ROTAX® aircraft  engines form part of the product portfolio  of BRP-Powertrain GmbH & Co. KG which develops and manufactures engines for snowmobiles, watercrafts, boats, roadsters, all-terrain and side-by-side vehicles, motorcycles, carts, and aircrafts.

BRP-ROTAX® product range includes certified and non certified internal combustion engines, parts and accessories for light and ultralight aircraft.

Different oil and water radiators, intercoolers and other cooling system parts are used in BRP-ROTAX® aircraft engines. They are offered as certified or non certified parts from the manufacturer. Non certified parts can be used in ultralights or other aircraft not requiring certification of parts for their installation. Certified parts are designated by the letters "CERT" in the product reference number (SKU).

Aircraft engine  parts are subject to changes from time to time. Some parts may be no longer available or replaced by others with different part numbers. Listed BRP-ROTAX® engine parts do not imply their current availability or suitability for your engine application. Always consult the most recent Illustrated Part Catalogs (IPCs) or other documentation available from the manufacturer for the correct part number before ordering.

ROTAX® aircraft  engines form part of the product portfolio  of BRP-Powertrain GmbH & Co. KG which develops and manufactures engines for snowmobiles, watercrafts, boats, roadsters, all-terrain and side-by-side vehicles, motorcycles, carts, and aircrafts.

BRP-ROTAX® product range includes certified and non certified internal combustion engines, parts and accessories for light and ultralight aircraft.

Different alternators are used in BRP-ROTAX® aircraft engines. They are offered as certified or non certified parts from the manufacturer. Non certified parts can be used in ultralights or other aircraft not requiring certification of parts for their installation. Certified parts are designated by the letters "CERT" after the part number in the product reference number (SKU).

Aircraft engine  parts are subject to changes from time to time. Some parts may be no longer available or replaced by others with different part numbers. Listed BRP-ROTAX® engine parts do not imply their current availability or suitability for your engine application. Always consult the most recent Illustrated Part Catalogs (IPCs) or other documentation available from the manufacturer for the correct part number before ordering.

The TURBONYCOIL® product range of high-performance mineral and synthetic oils produced by NYCO are used in aircraft turbine (turbo-jet, turbo-prop, etc.) and piston engines, power units, turbo-reactors, APUs, starters, IDGs for aircraft, helicopters, naval vessels (aircraft carriers, frigates, etc.) and land equipment. Also used for aero-derivative turbines for land and sea applications (cogeneration, offshore power generation, gas compression). NYCO TURBONYCOIL® turbine oils are fortified with carefully selected anti-oxidant, anti-corrosion, anti-wear and extreme-pressure additives. TURBONYCOIL® oils are used in aircraft of many air forces (Mirage, Rafale, Eurofighter, F-16, F-22 and F-35) as well as on aircraft from Russian & Ukrainian manufacturers.

Commonly used NYCO TURBONYCOIL®  products include:

TURBONYCOIL® 98: Synthetic turbine engine oil used on Russian-made aircraft

TURBONYCOIL® 160: Ester-based oil, specially designed to withstand high temperatures and remain fluid at very low temperatures

TURBONYCOIL® 321: 8 cSt mineral turbine engine oil for Russian-made aircraft

TURBONYCOIL® 3516: Mineral turbine oil designed for protection

TURBONYCOIL® 3560/3570: Single grade mineral oils for piston engines

TURBONYCOIL® 600: STD/SPC 5 cSt synthetic oil for turbojet engines

TURBONYCOIL® 601: 5 cSt corrosion inhibited synthetic turbine oil

TURBONYCOIL® 640: 5 cSt high thermal stability turbine oil

Many TURBONYCOIL®  products or their analogs by other producers are included in our offered product range and can be furnished on demand through our current network of co-operating suppliers.

Please refer to the Product Description section, the supplied documentation or contact us for additional information and assistance.

BRP-ROTAX® product range includes certified and non certified internal combustion engines, parts and accessories for light and ultralight aircraft. They form part of BRP-Powertrain GmbH & Co. KG product portfolio which also includes engines for snowmobiles, watercrafts, boats, roadsters, all-terrain and side-by-side vehicles, motorcycles & carts.

The BRP-ROTAX® 914 F series aircraft engines are turbo charged four cylinder engines (115 hp) certified according to FAR-33 and JAR-E . A non certified model (914 UL) is also offered (please refer to the respective product presentation).

