Tubes, sleeves and fittings from various plastic materials such as Polyethylene (PE), Polyurethane (PU), Polyamide (Nylon, PA), Polypropylene (PP) or Polyvinyl Chloride (PVC)) are used in aerospace and many other industrial sectors for a range of hydraulic, pneumatic, instrumentation, insulation and other applications.

Plastic tubes sleeves  combine durability and flexibility with low cost and light weight. Depending on the selected tube/sleeve, and intended use, they have resistance properties such as chemical, abrasion, kink, wear and tear resistance, heat resistance, electrical insulation, biocompatibility, and others. Plastic tube fittings come in various configurations, including straight connectors, elbows, tees, and adapters. Common applications include those involving corrosive substances and others where weight reduction is crucial.

Tubes intended for electrical Insulation in aerospace are typically made of polyvinyl chloride (PVC) and conform with MIL-I-7444 and SAE-AMS-I-7444 standards. They are rigid or flexible tubes with uniform inside and outside diameters in the length, specifically designed to prevent any undesirable flow of current between conductors and other objects.They are used on electrical insulation applications requiring flexibility at low temperatures.

Sourced from leading manufacturers, plastc tubes/sleeves and related fittings are offered in different sizes to meet application requirements and sold in rolls (in the case of tubes or sleeves) or pieces and packs (in the case of fittings).

For additional information on the supplied products please refer to the Product Description section, the respective documentation included in the Attachment section or contact us.

AN840 series of pipe thread hose nipple fittings are offered as part of our own (AVIATIONEU NEW ERA) portfolio of fittings. Sourced from quality producers these fittings can be furnished in aluminum or brass in different tube internal diameters and thread sizes in inches.Aluminum are designated by the letter "D" after the suffix number of the product reference number (SKU).

EATON AEROQUIP® brand name represents quality and innovation for aerospace and other industrial applications with a wide range of hoses, fittings, couplings and connectors available to cover application requirements. Eaton’s hydraulics were acquired by DANFOSS and form part of DANFOSS product portfolio.

DANFOSS EATON AEROQUIP® AE246/AE446/AE546/AE846 Series Hoses are based on AE246 advanced technology designed, tested and proved high pressure 3000 psi PTFE hose with Hi-Pac®braid reinforcement containing densely packed small diameter wires braided over a minimum thickness Teflon tube. This reinforcement offers up to 50% lighter in weight while the wires absorb stress more uniformly resulting in a stronger wire braid with less metal. Available in different tubing sizes and internal diameters in inches. They meet or exceed AS1339 performance requirements.

The AE546 series hoses feature an integral braided polyester chafe guard (manufactured by braiding polyester yarn onto existing hose styles) while those of  AE246 series come with an integral silicone firesleeve.

The AE446 and AE846 Series hoses are AE246 high pressure teflon hoses with an integral silicone asbestos free fire protection (sleeve), adhering directly onto the hose metal braid and end fittings to form a smooth, tight bond.

Common end fittings used with these hoses include CRES fittings of -3 to -12 thread size, flared (MS33656), flareless (MS33514) or BSP type offered in straight, 45 deg and 90 deg styles.

“Super Gem” Reusable Flared Fittings can also be used with these hoses. They consist of 3 pieces: a socket, sleeve and nipple assembly.Made from corrosion resistant materials elbow fittings are available in standard, 45°, and 90° styles. Mate with AS4395 and AS33514 end connections. These service proven flared fittings provide permanent protection against leakage, even after high temperature aging and pressure impulsing to 250,000 cycles or more. This is due to the separation of the sealing function from the retention function.

The AEROQUIP® hoses are priced and sold by the foot unless otherwise specified. Fittings can be separately purchased in pieces.

For additional information please consult the Product Description section and the supplied documentation.

Flared tube coupling nuts conforming SAE International standard AS5175 are used for a leak-free solution on aircraft and other applications replacing respective AN818 parts. They are offered  as part of our own (AVIATIONEU NEW ERA) product lines in different materials and grades and multiple thread sizes to suit application needs. Material Code Letters in the part numbers indicate the composition of the fitting (No code for Steel 1137 or 4130, "D" for Aluminum alloys (except 7075-T73), "J" for 304 Stainless Steel (CRES 304), "K" for 316 Stainless Steel (CRES 316), "T" for Titanium 64AI-4V or "W" for Aluminum 7075-T73. These nuts are designed to be used with AS5176 and MS20819 sleeves. The 2 digits after the series code indicate the tubing outer diameter (O.D.)  in inches. Finish code “V” in the PN indicates high purity Aluminum coating for “W” or “D” fittings. Depending on their Part Number they are sold in pieces but also in packs a with specified number of fittings indicated after the letters "PK" in the product reference number (SKU).

