SAE100 R7 thermoplastic hydraulic hoses are commonly used with petroleum, fire-resistant, and water-base fluids, pneumatic, fuel, and lubricating systems. These hoses are poduced by different manufacturers such as KURT HYDRAULICS, DANFOSS EATON, PARKER and others they are offered as standard (conductive) and non-conductive (blocking electrical flow). They are generally composed of three parts: tube, reinforcement and cover. The tube and cover are made from high quality thermoplastic while reinforcement is made from suitable synthetic fiber.

KURT HYDRAULICS, part of KURT Manufacturing Group. manufactures and supplies a wide range of hydraulic fittings, hoses and couplings. The KURT HYDRAULICS thermoplastic hydraulic hoses are manufactured to the highest quality standards. Available in different grades for medium- to high-pressure applications in a range of sizes from 1/8” to 1”, depending on grade. Matching hydraulic fittings, quick crimpers, and more are also offered to create a complete hydraulic system.

KURT HYDRAULICS SAE100 R7 hoses feature a three-layer construction—nylon inner tubes, braided synthetic fiber reinforcements, and flexible, durable urethane outer sleeves. Offered in electrically conductive and non-conductive styles in most grades. They are rated up to 5000 PSI WP and 20000 PSI BP, varying by grade and diameter. All grades and sizes feature an operational temperature range from -40°F to +212°F.

Hoses are priced and sold by the foot unless otherwise specified. Fittings can be separately purchased in pieces.

For additional information on different products please consult the Product Description section, the supplied documentation or contact us.

MIL-DTL 6000D Soft Flexible Aircraft Fuel (*), Oil, Water & Alcohol Rubber Hoses (superseeding MIL-DTL-6000C hoses) are offered as part of our own labeled (AVIATIONEU NEW ERA) product lines. They replace the respective MIL-DTL 6000C hoses.

These hoses are designed to handle oil, alcohol, coolant, and water.  The tube of these hoses is oil resistant with a black cover reinforced with high strength mildew resistant yarns. It withstands extreme temperature conditions from -40 deg. F to +250 deg. F.  Lightweight, flexible and easy-to-handle, they meet or exceed U.S. military specs and consist the right choice for hard-to-get-to spots in tight engine compartments. Their burst pressure is 1000 PSI (400 PSI for the hose with ID 2-1/2 in.).

AVIATIONEU NEW ERA MIL-DTL 6000D hoses are available in different internal and outer diameters in inches. Priced and sold in feet in one foot increments. The last part of our product reference code (SKU) indicates the inner diameter of the hose in inches.

For additional information please refer to the supplied documentation or contact us.

(*) MIL-DTL 6000D hoses are not recommended for use as fuel lines.

EATON AEROQUIP® brand name represents quality and innovation for aerospace and other industrial applications with a wide range of hoses, fittings, couplings and connectors available to cover application requirements. Following the acquisition of Eaton’s hydraulics business by DANFOSS, EATON AEROQUIP® products form now part of DANFOSS product portfolio.

DANFOSS EATON AEROQUIP® BLIND-MATE quick disconnect couplings are utilized in advanced liquid cooled electronics and avionics thermal management systems. These couplings are used between removable cold plates and fixed manifolds to allow for quick leak free removal and replacement of both evaporative and liquid flow through systems. Blind-mate couplings provide unequaled performance in pressure drop, radial misalignment, and envelope. In addition, these couplings incorporate a patented integral thermal relief feature that prevents pressure buildup when the liquid cooling module is disconnected. Like other EATON AEROQUIP® quick disconnect couplings, they can be ordered as separate halves. Available in different sizes.

AEROQUIP® BLIND-MATE  couplings have been tested to meet or exceed SAE AS5072 for modular style couplings. These requirements include:

• Ability to operate within a temperature range of –65°F to +160°F (-54°C to +71°C)

• Capable of enduring 1000 connect/disconnect cycles without evidence of malfunction, leakage or damage

• Standard operating pressure of 150 PSI, proof pressure of 225 PSI, and burst pressure of 375 PSI

• Ability to tolerate proof and burst pressure without rupture or loss of fluid

• Ultra-low spillage during disconnection

• Integral thermal relief valve

• Minimal air inclusion during connection

Applications: Ethylene Glycol Water, Propylene Glycol Water, Polyalphaolefin (PAO) per MIL-C-87252

For additional information please refer to the supplied documentation or contact us.

