Danfoss SEL brand includes a range of low, mid, and high pressure industrial and hydraulic rubber, thermoplastic, and PVC hoses that meet or exceed industry standards. Spanning a broad range of operating pressures, Danfoss SEL hoses are the perfect solution for maximum durability and long-lasting performance under even the toughest conditions. SEL product portfolio includes:

FORCESTREAM standard wire braided hydraulic hoses.

SUPERSTREAM and ULTRASTREAM premium wire braided hoses offering higher working pressures and improved flexibility.

POWERSTREAM spiral reinforced hydraulic hoses for high pressure applications.

COLDSTREAM  hydraulic hoses resistant to ambient temperatures down to -50 C, specifically designed for low temperature applications.

ULTIMATE hydraulic hoses supporting high temperature applications up to 135 C, or 150 C for short-term exposure.

ARMADILLO range of hydraulic hoses with specialized cover materials providing advantages like enhanced ozone or abrasion resistance. Ideal for demanding and dynamic applications, such as pit mining equipment.

SUPER ABRA hydraulic hoses offering an outer cover.

For additional information please refer to the supplied documentation.

EATON AEROQUIP® brand name represents quality and innovation for aerospace and other industrial applications with a wide range of hoses, fittings, couplings and connectors available to cover application requirements. Following the acquisition of Eaton’s hydraulics business by DANFOSS, EATON AEROQUIP® products form now part of DANFOSS product portfolio.

DANFOSS EATON AEROQUIP® 816/8846/8891 series flared hose fittings can be used with DANFOSS EATON AEROQUIP® 601 hoses  and are available in different sizes. The 816 series straight hose fittings and 8891 series 90 Deg. hose fittings both consist of a pre-assembled nut/nipple assembly and an internally threaded hose socket. The size 4 fitting has a cadmium plated steel nut and nipple. Sizes 6, 8 and 10 nuts and nipples, and all sizes of sockets, are anodized aluminum. The 8846 series fittings are 45° hose fittings with swivel flared UNJF threads. They are noted for their outstanding performance as a result of a unique lipseal design concept. During assembly the nipple spur cuts a lip in the tube stock of the hose forming the fluid seal.

For additional information please consult the supplied documentation or contact us.

Note: DANFOSS EATON AEROQUIP® 816 fittings ARE NOT THE SAME as AN816 fittings. Please specify at the time of ordering.

EATON AEROQUIP® brand name represents quality and innovation for aerospace and other industrial applications with a wide range of hoses, fittings, couplings and connectors available to cover application requirements. Following the acquisition of Eaton’s hydraulics business by DANFOSS, EATON AEROQUIP® products form now part of DANFOSS product portfolio.

DANFOSS EATON AEROQUIP® wire reinforced synthetic rubber hoses are offered in different series (types) described below to meet respective application requirements.

The AE701 hoses consist an upgraded version and a direct replacement for old 601 ones, widely used for aircraft fuel and oil lines where flexibility and light weight are prime considerations. They are made from specially formulated synthetic rubber  inner tube with two layers of stainless steel wire outer braid reinforcement.  Because of their lighter weight and lower operating pressure than type 303 hose, AE701 hoses are not recommended for hydraulic lines. The AE501 hoses are AE701 hoses overlaid with a blue braided chafeguard cover of tough polyester yarn. Both AE701 and  AE501 hoses meet MIL-H-83797, TSO C53a,Type A specification.

The AE401 series hoses are AE701 hoses with an integral cover of silicone rubber compound. They meet MIL-H-83797, TSO C53a,Type C specification.

Product Features:

Flexibility

Light weight

Non-age sensitive (no shelf life)

Fluid temperatures: -65°F (-54°C) to +300°F (+149°C)

TSO C53a, Type A and Type C approvals (with fire sleeve)

Mil-Spec Approvals: MIL-H-83796/1 through MIL-H-83796/9 Assemblies & MIL-H-83797 Hose, MIL-F-83798 Fittings

Field attachable fittings

Applications:  fuel, engine oil and coolants.

