For a number of years CLEVELAND WHEELS & BRAKES offered standard organic & heavy-duty asbestos brake linings for their wheels and brakes. In January 1988 these two types of brake linings were discontinued and a single, improved brake lining was introduced with improved performance and durability compared to older linings. Different versions are available to fit aircraft models based on their year of construction. Brake linings are sold as pad only or as kits together the required number of rivets. Most light aircraft take 2 linings per wheel. Extra rivets are also available. Please refer to the attached Application Guide for additional information.

Different screws used on Textron Aviation Cessna, Beechcraft and Hawker aircraft. Also available as FAA-PMA approved parts from other manufacturers.

AS8976 narrow spherical bearings from RBC Aerospace Bearings are available in grooved or chamfered versions from steel (MS21154S grooved & MS21155S chamfered steel series) or bronze (MS21154B grooved & MS21155B chamfered bronze series). For additional information please refer to the attached documentation.

AS8976 Bearing Product Features:

• Qualified to AS8976 (formerly MIL-B-8976)

• Narrow series, metal-to-metal

• Material MS21154S & MS21155S steel series 03-503 and 03-505

Outer ring: Alloy steel, AMS-S-5000, AMS-S-6758 or AMS-S-6050

Inner ring: CRES 440C, HRC 55 min. AMS 5630

• Material MS21154B & MS21155B bronze series 03-523 and 03-525

Outer ring: Aluminum bronze

Inner ring: CRES 440C, HRC 55 min. AMS 5630

NEWTON CONSULTING manufactures and offers Aero extensive range of fue/oiI/water tank caps and special fittings for use on most of the worlds super cars and bikes and many light aircraft (Adam, CAP, Cirrus, Diamond, Lancair Columbia, Lancair kits, Nemesis, Vans, Velocity and others). Their centres are forged from 6063 or 6082 aluminum and then polished and anodised. The high precision and easy to operate mechanism is very secure and non vented. The flanges are diamond turned and again polished and anodised.  Cap assemblies come complete with cap, gasket, and flanges as ordered. Two keys come with the locking version. Fixing can be by rivet, bolt, weld or glass in as appropriate. Attach o-ring kits are available and can be ordered separately as needed.

Different Aero cap series include:

The Aero 200 series, the smallest and lightest of Aero filler caps. Available only in non-locking version and with either a 6 hole bolt on flange  (A26S) or a Glass-in flange (A20G).

The Aero 300 series, the first choice among designers and installers, offered as standard (non-locking) or locking versions with four different bolt configurations (0 hole, glass in, 6 hole & 9 hole, flange necks with lead free restrictor flaps and many special flange options to meet application requirements such as:

- F30G for installation into a composite skin.

- F30 GS, ideal for wooden aeroplanes avoiding recesses and doors.

- A30L CIRRUS with a low profile threaded flange designed for Cirrus to enable the cap to be fitted after the wing is painted, avoiding damage, dirt, masking, filling and other nuisances.

- FN362, a 6 hole bolt-on flange with hose neck

- A30L VANS, offered if a metal version is preferred to the lightweight version which now comes as standard with Vans aircraft kits.

- Z3 used in specific circumstances.

- Z30L VANS, a cap/flange offered as a retrofit assembly that will go into the older Vans/Usher cap/ flange.

The Aero 400 series, with lock (L) or without a lock (S) including A48S/L with aluminum flange for direct connection to tank and A4LT, plastic centre for use with Aero 400 flanges.

The Aero 500 series, with lock (L) or without a lock (S) and two standard fixing arrangements: A512S/L with flange for direct connection to tank and A50S/LG, glass in flange, moulded directly into tank vehicle skin.

The Aero 600 series, a super light version of the Aero 500, with a smaller footprint but retailing the same 3 inch (77.0mm) filling hole allowing the cap to be used for all fuels.

When there is a need for connection of a set of electrical wires, terminal blocks provide a safe & convenient way to keep them organized. AVIATIONEU NEW ERA TR series of snap on (clip type) terminal blocks allows for terminal block assemblies to be installed and realeased fast and easily. Terminal block connectors are rugged, easy to use and designed to keep wires of varying gauges securely connected. They can be mounted on the 35/7.5mm DIN rail of 1 or 2 meter length made from aluminum or zinc plated steel which is in turn can be mounted on control panel backplates. Any pole assembly is possible. With the use of a DIN rail protective conductor terminal block, the rail itself can be used as the grounding terminal block.

The connectors are offered in black color (or other colors as per customer requirements), with a rated voltage of  600V and different rated current options (10A,20A,30A or 40A). They are sold in packs of 100 pieces each and come with paper marker strips & transparent cover. DIN mount rail & accessories are available at additional cost. These can be ordered only together with the terminal blocks. Appearing prices are for reference only. Contact us for a quotation.