Note: Special Order items. Non-Cancellable/Non-Returnable Upon Order Placement (NCNR). Minimum Order Quantities & long lead times usually apply. Contact us.

EATON AEROQUIP® brand name represents quality and innovation for aerospace and other industrial applications with a wide range of hoses, fittings, couplings and connectors available to cover application requirements. Following the acquisition of Eaton’s hydraulics business by DANFOSS, EATON AEROQUIP® products form now part of DANFOSS product portfolio. Made from different materials (S Steel, B Brass, C Stainless steel or D Aluminum alloy) DANFOSS EATON AEROQUIP® adapters & swivel Joints come in different types  and sizes. For additional information please consult the supplied documentation or contact us.

ROTAX® aircraft  engines form part of the product portfolio  of BRP-Powertrain GmbH & Co. KG which develops and manufactures engines for snowmobiles, watercrafts, boats, roadsters, all-terrain and side-by-side vehicles, motorcycles, carts, and aircrafts.

BRP-ROTAX® product range includes certified and non certified internal combustion engines, parts and accessories for light and ultralight aircraft.

Different hoses for water, heat, air intake, protection, form, connecting, low pressure and others & related fittings are used in BRP-ROTAX® aircraft engines. They are offered as certified or non certified parts from the manufacturer. Non certified parts can be used in ultralights or other aircraft not requiring certification of parts for their installation. Certified parts are designated by the letters "CERT" in the product reference number (SKU). ROTAX engine hoses are generally sold in meters and appearing prices are per meter but some hoses of specific dimensions and fittings are sold in pieces.

Aircraft engine  parts are subject to changes from time to time. Some parts may be no longer available or replaced by others with different part numbers. Listed BRP-ROTAX® engine parts do not imply their current availability or suitability for your engine application. Always consult the most recent Illustrated Part Catalogs (IPCs) or other documentation available from the manufacturer for the correct part number before ordering.

The  PARKER HANNIFIN (Stratoflex Products Division) offers a broad array of PTFE, rubber and metal hose and hose assemblies in different outside diameters (OD), hose fittings, rigid tube assemblies, couplings, quick disconnects, swivel joints, fuel break-away valves, hydraulic fuses, and flow regulators, and specialty fittings including permanently swaged and welded fittings suitable for virtually any aerospace application.

PARKER HANNIFIN Stratoflex rubber and PTFE hoses with various reinforcements and covers are briefly presented in the Product Description section with reference to their features and specifications. Offered in different sizes (tube and hose ODs) in inches and lengths in feet unless otherwise stated. Suitable fittings for use with Stratoflex hoses are separately presented. For additional information please refer to the attached Stratoflex catalogs for offered hoses, fittings and assemblies or contact us.

Eaton's Aeroquip® brand name represents quality and innovation in the aerospace industry and a wide range of options are available to meet the needs of aircraft OEM and maintenance engineers. Eaton’s Aeroquip hose, fittings, couplings and connectors are available for various pressures and applications. Lightweight and flexible rubber hoses, fittings & assemblies for aerospace applications qualified to industry standards are included within the company's product portfolio. The 306 Series is intended for low pressure while the 302A/303 Series (see separate product presentation) for medium pressure applications.

The 302A/303 medium pressure hose includes a seamless synthetic rubber compound inner tube with a single cotton braid reinforcement and a synthetic rubber outer cover. Operating temperatures: -65°F to +160°F (-53ºC to +71ºC). Used in air or vacuum instrument systems, automatic pilots and lines to pressure gauges used with these systems as specified in MS33620. Hose conforms to MIL-DTL-5593. Used with Aeroquip 491 hose fittings. Available in different tubing sizes and internal diameters in inches. Sold by the foot. Fittings are offfered in pieces and conform to MILDTL-38726 and MS27404 (superceding AN773). Hose assemblies conform to AN6270. For additional information please refer to the attached documentation.

