GARMIN® GTX™ transponder product line includes Mode A/C and Mode S TSO'd panel mounted transponders offered in a‭ ‬wide variety of configurations to choose‭ ‬from‭, ‬depending on desired functions‭.‬ Different models are listed under separate product presentations.

GARMIN® GTX™ 327  is a TSO-certified Mode C digital transponder. Its innovative features, proven performance and reliability bring a whole new level of transponder utility to your aircraft. Features include a solid state design, and with no warm up time, lower power consumption and much lower heat emissions for a longer service life. It provides 200 watts nominal power output and has an easy-to-read DSTN liquid crystal display which reverses the numbers out of black for optimal viewing. An innovative keypad facilitates entering a squawk code while a dedicated VFR button allows for quick-and-easy VFR squawking. Similar to the GTX™ 330 Mode S transponder, the GTX™  327 also offers several timing and display functions, including flight time, count-up and count-down timers, as well as current pressure altitude.

GARMIN® GTX™ 327 Specifications:

Solid State Digital Transmitter

Mode: A/C

Display: DSTN LCD Display

Nominal Output Power: 200 watts

Dimensions: 6.25"W x 1.65"H x 8.73"D (15.9 x 4.2 x 22.2 cm)

Weight: 3.1 lbs. (1.4 kg)

Product includes: GTX 327 Transponder, Installation kit, Pilot's guide

Both GARMIN® GMA 345 and 350 are certified (TSO'd) Audio Control Panels for General Aviation aircraft.

Bringing rich “home theater” quality sound and wireless Bluetooth¹ audio connectivity to your avionics stack, the GARMIN® GMA 345 digital audio panel offers a superior inflight audio experience at an affordable price. Featuring 3-D spatial sound processing, a USB charging port, marker beacon receiver, advanced auto squelch, clearance playback and impressive audio mixing and distribution features, this all-digital unit offers the ideal blend of capabilities for pilots who want to hear and do more with less effort in the cockpit. In addition, it’s an easy slide-in upgrade to legacy GMA 340 units and selected third-party audio panels. Offered with optional 3-COMM support.

The GARMIN® GMA 350 is the first truly all-digital audio panel, introducing a number of new technologies to the cockpit, including Telligence™ Voice Command, 3-D audio processing and advanced auto squelch. Virtual 3-D audio processing adjusts audio in the headset to mimic how the human ear normally hears and registers sounds in space. Advanced auto squelch automatically adapts to a quiet or noisy cockpit without clipping words or cutting out in the middle of phrases. Offered with or without Bluetooth connectivity.

For additional information please consult the Product Description section and the supplied documentation.

Installation parts and accessories for GARMIN® Audio Control Panels are sold separately. Please refer to the respective product presentation.

These precision quartz electric aircraft clocks are constructed for easy installation in a wide variety of replacement applications for home builts. The rugged quartz movement is accurate within 2 sec. in 24 hrs under normal operations and runs accurately in temperatures from -30º to 180ºF. Available in 14 Volt or 24 Volt versions.

Product Specifications:

OD: 2-1/4"

Depth: 2"

Weight: 4 ounces

Designed to help the pilot determine altitude by measuring existing atmospheric pressure, the altimeter translates the measurement into “height above sea level.” This is indicated on the dial of the instrument in feet, which requires setting the barometric pressure in the Kollsman window.

UNITED INSTRUMENTS 5934 series are FAA TSO'd 3"/ 3-pointer altimeters, intended for use with most single engine, turbo/piston prop aircraft. They are offered in 5934 and 5934A models with respective maximum calibrated ranges  of -1.000 to 20.000 feet and  -1.000 to 35.000 feet respectively. All lighted instruments require a light tray sold separately.

Product Features:

Affordable, certified 3-1/8" case for half the cost of existing systems

United series 5934

All units approved to FAA TSO (C10b,C2b and C4c)

Anti-reflective glass enhances visibility and reduces pilot fatigue

Altimeter available with right-hand or left hand knob 20,000 or 35,000 ft. Hg or Mb

All instruments are made in the USA

One year limited warranty

Product Specifications:

Typical Weight: 13 oz

Number of Pointers: 3

Barometric Setting: 28.1 to 31.0 in HG / 946 to 1050 mb

Calibrated Ranges: -1,000 to +20,000 or +35,000 feet

Static Pressure Connection: 1/8-27 ANPT

Installation: Removable Spring Nuts and screws

For additional information please consult the supplied documentation.