Available in different tubing sizes and internal diameters in inches. Priced and sold by the foot.

For additional information please refer to the supplied documentation ot contact us.

EATON AEROQUIP® brand name represents quality and innovation for aerospace and other industrial applications with a wide range of hoses, fittings, couplings and connectors available to cover application requirements. Eaton’s hydraulics were acquired by DANFOSS and form part of DANFOSS product portfolio.

DANFOSS EATON AEROQUIP® AE246/AE446/AE546/AE846 Series Hoses are based on AE246 advanced technology designed, tested and proved high pressure 3000 psi PTFE hose with Hi-Pac®braid reinforcement containing densely packed small diameter wires braided over a minimum thickness Teflon tube. This reinforcement offers up to 50% lighter in weight while the wires absorb stress more uniformly resulting in a stronger wire braid with less metal. Available in different tubing sizes and internal diameters in inches. They meet or exceed AS1339 performance requirements.

The AE546 series hoses feature an integral braided polyester chafe guard (manufactured by braiding polyester yarn onto existing hose styles) while those of  AE246 series come with an integral silicone firesleeve.

The AE446 and AE846 Series hoses are AE246 high pressure teflon hoses with an integral silicone asbestos free fire protection (sleeve), adhering directly onto the hose metal braid and end fittings to form a smooth, tight bond.

Common end fittings used with these hoses include CRES fittings of -3 to -12 thread size, flared (MS33656), flareless (MS33514) or BSP type offered in straight, 45 deg and 90 deg styles.

“Super Gem” Reusable Flared Fittings can also be used with these hoses. They consist of 3 pieces: a socket, sleeve and nipple assembly.Made from corrosion resistant materials elbow fittings are available in standard, 45°, and 90° styles. Mate with AS4395 and AS33514 end connections. These service proven flared fittings provide permanent protection against leakage, even after high temperature aging and pressure impulsing to 250,000 cycles or more. This is due to the separation of the sealing function from the retention function.

The AEROQUIP® hoses are priced and sold by the foot unless otherwise specified. Fittings can be separately purchased in pieces.

For additional information please consult the Product Description section and the supplied documentation.

The EATON AEROQUIP AE102 Aerospace  Firesleeve was specially developed to meet the fire resistance requirements of FAA TSO C53a or TSO-C75. This firesleeve can be indentified by its orange colored outer surface.  It can be used for all fuel, oil, hydraulic, fire extinguisher & propeller feathering lines for "Fire-proof"(*)  hose lines functioning effectively within a continuous operating temperature range of -65F to +450F (-54C to +232C). It is denser and more tightly woven and has more fiberglass than most of the competition. Even the thickness of the protective silicone is better. Available in different internal diameters in inches. Sold by the foot.

The EATON AEROQUIP AE102 can be used with EATON AEROQUIP hoses and 900591B clamps to secure firesleeve material on each end over the basic hose assembly. Please refer to chart for correct size or contact us for additional information.

(*) Conforming with FAA requirements, "Fire-resistant"hose  lines must withstand a 5-minute exposure under specified flow conditions without failure. "Fire-proof" hose lines must withstand a direct flame for 15 minutes.

Hose and tubing insert fittings are available in high density black polyethylene or white nylon. Polyethylene fittings can be used with tygon, nylon or soft rubber tubing to assemble low pressure instrument lines such as airspeed pitot and static lines. Nylon fittings can be used in gravity-feed fuel lines and engine breather lines.

AVIATIONEU NEW ERA air relief valves can be used in different industrial applications. They are made from different materials,  EN 1AL (free cutting steel), 1SMnPb30+C or SAE 12L13  and zinc plated. Available in the following sizes:

Metric: M10 x 1 ARV

British Standard Pipe (BSP): 1/8" BSP ARV

U.S. National Pipe Thread (NPT): 1/8" NPT ARV, 1/4" NPT ARV

Sold by the piece (pc.) with Minimum Order Quantity (MOQ) 1000 pcs.  Appearing price is for reference only per pc. Please contact us for a quotation.