In close co-operation with their respective quality manufacturers, AVIATIONEU NEW ERA industrial hoses address application requirements in many different industries. Combined with an extensive range of available fittings they consist cost-effective solutions with their high quality, cost savings and prompt deliveries.  Apart from the hoses, custom hose assemblies can be furnished with fittings pre-installed as per customer specifications.

Hoses are sold in feet or meters and fittings or hose assemblies in pieces. For additional information please consult the Product Description section or contact us for a quotation.

Flared tube coupling nuts conforming SAE International standard AS5175 are used for a leak-free solution on aircraft and other applications replacing respective AN818 parts. They are offered  as part of our own (AVIATIONEU NEW ERA) product lines in different materials and grades and multiple thread sizes to suit application needs. Material Code Letters in the part numbers indicate the composition of the fitting (No code for Steel 1137 or 4130, "D" for Aluminum alloys (except 7075-T73), "J" for 304 Stainless Steel (CRES 304), "K" for 316 Stainless Steel (CRES 316), "T" for Titanium 64AI-4V or "W" for Aluminum 7075-T73. These nuts are designed to be used with AS5176 and MS20819 sleeves. The 2 digits after the series code indicate the tubing outer diameter (O.D.)  in inches. Finish code “V” in the PN indicates high purity Aluminum coating for “W” or “D” fittings. Depending on their Part Number they are sold in pieces but also in packs a with specified number of fittings indicated after the letters "PK" in the product reference number (SKU).

Note: In SAE AS standards for new designs, aluminum fittings with material code letter D in their Part or Identifying Number (PIN) are replaced by those with material code letter W for Aluminum Alloy 7075-T73 providing a higher tensile strength.

VENA® HT Series flexible  hoses (SCAT equivalent) are  made of one layer of glass fabric silicone coated and visible steel wire  spiral inside. For use in conducting extremely cold or hot air (temperature range: -65°F to +550°F). Available in different internal diameters in inches. Sold by the foot.

Tubes, sleeves and fittings from various plastic materials such as Polyethylene (PE), Polyurethane (PU), Polyamide (Nylon, PA), Polypropylene (PP) or Polyvinyl Chloride (PVC)) are used in aerospace and many other industrial sectors for a range of hydraulic, pneumatic, instrumentation, insulation and other applications.

Plastic tubes sleeves  combine durability and flexibility with low cost and light weight. Depending on the selected tube/sleeve, and intended use, they have resistance properties such as chemical, abrasion, kink, wear and tear resistance, heat resistance, electrical insulation, biocompatibility, and others. Plastic tube fittings come in various configurations, including straight connectors, elbows, tees, and adapters. Common applications include those involving corrosive substances and others where weight reduction is crucial.

Tubes intended for electrical Insulation in aerospace are typically made of polyvinyl chloride (PVC) and conform with MIL-I-7444 and SAE-AMS-I-7444 standards. They are rigid or flexible tubes with uniform inside and outside diameters in the length, specifically designed to prevent any undesirable flow of current between conductors and other objects.They are used on electrical insulation applications requiring flexibility at low temperatures.

Sourced from leading manufacturers, plastc tubes/sleeves and related fittings are offered in different sizes to meet application requirements and sold in rolls (in the case of tubes or sleeves) or pieces and packs (in the case of fittings).

For additional information on the supplied products please refer to the Product Description section, the respective documentation included in the Attachment section or contact us.

DANFOSS EATON SYNFLEX® 1300 Series composite wall tubes are designed for pneumatic instrument control systems. They are also known as Dekabon or Maluform Metal/Plastic Composite tubing.

Their fully bonded polyethylene/aluminium construction combines the advantages of both metal and plastic tubing, and can withstand a working pressure of 10 Bar, making them ideal for a wide range of applications.

