The KLIXON® 7270/7271 series circuit breakers were designed to utilize less behind panel space while protecting wire and cable in aircraft and ground support equipment on either 120 VAC, 400 Hz or 30 VDC systems.

These circuit breakers are available with neck mounting (7270-1 and 7271-8) or standard cover plate (7270-7 and 7271-3). In each of these KLIXON® circuit breakers, the bi-metallic element assures uniform current distribution throughout its responsive area. This design reduces current density at the critical areas, resulting in an element having a much higher interrupting capability than conventional design. Inherently resistant to shock and vibration, the KLIXON® disc element is capable of precise calibration settings and will retain the initial calibration within close tolerances throughout the service life of the breaker. Both circuit breakers have conventional actuator action; i.e., the toggle actuator on the 7270 moves to the OFF position for trip indication and the button the 7271 pops out. A standard black button with a white collar is used. For additional information please refer to the attached documentation.

Military Specification MS35058 Series Toggle Switches can be used to upgrade your aircraft's cockpit controls. These heavy-duty metal switches have a standard shape that works well for a variety of applications can be used for most components that only function in either the on or off positions. They are available in several sizes to fit your particular airplane and are shipped with all necessary rings and hardware for installation. Toggle switches are available with two or three operating positions, 1 or 3 hole mounting and a variety of circuitry & electrical ratings. Contacts are made of solid silver. Wide usage is found in aircraft, mobile, marine, electronic and industrial applications. Available in full "AN" standard size & Ultra Miniature 1/2" size, contact types and circuit codes (see reference chart).

Different bolts used on Textron Aviation Cessna, Beechcraft and Hawker aircraft. Also available as FAA-PMA approved parts from other manufacturers.

Fine quality switch from ACS used in many aircraft. The switch housing is machined from billet aluminum which makes this switch 25% lighter. It provides “ON” and “OFF” electrical control of both magnetos on a single engine aircraft. The key-operated switch mounts from the rear of the panel in a 7/8” dia hole. Available with or without starter position. A-510-2 model with starter position is supplied with switch plate two keys. (diode included). FAA PMA Approved. Made in USA.

The SPRL fuel locking and non-locking caps have secure sealing and easy finger tip operation. These caps are made from the highest quality modern engineering plastics with Viton o ring seals (which can be easily replaced). The mounting rings are anodized aluminum with the flange recessed to give a perfect flush fit whether it is riveted under a metal skin, as in the RV series, or built into a composite structure. The SPRL caps are non vented and recommended to keep the fuel in, the water out and in the locking version, other unwanted items out of your tank.

SPRL-L (locking) and SPRL-S (non-locking) fuel  caps have an 65 mm O.D. and can be used on Europa, Compair, Glasair, Lancair, Murphy, OMF, Rocket, Velocity, Zenith and many more experimental aircraft. Wt: 80 grams.

DUNLOP AIRCRAFT TYRES manufactures several different types of aircraft tIre for many applications: bias tIres for modern jet and military aircraft, radial tires for military jets, bias tires for helicopters and chined tyres used for nose wheel applications primarily on rear-engined jet aircraft   Different tire size designations grouped into various 'types' are also used such as Type III mainly for low-pressure service on older piston-driven aircraft or Type VII related to high-pressure tires with high load capacity designed for modern jet and turboprop aircraft. All DUNLOP aircraft tires are manufactured in accordance with TSO-C62, MIL-PERF-5041 or AIR8505A and/or applicable airframe manufacturer specifications.

DUNLOP aircraft tires are offered as NEW or RETREAD ( the second designated by the letters "RT" after the product reference number (SKU).

DUNLOP does not mandate a maximum shelf life for its tires, so long as the storage conditions are met. The company recommends that tires be kept in a store for no more than 12 years from their date of manufacture, if they are to stay serviceable.

DUNLOP aircraft tires have a warranty of 12 months from the date of their delivery. The company undertakes at its option to repair or replace them or refund the customer for any of the tires which are defective by reason of defective material, design or workmanship.

DUNLOP AIRCRAFT TYRES also produces aircraft inner tubes manufactured to rigorous standards which meet or exceed all commercial and military performance requirements, including MIL-I-5014 military specification (except for packaging).

They are made from natural rubber which ensures maximum life and meets cold temperature performance requirements.

DUNLOP inner tubes are factory balanced. The heavy spot is marked in red. If there is no red mark, the valve is considered the heavy spot. The valve stem, core and cap are manufactured for aircraft use and designed for high and low pressure requirements.

