Both GARMIN® GMA 345 and 350 are certified (TSO'd) Audio Control Panels for General Aviation aircraft.

Bringing rich “home theater” quality sound and wireless Bluetooth¹ audio connectivity to your avionics stack, the GARMIN® GMA 345 digital audio panel offers a superior inflight audio experience at an affordable price. Featuring 3-D spatial sound processing, a USB charging port, marker beacon receiver, advanced auto squelch, clearance playback and impressive audio mixing and distribution features, this all-digital unit offers the ideal blend of capabilities for pilots who want to hear and do more with less effort in the cockpit. In addition, it’s an easy slide-in upgrade to legacy GMA 340 units and selected third-party audio panels. Offered with optional 3-COMM support.

The GARMIN® GMA 350 is the first truly all-digital audio panel, introducing a number of new technologies to the cockpit, including Telligence™ Voice Command, 3-D audio processing and advanced auto squelch. Virtual 3-D audio processing adjusts audio in the headset to mimic how the human ear normally hears and registers sounds in space. Advanced auto squelch automatically adapts to a quiet or noisy cockpit without clipping words or cutting out in the middle of phrases. Offered with or without Bluetooth connectivity.

For additional information please consult the Product Description section and the supplied documentation.

Installation parts and accessories for GARMIN® Audio Control Panels are sold separately. Please refer to the respective product presentation.

The HONEYWELL BENDIX KING® KX-125 is ideal as a replacement radio, a primary system for homebuilts or a very affordable back-up. despite its low price, it comes with a complete list of features. Its COMM section provides 760 frequencies, 'flip-flop' frequency selection, a built-in audio amplifier with side-tone and audio leveling, direct tuning, stuck-microphone alert, and even remote transfer of both COMM and NAV frequencies. The separate NAV section offers 200 frequencies, including localizer. It has gone through environmental testing and has FAA TSO approval but will still require a FAA 337 form for new installations.

Product Specifications:

Dimensions: 6.25"W x 2"H x 10.16"L

Weight: 3.88 lbs

Power Requirement: 14Vdc

Temperature Range: -20C to 55C

Altitude Range: Up to 35,000ft

Lighting: 14 Vdc

Transmitter Power: 5 watts minimum (7watts nominal)

TSO Compliance: C37c, C38c , C36e, C40c

GARMIN® GTX™ transponder product line includes Mode A/C and Mode S TSO'd panel mounted transponders offered in a‭ ‬wide variety of configurations to choose‭ ‬from‭, ‬depending on desired functions‭.‬ Different models are listed under separate product presentations.

GARMIN® GTX™ 325  is a Mode A/C panel-mounted full-featured, TSO'd certified transponder offering a simple, affordable replacement for standard Mode C transponders. It features aural alerts, total air temperature (TAT), pressure altitude readout, altitude monitor function, density altitude readout, built-in timers and automatic ALT/GND mode.  ‬It replaces the popular GTX™ 327 ‬and is essentially the same unit‮—‬but carries the GTX™ 335/345‭ ‬display and button layout‭. ‬It would be a meaningful ‬choice for the replacement of an older Mode C ADS-B‭ ‬Out transponder.

The AV-525 is a VOR/LOC/GS antenna similar in style to the AV-12 but utilizes an internal balun transformer. The antenna is rated at speeds up to 350 mph and altitudes up to 50,000 feet. It is a direct replacement for the CI 157P.

Product Specifications:

Model: AV-525

Application: VOR/LOC/GS Receive Only

Frequency: 108-118 MHz (VOR/LOC) -328-336 MHz (GS)

Impedance: 50 Ohms Nominal

VSWR: 3.0:1 Maximum 108-118 MHz - 2.0:1 Maximum 329-335 MHz

Polarization: Horizontal

Pattern: Omni-Directional

Connector: “BNC” Female

Max. Weight: 0.50 lbs.