Their outer, high density polyethylene layer is impervious to most chemical environments and enables SYNFLEX® 1300 tubes to outperform practically all types of unprotected metal tubing.

Product Features:

• Combine the advantages of both metal and plastic tubing

• Offered in Inch & Metric sizes

• Construction: Polyethylene/Aluminum composite

• Temperature range: -40 °C to 80 °C (-40°F to 176°F)

• Very light (5 times lighter than a standard instrument control tubes)

• Provide neat looking bends without special bending tools

• Corrosion and chemical environment resistant

• Excellent chemical compatibility

• Tubing contents dry thanks to aluminum barrier

• Enable direct burial w ithout additional protection (whatever the installation)

• Connection with standard compression fittings

• Standard color: black, other colours on request

• Also available with "Halogen free" jacket

Applications

• Pneumatic instrumentation and control lines located in very wet or moist environments

• Air and gas sampling

• Corrosive environments

• ID surface best suited for air

Depending on stock availability, these tubes are supplied as EATON SYNFLEX®  or DEKABON parts under their respective part numbers. Depending on the selected part number they are sold by foot / meter or in coils of standard lengths.

Hydraulic  & pneumatic fittings (also called compressed air connectors)  are used today in a wide range of applications as a connection for conductors such as hoses, tubes, pipes and machinery carrying fluids or gas and compressed air respectively to maintain their pressure without leakage. Whether their intended use is for fluids (hydraulic) or gas/compressed air (pneumatic) they are manufactured in a range of materials from plastic and aluminum to steel and stainless steel for maximum corrosion and chemical resistance. They come in different specifications (for military,aerospace or industrial uses), different thread types, such as British Standard Pipe (BSP) or U.S. National Pipe Thread (NPT/PTF) and sizes in inch or metric systems. Depending on the specific conductor/fitting application requirement different fittings are selected. Push-in fittings are quick and easy to install, connect and disconnect, even multiple times. Compressed air couplings,consisting of a socket and plug combination are self-sealing connecting components traditionally used for pneumatic tools, hall installations and laboratory equipment.  Compressed air distributors are the ideal choice whenever distribution of compressed air to different systems is required. Different types can be used to direct the compressed air from one access point to several  outputs at the required location.

Hydraulic  & pneumatic fittings are offered as OEM parts from well known manufacturers or as part of our own labelled (AVIATIONEU NEW ERA) product lines. They are included in different product presentations throughout our Web Platform. In addition, a comprehensive range of tools and accessories (separately presented) are also offered ranging from connecting and disconnecting pliers, tubing and pipe cutters to union nuts, sealing caps, hollow bolts, hose clips, tubing straps and others.

Extending our range of offered fittings for hydraulic systems and fluid power applications, JIC (Joint Industry Council) 37° flare fittings can be supplied as part of AVIATIONEU NEW ERA product porffolio. JIC fittings share the same 37° flare angle as AN (Army-Navy) fittings, listed separately but they exhibit significant differences in materials, design tolerances, and intended applications. Typically made from carbon steel, stainless steel, or brass, JIC 37° flare fittings are commonly used in agricultural equipment, construction, and general hydraulic industrial applications unlike AN fittings which were originally designed, developed and still widely used for military and aerospace applications meeting their strict performance requirements. Although JIC fittings are often interchangeable with AN fittings and also a cost-effective alternative for less demanding applications, AN fittings should be a prefered choice for aerospace,  military or critical applications in high-pressure or high-precision environments.

Please consult the supplied documentation or contact us for non listed items.

Flared sleeve fittings are cylindrical metallic parts designed to be used on tubing to back up the flared end and provide a bearing surface for the coupling nut, thereby reducing wear on the tubing flare. The inside diameter of the flanged end is countersunk to form a seat for the flare when assembled to a mating fitting.

Coupling sleeves conforming to SAE International, standard AS5176 standard replace respective MS20819/AN819 sleeves and they are offered as part of our own (AVIATIONEU NEW ERA) product lines. Sourced from quality producers these fittings are manufactured in different materials including 4130 Steel, Copper, Corrosion Resistant Steel (CRES) and Aluminum & Titanium Alloys. Material Code Letters in the part numbers indicate the composition of the fitting.