For additional information on DUNLOP AIRCRAFT TYRES  products please consult the supplied Guide and tire specification sheets.

GROVE manufactures axles and hardware for use in GROVE wheels as well as those of other manufacturers.

GROVE 500x5 wheel axles (P/N. 5013 standard and P/N. 5018 with wheel pant stub) are produced from solid 2024-T3 aluminum with anodized finish. They have a 1-15/16" Bolt Circle hole pattern and 1/4" diameter holes.

500x5 1-1/4" diameter standard axle (P/N. 5013) is the most popular axle for 500x5 wheels. It is designed to fit Grove 50-1, 51-1, 56-1, 57-1, 57-5 and Cleveland 500x5 wheels. Axle Weight: 0.92 lbs. Static Load Rating 1,250 lbs.

500x5 1-1/4" diameter axle (P/N. 5018) has built-in wheel pant stub with 1/4-28 thread. It is designed for use with Grove 50-1, 51-1, 56-1, 57-1, 57-5 and Cleveland 500x5 wheels. Axle Weight: 0.95 lbs. Static Load Rating 1,250 lbs.

Both axles require two spacers per axle (P/N. 5710) sold separately.  I.D: 1-1/4", O.D. 1-3/4", Thickness: 1/4". They can be used with 500x5 axles.

Standard axle nuts and axle bolt kits sold separately are also offered as part of GROVE product portfolio. Castle type nuts are manufactured to MIL Specification MS21025 using 4140 steel. Mild steel nuts are not acceptable for use on certificated aircraft. 1-1/4" dia. nuts for 500 x 5 axles, 1-1/2" dia. nuts for 600 x 6 axles.

In 1971 AURORA BEARING COMPANY entered the rod end and spherical bearing market and soon became a major force in the rod end industry. The AURORA BEARING product potfolio today includes both Aerospace / Military and Commercial / Industrial rod ends and standard spherical bearings in inch and metric systems while special bearings can be designed and manufactured on request. Different series of these bearings are separately presented together with respective documentation.

AURORA BEARING MM & MB Series include Precision General Purpose Male Rod Ends with the following features. Rod ends in these series are equivalent to RBC® HEIM® BEARINGS part numbers shown in the parenthesis.

Body - Low carbon steel, protective coated for corrosion resistance. Size 16 standard series body is alloy steel not heat treated.

Ball - Alloy steel, heat treated, hard chrome plated.

Race - Low carbon steel, protective coated for corrosion resistance.

Grease Fitting -  supplied without grease fittings. When a grease fitting is required, specify by adding suffix "Z" or "F". Ex.: MM-6Z = Zerk Type Fitting MM-6F = Flush Type Fitting.

Load ratings apply only to rod ends without grease fittings.

PTFE Liners available upon request. Specify by adding suffix "T". Ex.: MM-6T.

ALPHA AVIATION is a supplier of new, replacement and upgrade restraint systems based on AMSAFE® restraints. ALPHA AVIATION restraints are available for many models of General Aviation aircraft including Cessna 150, 150A thru K, Cessna 172L thru Q, 172RG (rear harnesses), Cessna 200 series and M20 A thru early J model aircraft which can add restraint assemblies by Minor Change.

ALPHA AVIATION replacement and upgrade restraints include complete, new FAA approved OEM quality AmSafe® 3-point diagonal restraints that meet current TSO standards and are available in both fixed strap and inertial reel equipped styles as well as 2-point rear seat lap belt replacements.  An 8130-3 Airworthiness Certificate is included.

For new installations ALPHA AVIATION provides FAA/PMA STC shoulder harness installation kits which include complete new OEM quality AmSafe® belt assemblies, meeting TSO-C114, as well as all FAA/PMA approved hardware for the addition of shoulder harnesses in  both the pilot and co-pilot seats. Matching 2-point rear seat lap belt replacements are also available. Usual lead time is 4 weeks for shipment.

ALPHA AVIATION  new, replacement and upgrade restraints are stocked in black, gray or fawn colors and are sold as "Per Seat" including 1 (one) restraint assembly - shoulder and lap belt.  They are also offered in over 50 different colors as Special Order at no additional charge.

For additional information please consult the supplied documentation.

KAMAN CORPORATION bearings include a wide range of spherical bearings, rod ends and journal bearings.

KAMAN KAMATICS Metal-To-Metal Self-Lubricating Spherical Bearings are designed with conventional stainless steel alloys, or other specialized alloys based on application, temperature and environment and come with KAron™ self-lubricating liners. They  are maintenance free and provide increased reliability and longer application life, reducing operating cost in challenging applications across industries.  They are offered in different series outlined below, in inch and metric systems and used in a a variety of applications in  aerospace (commercial fixed wing aircrafts), engines,commercial and military helicopters, heavy industry, hydropower, or marine vehicles.