Certification: FAA TSO C34e, C36e, C40c

HONEYWELL BENDIX KING®  TSO'd KMA 24 & KMA 24H Audio Panels ae probably ones of the most common audio panels found in aircraft. They are compact, self contained, fully solid-state TSO'd Audio Panels featuring push button audio selector panel, speaker and headphone isolation amplifiers, and a marker beacon receiver. The KMA24 controls as many as 3 transceivers and 6 receivers, including the internal marker beacon receiver and its automatically dimmed 3-light indicator. The KMA 24H controls up to 5 transceivers and 5 receivers, or 4 transceivers and 6 receivers. The KMA24H includes the internal marker beacon receiver and VOX intercom, which provides unprecedented flexibility.

BENDIX KING® KMA 24 & KMA 24H Audio Panels are DISCONTINUED products. Although some NEW units may be available under special order or while stocks exist, they are mostly offered for outright sale or in exchange / trade-ins  (*) for returned customer owned units in USED (Serviceable or Overhauled) Conditions (**) and  accompanied by the relevant certification (e.g. yellow tag, 8130-3 form). The letters "SV","OH" and "EX" in the product reference numbers (SKU) indicate the condition/sale terms. Racks & connectors (for new installations) are sold separately.

BENDIX KING® KMA 24 & KMA 24H Audio Panels are sold on demand. Require backordering. Delivery time cannot be specified.

(*) In the case of an exchange/trade-in option of a customer unit, the  full selling price of the ordered unit is charged and the core credit is refunded or credited towards future orders when our co-operating supplier verifies that the unit is in a reasonable, repairable condition. It is recommended that this option is selected by our customers mainly for upgrades and only in cases when their units are functioning properly at the time removal from the aircraft. In cases when customer units are found by our supplier to be non-repairable, the core deposit shall not be refunded and shipping charges shall apply if customers wish the return of these units to them.

(**) As per FAA requirements, Serviceable Condition means that the units have been repaired as needed and tested according to the manufacturer's procedure to meet the manufacturer's performance specifications.  They are legally approved for installation and use (return to service). In this condition, the unit is NOT disassembled unless problems and/or repair needs are detected during testing. In Overhaul Condition,  the units have been tested to determine any problems, disassembled, inspected, cleaned and repaired as necessary, reassembled, tested and aligned as required by the manufacturer manual and finally certified that they meet manufacturer’s specifications.

The ICOM IC-A220 Series of VHF Air Band 760 COMM transceivers operating in 118-136.975MHz range are offered as non certified (IC-A220) or certified (IC-A220T) versions. The IC-A220  is a popular fit with experimental and light sport aircraft. The TSO/ETSO approved IC-A220T will work for all certified aircraft and it comes as a standard unit complete with install kit and mounting tray (IC-A220T), adapted unit IC-A220T-K with edge connector MBA-3 (*) fitted as a replacement for King KY96A/97A, KY196A/197A (**), Icom A200 or A210,and adapted unit IC-A220T-G with D-Sub connector MB113 as a replacement for Garmin SL40 (***).

Production of  IC-A220T has been discontinued. IC-A220T transceivers have limited availability  in NEW or NEW SURPLUS condition from existing stocks and they are also offered as USED units.

Both IC-A220 and IC-A220T radios support  8.33 kHz and 25 kHz frequency spacings and feature OLED display, 20 memory channels and 20 history memory channels, "flip-flop" arrow button switches between main and stand-by channels, 8W output power, a built-in 2 station intercom, 12 or 24 volt compatibility and automatic squelch. They can be used for radio upgrades and replacecements of  KY96A/KY97A & SL40 radios.

(*) The MBA-3 is intended for use with the Non-TSO'd model (IC-A220). Use with the TSO'd model (IC-A220T) may void the TSO.

(**) The adapted unit will not directly replace King KY96, KY97, KY196 or KY197 units.

(***) Metal work modification is required as the locking mechanism for the IC-A220T is in a different position on the SL40 tray/rack.

