Military Specification MS35058 Series Toggle Switches can be used to upgrade your aircraft's cockpit controls. These heavy-duty metal switches have a standard shape that works well for a variety of applications can be used for most components that only function in either the on or off positions. They are available in several sizes to fit your particular airplane and are shipped with all necessary rings and hardware for installation. Toggle switches are available with two or three operating positions, 1 or 3 hole mounting and a variety of circuitry & electrical ratings. Contacts are made of solid silver. Wide usage is found in aircraft, mobile, marine, electronic and industrial applications. Available in full "AN" standard size & Ultra Miniature 1/2" size, contact types and circuit codes (see reference chart).

Fine quality switch from ACS used in many aircraft. The switch housing is machined from billet aluminum which makes this switch 25% lighter. It provides “ON” and “OFF” electrical control of both magnetos on a single engine aircraft. The key-operated switch mounts from the rear of the panel in a 7/8” dia hole. Available with or without starter position. A-510-2 model with starter position is supplied with switch plate two keys. (diode included). FAA PMA Approved. Made in USA.

Bellcrank bearings are commonly used for various control bellcranks throughout many experimental aircraft. They are prepacked with lubricant conforming to Mil. -G23827, inspected per Mil. I 45208A and 100% traceable. Operating temperature range -30 Deg. F to +250 Deg. F

CURTIS PLT-275AV Flush Valves 6 Holes' Adapter Plates Assembly.

Product Specifications:

Diameter: 2.75 in.

Depth: 640,000-650,000

From Mounting Surface to Bottom Hole Diameter: 1-1/2 in.

Not Certified

EATON CUTLER - HAMMER 8836-8838 & 8843-8845 Series MIL-S-8834 environmentally sealed positive action switches are offered with one, two & four pole circuitry, solderable screw or solder lug terminal variations and toggle or lever lock actuators. They are  MS approved, QPL’d per MIL-S-8834 and feature:

• High electrical/mechanical reliability

• Non-teasible mechanism

• Wiping action contacts

• Positive make and break action

• Molded-in terminal numbers

• One hole mounting for easy installation

• Dry circuit (logic level loads) to power switching levels

• Environmentally sealed per MIL-S-8834

• Two terminal variations: Screw 6-32 UNC-2B threads | Solder Lug .125 [3,17] dia. hole

• Temperature range: -67°F to +160°F (-55°C to +71°C)

• Life: 20,000 cycles at rated load 40,000 cycles mechanical life

• Positive action mechanism for high reliability and low contact bounce

Please refer to the supplied documentation for technical specifications and the correlation of EATON CUTLER - HAMMER to respective MS25306, MS25307, MS25308, MS14001, MS14002 & MS14003 part numbers.

Gill has become the OEM "original equipment battery" for Raytheon, Cessna, LearJet, Mooney, Piper, Ayres, Airtractor, Maule, Scheizer and other commercial, private and military aircraft  in the aviation industry and continues to be the industry's choice for quality battery products. In addition to the traditional Dry Battery line, Gill offers the LT Battery Sealed products featuring improved shelf life, lower weight, dependability, durability, high reliability, improved energy density, robust construction, testing and approval to DO-160E as well as FAA/PMA approval.

LT Series Batteries are fully recyclable and ship Hazmat exempt (Non Dangerous Goods).

The RAY ALLEN Trim Systems are trim servos of flight surfaces offered with different travel options designed specifically for experimental aircraft. RAY ALLEN servos are small enough to fit in individual control surfaces or can be used with lighweight springs acting directly on the control system. They come with RS2 rocker switches,  RP3 LED indicators and a RC8-7 clevis/pushrod kit. All RC ALLEN indicators operate off of feedback sensors located inside the servo. These feedback sensors are purposefully isolated from the power supply to the servo motor to guard against possible electronic failure.  Different servos are available:

T2-7A Trim System with a  .7" (17mm) travel

T2-10A Trim System with a  1.0" (26mm) travel

T3-12A Trim System with a 1.2" (31 mm) travel

T4-5 Trim System with a .5 inch (13mm) travel. This servo does not have a compatible indicator.