MICHELIN® Aircraft Tyres is internationally recognized as the No.1 tire manufacturer in the world. The company provides bias tires, radial tires, and tubes for aviation customers around the world, in a range of applications including commercial and regional airlines, general aviation and military aviation.

MICHELIN® AIRSTOP® Aircraft Tire Inner Tubes provide long-lasting, dependable performance you can rely on in just about any operating condition. Made from exclusive Michelin butyl compound they offer  extended air retention and can sustain temperatures as low as -50°C.  In addition, they are formed without a circumferential splice, resulting in fewer joints and a more uniform tubewall thickness after inflation for optimized reliability at a minimal weight.  AIRSTOP tubes are manufactured to exacting balance tolerances (without correction), which meet or exceed all industry standards. This eliminates the need to further balance the wheel assembly in order to compensate for balance irregularities in the tube. Tube lubricant is factory applied to the tube exterior for easier installation and to help minimize foldover after installation and inflation. Comply with Aerospace Standard AS50141. Available in different sizes. Please also refer to the attached documentation.

Product Features:

Advanced Butyl Material

Exclusive Michelin® butyl compound offers excellent resistance to diffusion for extended air retention and dependable performance. Michelin® AIRSTOP® tubes help provide the same high quality seal found in Michelin® AIR X® radial tires.

Circular Extrusion Manufacturing Process

A Michelin® exclusive, Michelin® AIRSTOP® tubes are formed without a circumferential splice, resulting in fewer joints and a more uniform tubewall thickness after inflation. This helps provide optimized reliability at a minimal weight.

Built-In Balance

All Michelin® AIRSTOP® tubes are manufactured to exacting balance tolerances (without correction), which meet or exceed all industry standards. This eliminates the need to further balance the wheel assembly in order to compensate for balance irregularities in the tube.

Easy Installation

Tube lubricant is factory applied to the tube exterior for easier installation and to help minimize foldover after installation and inflation. In addition, molded vent ridges help channel trapped air back to the valve stem for easy release.

Low Temperature Performance

Michelin® AIRSTOP® tubes are designed to perform in the extreme low operating temperature of minus 50o C, so you can confidently fly in cold weather with consistent, reliable performance.

High Quality Complies with Aerospace Standard AS50141.

GROVE Wheels and Brakes are precision engineered and manufactured to provide the highest quality and performance in the aircraft industry. GROVE wheels are manufactured in both aluminum and magnesium.  Aluminum wheels are more corrosion resistant than magnesium, are less expensive, but weigh more.  Both have the same strength and performance ratings. They are offered in sets (kits) in different sizes to comply with tire and axle sizes and static load ratings to match  the static aircraft gross weight on each wheel. GROVE brakes are offered for different braking torques, a function of the hydraulic system pressure and total caliper piston area, and with different kinetic energy capabilities. Aircraft with oversized tires or with a larger than normal engine should consider brake calipers with more or larger pistons. Different brake discs offered absorb the heat energy developed during braking.

Please refer to the Product Description section and the supplied documentation for additional information.

Electrodelta (Hartzell Engine Technologies) is the world market leader in top quality voltage regulators for general aviation aircraft, and continues to revolutionize the industry with proven technologies and improvements. The units are assembled from the highest quality electronic components available and are meticulously tested and calibrated to ensure maximum performance.The Electrodelta product line was acquired by by Lamar Technologies LLC in order to add new and alternative  parts to the company's product lines.

The ACS unvented flush fuel cap operates with a lift and turn lever. This cap has a 3" opening for easy refueling. Cap & adapter ring are anodized "clear" for corrosion resistance. Cap is fastened to adapter ring with safety chain.

Aircraft wheels and braking systems serve a vital function during takeoff, landing and taxiing. Along with landing gear, aircraft wheels and brakes are critical to ensure safe and reliable aircraft ground operations under extreme forces, stress, as well as wear and tear from general operation and the environment.

Aircraft brakes are arranged in multiple disk pairs, which are commonly referred to as brake Heat Sink. As aircraft brakes convert the kinetic energy of the moving airplane to heat energy, they are also referred to as Heat Packs made of steel or carbon fibres. Conventional metal (steel) brakes are gradually replaced by carbon brakes (particularly on larger, long-haul commercial airplanes) due to their higher efficiency in braking applications, lower weight and resulting less fuel consumption and lower CO2 emission by the engines.

Commercial aircraft wheels and braking systems are produced by by leading manufacturers such as Honeywell Aerospace, Collins Aerospace/Goodrich Wheels & Brakes, Parker Meggitt Aircraft Braking Systems and Safran Landing Systems (formerly Messier-Bugatti-Dowty) and offered as OEM products/parts for an extensive list of commercial aircraft platforms.  For more information on different OEM products please refer to the Product Description section, the supplied documentation or contact us.