Depending on their Part Number they are sold in pieces but also in packs a with specified number of fittings indicated after the letters "PK" in the product reference number (SKU).

The  Parker Aerospace (Stratoflex Products Division) offers a broad array of PTFE, rubber and metal hose and hose assemblies, hose fittings, rigid tube assemblies, couplings, quick disconnects, swivel joints, fuel break-away valves, hydraulic fuses, and flow regulators, and specialty fittings including permanently swaged and welded fittings suitable for virtually any aerospace application. Parker  300/312 Series are straight flared fittings while those of  646/640 Series are 45º elbow flared fittings, both field attachable and intended for use with Stratoflex 111 hoses. They come in different outside diameters (OD) and thread sizes in inches. Please refer to the supplied documentation on offered Stratoflex hoses and fittings or contact us.

Textron Lycoming™ engine part, fitting, breather 71140 w/out certification.

AVIATIONEU NEW ERA plain banjo fittings are intended for use in hydraulic pipes in automotive fuel, oil and hydraulic systems. They are available from different materials, mild steel, EN 1AL(free cutting steel), 11SMnPb30, EN 8, stainless steel 202 & 304. Sourced by certified manufacturers these banjo fittings are competitively priced and offered in different Metric sizes (M10x5/16", M12x5/16", M14x5/16", M14x3/8", M16x3/8", M18x3/8", M18x1/2") and different surface treatments (clear /yellow zinc plated, olive green zinc plated, dacromet). Sold by the piece (pc.) with Minimum Order Quantity (MOQ) 1000 pcs.  Appearing price is for reference only per pc. Please contact us for a quotation.

I.M.M.® HYDRAULICS (part of INTERPUMP GROUP) is a multinational company that project manages, produces and distributes hydraulic hoses and hose fittings, as well as related assembly and test trial equipment.

I.M.M.® HYDRAULICS manufactures an extensive range of high and very high pressure rubber wire braided and wire multispiralled, thermoplastic and P.T.F.E. hoses for use in different industrial applications.

INTERPUMP/ I.M.M.® hose product range includes:

Double wire braid and four wire spiral hoses for marine and offshore applications,

Single/Double wire braid, four wire spiral, textile and suction line hoses conforming to different international standards,

High performance hoses including compressor, high and low temperature, HyOzone, HIPAC and others,

Thermoplastic and P.T.F.E. hoses

INTERPUMP/ I.M.M.® hoses are offered in desired cut lengths in meters but also in coils of specified meter lengths.

Different fittings, adapters, couplings and other components and accessories are offered for use with INTERPUMP/ I.M.M.® hoses.

Component compatibility, along with the use of quality components, insures the production of reliable hose assemblies when properly assembled. Use or intermixing of other components not specifically engineered and designed for use with INTERPUMP/ I.M.M.® hoses is not recommended and may result in the production of unsafe or unreliable hose assemblies.

Please refer to the supplied documentation or contact us for additional information or assistance on non listed products.

The  Parker Aerospace (Stratoflex Products Division) offers a broad array of PTFE, rubber and metal hose and hose assemblies, hose fittings, rigid tube assemblies, couplings, quick disconnects, swivel joints, fuel break-away valves, hydraulic fuses, and flow regulators, and specialty fittings including permanently swaged and welded fittings suitable for virtually any aerospace application. 680 Series are 90º elbow flared fittings  for use with Stratoflex 156 hoses. They come in different outside diameters (OD) and thread sizes in inches. Please refer to the attached Stratoflex catalog for offered hoses and fittings or contact us.

Hose and tubing insert fittings are available in high density black polyethylene or white nylon. Polyethylene fittings can be used with tygon, nylon or soft rubber tubing to assemble low pressure instrument lines such as airspeed pitot and static lines. Nylon fittings can be used in gravity-feed fuel lines and engine breather lines.