EATON products are known for their quality and innovation in aerospace and other industrial applications with a wide range of hoses, fittings, couplings and connectors available to cover application requirements. Following the acquisition of Eaton’s hydraulics business by DANFOSS, EATON hydraulic products form now part of DANFOSS product portfolio.

DANFOSS EATON WINNER® Series wire reinforced synthetic rubber hoses are constructed by a synthetic rubber tube with one or two wire braid reinforcement and a synthetic rubber cover. These hoses feature an operating temperature range of -40°C to +100°C / -40°F to +212°F. They can be used for a wide range of applications in hydraulic systems with petroleum and waterbased fluids as well as for general industrial uses. Available in different tubing sizes and internal diameters in inches. Priced and sold in meters unless otherwise stated.

EATON WINNER® Series include the following hoses:

The EATON WINNER® EC110 hoses which have one wire braid reinforcement and meet EN 853 1SN specification.

The EATON WINNER® EC115 hoses with one wire braid reinforcement and compliance with EN 857 1SC specification.

The EATON WINNER® EC210 hoses wiyh two wire braid reinforcement meeting EN 853 2SN specification.

The EATON WINNER® EC215 hoses with two wire braid reinforcement meeting  EN 857 2SC specification.

For additional information please refer to the supplied documentation ot contact us.

MIL-DTL 6000D Soft Flexible Aircraft Fuel (*), Oil, Water & Alcohol Rubber Hoses (superseeding MIL-DTL-6000C hoses) are offered as part of our own labeled (AVIATIONEU NEW ERA) product lines. They replace the respective MIL-DTL 6000C hoses.

These hoses are designed to handle oil, alcohol, coolant, and water.  The tube of these hoses is oil resistant with a black cover reinforced with high strength mildew resistant yarns. It withstands extreme temperature conditions from -40 deg. F to +250 deg. F.  Lightweight, flexible and easy-to-handle, they meet or exceed U.S. military specs and consist the right choice for hard-to-get-to spots in tight engine compartments. Their burst pressure is 1000 PSI (400 PSI for the hose with ID 2-1/2 in.).

AVIATIONEU NEW ERA MIL-DTL 6000D hoses are available in different internal and outer diameters in inches. Priced and sold in feet in one foot increments. The last part of our product reference code (SKU) indicates the inner diameter of the hose in inches.

For additional information please refer to the supplied documentation or contact us.

(*) MIL-DTL 6000D hoses are not recommended for use as fuel lines.

Thermoplastic hydraulic hoses are used in certain hydraulic control applications where low volumetric expansion properties are desired for more precise actions or control. Such applications include those for precision gauging, pilot lines, steering lines, grease systems, as well as other applications which cannot be subject to conductivity (use around power lines) or where moisture cannot be present, such as for spray foam. As with "rubber" hydraulic hose, not all brands of thermoplastic hydraulic hoses are built the same even though they may meet the same SAE specifications. Higher end brand hoses will typically be made to higher tolerances, better compounds, better resistance to various factors, added durability, enhanced engineering methods, and additional assurance of a proven system. With leading, innovative manufacturers such as Aeroquip, the market has seen improvements in hose design - such as more flexibility, lighter weight, higher temperature compounds, tougher covers, less manufacturing defects, and overall more durable products.

ΕΑΤΟΝ SYNFLEX® thermoplastic hose and tubing has been replacing rubber hose or metal tubing designs offering customers a number of benefits, including flexibility, durability, abrasion resistance, lighter weight materials, superior chemical resistance, variety of colors, high pressure capability and extended product performance.