Carbon and steel heat packs are also offered as part of our own labelled (AVIATIONEU NEW ERA) product lines. They are  PMA approved (*) parts by the Civil Aviation Administration of China (CAAC) for use on an extensive list of Western and Eastern commercial (civil ) aircraft platforms including Boeing, Airbus, McDonnell Douglas, Ilyushin and others. Sourced from quality suppliers they are available in an extensive product range, consist cost effective alternatives equalling or exceeding standards of the respective OEM products and feature high quality, safety, improved design, significant cost savings and fast deliveries. For more information on AVIATIONEU NEW ERA PMA brake heat packs please consult our separate product presentation or contact us.

Pitot tubes scan the static and dynamic pressure, and they are used on aircraft to determine the aircraft airspeed.

WULTRAD INC. is a manufacturer of non-certified flight and engine instruments under FALCON GAUGE brand for experimental and homebuilt aircraft. Although their products are Non-TSO, they are made to TSO or MIL specifications for quality.

FALCON GAUGE Non TSO'd (non-certified) pitot tubes have been used for many years on different types of experimental or other aircraft where no certification is required. Available in different heated and unheated versions for 12 or 24 V electrical supplies, for vertical or flat installations. Standard (3/4") and long (4") mounting brackets are offered. Heated Material: Stainless Steel. Please consult the supplied documentation or contact us for further information.

Oval shaped copper sleeves used in making eye or lap splices in flexible cable. Sleeves are slipped over the two strands of cable to be fastened and are then compressed with special Nicropress hand squeezers. Provides a bond that is even stronger than a standard splice. They are offered in pure copper or zinc/tin coated for different cable sizes in inches. Plain copper ("18" series) and zinc coated sleeves ("28" series) are used with galvanized cable, and tin coated sleeves are to be used with stainless steel cable.

CURTIS Superior Valves are designed for installation in a standard NPT port for NPT threaded valves or an AND-10050 stlye port for UNF threaded valves. CURTIS CCA valves are quick opening brass drain valves for aircraft oil or fuel systems. A slight twist opens the valve. No safety wire needed in closed position. FAA approved. TSO-C76 Approved. Available in different thread sizes and lengths in inches.

Use a sealant on NPT threaded valves or a fuel resistant o-ring of the proper size for UNF threaded valves. Refer to aircraft manufacturers torque specifications for the aircraft in which it is being used. Curtis Superior Valves require no special maintenance. Keep them reasonably clean and replace according to the prescribed synthetic rubber maintenance schedule for the aircraft in which they are used or 10 year usable life per Curtis Superior Valve whichever occurs first. Curtis Superior Valves cannot be OVERHAULED. Replace the entire valve per the maintenance schedule of the aircraft in which it is used or usable life per Curtis Superior Valve should it begin to leak.

Note: FAA Approval applies to fuel applications only. NOT FAA Approved for oil applications.

TOST Flugzeuggerätebau designs and manufactures top quality products including aircraft wheels, brakes, tires, tubes, glider towing and launching equipment and tow releases serving the needs of aviation sports and industry. TOST and TOST AERO brands for tires are synonyms for safety in aviation.

For more than 30 years TOST has manufactured aircraft tires from 3" to 10" exclusively under the TOST AERO brand with a long lifetime, robustness and capability for high loads and speeds. TOST AERO tires and tires from other brands can be used with TOST wheels designed to cover a wide range of applications in gliders, motor gliders, aircraft, ultralight, amphibium aircraft, helicopters and gyrocopters but also in heavy-duty applications. Matching tire tubes with different valves and valve extensions are also offered by TOST to cover application requirements.

For additional information please refer to the supplied documentation.

ARKWIN INDUSTRIES has been designing and manufacturing engine actuators for over 60 years for operation with fuel, engine oil and hydraulic oil pressurization. Their actuators are used on numerous civil, military, and industrial applications to provide actuation force to direct engine control components. They differ from conventional hydraulic actuators, a major difference being the incorporation of the fire resistance features necessary to meet engine safety requirements. Engine actuators are frequently exposed to elevated temperature during normal operation. If extended periods of flame resistance are required, protective coatings can be applied to the actuator housings including the use of intumescence or ablative coatings. Where temperature permits, ARKWIN uses aluminum alloys. For higher operating  temperatures or pressure requirements exceeding the allowables of aluminum alloy, stainless PH steel alloys or titanium alloys can be provided. Two stage sealing is common for both static and dynamic seals. Specifically selected seal compounds allow zero external leakage, long durability life, high temperature resistance, while providing protection in fire.

ARKWIN’s  engine actuators feature a high side load tolerance to ensure long piston life, high resistant wear plating, high reliability/low maintenance and fire resistance. Their key design characteristics include:

• Fuel and petroleum based operating fluids

• Operating pressures up to 4,000 psig

• Position feedback of the actuators is provided by integral or externally mounted LVDT’s.

