4-Pin connector by AMPHENOL for use in all electrical gyros (DG or Horizon) including Falcon models.

The SIRS "Navigator" magnetic compass delivers extremely accurate readings due to its fully integrated, 4 magnet correction facility.  It has the same features as the "Pegasus", but is mounted with a fully adjustable bracket that allows attachment to a variety of positions including the glare-shield or the windshield. This allows the compass to be located away from magnetic influences. Available in different versions for Northern or Southern hemisphere, unlighted  or lighted 12/28V and has a 3-year warranty. Size: 203/8" H x 2-1/4" W. Product accessories such as installation kit, GS1 glareshield mount, SIRS MF1 short foot bracket and SIRS compass correction key are also available and sold separately.

OMRON A16 series pushbutton 16-dia. cylindrical body switches are detachable switches. The same contacts can be used for both standard loads and microloads. Their miniature design of 28.5 mm makes these switches the smallest class in the industry. Easy-to-wire terminal arrangement. Certified for EN 60947-5-1. These switches are offered in lighted and non lighted versions, different colors, display shapes, with LED or incandescent lamps and different socket units. Please consult the attached documentation for ordering.

Range of special accessories by FRANZ AIRCRAFT ENGINES for use in BRP-ROTAX® aircraft engines and other applications.

MITCHELL AIRCRAFT PRODUCTS, Inc. is a well known manufacturer of tachometers, gauges, and instruments the general aviation industry, built under an FAA-approved quality system.

Their product range includes:

Mechanical 3-1/8″ Clockwise, & Counter-Clockwise, 2, 2-1/4″ Mechanical Recording & Electric Lighted Tachometers,

Electric Gauges (Ammeters, Cylinder Head Temperature, Exhaust Gas Temperature, Fuel Quantity Gauges, Outside Air Temperature, Pressure & Temperature Gauges, and Voltmeters,

Mechanical Pressure &Temperature Gauges

Modular Gauges (Ammeters, Blank, Fuel Quantity,Pressure, Temperature Gauges, and Voltmeters, Modular Gauge Frames. This line of FAA PMA  miniature square engine gauges is ideal for a wide variety of general aviation applications. They measure nearly 1-1/2″  and are stackable. The modular design allows them to be plugged from the front of the panel. The units are internally lighted. Complete standard panels are also available. If individual gauges are ordered, appropriate backplate with pigtail must be ordered to mount and connect the gauge. If more than one gauge are ordered to be mounted together, a special order clustering requires custom backplates.

Sending Units (CHT & EGT Thermocouples, Fuel Quantity & Pressure Senders, 1/8″ & 5/8″ Temperature Senders.

MITCHELL FAA PMA'd D1-211 Series  modular 1-1/2 " fuel quantity square  gauges can be stacked in horizontal and/or vertical rows in any position in the aircraft panel. These  modular gauges are internally lighted and are plug removable from the front of the panel for easy maintenance. Available in different sender resistances for the indication of fuel quantity in the aircraft's left or right fuel tank.

MITCHELL FAA PMA'd D1-211 Series  modular electric 12V (PN D1-211-5074) & 24V (P/N PE-111-4074) fuel quantity gauges are lighted and easily installed in a 2-1/4" panel hole. They feature a 2 year factory warranty.

The gauges and senders must be ordered separately.

For the 12V Fuel Quantity Gauge D1-211-5074 the matching sender is PS-211-8038, 10-180 Ohm. For 24V operation, P/N PE-111-4074  resistors for each instrument must be ordered.

MITCHELL Pressure Senders 80 PSI (PN PS-211-9002) and 150 PSI (PN PS-211-9040) are offered for use with D1-211-6089 and D1-211-6092 FAA PMA Pressure Gauges respectively. Both have 2 terminals (one terminal to be grounded).

MITCHELL EGT Gauge 0-1600 Deg. F, PN D1-211-6101 requires PN PS-211-8162 sender (probe).

UMA Non FAA Approved standard 2-1/4" and 3-1/8" altimeters are high quality, simple type (single pointer) with 2 revolution dial, designed to meet the needs of the low cost non-IFR users. Both altimeters utilize a knob adjustable barometric in. Hg scale, viewed through a Kollsman Window.