Each component of the SYNFLEX® hose assembly system is compatible with other approved Eaton components to which it relates ensuring a complete hose assembly system. Component compatibility, along with the use of quality components, insures the production of reliable hose assemblies when properly assembled. Intermixing of fittings and hose not specifically engineered and designed for use with each other and Eaton equipment is not recommended and may result in the production of unsafe or unreliable hose assemblies. This can result in hose assembly leakage, hose separation or other failures which can cause serious bodily injury or property damage from spraying fluids, flying projectiles, or other substances. The ΕΑΤΟΝ warranty is limited to apply only when approved ΕΑΤΟΝ hose fittings and compatible ΕΑΤΟΝ SYNFLEX® hose are used with Eaton assembly equipment.

Hoses are priced and sold by the foot unless otherwise specified. Fittings can be separately purchased in pieces.

For additional information on different products please consult the supplied documentation or contact us.

I.M.M.® HYDRAULICS (part of INTERPUMP GROUP) is a multinational company that project manages, produces and distributes hydraulic hoses and hose fittings, as well as related assembly and test trial equipment.

I.M.M.® HYDRAULICS manufactures an extensive range of high and very high pressure rubber wire braided and wire multispiralled, thermoplastic and P.T.F.E. hoses for use in different industrial applications.

INTERPUMP/ I.M.M.® hose product range includes:

Double wire braid and four wire spiral hoses for marine and offshore applications,

Single/Double wire braid, four wire spiral, textile and suction line hoses conforming to different international standards,

High performance hoses including compressor, high and low temperature, HyOzone, HIPAC and others,

Thermoplastic and P.T.F.E. hoses

INTERPUMP/ I.M.M.® hoses are offered in desired cut lengths in meters but also in coils of specified meter lengths.

Different fittings, adapters, couplings and other components and accessories are offered for use with INTERPUMP/ I.M.M.® hoses.

Component compatibility, along with the use of quality components, insures the production of reliable hose assemblies when properly assembled. Use or intermixing of other components not specifically engineered and designed for use with INTERPUMP/ I.M.M.® hoses is not recommended and may result in the production of unsafe or unreliable hose assemblies.

Please refer to the supplied documentation or contact us for additional information or assistance on non listed products.

NAS1922/NAS1924 series clamps are light-weight, aircraft application clamps from 300-series stainless steel available with either a 1/4" round slotted screw or a 1/4" slotted hex-head screw.

NAS1922/NAS1924 series clamps are included as part of our own branded (AVIATIONEU NEW ERA) product lines. They are available in different sizes (NAS1924 clamps are available in sizes 48 & above). Both screw styles can be supplied with optional lock wire hole for tamper resistance. Black Oxide coated band versions (designated by the letter "L" in the part number) are also offered for increased wear resistance.

The following designators in the product reference number (SKU) indicate the different versions:

-1 Clamp with round slotted screw

-3 Clamp with slotted hex-head screw

-1H Clamp with round slotted screw & lock wire hole

-3H Clamp with slotted hex-head screw & lock wire hole

NAS1922/NAS1924 series clamps are sold in pieces or packs of specified number of pieces indicated after the letters "PK" in the product reference number (SKU).

Please refer to the attached documentation of the effective diameter range for different part numbers.

The  PARKER HANNIFIN (Hose Products Divisionn) offers the following series of Medium & High Pressure hydraulic hoses compatible with No-Skive fittings.

- BCH Series braided and SX Series spiral hoses meeting international technical standards. More recently developed they are intended for demanding small and medium OEMs and general distribution,

- ELITE No-Skive braided and Parkrimp® No-Skive spiral hoses, exceeding the standards and highly appreciated in the very demanding MRO and OEM markets.

- GLOBALCORE™ State-of-the-art  hose product range, exceeding the newest ISO 18752 and providing technical and economical excellence to the most demanding customers.