Technical Specifications as follows (RAC  Model / Output Shaft Movement / Travel Time):

T2-7A /  0.7 in. / 10 sec.

T2-10A / 1.0 in.  / 16 sec.

T3-12A /  1.2 in.  / 19 sec.

T4-5 / 0.5 in. / 15 sec.

The SPRL fuel locking and non-locking caps have secure sealing and easy finger tip operation. These caps are made from the highest quality modern engineering plastics with Viton o ring seals (which can be easily replaced). The mounting rings are anodized aluminum with the flange recessed to give a perfect flush fit whether it is riveted under a metal skin, as in the RV series, or built into a composite structure. The SPRL caps are non vented and recommended to keep the fuel in, the water out and in the locking version, other unwanted items out of your tank.

SPRL-L (locking) and SPRL-S (non-locking) fuel  caps have an 65 mm O.D. and can be used on Europa, Compair, Glasair, Lancair, Murphy, OMF, Rocket, Velocity, Zenith and many more experimental aircraft. Wt: 80 grams.

The EATON AEROQUIP FC300 are AQP elastomer hoses with a blue, abrasion-resistant fabric cover with single wire braid reinforcement over a synthetic rubber inner tube for longer life. The FC300 hoses are designed for high pressure fluid applications such as power steering, hydraulics, air, fuel, lubricating oils, fire resistant hydraulic fluids and other industrial fluids. They are also suitable for biodiesel use up to B20 and max temperature of 212°F (100°C). Available in different internal diameters in inches and for use in different maximum operating pressures (psi). Priced and sold by the foot.

Indicative Applications:

Power steering lines

Hydraulics

Air

Gasoline

Fuel

Lubricating oils

Over the wall air tool

Dot-approved air brake

Max operating pressure is 2250 psi

Operating Temperature Range

-55°F to +302°F (-49°C to +150°C)

Air not to exceed +250°F [+121°C]

Notes:

(1) The FC300 Hose only works with FC300 steel fittings (to be ordered separately). Easily assembles with a bench vise and/or wrenches.

(2) FC300-32 and FC300-40 hoses DO NOT meet SAE 100R5 pressure with reusable fittings. FC300-32 is rated to 350 psi with crimp fittings.

ELECTRODELTA is the world market leader in top quality voltage regulators for general aviation aircraft, and continues to revolutionize the industry with proven technologies and improvements. The units are assembled from the highest quality electronic components available and are meticulously tested and calibrated to ensure maximum performance. The ELECTRODELTA product line was acquired in October 2012 by LAMAR TECHNOLOGIES LLC.

ELECTRODELTA VR Series voltage regulators are offered in 14 and 28 Volt models with FAA/PMA or TSO certifications and are suitable as replacements for use in aircrafts of different manufacturers.

UNIFRAX® is the largest ceramic fiber producer worldwide with in-house paper-making capabilities. UNIFRAX® products include FIBERFRAX®Ceramic Fiber Insulation Blankets (S Durablanket 2300F and 2600F, Fibermax Blanket 3000F), FIBERFRAX® Ceramic Fiber Insulation Papers in different grades, FIBERFRAX® Ceramic Fiber Insulation Boards (Duraboard LD and HD 2300F, Duraboard 2600F and 3000F), FyreWrap Insulation Ducts (Elite Grease, Elite Air Distribution System (ADS), Dryer Protection System (DPS), Plenum and Cable) and High Temperature Textiles (Ceramic Cloths 2300F, Ceramic Tapes 2300F, Ceramic Square and Round Braids 2300F, Ceramic Twisted Ropes 2300F, Silica Textiles 2000F and Fiberglass Textiles 1000F. UNIFRAX® products are distributed by Thermal Products Company, Inc.

For FIBERFRAX® Ceramic Fiber Insulation Papers please consult the Product Description section and supplied documentation. Other products can also be supplied on demand. Please contact us.

High Pressure Strut Valve with Small Diameter Thread Adapter. Fits in nose gear of certain Cessna models.