Product Specifications:

Case: Aluminum Casting

Weight: 10.6 oz.

Case: Valox 420 Plastic

Weight: 5.0 oz.

Not FAA Approved

The HONEYWELL BENDIX KING® KCS 55A Compass System provides the pilot with a simple, comprehensive visual display of the aircraft's heading and position in relation to a desired course. The system simplifies course orientation, intercept and tracking. Although only the KI 525A Pictorial Navigation Indicator (PNI) and the KA 51B Slaving Control & Compensator Unit appear in the aircraft panel, other remote components  of the KCS 55A system include the KMT 112 Magnetic Slaving Transmitter, the KG 102A Directional Gyro for stabilization of the system and optionally the KA 52 or KA 57 Autopilot Adapters making the KCS 55A a complete slaved compass system. Installation parts and manuals of the above components are sold separately. For further information on these components please refer to their individual product presentations. For additional information on  KCS 55A and technical specifications please consult the Product Description section.

The HONEYWELL BENDIX KING® components of KCS 55A Compass System can be furnished in NEW condition or as USED in Serviceable or Overhauled conditions indicated respectively by the letters "SV" and "OH" in the product reference numbers (SKU and  accompanied by the relevant certification (e.g. yellow tag, 8130-3 form). They are also offered as exchanges / trade-ins  for returned customer owned units indicated by the letter "EX" in the SKU. In the case of an exchange/trade-in option of a customer unit, the  full selling price of the ordered unit is charged and the core credit is refunded or credited towards future orders when our co-operating supplier verifies that the unit is in a reasonable, repairable condition. It is recommended that this option is selected by our customers mainly for upgrades and only in cases when their units are functioning properly at the time removal from the aircraft. In cases when customer units are found by our supplier to be non-repairable, the core deposit shall not be refunded and shipping charges shall apply if customers wish the return of these units to them.

1-1/4 inch TSO'd Electronic Fuel Pressure Gauges from UMA INSTRUMENTS. Black & White dial marking. Available in different pressure (PSI) ranges. Case: Aluminum. Weight: 4.0 oz. UMA sensors are sold separately.

Amphenol MS MIL-C-5015 Circular Plug Connectors are designed to meet the demanding performance requirements of military standards. These cable mount circular plug connectors have proven electrical capability for equipment applications where durability is important. The Amphenol plugs have threaded couplings and single key/keyway shell polarization for an accurate and reliable connection. The solid shells of these MS Series circular MIL-C-5015 connectors are made from high grade aluminium alloy. The shells are electrically zinc plated with an olive drab chromate finish which ensures a high resistance to corrosion. The inserts of these military circular connectors are made from resilient synthetic rubber which offers a high dielectric strength and resistance to vibration.

The MS3106A-10SL-3S plug can be used with Turn Coordinator TC02E-3-2 or Turn & Bank Indicator TB02E-2-1.

The RCA 22 Series of vacuum artificial horizon are controlled by air driven precision gyros to present the pilot with pitch and roll information. The attractive color scheme of blue sky and brown ground presents a realistic spherical display of flight. Unless otherwise indicated all instruments have a  "standard" display (dark blue/brown display with fixed pointer) and are unlighted.

All R.C. Allen vacuum gyros run off of 4.5" Hg, erect time is 3 min. The instrument fits in a standard 3 1/8 panel cutout. A ¼ -18 NPTF nylon tube slip fitting is recommended for vacuum hose installation. A 1/8 – 27 NPTF nylon tube slip fitting is recommended for vacuum gauge installation.

Dimensions: H: 3-3/8", W: 3-3/8", L: 6"

Weight: 2.75 lbs.

Certification: Meet or exceed all requirements of FAA TSO C4c and Aeronautical Standard AS396B.

Made in the USA

NOTE: The RC Allen RCA22-7 Vacuum Horizon Gyro can be an alternate device for Cessna Gyro Horizon C661076-0101.