KR-CN Series. MS14104 qualified bearings, narrow, chamfered outer race, -65° F to +325° F

KR-CNG Series. MS14101 qualified bearings, narrow, grooved outer race, -65° F to +325° F

KR-CW Series. MS14102 qualified bearings, wide, chamfered outer race, -65° F to +325° F

KR-CWG Series. MS14103 qualified bearings, wide, grooved outer race, -65° F to +325° F

KR-CN/4 Series. MS81820/4 qualified bearings, lined bore, narrow, chamfered outer race, -65° F to +325° F

KR-CNG/1 Series. MS81820/1  qualified bearings, lined bore, narrow,  grooved outer race, -65° F to +325° F

KR-CW/2 Series. MS81820/2 qualified bearings, lined bore, wide, chamfered outer race, -65° F to +325° F

KR-CWG/3 Series. MS81820/3 qualified bearings, lined bore, wide, grooved outer race, -65° F to +325° F

KR-CE Series. Extended inner race bearings, high misalignment, chamfered outer race

KR-CEG Series. Extended inner race bearings, high misalignment, grooved outer race

KR-C Series. Miniature Series bearings, chamfered outer race

For additional information and specifications please refer to the supplied documentation.

Rest products are commonly used during travelling and leisure activities and span from small accessories such as travel pillows and camping mats to complete bed systems used in airlines, corporate jets, railways, ships and other means of transport.

In aircraft operating on long haul flights, secret compartments equipped with lie-flat beds are used for crew to rest and sleep. On smaller aircraft,  a few rows of passenger seats in the passenger cabin are reserved for crew rest.

Different types of mattresses integrating respective technologies are offered by various manufacturers depending on their intended application.Air mattresses (aka Air beds) utilize a series of air chambers to provide sleepers with comfort and support.Their benefits include a lightweight design, low price, and easy storage. Memory foam mattresses are made up of several dense foam layers and provide benefits such as pressure relief from conforming to the body, enhanced spinal alignment, and motion isolation.Some models include cooling technologies to counteract heat retention. Commonly used as mattresses for crew rest in aviation meeting U.S. Federal Aviation Regulation FAR 25.853  that sets flammability standards for materials used in aircraft interiors. Hybrid mattresses offer a balance of comfort and support by combining foam layers with a pocketed coil system. Their benefits include pressure relief, better spinal alignment, improved airflow for cooling, and reduced motion transfer. Natural latex mattresses are environmentally friendly  and considered to last longer than traditional ones. Also offered from synthetic latex. These mattresses offer pressure relief by conforming to body curves while maintaining spinal alignment, are resistant to dust mites and mold, and have an open-cell structure for better airflow.

Complete bed systems in Aviation are commonly encountered in private jets, corporate aircraft , VIP cabins & lounges but also as commercial jet retrofits. Portable systems are equipped with a rechargeable battery-powered air pump as an inflation mechanism of the foundation and folding the ends of the mattress  in place over the aircraft seats. Bed accessories such as matrtress covers, pillows, and linen are also offered.

Listed products and materials are supplied as OEM parts of their respective manufacturers or as parts of our own labelled (AVIATIONEU NEW ERA) product lines. For additional information please refer to the supplied documentation or contact us.

The 90340/90375 Series wing tip mounted light systems from WHELEN AEROSPACE TECHNOLOGIES (WAT) combine  strobe anti-collision/LED position lights, eliminating the need for a tail mounted position light. 90375 Series is same as 90340 with the addition of 3 feet of braided bonded protection for use in composite wingtip structure. They can be direct replacements (exact footprint) for the Whelen Model A600PG/PR series without replacing the current strobe power supply. The LEDs in position lights provide a significant reduction in current draw over conventional light bulbs. The strobe light lens assembly is radio shielded for maximum EMI/RFI protection. Single set of flying leads operates both forward & tail nav on 28 VDC version, and one set each of flying leads for the forward & tail nav on the 14 VDC version. FAA TSO'd.