The HONEYWELL BENDIX KING® KX-125 is ideal as a replacement radio, a primary system for homebuilts or a very affordable back-up. despite its low price, it comes with a complete list of features. Its COMM section provides 760 frequencies, 'flip-flop' frequency selection, a built-in audio amplifier with side-tone and audio leveling, direct tuning, stuck-microphone alert, and even remote transfer of both COMM and NAV frequencies. The separate NAV section offers 200 frequencies, including localizer. It has gone through environmental testing and has FAA TSO approval but will still require a FAA 337 form for new installations.

Product Specifications:

Dimensions: 6.25"W x 2"H x 10.16"L

Weight: 3.88 lbs

Power Requirement: 14Vdc

Temperature Range: -20C to 55C

Altitude Range: Up to 35,000ft

Lighting: 14 Vdc

Transmitter Power: 5 watts minimum (7watts nominal)

TSO Compliance: C37c, C38c , C36e, C40c

Stratus ESG digital transponders by APPAREO have been designed with non-glass panel aircraft in mind. Different models are offered for non certified and certified aircraft. Stratus ESG transponders feature 1090 ES (Mode-S extended squitter), 310 W nominal power output, a built-in WAAS GPS, compliance with global mandates for ADS-B Out transponders, push-button operation with modern keypad makes entering a squawk code easy, easy-to-use interface and pressure altitude monitor. Their form-factor enables easy replacement for existing transponders.

Version for non certified aircraft is offered as unit only or together with wire pigtail.

The version for certified aircraft is TSO'd and can be used to replace existing transponders in a wide range of aircraft models from different aircraft manufacturers like Cessna, Piper, Beechcraft, Mooney, Diamond and others. Certified units can only be shipped to a certified Appareo installer.

Product Specifications:

Bezel Height: 1.69 in. (43 mm)

Bezel Width: 6.38 in. (162 mm)

Depth: 10.75 in. (273 mm) front of panel to connector backshell

Weight: 3.29 lbs. (1.49 kg) including rack and connectors

Operating Temperature: -20°C to 55°C

Storage Temperature: -55°C to 85°C

Power Input: 9.0 to 36.0 VDC, 15 W typical

Cooling Input: No fan required

Environmental Compliance: DO-160G

Software Compliance: DO-178B Level C

Hardware Compliance: DO-254 Level C

TSO Compliance: C112e (Level 2els, Class 1), C145d (Class Beta 1 GPS/WAAS), C166b (Class B1S)

Display: OLED

Transmitter Power: 310 W

Accelerometers (aka G-Meters) are used extensively in a wide range of applications including Aviation, Marine, Automotive, Military, and others. They are also used  in inertial navigation and guidance systems in airplane and ship autopilots.They help in a better understanding of static, such as gravity, or dynamic forces due to motion or vibration acting on an object.

Original Mechanical and more recent Digital accelerometers, used on civil and military aircraft, measure the instantaneous acceleration (or G-force) of an aircraft and its occupants compared to Earth's standard gravitational pull, in units of "G" (e.g., 1G, 2G). They enable pilots to monitor flight conditions, maintain safety, or practice aerobatics or combat maneuvers. Made by different manufacturers, they are offered as non-certified instruments, for use on  experimental and homebuilt aircraft, or certified products, installed on civil transport an military aircraft.

Mechanical accelerometers, included in this listing, use traditional components like proof masses, springs, and damping to measure acceleration based on displacement, offering high accuracy and durability for specific applications like flight stabilization and weapons communication. They are often of larger size and more expensive. Digital accelerometers, separately listed, are often Micromachined Micro-electromechanical (MEMS) systems, integrating sensors with microelectronic circuits for smaller size, lower cost, and high precision, making them ideal for flight stabilization, AHARS, and autopilot systems.

The choice of an accelerometer depends on the application's need for accuracy, size, cost, and resistance to harsh environments.

Please consult the Product Description section and the supplied documentation for more information on different brands of our offered accelerometers.

DUKANE SEACOM, wholly-owned subsidiary of HEICO Corporation, is the world’s leading supplier of FAA / EASA  & BSH qualified (Certified) high-impact underwater acoustic beacons for  the commercial air transport, business and regional jets, as well as fixed and rotary wing commercial and military markets. Other products in DUKANE SEACOM range include marine underwater beacons for Voyage Data Recorder (VDR) applications and Emergency Locator Transmitters (ELT) separately listed.