LORD Corporation AM Series Low Profile Avionics Mounts (also referred to as isolators)) set the standard for compact, highload, high-capacity isolators. They are designed to support and protect avionics equipment in all types of aircraft. Inertial guidance and navigation systems and radar components are examples of applications where these mounts are used. In addition, AM Series mounts are used to isolate engine/aircraft accessories such as fuel controls, pressure sensors and oil coolers. These mounts  are tested and approved to the environmental tests appearing in MIL-STD-810 or MIL-E-5400. They may be used in a temperature range of -65°F to +300°F (-54°C to +149°C) for BTR® Silicone and -40°F to +300°F (-40°C to +149°C) for BTR® II Silicone. They are made with specially compounded silicone elastomers which exhibit excellent resonant control evidenced by the low transmissibility at resonance. These designs also provide linear deflection characteristics.

LORD Corporation AM Series vibration isolators are offered in different sizes and capacities. Please refer to the attached documentation.

The GARMIN® GTN 650Xi (*) GPS/Nav/Comm/MFD panel-mount platform replaces discontinued GTN 650 (**) offering more pixels, processing power, speed and performance.  It’s approved for installation in many of makes and models of fixed-wing aircraft and helicopters providing high-resolution terrain mapping, graphical flight planning, traffic target surveillance, multiple weather options, taxiway diagrams and a host of other advanced navigation features. It comes with Americas or International Database (specified at the time of ordering).

The GARMIN® GTN 650Xi features:

- a brighter, faster, sharper, better Do-It-All intuitive touchscreen interface providing quick access to navigation, radio tuning, multifunction display features and more,

- powerful fast response dual-core processors boosting the GTN Xi series graphical display capabilities — with faster zooming, panning and map rendering on the display,

- high-resolution  4.9” display with almost double the pixel count of its predecessor and wider viewing angles,

- multi-function display cpability supporting multiple inputs of moving maps, terrain, traffic, weather, airport diagrams and more,

- easy data entry with the use the on-screen QWERTY keyboard or traditional concentric knobs to enter frequencies, waypoint identifiers, routings and more,

- Telligence™ voice control technology helping reduce pilot workload by responding to hundreds of spoken commands with the press of a button on the yoke,

- finger swipe gestures enabling pilots to pan across the map display or use a smartphone-like pinch-to-zoom motion to scale up or down on any map, traffic or terrain page.

GARMIN® GTN 650Xi Specifications

TSO applicability: C34e; 2C34f; C36e Class A; 2C36f Class A; C40c; 2C40c; C74d Class A; C112e; C128a; 2C128; C146e Class 3; C151d Class A, B; C157b Class 1, 2; 165b; C169a Class C, E, 3, 4, 5, 6; 2C169a Class C, E, H2, 3, 4, 5, 6; C194; C195b Class B1, B3, B5, B7; C209

Display size: 4.9" (125 mm) diagonal

Display resolution: 834 pixels (W) x 370 pixels (H)

Unit bezel height: 2.65" (67 mm)

Unit bezel width: 6.25" (159 mm)

Unit depth with connectors: 11.25" (286 mm) (measured from face of aircraft panel to rear of connector backshells)

Unit weight: 5.5 lbs (2.48 kg)

Input voltage range: 11 VDC - 33 VDC

Operating temperature range: -20° C to 55° C (-4° F to 131° F)

Number of GPS channels: 15 (12 GPS and 3 GPS/WAAS/SBAS)

LAT/LON position accuracy: <1.25 meter RMS horizontal, < 2 meter vertical, with WAAS

Maximum velocity: 1,166 knots

Position update Interval: 0.2 sec (5 Hz)

Notes:

(*) The GARMIN® GTN 650Xi can be supplied as kit with 4 feet pigtail wire harness without certification . If cerification is required installation must be done by a GARMIN® Authoried Service Center.

(**) The GARMIN® GTN 650 can be supplied as USED (Serviceable) Certified unit (FAA 8130-3 Form) with GPS antenna, rack, connector, existing Database, 6 nonth warranty.