Note: In SAE AS standards for new designs, aluminum fittings with material code letter D in their Part or Identifying Number (PIN) are replaced by those with material code letter W for Aluminum Alloy 7075-T73 providing a higher tensile strength.

EATON HANSEN HA 15000  Series couplings, now part of DANFOSS product portfolio,  are general purpose hydraulic and fluid transfer couplings conforming to the dimensional requirements of ISO 7241-1 Series A. Body sizes are 1/4", 3/8", 1/2", 3/4" and 1".

Standard Materials used in their manufacturing include:

• Zinc-plated steel construction

• Stainless steel springs, balls and retaining rings

• Buna-N (Nitrile) seals

Product Features:

• Ball lock

• Manual connect, disconnect

• Poppet valving

• Slim profile

• Zinc plated steel construction

• NPTF and BSPP end connections

• Available push-to-connect socket designed for bulkhead mounting (1/2" body size only)

Rated Pressure in PSI / BAR per Body Size

1/4" - 4,568 / 315

 3/8" - 4,568 / 315

 1/2" - 3,625 / 250

 3/4" - 3,625 / 250

 1" - 2,900 / 200

For additional information please refer to the supplied documentation or contact us.

Note: Special Order items. Non-Cancellable/Non-Returnable Upon Order Placement (NCNR).

GATES FLEXCORD PLUS Series lightweight straight coolant hoses have been designed to withstand today's severe conditions in automotive applications. They feature EPDM tube with Aramid reinforcement and EPDM cover.  Engineered to resist electrochemical degradation, the leading cause of hose failure they are very flexible hoses with a strong body to absorb vibrations and shock while their tubes and covers resist heat, ozone and coolant additives. Comply with SAE 20R4 class D2 and DIN 73411 class B1 norms.

GATES Type  4272 Flexcord Plus professional cooling water / heating hoses are offered in inner diameters 8-50mm and sold in pieces with a maximum length of 1 meter per piece.  Appearing prices are per piece of one meter each. For additional information please refer to the attached documentation.

Danfoss SEL brand includes a range of low, mid, and high pressure industrial and hydraulic rubber, thermoplastic, and PVC hoses that meet or exceed industry standards. Spanning a broad range of operating pressures, Danfoss SEL hoses are the perfect solution for maximum durability and long-lasting performance under even the toughest conditions. SEL product portfolio includes:

FORCESTREAM standard wire braided hydraulic hoses.

SUPERSTREAM and ULTRASTREAM premium wire braided hoses offering higher working pressures and improved flexibility.

POWERSTREAM spiral reinforced hydraulic hoses for high pressure applications.

COLDSTREAM  hydraulic hoses resistant to ambient temperatures down to -50 C, specifically designed for low temperature applications.

ULTIMATE hydraulic hoses supporting high temperature applications up to 135 C, or 150 C for short-term exposure.

ARMADILLO range of hydraulic hoses with specialized cover materials providing advantages like enhanced ozone or abrasion resistance. Ideal for demanding and dynamic applications, such as pit mining equipment.

SUPER ABRA hydraulic hoses offering an outer cover.

For additional information please refer to the supplied documentation.

NYLO-SEAL tube fittings are exceptionally strong. The bodies, made of nylon, are stronger than machined fittings of similar composition. They are furnished complete with nut/sleeve assemblies, made of acetal copolymer. Since the sleeve snaps into and is retained by the nut there is no fumbling for a loose sleeve. Just insert tube into the fitting and tighten the nut 2 to 2-1/2 full turns. Note: The most frequently used combination of tube and pipe sizes are 1/4" Tube x 1/8" Pipe and 3/8" Tube x1/4" Pipe.

EATON AEROQUIP® brand name represents quality and innovation for aerospace and other industrial applications with a wide range of hoses, fittings, couplings and connectors available to cover application requirements. Following the acquisition of Eaton’s hydraulics business by DANFOSS, EATON AEROQUIP® products form now part of DANFOSS product portfolio.

DANFOSS EATON AEROQUIP® BLIND-MATE quick disconnect couplings are utilized in advanced liquid cooled electronics and avionics thermal management systems. These couplings are used between removable cold plates and fixed manifolds to allow for quick leak free removal and replacement of both evaporative and liquid flow through systems. Blind-mate couplings provide unequaled performance in pressure drop, radial misalignment, and envelope. In addition, these couplings incorporate a patented integral thermal relief feature that prevents pressure buildup when the liquid cooling module is disconnected. Like other EATON AEROQUIP® quick disconnect couplings, they can be ordered as separate halves. Available in different sizes.