Good, Better, Best classification system is used for easier hose and fitting understanding and selection with superior performance of Best hoses versus their Better and Good counterparts including:

- Bend radius up to 50% smaller

- Flexibility (bending force) up to 30% higher

- Weight up to 20% lower

- Dimensions up to 25% smaller area

- Impulse resistance and service life up to four times higher

- Working temperature up to 25% higher

Agriculture is one of the typical markets and applications where Good hoses and fittings are the preferred product selection.

For additional information please refer to the supplied documentation or contact us.

The  Parker Aerospace (Stratoflex Products Division) offers a broad array of PTFE, rubber and metal hose and hose assemblies, hose fittings, rigid tube assemblies, couplings, quick disconnects, swivel joints, fuel break-away valves, hydraulic fuses, and flow regulators, and specialty fittings including permanently swaged and welded fittings suitable for virtually any aerospace application. Parker  300/312 Series are straight flared fittings while those of  646/640 Series are 45º elbow flared fittings, both field attachable and intended for use with Stratoflex 111 hoses. They come in different outside diameters (OD) and thread sizes in inches. Please refer to the supplied documentation on offered Stratoflex hoses and fittings or contact us.

EATON AEROQUIP® brand name represents quality and innovation for aerospace and other industrial applications with a wide range of hoses, fittings, couplings and connectors available to cover application requirements. Following the acquisition of Eaton’s hydraulics business by DANFOSS, EATON AEROQUIP® products form now part of DANFOSS product portfolio.

DANFOSS EATON AEROQUIP® 491 and 471 hose fittings consist of an AN818 style nut, an externally threaded 37 nipple and an internally threaded hose socket. Fittings of sizes 3 through 6 have nuts and nipples of cadmium plated steel. Nuts and nipples for size 8 and larger are of anodized aluminum. Fittings conform to MS24587. Available in different tube and thread sizes in inches.

For additional information please consult the supplied documentation or contact us.

Non-latching automatic self-sealing and Thread-Lok Quick Disconnect (QD) valved hose couplings are manufactured by the Stratoflex Products Division of Parker Hannifin Corporation.

Automatic couplings are recommended for use with today's advanced precision fluid systems for space flight, aircraft, ground and undersea applications. Stratoflex non-latching automatic self-sealing couplings are designed for use in diverse applications like electronic cooling systems, hydraulic accumulators/cylinders, brake systems, manifolds, vapor cycle and cryogenic systems. Automatic couplings are best utilized where space is limited, and hands off operation is required. Small envelope, high performance and unsurpassed reliability are key features of Stratoflex non-latching couplings. Available in different tube sizes, from sub-miniature to one inch in aluminum alloy, stainless steel, titanium and other exotic materials. They meet SAE Aerospace Standards AS4251,AS5072/1/2/3.

The Parker Stratoflex’s Thread-Lok Quick Disconnect (QD) valved couplings provide a proven solution for fluid conveyance systems  for aerospace and derivative markets when envelope and weight are important and robust performance is critical. Applications range from hydraulic, fuel, and cooling systems to pneumatic, air data systems, landing gears, wheel and brakes hydraulic fluid motors, military ground vehicles and space applications. Their respective Thread-Lok Ground Service Equipment (GSE) Quick Disconnect (QD) couplings are intended for use with fluid conveyance systems providing a robust connection for ground service equipment to the aircraft flight systems. The Thread-Lok QD is used in a wide range of pressure and temperature applications.

They integrate a highly reliable and robust positive locking mechanism to ensure the performance needed in difficult aircraft system environments such as the engine nacelle, landing gear and brake systems, and other QD demanding installations . The Thread-Lok QD couplings can be used in a wide range of pressure and temperature applications while they provide a simple one-hand operation to thread the QD halves together with a visual confirmation of proper and full coupling to improve both time and safety.

The Thread-Lok QDs incorporate tang and slot design, with QDs engaging and locking in one position when the coupling halves are threaded together and fully connected, providing both visual and touch indication of the fully connected position. They use Parker’s efficient, self-sealing valve design that permits fluid flow with minimum pressure loss and turbulence.