R.A. MILLER INDUSTRIES (RAMI) aircraft antennas cover a wide range of functions including communications, NAV antennas, GPS, ADS-B, transponder, VOR localizer, glide slope antennas, and marker beacons. They are known for their streamlined aesthetics, quality, and reliable performance. Offered in different TSO models, RAMI wire whip and rod antennas ELT (Emergency Locator Transmitter) devices are intended for use on low-speed General Aviation aircraft.

RAMI AV-100 FAA TSO C126a Airborne ELT Antenna is a passive two frequency (121.5 & 406 MHz) whip antenna, designed for speeds up to 250 knots. Impedance 50 Ohms Nominal, VSWR (Maximum):121.5 MHz 2.0:1 / 406 MHz 1.5:1, Polarization Vertical, Pattern Omni-Directional, Connector BNC Female, Weight: 3 oz. Maximum, Color: Black.

RAMI AV-200 FAA TSO C126a Airborne ELT Antenna is a passive two frequency (121.5 & 406 MHz) whip antenna, designed for speeds up to 250 knots. It meets DO-160G, Section 8, Category U requirements for robust vibration and is qualified for installation on helicopters with unknown related rotor frequencies. Impedance 50 Ohms Nominal, VSWR (Maximum):121.5 MHz 2.0:1 / 406 MHz 1.5:1, Polarization Vertical, Pattern Omni-Directional, RF Power Capacity 10 Watts CW, Connector BNC Female, Weight: 0.19 lbs. Maximum, Max Height 24″.

RAMI AV-300 FAA TSO Airborne ELT Antenna is a passive three frequency (121.5, 243 & 406 MHz) fiberglass rod antenna, designed for speeds up to 350 knots. Impedance 50 Ohms Nominal, VSWR: 2.0:1 max at 121.5 MHz,2.0:1 max at 243 MHz, 1.5:1 max. at 406 MHz,  Polarization Vertical, Pattern Omni-Directional, RF Power Capacity 10 Watts CW, Connector BNC Female, Max Weight 9 oz, Max Height 14″.

ETSO'd Slimline Panel Mounted 16 W VHF Radio with built in 2-place intercom with auxiliary inputs for stereo music and audio warnings. Available with 8.33 kHz or  25kHz frequency spacing options.

Stratus ESG digital transponders by APPAREO have been designed with non-glass panel aircraft in mind. Different models are offered for non certified and certified aircraft. Stratus ESG transponders feature 1090 ES (Mode-S extended squitter), 310 W nominal power output, a built-in WAAS GPS, compliance with global mandates for ADS-B Out transponders, push-button operation with modern keypad makes entering a squawk code easy, easy-to-use interface and pressure altitude monitor. Their form-factor enables easy replacement for existing transponders.

Version for non certified aircraft is offered as unit only or together with wire pigtail.

The version for certified aircraft is TSO'd and can be used to replace existing transponders in a wide range of aircraft models from different aircraft manufacturers like Cessna, Piper, Beechcraft, Mooney, Diamond and others. Certified units can only be shipped to a certified Appareo installer.

Product Specifications:

Bezel Height: 1.69 in. (43 mm)

Bezel Width: 6.38 in. (162 mm)

Depth: 10.75 in. (273 mm) front of panel to connector backshell

Weight: 3.29 lbs. (1.49 kg) including rack and connectors

Operating Temperature: -20°C to 55°C

Storage Temperature: -55°C to 85°C

Power Input: 9.0 to 36.0 VDC, 15 W typical

Cooling Input: No fan required

Environmental Compliance: DO-160G

Software Compliance: DO-178B Level C

Hardware Compliance: DO-254 Level C

TSO Compliance: C112e (Level 2els, Class 1), C145d (Class Beta 1 GPS/WAAS), C166b (Class B1S)