AEROQUIP® BLIND-MATE  couplings have been tested to meet or exceed SAE AS5072 for modular style couplings. These requirements include:

• Ability to operate within a temperature range of –65°F to +160°F (-54°C to +71°C)

• Capable of enduring 1000 connect/disconnect cycles without evidence of malfunction, leakage or damage

• Standard operating pressure of 150 PSI, proof pressure of 225 PSI, and burst pressure of 375 PSI

• Ability to tolerate proof and burst pressure without rupture or loss of fluid

• Ultra-low spillage during disconnection

• Integral thermal relief valve

• Minimal air inclusion during connection

Applications: Ethylene Glycol Water, Propylene Glycol Water, Polyalphaolefin (PAO) per MIL-C-87252

For additional information please refer to the supplied documentation or contact us.

Note: Special Order items. Non-Cancellable/Non-Returnable Upon Order Placement (NCNR). Minimum Order Quantities & long lead times usually apply. Contact us.

EATON AEROQUIP® brand name represents quality and innovation for aerospace and other industrial applications with a wide range of hoses, fittings, couplings and connectors available to cover application requirements. Following the acquisition of Eaton’s hydraulics business by DANFOSS, EATON AEROQUIP® products form now part of DANFOSS product portfolio.

DANFOSS EATON AEROQUIP® wire reinforced synthetic rubber hoses are offered in different series (types) described below to meet respective application requirements.

The AE701 hoses consist an upgraded version and a direct replacement for old 601 ones, widely used for aircraft fuel and oil lines where flexibility and light weight are prime considerations. They are made from specially formulated synthetic rubber  inner tube with two layers of stainless steel wire outer braid reinforcement.  Because of their lighter weight and lower operating pressure than type 303 hose, AE701 hoses are not recommended for hydraulic lines. The AE501 hoses are AE701 hoses overlaid with a blue braided chafeguard cover of tough polyester yarn. Both AE701 and  AE501 hoses meet MIL-H-83797, TSO C53a,Type A specification.

The AE401 series hoses are AE701 hoses with an integral cover of silicone rubber compound. They meet MIL-H-83797, TSO C53a,Type C specification.

Product Features:

Flexibility

Light weight

Non-age sensitive (no shelf life)

Fluid temperatures: -65°F (-54°C) to +300°F (+149°C)

TSO C53a, Type A and Type C approvals (with fire sleeve)

Mil-Spec Approvals: MIL-H-83796/1 through MIL-H-83796/9 Assemblies & MIL-H-83797 Hose, MIL-F-83798 Fittings

Field attachable fittings

Applications:  fuel, engine oil and coolants.

Available in different tubing sizes and internal diameters in inches. Priced and sold by the foot.

For additional information please refer to the supplied documentation ot contact us.

BAND-IT Junior® series smooth ID hose clamps come in a wide choice of widths, thicknesses and inside diameters in Imperial and Metric systems. They are made from different materials such as 201 austenitic chromium-nickel-manganese Stainless Steel, 316 Stainless Steel or Galvanized Carbon Steel (GCS). With their leak resistant design BAND-IT JS® clamps out-perform the other common clamping methods of hose sleeve clamping. They reduce the risk of leaks especially when used on thin walled hoses, ensuring that hose sleeving stays in place through the life of the sleeve. Their low profile buckle design reduces the clearance needed around the hose and has no sharp edges or tail that could cause injuries. Available for hose assemblies up to 8" outside diameter.

BAND-IT Junior® clamps are also offered as preformed clamps used in a wide array of agricultural and industrial applications. Preformed clamps are  made from Alloy 625, a nickel-chromium-molybdenum alloy known for its high strength, high toughness and excellent corrosion resistance. They are vibration resistant and require no hammering or crimping to complete installation. Clamps automatically lock in place under full tension in one simple level movement of the clamp tool(*).

BAND-IT JS® Clamp Features:

Vibration resistant lip lock design. No hammering or crimping

Unique buckle nest and smooth ID design reduces leak paths

Double wrapped steel bands for additional strength

Various materials for corrosive environments

Sold in packages with specified number of clamps per package indicated after the letters "PKG" in the product reference number (SKU).

For more information please refer to the product specifications or contact us.