Available in different tube sizes, from ¼ to one inch. Their stainless steel construction meets typical electrical bonding requirements.They meet or exceed MIL-C-25427 and AS1709 specifications.

For additional information please consult the Product Description section, the supplied documentation or contact us.

SAE-AS5174/MS24392/AN815 series union, flared tube male to male hydraulic fittings are available as part of our own labelled (AVIATIONEU NEW ERA) product lines in different materials, tube outer diameters and thread sizes in inches. The AN815 series fittings are superseded by the respective fittings of Military Standard MS24392 which in turn are superseded by SAE International standard  SAE-AS5174 series. Materials include: Carbon Steel, Aluminum Alloy, Corrosion Resistant Steel (CRES), Titanium Alloy. The 2 digits after the series code indicate the tubing outer diameter (O.D.)  in inches. The following Material Code Letters in the part numbers indicate the composition of the fitting. Finish code “V” in the PN indicates high purity Aluminum coating for “W” or “D” fittings.

Depending on their Part Number they are sold in pieces but also in packs a with specified number of fittings indicated after the letters "PK" in the product reference number (SKU).

No code letter in part number for Carbon Steel

“D” for Aluminum Alloy (except 7075-T73)

“J” for CRES, type 304

“K” for CRES, type 316

“R” for CRES, type 321

“S” for CRES, type 347

“T” for Titanium Alloy 6AL-4V

“W” for Aluminum Alloy 7075-T73

“Z” for Carbon Steel, Zinc plated

For example, AS5174D0606 union fitting is made from Aluminum Alloy with a tubing outer diameter (O.D.) 3/8" and a 0.5625-18 UNJF thread. The corresponding union fitting in AN832 series would be AN815-6D.

Note: In SAE AS standards for new designs, Aluminum fittings with material code letter D in their Part or Identifying Number (PIN) are replaced by those with material code letter W for Aluminum Alloy 7075-T73 providing a higher tensile strength. In addition CRES fittings with material code letter S can be used for replacement parts. For new designs use of CRES fittings with material code letter R is recommended for applications requiring higher temperature.

AN840 series of pipe thread hose nipple fittings are offered as part of our own (AVIATIONEU NEW ERA) portfolio of fittings. Sourced from quality producers these fittings can be furnished in aluminum or brass in different tube internal diameters and thread sizes in inches.Aluminum are designated by the letter "D" after the suffix number of the product reference number (SKU).

Tubes, sleeves and fittings from various plastic materials such as Polyethylene (PE), Polyurethane (PU), Polyamide (Nylon, PA), Polypropylene (PP) or Polyvinyl Chloride (PVC)) are used in aerospace and many other industrial sectors for a range of hydraulic, pneumatic, instrumentation, insulation and other applications.

Plastic tubes sleeves  combine durability and flexibility with low cost and light weight. Depending on the selected tube/sleeve, and intended use, they have resistance properties such as chemical, abrasion, kink, wear and tear resistance, heat resistance, electrical insulation, biocompatibility, and others. Plastic tube fittings come in various configurations, including straight connectors, elbows, tees, and adapters. Common applications include those involving corrosive substances and others where weight reduction is crucial.

Tubes intended for electrical Insulation in aerospace are typically made of polyvinyl chloride (PVC) and conform with MIL-I-7444 and SAE-AMS-I-7444 standards. They are rigid or flexible tubes with uniform inside and outside diameters in the length, specifically designed to prevent any undesirable flow of current between conductors and other objects.They are used on electrical insulation applications requiring flexibility at low temperatures.

Sourced from leading manufacturers, plastc tubes/sleeves and related fittings are offered in different sizes to meet application requirements and sold in rolls (in the case of tubes or sleeves) or pieces and packs (in the case of fittings).

For additional information on the supplied products please refer to the Product Description section, the respective documentation included in the Attachment section or contact us.