Display: OLED

Transmitter Power: 310 W

The STRATOMASTER VEGA range instruments/indicators from MGL AVIONICS includes different 2 1/4" (57mm) microprocessor based color display instruments operating over a wide supply voltage range of 8 to 30V DC with with built in reverse and over voltage protection. They are non certified and only suitable for installation in experimental and sport  (LSA) aircraft. Using a high resolution color graphics display, these instruments/indicators provide excellent daylight readability with built in backlighting making them easy to read at night time. They include a rotary control plus 2 independent keys for easy menu navigation and to access specific instrument features. Sensors are also offered to enhance their functionality. The MGL AVIONICS STRATOMASTER VEGA Series instruments/Indicators include: Artificial Horizon & Magnetic Compass Display, Altimeter/VSI, ASI, ASI/VSI, Engine Monitoring System (EMS), Fuel Computer, Information Display, Manifold Pressure, Température, RPM, Hobbs, Universal Engine/Rotor RPM, Hobbs, 4-Channel Thermocouple (EGT/CHT), 4 Channel Universal Analog Input (Pressure/Temperature/Voltage/Current) and NAVCOM Control head for MGL N16 NAV/COMM or V16 COMM VHF.

The N16 split design remote-mount VHF Navigation Receiver by MGL AVIONICS belongs to a new generation of navigation receivers based on RF direct conversion technology. The N16 is identical in size to the V16 COMM radio and can be used in a simple configuration as combined NAV/COMM solution for both MGL EFIS systems using the MGL protocols or, if at least one MGL VEGA or RAZOR control head is used these heads can provide NAV/COMM data output on RS-232 that is compatible with most EFIS systems on the market. Like V16 COMM, it is a Non-TSO'd NAV receiver for use in experimental and light-sport aircraft. For stand-alone operation, at least one MGL RAZOR control head or two MGL VEGA heads are required. Using these heads a fully compliant solution is presented that provides both VOR CDI using a rotary control for OBS bearing entry as well as the familiar two bar ILS localizer and glideslope indication. The VOR provides a display for bearing to station and radial from station at the same time for up to two simultaneously-received VOR stations. For additional information please refer to the attached documentation.

The GARMIN® GTR series COMM TSO'd panel mounted transceivers together with the GARMIN® GNC series NAV/COMM radios (please see separate presentation) are replacement products for the popular SL30 and SL40 models. They include new features to reduce pilot workload, while also offering an affordable solution to meet the requirements of the 8.33 kHz channel spacing European Union mandate under the Single European Sky (SES) initiative. They are more powerful than their SL-series predecessors with 10- or 16-Watt transmit power  available versions. They are offered as units only or as kits with a 4ft harness to AUDIO Panel.  If purchased with the 4ft harness, they can only be used  in experimental aircraft.

PS ENGINEERING has revolutionized audio control in general aviation airplanes. At that time, the original PMA6000 took the audio panel from a collection of switches added as an afterthought, to a multitalented intersystem focal point for cockpit audio.

Radio selection, cockpit communications and even music were seamlessly combined in the modern audio control panel. The PMA6000-series set a benchmark for all GA audio panels that followed.

The next generation PMA6000B benefits from PS Engineering's long experience of audio panel control design and manufacturing experiences. It is an excellent low cost audio panel alternative to the higher end systems that PS Engineering has become so famous for.

The PMA6000B combines an audio selector panel with a top-quality manually adjusted 4 place VOX mono intercom and a slew of features to enhance versatility and utility. The PMA6000B holds both FAA TSO as well as EASA ETSO and was designed to be made easier to install because of a single 44-pin Sub-d connector. Different PMA6000B models offered with or without marker beacon receiver.

Product Features:

Built-in 4 place mono intercom PS Engineering's ""Set-it and Forget-it"" manual VOX

Optional built-in marker beacon receiver

Split mode for dual audio capability

2 - Com Capability

3 - Intercom isolation modes - Pilot Isolate, All, and Crew

2 - Music inputs with Soft Mute™

2 - Unswitched inputs

6 - Switched inputs

A patented ""swap"" function allows selection of Com 1 or Com 2 from remote pushbutton

Fail-safe feature automatically hard-wires the pilot to Com1 in the case of an outage