(*) Note: BAND-IT Junior® Preformed Clamps should be installed using BAND-IT C001 Tool and J001 Junior® Adapter. 3/8" clamps can also be installed using the BAND-IT J020 POK-IT Tool.

Range of special accessories by FRANZ AIRCRAFT ENGINES for use in BRP-ROTAX® aircraft engines and other applications.

SAE100 R7 thermoplastic hydraulic hoses are commonly used with petroleum, fire-resistant, and water-base fluids, pneumatic, fuel, and lubricating systems. These hoses are poduced by different manufacturers such as KURT HYDRAULICS, DANFOSS EATON, PARKER and others they are offered as standard (conductive) and non-conductive (blocking electrical flow). They are generally composed of three parts: tube, reinforcement and cover. The tube and cover are made from high quality thermoplastic while reinforcement is made from suitable synthetic fiber.

KURT HYDRAULICS, part of KURT Manufacturing Group. manufactures and supplies a wide range of hydraulic fittings, hoses and couplings. The KURT HYDRAULICS thermoplastic hydraulic hoses are manufactured to the highest quality standards. Available in different grades for medium- to high-pressure applications in a range of sizes from 1/8” to 1”, depending on grade. Matching hydraulic fittings, quick crimpers, and more are also offered to create a complete hydraulic system.

KURT HYDRAULICS SAE100 R7 hoses feature a three-layer construction—nylon inner tubes, braided synthetic fiber reinforcements, and flexible, durable urethane outer sleeves. Offered in electrically conductive and non-conductive styles in most grades. They are rated up to 5000 PSI WP and 20000 PSI BP, varying by grade and diameter. All grades and sizes feature an operational temperature range from -40°F to +212°F.

Hoses are priced and sold by the foot unless otherwise specified. Fittings can be separately purchased in pieces.

For additional information on different products please consult the Product Description section, the supplied documentation or contact us.

EATON AEROQUIP® brand name represents quality and innovation for aerospace and other industrial applications with a wide range of hoses, fittings, couplings and connectors available to cover application requirements. Following the acquisition of Eaton’s hydraulics business by DANFOSS, EATON AEROQUIP® products form now part of DANFOSS product portfolio.

DANFOSS EATON AEROQUIP® 491 and 471 hose fittings consist of an AN818 style nut, an externally threaded 37 nipple and an internally threaded hose socket. Fittings of sizes 3 through 6 have nuts and nipples of cadmium plated steel. Nuts and nipples for size 8 and larger are of anodized aluminum. Fittings conform to MS24587. Available in different tube and thread sizes in inches.

For additional information please consult the supplied documentation or contact us.

DANFOSS EATON SYNFLEX® subsea hoses and bundles are built to meet and exceed the most demanding industry requirements. Their rigorous hose qualification ensures long hose service life while their robust construction enables them to withstand high pressures. They are offered in long, continuous lengths to cover requirements of diverse applications all over the world.

At its core, SYNFLEX® High Pressure hose is a smooth, seamless, continuous extrusion of Nylon 11 Besno P40 TLO. The hose is reinforced with premium aramid fiber and jacketed with a highly UV resistant thermoplastic for long term aging and resistance to hydrolysis. Long continuous lengths are available for subsea bundles and single line applications. Available in 3,000, 5,000, 10,000, and 15,000 psi working pressures these hoses are lightweight, easy to install and assemble, and available in multiple sizes and long continuous lengths. Used in a wide range of applications including Hydraulic flying leads, workover umbilical components, hot lines, chemical, water and nitrogen injections and  subsea blow out prevention (BOP) bundles and hot lines enabling faster and more effective response to subsea events.

Like in other SYNFLEX® hoses, approved Eaton components are offered to ensure complete hose assembly systems.

Hoses are priced and sold by the foot unless otherwise specified. Fittings can be separately purchased in pieces.

For additional information on different products please consult the Product Description section, supplied documentation or contact us.

SAE-AS5406/AN832 series union tube hydraulic fittings are available as part of our own labelled (AVIATIONEU NEW ERA) product lines in different materials, tube outer diameters and thread sizes in inches. The AN832 series fittings are superseded by the respective fittings of  SAE International standard  SAE-AS5406 series.

Like their SAE-AS5174/MS24392/AN815 union flared tube counterparts, SAE-AS5406/AN832 series fittings are manufactured from Carbon Steel, Aluminum Alloy, Corrosion Resistant Steel (CRES), Titanium Alloy. The 2 digits after the series code indicate the tubing outer diameter (O.D.)  in inches. The following Material Code Letters in the part numbers indicate the composition of the fitting.