The DK120/90 was the first ULB certified to provide a minimum of 90-day underwater operating life. Certified to TSO-C121b & TSO-C142a and ESO ETSO-C121b & ETSO-C142a. Airframe mounted DK180 series low frequency beacon is designed and qualified to meet the newly developed standards FAA TSO-C200 / ETSO-C200 dated 6/26/2012 as per SAE–AS6254 & ARINC 667. For applications not requiring compliance to the 90-day operating requirement, the DUKANE SEACOM DK120/90 and DK140 (short) are still available.  An overview of DUKANE SEACOM Aviation  Underwater Location Beacons is provided in the Product Description Section.

OMRON A3C series cylindrical pushbutton switches have the basic design as the M2C Series cylindrical indicators. They provide a high-intensity uniform surface lighting while they have a miniature size with excellent feeling of operation. They have a cylindrical 20-mmX12-dia. body making panel cutouts easier. These switches are offered in lighted and non lighted versions, different colors, display shapes, with LED or incandescent lamps and different socket units. Please consult the attached documentation for ordering.

UMA Non FAA Approved standard 2-1/4" and 3-1/8" altimeters are high quality, simple type (single pointer) with 2 revolution dial, designed to meet the needs of the low cost non-IFR users. Both altimeters utilize a knob adjustable barometric in. Hg scale, viewed through a Kollsman Window.

Product Specifications:

Case: Aluminum Casting

Weight: 10.6 oz.

Case: Valox 420 Plastic

Weight: 5.0 oz.

Not FAA Approved

The EDM 930 by JPI collects and displays engine data in a useful way. This EDM monitors engine temperatures and voltages, adjusts the fuel/air mixture, and diagnoses engine malfunctions. The EDM 930 display screen is arranged into three sections. The top left is the RPM and MAP section. The bottom left is the Scanner® section. And the right side is the Bar Graphs section.

The RPM and MAP Display shows the RPM (Revolutions per Minute) and the MAP (Manifold Pressure).

The Bar Graphs Display shows:

- Oil temperature

- Oil pressure

- Fuel pressure

- Bus voltage

- Amps load or charge/discharge

- Outside air temperature (or owner selectable )

- Fuel flow, units per hour

- Left fuel quantity (or owner selectable)

- Right fuel quantity (or owner selectable)

The Scanner Display has the exhaust gas temperature (EGT) bar graph presentation as its central part with additional Cylinder Head Temperature (CHT) and TIT indications.

The Distance Measuring Equipment (DME) systems used on aircraft provide information on aircraft slant distance, ground speed, and time to a ground station. They operate in the 960 – 1215 MHz frequency band.

HONEYWELL BENDIX KING®, a leading avionics manufacturer offers panel mounted, remote DME, DME displays outlined below as well as accesories such as racks & connectors for DME installation and connection. They are offered for outright sale or in exchange for returned customer owned units in NEW Condition or USED (Serviceable or Overhauled) Conditions. The letters "SV","OH" and "EX" in the product reference numbers (SKU) indicate the condition/sale terms.

For additional information please consult the Product Description section & the supplied documentation.

HONEYWELL BENDIX KING® Panel Mounted DME

BENDIX KING® Silver Crown Plus line of Panel Mounted 100 watt KN 62A and 50 watt KN 64 DME are self-contained, 200-channel systems, which can be channeled remotely through almost any NAV receiver or tuned directly with their own frequency selection knobs. They offer dual channeling capability with two DME frequencies available at all times (one remote & one stored internally). Also feature redesigned faceplates for improved readings' illumination, large sturdy knobs and a three-position function switch for easy operation. They operate on any 11 to 33 VDC voltage without adapters or power converters while due to their modest power requirements no external cooling is needed.

HONEYWELL BENDIX KING® Remote DME

BENDIX KING® TSO'd KN 63 DME is a complete 100 watt, 200-channel remote DME system utilizing Large Scale Integrated (LSI) circuit technology. Offering significant advantages in DME reliability and performance, the KN 63 is all solid-state (no transmitter tubes) and can be installed with either single or dual panel DME indicators (displays) such as the BENDIX KING® KDI-572 or KDI-574.