START PAC® manufactures an extensive range of portable & mobile aircraft Ground Power Units (aka GPU) & starting battery packs used in different applications and operational scenarios, from supply of reliable mobile ground power for remote airstrips through to powerful hybrid solutions for fully high throughput Aircraft Maintenance, Repair & Overhaul operations. START PAC®’s product range includes GPU providing clean power for both maintenance and engine starting aircraft on the ground, a range of  of starting units with high power batteries and over voltage protection relays capable of starting any type of electrically started engine, power supply units to power up your aircraft’s cockpit whenever there is a need to operate any onboard device on the ground and check avionics as well as related accessories. Power supply units plug to the wall AC socket and provide continuous, clean, no duty cycle DC power.

Miniature incandescent and LED lams (bulbs) sourced from different manufacturers such as GENERAL ELECTRIC (GE), NORMAN LAMPS, AMGLO KEMLITE LABORATORIES,AERO-TECH LIGHT BULB Co. and others, for use in various aircraft applications (cockpit/wing/tail lights).

Unless a specific manufacturer is mentioned at the time of ordering and the selected lamp model is in production by this manufacturer, alternative lamps from different manufacturers shall be provided meeting the same or equivalent specifications.

 GE Lighting has been acquired by Tungsram. All bulbs are identical, but packaging may differ at the time of shipment.

NEWTON CONSULTING offers a range of SPRL branded fuel valves featuring distinct features that make them better than the rest. Ceramic disks have no soft moving/rubbing seals to wear out, unlike other valves but also give an 'indefinite' life with a very smooth light action. The lift and turn selector of their SPRL valves is instinctive, secure, and easier to use than the complex 'lift button' type. The locking detents avoid accidental movements. The fixings match most installations, and the internal ports prevent cross feeds, unless 'selected to 'Both'. NEWTON offered valves range from simple V1 and V3, designed to minimise stockholding costs to V6, tapped 10mm for standard Rotax banjo's on the input and 1/4" nps output or V9 and V10 duplex valves, threaded 1/4"nps which will accept 1/4"npt fittings and NEWTON AN-6 banjo assembly.Their lightweight alloy construction is anodized for protection while the Viton O-ring seals are suitable for all current fuels.

NEWTON also offers a variety of adaptors/fittings (purchased separately) which can be used with these valves as normal AN fittings will not fit directly to these valves.  Their offered product portfolio includes AN8 Male NPT 1/4" or 3/8", Female 1/4" NPT, Female 3/8" NPT, Female 14mm used for commercial automotive banjo's and Female 1/4"NPS supplied in their -6 banjo assembly.

Their Male AN fittings enable plumbing straight into the aeroplane system with no extra fittings to buy. The lightweight alloy construction is anodized for protection. Viton O ring seals, used as  seals to the valve, are suitable for all current fuels. They can be used on experimental aircraft only.

MICHELIN® Aircraft Tyres is internationally recognized as the No.1 tire manufacturer in the world. The company provides bias tires, radial tires, and tubes for aviation customers around the world, in a range of applications including commercial and regional airlines, general aviation and military aviation.

Michelin® AIR® Aircraft Tires offer just the right balance of performance and durability required by demanding pilots. The sidewall compound is optimized to provide maximum ozone and ultraviolet light protection, while the MX2000 tread compound is Michelin’s toughest. In addition, the new Air Cushion Inner Liner provides a protective cushion over the casing plies which guards against inner tube chafing. And the “Posi-Fit” bead construction reduces movement between the tire and the wheel for improved lateral stability. Offered in NEW or USED (RETREAD) (*) Condition.

Michelin® AIR® Aircraft Tires are designed to provide:

- a very long tire life and lower maintenance costs due to fewer tire changes

- exceptional balance for smooth taxiing,even wear, and heat resistance

- maximum protection against sidewall cracking caused by ozone and UV light

- excellent lateral stability and impact absorption, even under rough landing conditions

Product Features:

Deep Tread Depth: Thick rubber in the tread area helps provide for a long tire life. Contributes to lower maintenance costs due to fewer tire changes.