The HONEYWELL BENDIX KING® KI 525A HSI is a pictorial navigation indicator used in the KCS-55A compass system which also includes KG-102A Directional Gyro, KMT-112 Magnetic Azimuth Transmitter (flux valve), KA-51B Slaving Control & Compensator Unit and optionally KA 52/KA 57 Autopilot Adapters. It was a popular avionics upgrade for light aircraft until the advent of the Sandell electronic HSI and, more recently, glass-cockpit systems from Garmin, Aspen and others. This indicator combines the display functions of both the standard directional gyro and the course deviation indicator offering the pilot a single view of the horizontal navigation situation. It greatly simplifies course orientation, interception, and tracking resulting in less work from the pilot. Internally lighted, the KI 525A operates at 14 or 28 VDC.

The HONEYWELL BENDIX KING® KI 525A HSI is available in different models to serve application requirements:

- with bootstrap heading synchro to provide source of slaved heading information for any device, such as an autopilot

- with glideslope needle damping for use in high vibration environments such as helicopter

- capable of operating at either 30Hz or 400Hz

- capable of operating at 14 or 28VDC and 5 volt operation

Like other KCS 55A compass system components, the  KI 525A indicator can be furnished in NEW condition or as USED in Serviceable or Overhauled conditions indicated respectively by the letters "SV" and "OH" in the product reference numbers (SKU and  accompanied by the relevant certification (e.g. yellow tag, 8130-3 form). They are also offered as exchanges / trade-ins  for returned customer owned units indicated by the letter "EX" in the SKU.  In the case of an exchange/trade-in option of a customer unit, the  full selling price of the ordered unit is charged and the core credit is refunded or credited towards future orders when our co-operating supplier verifies that the unit is in a reasonable, repairable condition. It is recommended that this option is selected by our customers mainly for upgrades and only in cases when their units are functioning properly at the time removal from the aircraft. In cases when customer units are found by our supplier to be non-repairable, the core deposit shall not be refunded and shipping charges shall apply if customers wish the return of these units to them. Please refer to the Product Description section for technical specifications and additional information.

KELLY MANUFACTURING (RC ALLEN) RCA 15AK series are TSO'd 3-1/8" ( 80mm) electric directional gyros suitable for both fixed wing and rotor wing aircraft.

WULTRAD INC. is a manufacturer of non-certified flight and engine instruments under FALCON GAUGE brand for experimental and homebuilt aircraft. Although their products are Non-TSO, they are made to TSO or MIL specifications for quality.

FALCON GAUGE Electrical Attitude Gyro is intended for use in experimental aircraft only. It provides a continuous visual display of the aircraft attitude with respect to the earth for maneuvering around the longitudinal (pitch), and lateral (roll) axes, and yaw. A precision AC brushless motor is featured in the electrical attitude gyro. The Power failure drops into view whenever the power is insufficient for operation of the gyro. Electrical gyro can be caged by pulling the "Pull to Cage" knob. It is offεred with or without internal lighting and is designed to work with a 12V system. Dimension: 3-3/8"X 6.46/164mm.

These UMA new manufacture NON TSO'd electric ammeters offer accuracy, rugged construction, and contemporary styling. They are available in different  measurement ranges with a 270° sweep and are suitable for installation in 2-1/4" panel hole diameters. Made in U. S. A. and furnished with shunt.

Accelerometers (aka G-Meters) are used extensively in a wide range of applications including Aviation, Marine, Automotive, Military, and others. They are also used  in inertial navigation and guidance systems in airplane and ship autopilots.They help in a better understanding of static, such as gravity, or dynamic forces due to motion or vibration acting on an object.

Original Mechanical and more recent Digital accelerometers, used on civil and military aircraft, measure the instantaneous acceleration (or G-force) of an aircraft and its occupants compared to Earth's standard gravitational pull, in units of "G" (e.g., 1G, 2G). They enable pilots to monitor flight conditions, maintain safety, or practice aerobatics or combat maneuvers. Made by different manufacturers, they are offered as non-certified instruments, for use on  experimental and homebuilt aircraft, or certified products, installed on civil transport an military aircraft.

Mechanical accelerometers, included in this listing, use traditional components like proof masses, springs, and damping to measure acceleration based on displacement, offering high accuracy and durability for specific applications like flight stabilization and weapons communication. They are often of larger size and more expensive. Digital accelerometers, separately listed, are often Micromachined Micro-electromechanical (MEMS) systems, integrating sensors with microelectronic circuits for smaller size, lower cost, and high precision, making them ideal for flight stabilization, AHARS, and autopilot systems.

