit power available versions.

The GARMIN® GNC series NAV/COMM radios are offered with either a 10 W (GNC 255A) or 16W (GNC 255B) COMM featuring a 25 kHz or 8.33 kHz spacing. Both come with a an internal VOR/LOC converter, a 40-channel glideslope (GS) receiver and include the rack, connector kit, and back plate. They are offered as units only or as kits with a 4ft harness to AUDIO Panel.  If purchased with the 4ft harness, they can only be used  in experimental aircraft.

UMA line of precision electronic pressure senders feature precision, solid state sensors and circuitry to give unequalled performance and are designed for rugged use in just about any environment.  They are offered in TSO'd and Non TSO'd models and gauge, differential and absolute types. UMA TSO'd electronic pressure senders are the most economical TSO’d units on the market. They are compatible with avgas, jet fuel, engine oil and many other fluids. Because they have internal voltage regulation, they are compatible with indicating instruments that do not have precision output voltages. Units for fuel and oil pressure are certified under TSO C47. Units for manifold pressure are under TSO C45a. For additional information please refer to the attached documentation.

HONEYWELL BENDIX KING® KI-229 Radio Magnetic Indicator (RMI) provides bearing information to either ADF or VOR stations by means of two pointers each of which is read against compass card.

The KI-229 RMI combines three data points on one indicator. The current aircraft heading from an HSI is shown on the card. The magnetic headings to VOR and NDB stations are shown by the twin needles. By combining all this information visually, less interpretation is required thus enhancing overall situational awareness, something especially helpful when the workload is high.

The KI-229 requires inputs from ADF, HSI and NAV receivers.

Product Features:

14/28 volt lighting

Compatible with Nav Receivers such as KN-53, KNR-615, KNR-630/631/632/633, KNR-634, KNR-665, and KNR-665A

Compatible with Nav systems including RNAV such as KNS-80 and KNS-81

Compatible with ADF receivers such as KR-87 and KDF-806

Compatible with Compass systems such as KCS-305 and KCS-55/55A

Requires input ARINC Compass System

TSO'd

Product Specifications:

TSO Compliance: Env. Cat. RTCA DO-160A A1C1/A/SKP/XXXXXXA/B/AAA

Weight: 2.8 lbs. (1.3 kg)

Temperature: -20 to +55°C

Altitude: 35,000 feet

TSO (Compass): TSO C6c

TSO (ADF): TSO C41c Class A

TSO (VOR): TSO C40a

Heading Input: Operates from any slaved magnetic compass with ARINC X,Y,Z outputs

VOR Video Input: 0.5VRMS 0 deg. phase composite 30Hz variable AM and 30Hz reference FM on a 9960Hz carrier (0.7VRMS maximum)

EASA Certified VHF transceiver with 6W output power and 8.33kHz frequency spacing.

The AV-532 is a VOR/LOC/GS receive only antenna which consists of taper ground high-strength 17-7PH stainless steel elements to reliably withstand vibration and wind loads. The insulators are weather-sealed compression-molded bakelite with the mounting holes provided. The unit may be mounted with the V pointed either forward or aft. The antenna is designed to operate at speeds up to 350 mph and altitudes up to 50,000 ft. It has a drag force of 3.42 lb @ 250 mph.

KANARDIA INDU Series round Vertical Speed Indicators (Variometers) are part of INDU diverse family of non-certified gauges for use in ultralight aeroplanes, autogyros and helicopters. They feature an LCD display with possibility to personalise the displays and scales. They are offered as standalone (master) VSIs with internal pressure sensors or as slave instruments. The slave version requires a master altimeter or some PFD like KANARDIA NESIS, EMSIS, AETOS or HORIS to be present on the CAN bus. KANARDIA INDU Series round altimeters are available for two standard panel hole diameters of 57 mm (2.25") and 80 mm (3.15").

Scale Ranges:

-M scale in meters per second (-10, 10)

-FT scale in feet per minute (-2000, 2000)

-KTS scale in knots (-20, 20)

JEPPESEN NavData Databases are offered for different GARMIN AERA portable GPS models such as 500/510, 550, 695 and 795. They are available for different geographical regions. JEPPESEN NavData databases can be included only in the respective orders of GARMIN AERA GPS units. Orders for these database and their updates are fulfilled by AVIATIONEU TRAINING SYSTEMS & SERVICES which offers aviation database services, in cooperation with respective database providers, on a simplified subscription-based ordering process saving man effort, time and costs for customers. Please refer to our listed services or contact us for additional information.

These precision quartz electric aircraft clocks are constructed for easy installation in a wide variety of replacement applications for home builts. The rugged quartz movement is accurate within 2 sec. in 24 hrs under normal operations and runs accurately in temperatures from -30º to 180ºF. Available in 14 Volt or 24 Volt versions.

Product Specifications:

OD: 2-1/4"

Depth: 2"

Weight: 4 ounces

HONEYWELL BENDIX KING® Panel-Mounted KLN 35A VFR GPS & KLX 135A VFR GPS/COMM with moving map. These products are DISCONTINUED and NO LONGER AVAILABLE IN NEW CONDITION.

The KLN 35A VFR GPS receiver combines satellite derived GPS worldwide navigation system with moving map graphics, a high-visibility display and and a choice of customized Jeppesen Nav Data databases, including coverage for Americas, Atlantic and Pacific areas. The KLX 135A offers even greater capability, incorporating all the same GPS performance and features as the KLN 35A also integrating a TSO'd, 760-channel, very-high frequency (VHF) communications radio with its navigation functions.

Limited Availability exists in USED devices which can be furnished in Serviceable or Overhauled conditions indicated respectively by the letters "SV" and "OH" in the product reference numbers (SKU and  accompanied by the relevant certification (e.g. yellow tag, 8130-3 form). In addition, they may be offered as exchanges / trade-ins  for returned customer owned units indicated by the letter "EX" in the SKU.  In the case of an exchange/trade-in option of a customer unit, the  full selling price of the ordered unit is charged and the core credit is refunded or credited towards future orders when our co-operating supplier verifies that the unit is in a reasonable, repairable condition. It is recommended that this option is selected by our customers mainly for upgrades and only in cases when their units are functioning properly at the time removal from the aircraft. In cases when customer units are found by our supplier to be non-repairable, the core deposit shall not be refunded and shipping charges shall apply if customers wish the return of these units to them.

Installation parts (for new installations) and manuals are sold separately.

Please refer to the Product Description section for technical specifications and information on USED avionics.

MIL-DTL-26482 Standard Series II connectors are widely used on applications in aerospace environments requiring a general-purpose, miniature cylindrical bayonet connector.They are environmentally sealed and offered different receptacle-mounting styles.

WULTRAD INC. is a manufacturer of non-certified flight and engine instruments under FALCON GAUGE brand for experimental and homebuilt aircraft. Although their products are Non-TSO, they are made to TSO or MIL specifications for quality.

FALCON GAUGE  Electrical Turn Coordinator is used for displaying the angular rate and sideslip of turning in horizontal flying and turning. The inclinometer indicates the slip angle of the aircraft while in a turn. A power failure flag drops into view whenever the voltage drops below a level for proper operation. The Turn Coordinator incorporates a built-in voltage regulator so it can be used with either 14VDC or 28VDC power system. It is compact in size and light weight eliminating radio interference.

This small, lightweight unlighted turn coordinator is excellent for homebuilt aircraft. Works for 14 Volt or 28 Volt systems. Features, power out warning flag with a 0° Panel. Fits Standard 3-1/8" Cut Out, 3-3/4" long.