Product Specifications:

LED Navigation Light Power Consumption: 0.5 amps @ 14 VDC, 0.25 amps @ 28 VDC

Weight: 0.60 lbs. (272gm) 14 VDC, 0.65 lbs. (295gm) 28 VDC

Exposed Height: 2.70” (69mm)

LED Colors: Aviation Red, Aviation Green & Aviation White 1.1 lbs. (499gm)

Lens: Clear RFI coated glass: strobe, Clear Polycarbonate: Navigation Lights

HYDRO-AIRE, Inc. is part of the CRANE AEROSPACE & ELECTRONICS providing solutions for Landing Gear Systems and Fluid Management for all Aerospace markets. HYDRO-AIRE manufactures anti-skid brake systems, landing systems, fuel pumps for commercial, regional, business, and military aircraft and hydraulic components including shutoff valves, check valves, and fluid reservoirs. The company's brake systems are selected for the evolving market of military unmanned aircraft vehicles.

ZEFTRONICS Voltage Regulator with ground fault protection, trouble shooting light, black plastic connector & 16V over voltage protection built in.

High quality vinyl toggle switch covers that do not have a nipple at the end of the cover. Suitable for MS35058 series switches. Available in different colors.

Fuel and oil drain valves for use on Textron Aviation Cessna, Beechcraft and Hawker aircraft. Also available as FAA-PMA approved parts from other manufacturers.

Aircraft hydraulic pumps are used to move non-compressible fluid through an aircraft hydraulic system. This power is often used on small airplanes to operate wheel brakes, retractable landing gear, and some constant-speed propellers. On larger airplanes, hydraulics are used for flight control surfaces, wing flaps, spoilers, and other systems. Aircraft hydraulic pumps are normally engine driven, but sometimes to simplify the system manufacturers use an electric motor to drive the hydraulic system. These hydraulic power packs incorporate a reservoir, control valve and auxiliary valves into a single unit.

As the OEM for the PRESTOLITE Power Packs, AEROSPACE TURBINE ROTABLES Inc.applies an extensive overhaul and testing process to ensure a long and reliable operation of PRESTOLITE Hydraulic Power Packs offered as Overhaul/Exchange (*).

(*)requires the return of the old unit and its exchange by an overhauled one. The supplier maintains the right to check the condition of the returned unit before the exchange. The price also applies to the hydraulic power packs shipped for overhaul of the same unit and return.

When intended for use on certified aircraft applications, PRESTOLITE Overhaul/Exchange Hydraulic Power Packs come with Dual Release (FAA/EASA) Certification . It must specified at the time of ordering as additional charges may apply.

For additional information please consult the supplied documentation.

An extensive range of standard MIL-SPEC and Cessna pulleys and pulley kits is offered by McFARLANE® AVIATION. The kits contain all pulleys and cotter pins required to replace all flight control system pulleys in one airplane containing the respective part numbers and quantities required. Different McFarlane pulley series include:

MCS378 Series phenolic flight control pulleys with ball bearings, FAA-PMA approved replacements for the Cessna S378, A-/BB-, and NAS383- series pulleys on Cessna Aircraft. The MCS378- series pulleys supersede these for most Cessna aircraft applications and  feature high quality sealed precision ball bearings, superior to low grade, open seal bearings used in the Cessna S378-()L light duty series pulleys that they replace.

MS20219 Series aircraft secondary control pulleys, superseding the respective AN219 series pulleys are offered either with high pressure laminated phenolic sheave (MS20219 Series) or aluminum alloy sheave anodized per MIL-A-8625 (MS20219A Series), both with fixed ball bearing with contact seal. The aluminum body is recommended for -1 and -3 pulleys. The -1 pulley should not be installed in flight control systems.

MS20220 Series phenolic flight control pulleys with ball bearings. These supersede the AN220- Series pulleys of like dash number.

MS24566 Series phenolic flight control pulleys with ball bearings. MS24566 pulleys can be used to replace the corresponding AN210 pulleys designated by the letters "A" or "B" in their dash numbers as they differ in the maximum load limit.

NAS383 Series phenolic commercial grade pulleys with graphite impregnated bronze sleeve bearings. These are typically used with a bushing. The MCS378 pulley replaces both the NAS383 pulley and it's bushing.

S394, S1052-1/ S1710-1 Cessna nylon pulleys with no bearings.

S378-4S Cessna pulley similar to S378-4 but with smaller diameter. Used on Cessna airplanes 177RG s/n 177RG0202 and on, and F177RG0038 and on for routing stabilator, stabilator trim, and rudder cables. Six required per aircraft.

1660433 Series Cessna phenolic pulleys with ball bearings.

MS24665 series cotter pins are also available with the pulley kits or separately in packs of 10 or 25.

Please refer to the individual product presentations, the respective charts provided for specifications and cross-reference information or contact us.