The choice of an accelerometer depends on the application's need for accuracy, size, cost, and resistance to harsh environments.

Please consult the Product Description section and the supplied documentation for more information on different brands of our offered accelerometers.

The 730/830 Engine Monitoring Systems (EDM) from JP INSTRUMENTS revolutionize engine monitoring by the compact size integration of a full color graphical LCD display with the extremely popular EDM 700/800 series functionally. Both 730 and 830 EDMs feature: colourful graphics, larger data display for easy reading, parameters in full colour, annunciation of exceedances, less page swapping, more data per page. The units are "Plug and Play" compatible with existing EDM-700/800 units. Oil pressure has also been added to the entire EDM series line.  Both 730 and 830 are FAA approved for use as secondary engine monitors. However they CANNOT BE USED as a replacement for primary gauges which have to be maintained. Different options and accessories are also available at additional cost.

The STRATOMASTER VEGA range instruments/indicators from MGL AVIONICS includes different 2 1/4" (57mm) microprocessor based color display instruments operating over a wide supply voltage range of 8 to 30V DC with with built in reverse and over voltage protection. They are non certified and only suitable for installation in experimental and sport  (LSA) aircraft. Using a high resolution color graphics display, these instruments/indicators provide excellent daylight readability with built in backlighting making them easy to read at night time. They include a rotary control plus 2 independent keys for easy menu navigation and to access specific instrument features. Sensors are also offered to enhance their functionality. The MGL AVIONICS STRATOMASTER VEGA Series instruments/Indicators include: Artificial Horizon & Magnetic Compass Display, Altimeter/VSI, ASI, ASI/VSI, Engine Monitoring System (EMS), Fuel Computer, Information Display, Manifold Pressure, Température, RPM, Hobbs, Universal Engine/Rotor RPM, Hobbs, 4-Channel Thermocouple (EGT/CHT), 4 Channel Universal Analog Input (Pressure/Temperature/Voltage/Current) and NAVCOM Control head for MGL N16 NAV/COMM or V16 COMM VHF.

UMA NON TSO'd Electronic Amp Meter Gauges (Ammeters) are available in different series for different measurement ranges and installation in different panel hole diameters. 1-1/4" series allow utilization of panel space without compromising readability. They can be powered from 14 or 28 volts. Signals are acquired from remote mounted sensors, processed and displayed on analog dials with easy to read markings. Each gauge uses rugged aircore meter movement for vibration resistance and repeatability. Each gauge can be placed in a 1-1/4” diameter hole and mounted behind the panel with (4) 6-32 screws. They can be cluster mounted as close as 11/2” centers. Also available as new manufacture electric with 2-1/4" dia. Other UMA series of electronic ammeters include 2-1/4" series with moving coil and 85° Sweep and 2-1/4" Dual Amp/ 0-30 volt meters with moving coil  and 85° sweep.

NOTES:

These ammeters come with the suitable shunt. Different shunts are used depending on ammeter part number.

All Part Numbers beginning with the letter "T" are TSO'd for Certified Aircraft.

ROTAX® aircraft  engines form part of the product portfolio  of BRP-Powertrain GmbH & Co. KG which develops and manufactures engines for snowmobiles, watercrafts, boats, roadsters, all-terrain and side-by-side vehicles, motorcycles, carts, and aircrafts.

BRP-ROTAX® product range includes certified and non certified internal combustion engines, parts and accessories for light and ultralight aircraft.

Fuel pressure gauges are used in BRP-ROTAX® aircraft engines and offered as certified or non certified parts from their respective manufacturers. Non certified parts can be used in ultralights or other aircraft not requiring certification of parts for their installation.

Aircraft engine  parts are subject to changes from time to time. Some parts may be no longer available or replaced by others with different part numbers. Listed BRP-ROTAX® engine parts do not imply their current availability or suitability for your engine application. Always consult the most recent Illustrated Part Catalogs (IPCs) or other documentation available from the manufacturer for the correct part number before ordering.

Fuel pressure gauges are no longer offered as ROTAX Part Numbers. These part numbers are provided for reference only. For these gauges please refer to our product presentation on AVIASPORT Fuel Pressure Gauges or contact us.