No code letter in part number for Carbon Steel

Code letter “D” for Aluminum Alloy (except 7075-T73)

Code letter “J” for CRES, type 304

Code letter “K” for CRES, type 316

Code letter “S” for CRES, type 347

Code letter “T” for Titanium Alloy 6AL-4V

Code letter “W” for Aluminum Alloy 7075-T73

For example, AS5406D06 union fitting is made from Aluminum Alloy with a tubing outer diameter (O.D.) 3/8". The corresponding union fitting in AN832 series would be AN832-6D.

Depending on their Part Number they are sold in pieces but also in packs a with specified number of fittings indicated after the letters "PK" in the product reference number (SKU).

EATON AEROQUIP® brand name represents quality and innovation for aerospace and other industrial applications with a wide range of hoses, fittings, couplings and connectors available to cover application requirements. Following the acquisition of Eaton’s hydraulics business by DANFOSS, EATON AEROQUIP® products form now part of DANFOSS product portfolio.

DANFOSS EATON AEROQUIP® 816/8846/8891 series flared hose fittings can be used with DANFOSS EATON AEROQUIP® 601 hoses  and are available in different sizes. The 816 series straight hose fittings and 8891 series 90 Deg. hose fittings both consist of a pre-assembled nut/nipple assembly and an internally threaded hose socket. The size 4 fitting has a cadmium plated steel nut and nipple. Sizes 6, 8 and 10 nuts and nipples, and all sizes of sockets, are anodized aluminum. The 8846 series fittings are 45° hose fittings with swivel flared UNJF threads. They are noted for their outstanding performance as a result of a unique lipseal design concept. During assembly the nipple spur cuts a lip in the tube stock of the hose forming the fluid seal.

For additional information please consult the supplied documentation or contact us.

Note: DANFOSS EATON AEROQUIP® 816 fittings ARE NOT THE SAME as AN816 fittings. Please specify at the time of ordering.

Eaton's Aeroquip® brand name represents quality and innovation in the aerospace industry and a wide range of options are available to meet the needs of aircraft OEM and maintenance engineers. Eaton’s Aeroquip hose, fittings, couplings and connectors are available for various pressures and applications. Lightweight and flexible rubber hoses, fittings & assemblies for aerospace applications qualified to industry standards are included within the company's product portfolio. The 306 Series is intended for low pressure while the 302A/303 Series (see separate product presentation) for medium pressure applications.

The 302A/303 medium pressure hose includes a seamless synthetic rubber compound inner tube with a single cotton braid reinforcement and a synthetic rubber outer cover. Operating temperatures: -65°F to +160°F (-53ºC to +71ºC). Used in air or vacuum instrument systems, automatic pilots and lines to pressure gauges used with these systems as specified in MS33620. Hose conforms to MIL-DTL-5593. Used with Aeroquip 491 hose fittings. Available in different tubing sizes and internal diameters in inches. Sold by the foot. Fittings are offfered in pieces and conform to MILDTL-38726 and MS27404 (superceding AN773). Hose assemblies conform to AN6270. For additional information please refer to the attached documentation.

EATON HANSEN FF (Flat Face) Series quick disconnect couplings, now part of DANFOSS product portfolio, are specifically designed for those applications where quick and easy connections and no-spill performance are essential. The FF Series is ideal for use when global interchangeability with other manufacturers is important and is available in sizes from 1/4” through 2” to best meet your specific size requirements.

Product Features:

• Meets or exceeds the ISO 16028 standard

• Push-to-connect

• Standard sleeve lock prevents accidental disconnection

• Color identification rings available to help prevent crossing of lines

• Standard Material: High-resistant carbon steel with Guardian Seal™ plating, a whole new level of corrosion resistance with minimum 720 hours RR protection

• Guardian Seal™ plating

• Nickel-free

• Solvent-free

• Meets Global RoHS, ELV and REACH requirements

• Standard Seal Material: NBR+AU

• Available seal options: NBR+AU, FKM, EPDM, HNBR (upon request)

Applications:

• Hydraulic and Fluid Transfer

• Construction equipment

• Agricultural equipment

• Utility vehicles

• On-Highway vehicles

• Stationary in-plant hydraulics and fluid transfer

• Interchangeable with HTMA couplings in the 3/8” size

For additional information please refer to the supplied documentation or contact us.

Note: Special Order items. Non-Cancellable/Non-Returnable Upon Order Placement (NCNR).