HONEYWELL BENDIX KING® DME Displays

BENDIX KING® TSO'd KDI-572 or KDI-574 DME Displays can be used as master display controls and  information displays from KN 63 remote DME transceiver. The top-quality KDI 572 DME displays distance, groundspeed, and time-to-station all at the same time. Slant-range distance is computed digitally and displayed up to the maximum range of 399 nautical miles. Station lock-on is typically achieved within three seconds, with accurate groundspeed and time to station computations becoming available within one minute. The KDI 572's single control switch offers easy operation of the entire DME system as well as DME channeling. It has settings for ON/OFF, NAV 1, NAV 2, and DME HOLD. Comes with an indicator for area navigation (RNAV) to let you know if the displayed distance and time are to a waypoint or a radio navigation beacon. The TSO'd KDI 574 DME display is similar to KDI-572 but DOES NOT include ON/OFF, NAV 1/2, DME Hold selector. For use with Bendix/King Remote DMEs KDM-706 / KDM-706A, KN-63 DME and KTU-709 TACAN.

The SIRS "Navigator" magnetic compass delivers extremely accurate readings due to its fully integrated, 4 magnet correction facility.  It has the same features as the "Pegasus", but is mounted with a fully adjustable bracket that allows attachment to a variety of positions including the glare-shield or the windshield. This allows the compass to be located away from magnetic influences. Available in different versions for Northern or Southern hemisphere, unlighted  or lighted 12/28V and has a 3-year warranty. Size: 203/8" H x 2-1/4" W. Product accessories such as installation kit, GS1 glareshield mount, SIRS MF1 short foot bracket and SIRS compass correction key are also available and sold separately.

The  MID CONTINENT® INSTRUMENT (MCI) MD–90 Series Precision Quartz Clocks provide  an ideal solution for accurate time-keeping, and consist original equipment for many major aircraft manufacturers. Designed for accurancy, the 2-inch MD–90 Series clocks are manufactured to meet rugged aircraft environmental standards, they are FAA/PMA certified and offered in standard MD–90–1 and MD–90L versions, both operating with 8–32 VDC power input. Their key features include:

Precision quartz movement

Compact 2-inch size — fit standard panel cutout

Lighted version available with field-replaceable light tray

Transient and reverse polarity protection

Extremely low current consumption (3 mA)

Continuously powered by aircraft battery

FAA PMA certified

Designed and built in the USA

One-year limited warranty

Product Specifications:

Power Input: 8–32 VDC - 3 mA max (without lighting)

Accuracy:  ±30 seconds in 24 hrs

Dimensions: 2.5 x 2.5 x 3.2 inches max

Weight: 0.5 lbs

Temperature: –40°C to +82°C (–40°F to +180°F)

Altitude: –1,000 to +55,000 feet

Humidity: 0 to 95% at 25°C

Vibration: .02 in. dbl. ampl., 1.5g @ 5 to 50 Hz

Mounting: Front or rear panel mounted

Connector: #6-32 threaded terminals

For additional information please consult the supplied documentation.

GARMIN GI-106B TSO'd panel-mounted CDI is a high-quality course deviation indicator which includes a VOR/LOC/GPS needle as well as a glideslope needle, that can be hidden and disabled by an installer if the glideslope functionality is not needed. The GI 106B contains LED-lit GPS, NAV and VLOC mode annunciators, for an easy-to-read and modern look. TO/FROM annunciators are also LED, and when invalid, the needles are simply hidden out of the pilot’s view instead of using conventional invalid flags. The GI 106B replaces existing Garmin GI-102A & GI-106A models. It is compatible with the same pinout connections as the legacy GI 102A and GI 106A course deviation indicators, allowing for an easy upgrade path. It also features anti-reflective lenses and LED flood lighting for viewing at night.

The ICOM IC-A220 Series of VHF Air Band 760 COMM transceivers operating in 118-136.975MHz range are offered as non certified (IC-A220) or certified (IC-A220T) versions. The IC-A220  is a popular fit with experimental and light sport aircraft. The TSO/ETSO approved IC-A220T will work for all certified aircraft and it comes as a standard unit complete with install kit and mounting tray (IC-A220T), adapted unit IC-A220T-K with edge connector MBA-3 (*) fitted as a replacement for King KY96A/97A, KY196A/197A (**), Icom A200 or A210,and adapted unit IC-A220T-G with D-Sub connector MB113 as a replacement for Garmin SL40 (***).

Production of  IC-A220T has been discontinued. IC-A220T transceivers have limited availability  in NEW or NEW SURPLUS condition from existing stocks and they are also offered as USED units.

Both IC-A220 and IC-A220T radios support  8.33 kHz and 25 kHz frequency spacings and feature OLED display, 20 memory channels and 20 history memory channels, "flip-flop" arrow button switches between main and stand-by channels, 8W output power, a built-in 2 station intercom, 12 or 24 volt compatibility and automatic squelch. They can be used for radio upgrades and replacecements of  KY96A/KY97A & SL40 radios.