• Multiple mounting options

• Servo valve applications (Control of actuators through external pressurization valving or through an integral electro hydraulic servo valve).

• Master/Slave configurations

ARKWIN’s  engine actuators are offered for different platforms including:

CFM International CFM56-2/-3, CFM56-5/-7

General Electric CF34-3, CF34-8C/E, CF6, F110, F404,  F414, LM2500, LM6000, TF34

ARKWIN EXCHANGE PROGRAM: ARKWIN’s commercial and industrial gas turbine engine actuator exchange program was developed for the CFM56-5/7, CF6-80C2, CF6-80E1, CF34-8C/E, LM2500, and LM6000 engines.  The program provides operators the reliability of OEM NEW products at competitive prices. Qualifying actuators are exchanged in a very short time for FACTORY NEW OEM production units complete with FACTORY NEW OEM and a three-year/6000 EOH warranty. For additional information please consult the supplied documentation or contact us.

SKYBOLT® stainless cowling fastener kits replace the old parts from other manufacturers originally installed on aircraft cowlings and access panels with exclusive SKYBOLT® CLoc®, ZLoc®, or ALoc® style stainless steel fasteners manufactured by SKYBOLT®. SKYBOLT® Cloc style fasteners are compatible with Camloc and are available in 2000 and 4000 series. ZLoc fasteners are compatible with Dzus and Aloc fasteners with Airloc ones. In addition SKYBOLT® SK2003 plate mounts upgrades those of J 7444 series commonly used in Cessna aircraft. SKYBOLT® kits for different aircraft models and year of construction are offered to cover all panels or certain portions of the engine cowling. The SKYBOLT® Cowling Fastener Kits will usually contain more of a selection than the aircraft may actually require so that a replacement project can efficiently move from start to finish. Other kits like the Trim and Fuel Tank Kit are also available.

Note: Alternative kits from competition may include less fasteners than those required for the replacement project. It is recommended that kit evaluations and price comparisons should be made on the basis of the hardware included in each kit.

ALPHA AVIATION is a supplier of new, replacement and upgrade restraint systems based on AMSAFE® restraints. ALPHA AVIATION restraints are available for many models of General Aviation aircraft including Cessna 150, 150A thru K, Cessna 172L thru Q, 172RG (rear harnesses), Cessna 200 series and M20 A thru early J model aircraft which can add restraint assemblies by Minor Change.

ALPHA AVIATION replacement and upgrade restraints include complete, new FAA approved OEM quality AmSafe® 3-point diagonal restraints that meet current TSO standards and are available in both fixed strap and inertial reel equipped styles as well as 2-point rear seat lap belt replacements.  An 8130-3 Airworthiness Certificate is included.

For new installations ALPHA AVIATION provides FAA/PMA STC shoulder harness installation kits which include complete new OEM quality AmSafe® belt assemblies, meeting TSO-C114, as well as all FAA/PMA approved hardware for the addition of shoulder harnesses in  both the pilot and co-pilot seats. Matching 2-point rear seat lap belt replacements are also available. Usual lead time is 4 weeks for shipment.

ALPHA AVIATION  new, replacement and upgrade restraints are stocked in black, gray or fawn colors and are sold as "Per Seat" including 1 (one) restraint assembly - shoulder and lap belt.  They are also offered in over 50 different colors as Special Order at no additional charge.

For additional information please consult the supplied documentation.

BRS AEROSPACE™ has first invented the first Whole Aircraft Rescue Parachute System (WARPS) in 1980 currently being installed on more than 35,000 aircraft. Today the company offers a wide range of WARPS suitable as retrofits to Cessna series 172 and Cessna 182, as standard installations on Cirrus SR20 and SR22 models but also for installations on LSA and experimental aircraft.

BRS WARPS are offered in 3 different types:

Canister. The BRS Canister is waterproof when the original factory seal remains intact, making it the perfect design for exterior installations. With a six year repack schedule and versatile mounting hardware, it is one of the most popular systems.

Softpack. The BRS Softpack is best suited for aircraft manufactur-ers that require a ballistic parachute mounted inside their aircraft. When mounted internally, this system also has a six year repack schedule.

VLS - Vertical Launch System. Built specifically for aircraft with limited interior space, the VLS (Vertical Launch System) installs on top of the wing or fuselage. Upward firing works well with pusher designed aircraft

A small solid-fuel rocket is used to pull the parachute out from its housing and deploy the canopy fully within seconds. Typically on ultralight installations the rocket is mounted on the parachute container. On larger aircraft installations the rocket may be remotely mounted. The current version, BRS-6. has a separate rocket installation that can be removed from the parachute so that the parachute can be sent for re-packing without the problems of trying to ship the rocket along with it. Typically the parachute requires repacking every six years and the rocket requires replacing every 12 years.