Unique Bead Construction: Provides a firm (tight) fit to help reduce movement between the tire and wheel. Helps improve lateral stability for a long tire life, even under rough landing conditions

Optimized Casing Design: Proprietary Michelin production processes help balance stresses within the tire structure. Strong, yet lightweight nylon cords are designed to exceed strict industry standards for overpressure strength. Results in an effi cient, lightweight product with excellent balance properties for smooth taxiing, even wear, and resistance to heat buildup for a long tire life.

Customized Rubber Compounds: Sidewall is optimized for both ozone and ultraviolet light protection which helps reduce ozone cracking in key areas of the tire. Provides our maximum amount of exterior wear and crack resistance for a long tire life.

Contoured Shoulder Design: Helps absorb lateral impacts associated with landing. Designed to help the tire achieve a full life, even under adverse conditions.

(*) Retread tires have undergone a remanufacturing process to replace the worn tread on used tires with new tread to help extend the life of the tire. The number of times the  tread has been replaced in the tire casing is indicated by a number just after the letter "R" in the product reference number (SKU), namely R1, R2, R3 and so on.

AMP Flexi Block Modular Terminal is used for assembles of terminal blocks to custom requirements and it is avalable in Users and Professional complete kits.

Users Kit consists of 25 pieces Flexi-BLock terminal block, 12 end stops and two 12 in pieces of track,

Professional Kit - No. 6 kit consists of 100 ea. P/N 604101-1 block assemblies, 25 ea. of P/N 604111-1 end stops and 2 ea. track 3 ft. long.

Metal cables are are stranded wires used in a wide variety of applications in aviation and many other industries. The term "wire rope" is also used when the cable diameter is larger than 3/8" (9.52 mm), with smaller gauges designated as cables or cords. They are specified in terms of their construction by the number of strands times the number of wires in each strand. For example, “7x19” means the cable with seven (7) strands, and 19 wires in each strand. 7x19 is the most flexible cable, approximately twice as flexible as its 7x7 counterpart.

Aircraft cables are encountered on or around the aircraft including flight control surfaces and tie-downs or other uses. In contrast to the commercial (industrial use) cables, aircraft  cables undergo extensive testing and are lubricated providing substantially better fatigue life. They conform to MIL-DTL-83420 specification. Sourced by leading manufacturers such as CONTINENTAL CABLE or CENTRAL WIRE Group of Companies (CWI) they are offered with or without coating (jacket) in different constructions, materials (such as galvanized carbon steel or stainless steel), diameters in inches and pre-cut or cut-to-order lengths in feet. Many of the offered aircraft cables are also included in U.S. DoD Qualified Products List (QPL) which relates to products, components, or materials, often used in aerospace or military applications, which have been examined, pre-tested & found to conform with all applicable standards or qualification requirements set by a certifying organization or government entity.

Different flight control cables, general use cable, cable assemblies and related parts from various manufacturers (*) are also offered either as OEM or FAA-PMA approved parts including our own labelled (AVIATIONEU NEW ERA) product lines aircraft and industrial (general use) cables for applications when no compliance to MIL specifications is required. For additional information please consult the Product Description section and the supplied documentation.

(*) OEM aircraft cables & assemblies are offered from TEXTRON AVIATION and are intended for use on Cessna, Beechcraft and Hawker aircraft. FAA-PMA approved aircraft cables and parts are offered from McFARLANE® AVIATION and other manufacturers for use on different aircraft.

For a number of years CLEVELAND WHEELS & BRAKES offered standard organic & heavy-duty asbestos brake linings for their wheels and brakes. In January 1988 these two types of brake linings were discontinued and a single, improved brake lining was introduced with improved performance and durability compared to older linings. Different versions are available to fit aircraft models based on their year of construction. Brake linings are sold as pad only or as kits together the required number of rivets. Most light aircraft take 2 linings per wheel. Extra rivets are also available. Please refer to the attached Application Guide for additional information.