(*) The MBA-3 is intended for use with the Non-TSO'd model (IC-A220). Use with the TSO'd model (IC-A220T) may void the TSO.

(**) The adapted unit will not directly replace King KY96, KY97, KY196 or KY197 units.

(***) Metal work modification is required as the locking mechanism for the IC-A220T is in a different position on the SL40 tray/rack.

FLYBOX® brand  by MICROEL SRL relates to a wide range of avionics and flight instruments specialy designed and developed for ultralight and experimental aircraft. FLYBOX® product portfolio includes

My-EMS & Vigilus Engine Monitoring Systems

Engimaster EMS Engine Monitoring Systems

Oblò,  Oblò 2 and Eclipse NG Electronic Flight Instrument Systems (EFIS)

Omnia 57 and 80 Series of Legacy Instruments/Indicators

FLYBOX® Autopilot Systems

Flap & Propeller Controllers

For further information please refer to the Product Description section & the supplied documentation.

AMPHENOL Bayonet Neill Concelman (BNC) product series connectors are miniature quick connect RF connectors. They feature two bayonet lugs on the female connector. BNCs are ideally suited for termination on miniature and subminiature coaxial cable (RG-58, 59, to RG-179, RG-316, etc.). Other BNC series include:

HD-BNC product series featuring the trusted, push and turn interface of a traditional BNC and providing tactile feedback and a positive lock for quick and guaranteed mating and

Mini-BNC product series allowing higher connector densities while preserving the positive characteristics of the full-size 75 Ω BNC. The Mini-BNC provides the same positive locking bayonet system found on the BNC but allows 40% more interconnects in the same area.

HONEYWELL BENDIX KING® KX 155A and KX 165A TSO'd Panel-Mounted NAVCOMM Transceivers update the concept of the combined navigation and communications radio for the 21st century. With such features as programmable comm channels, support for 8.33 kHz Comm tuning (KX 165A model only), GPS QuickTune, multiple operating modes, remote channel increment with flip-flop tuning & a built-in timer, they combine a sophisticated appearance with a number of advanced capabilities including:

Programming of up to 32 Comm channels in a non-volatile memory circuit for ready recall of regularly used frequencies.

Pre-selected frequencies stored in a non-volatile memory circuit.

When interfaced to the KLN 94 GPS, both the standby Comm and Nav frequencies can be selected and remotely tuned from the GPS database.

The KX155A (a KX155 upgrade) provides access to all 200 NAV and 760 COMM frequencies, along with its optional 40-channel glideslope. In addition to its standard use, it incorporates new features including a bearing-to-station mode and a radial-from-station mode, an internal Course Deviation Indicator (CDI) for use when the external CDI is being driven by a GPS receiver, and an elapsed-time and approach timer. The KX 155A system offers 10W minimum COMM transmitter power.

The KX-165A NAV/COMM replaces BENDIX KING® KX-155, KX-155A and KX-165 NAV/COMMs which are discontinued but are still available for outright sale or in exchange for returned customer owned units in USED Serviceable or Overhauled Conditions with FAA 8130-3 Form certification. The letters "SV","OH" and "EX" in the product reference numbers (SKU) indicate the condition/sale terms.

Very similar to KX 155, the BENDIX KING® KX 165 NAV/COMM additionally incorporates an internal VOR/LOC Converter to directly drive the BENDIX KING®  KI 525A HSI (part of the KCS 55A Compass System). It can also display the current radial from the active VOR instead of the standby NAV frequency. Other features include 10 watts min transmitter power, easy-to-read, bright gas-discharge display, large, self-dimming, microprocessor- controlled gas discharge readouts and solid-state electronic tuning for fast, accurate selection of all 200 NAV and 760 COMM frequencies.

The KX 165A (-0201 model) NAV/COMM is a slide in 8.33 kHz replacement for its predecessors, the KX 155A which is discontinued and KX 165A 25 kHz NAV/COMMs (-0101 model). Completely redesigned, it features programmable Comm channels, support for 8.33kHz Comm tuning, GPS Quick-Tune, multiple operating modes, remote channel increment with flip-flop tuning and a built-in timer.

Mounting racks, connectors and manuals  for the installation of the NAV/COMMs are also offered.

For additional information please consult the Product Description section and the supplied documentation.