Single 44-pin connector making installation easier

Certification: FAA TSO/EASA ETSO

Warranty: 24 months

The GARMIN® GMA 342 is an affordably priced yet loaded with features TSO'd panel-mounted audio panel providing direct slide-in replacement for legacy GMA 340 or select third-party units. It can support dual comm, dual nav, 3 aux receivers and 2 wired stereo music inputs — enhanced with bass boost levels, equalizer settings and exclusive 3D Audio technology that spatially separates the multiple communication sources entering the pilot's headset.  Up to 2 dedicated stereo music sources can be connected via the unit’s rear connectors. With stereo headsets, incoming audio is spatially separated to reflect how different audio sources come from different directions. An automatic digital voice recorder on GMA 342 continuously captures the last 60 seconds of incoming active comm audio for instant playback with a single button press. Advanced auto squelch technology automatically adapts to a quiet or noisy environment without clipping words or cutting out during conversation.

Accessories: If not included in the ordered unit, installation Kit and other accessories are available at additional cost.

The FLIGHTCOM 403MC is a 4-place panel mount, easy to use, voice-activated mono intercom with 3-position transmit capability designed to fit almost anywhere in the panel.

ETSO'd Slimline Panel Mounted 10 W VHF Radio with built in 2-place intercom with auxiliary inputs for stereo music and audio warnings. Available with 8.33 kHz or  25kHz frequency spacing options.

GARMIN® GTX™ transponder product line includes Mode A/C and Mode S TSO'd panel mounted transponders offered in a‭ ‬wide variety of configurations to choose‭ ‬from‭, ‬depending on desired functions‭.‬ Different models are listed under separate product presentations.

GARMIN® GTX™ 330 is a panel-mounted IFR-certified 250 W, Mode S digital transponder with traffic datalink capability and dedicated pushbutton keys for squawk code selection. The GTX™ 330 series brings ATC aircraft surveillance to new levels of precision, reliability and performance. Optionally available with 1090 MHz extended squitter transmission, certified to TSO-C166b authorization, the GTX™ 330 ES (Extended Squitter) provides an affordable pathway to ADS-B compliance for the Next Generation airspace system. The extended squitter technology enables transponders to automatically transmit traffic surveillance data (including aircraft flight ID, position, altitude, velocity, climb/descent, and heading information) compared to traditional Mode S and Mode C transponders, which can only broadcast altitude, and thus require a ground-based radar to correlate and identify the aircraft's position. In addition, simultaneous broadcast of this information to TAS or TCAS equipped aircraft, enables them to essentially see the same traffic picture for their location that ATC is watching on the ground. The ‬“ES” upgrade provides a ADS-B‭ ‬Out‭ solution but an input from an approved position source is still needed as GTX™ 330 does not have a WAAS GPS.

GARMIN® GTX™ 330 is discontinued and replaced by GTX™ 335, an entry-level ADS-B Out model‭ with a version integrating an  internal WAAS GPS. If ADS-B‭ ‬In capability is required then the the GTX™ 345 transponder should be selected.

For additional information please refer to the Product Description section.

Air Avionics is the common brand for Garrecht Avionik GmbH and Butterfly Avionics GmbH.  VT-2000 is a modern 6.25" rack format Mode-S/ADS-B EASA Certified Transponder (EASA Approval No. EASA.21O.705) with an integrated keyboard for easy operation. It can be installed as a direct replacement for the popular Bendix-king KT76 / KT76A/C series of transponders without any changes to pre-existent wiring and mounting trays. A special mounting tray (sold separately) is available for new installations. It has an integrated internal altitude encoder (alticoder) or or can be connected to any kind of existent alticoder in the aircraft (parallel and serial).

Product Features:

Installation without adapter and modification of existing wiring harness. Just slide in into existing mounting frame of your KT-76 or KT-76A / KT-76C.

Interfaces for future applications (i.e. ADS-B, TIS)

Certification base: ETSO-2C112a, ED-73B

Output power: min. 220 Watt (Class-1) Level 2es (extended Squitter)

Internal Alticoder

Interfaces für external alticoder (serial or parallel)

Direct-GPS NMEA Interface for ADS-B, no adapter required

Transflective color TFT Display

Illuminated keyboard