With a time between overhauls of 2.000 hrs these engines offer more performance at high altitudes while keeping weight at a low level. The BRP-ROTAX® model 914 F2 is suitable for aircraft equipped with a fixed pitch propeller while the model 914 F3 for constant speed propeller is the same as 914 F2  with additionally a drive for hydraulic governor, a cover for sealing of governor flange and a slipper clutch for reduction gear box. Different options are also available and can be supplied with the engine at additional cost.  They can only be ordered at the time of ordering of the respective engine(s).

914 F2/F3 Engine Features:

Performance: 73,5 kw at 5500 1/min, 84,5 kw at 5800 1/min (max. 5 min)

Four cylinder engine

Liquid cooled cylinder heads,aircooled cylinders

Turbocharger

2.000 hrs TBO

integrated reduction gearbox i = 2,43

slipper clutch for reduction gearbox

electric starter standard + starter relay

electronic dual ignition system

ignition cover

R.F.I. suppression

regulator rectifier 965347

2 carburetors

turbocharger with electronic controlled wastegate

2 external electric 12V fuel pumps 996738

engine truss Assembly (ASSY) without silent block

stainless steel exhaust system

expansion tank 922666

oil filter, oil tank,without hoses

coolant pump and internal coolant hoses

2 sensors for cylinder head temperature 965531

1 sensor for oil temperature

1 oil pressure sensor 10 bar

airbox with drip tray set

without propeller cover disc and round neck nut set

drive for hydraulic governor (Model 914 F3)

cover for sealing of governor flange (Model 914 F3)

slipper clutch for reduction gear box (Model 914 F3)

Available Options (supplied with the engine):

drive vacuum pump

electric starter large (HD- high duty)

mechanical tachometer pick-up

NOTE: Options are additionally charged and must be specified at the time of ordering. They can only be ordered with the respective engine(s).

ROTAX® aircraft  engines form part of the product portfolio  of BRP-Powertrain GmbH & Co. KG which develops and manufactures engines for snowmobiles, watercrafts, boats, roadsters, all-terrain and side-by-side vehicles, motorcycles, carts, and aircrafts.

BRP-ROTAX® product range includes certified and non certified internal combustion engines, parts and accessories for light and ultralight aircraft.

Different fuel pumps, filters and other fuel system parts are used in BRP-ROTAX® aircraft engines. They are offered as certified or non certified parts from the manufacturer. Non certified parts can be used in ultralights or other aircraft not requiring certification of parts for their installation. Certified parts are designated by the letters "CERT" in the product reference number (SKU).

Aircraft engine  parts are subject to changes from time to time. Some parts may be no longer available or replaced by others with different part numbers. Listed BRP-ROTAX® engine parts do not imply their current availability or suitability for your engine application. Always consult the most recent Illustrated Part Catalogs (IPCs) or other documentation available from the manufacturer for the correct part number before ordering.

ROTAX® aircraft engines form part of the product portfolio  of BRP-Powertrain GmbH & Co. KG which develops and manufactures engines for snowmobiles, watercrafts, boats, roadsters, all-terrain and side-by-side vehicles, motorcycles, carts, and aircrafts.

BRP-ROTAX® product range includes certified and non certified internal combustion engines, parts and accessories for light and ultralight aircraft.

Exhaust systems and parts are used in BRP-ROTAX® aircraft engines. They are offered as certified or non certified parts from BRP-ROTAX® but also from other manufacturers.  Non certified parts can be used in ultralights or other aircraft not requiring certification of parts for their installation. Certified parts are designated by the letters "CERT" after the part number in the product reference number (SKU).

Aircraft engine  parts are subject to changes from time to time. Some parts may be no longer available or replaced by others with different part numbers. Listed BRP-ROTAX® engine parts do not imply their current availability or suitability for your engine application. Always consult the most recent Illustrated Part Catalogs (IPCs) or other documentation available from the manufacturer for the correct part number before ordering.

ROTAX® aircraft engines form part of the product portfolio of BRP-Powertrain GmbH & Co. KG which develops and manufactures engines for snowmobiles, watercrafts, boats, roadsters, all-terrain and side-by-side vehicles, motorcycles, carts, and aircrafts. BRP-ROTAX® product range includes certified and non certified internal combustion engines, parts and accessories for light and ultralight aircraft.

The BRP-ROTAX® 912 UL/912 ULS series aircraft engines are four cylinder/four stroke non certified engines suitable for experimental and ultralight aircraft. Different models include 912 UL, 912 UL 3, 912 UL S2 as well as  and 912 UL S3 (UL 3/UL S3 models are for constant speed propeller). The BRP-ROTAX® 912 UL 3 engine is the same as 912 UL engine additionally with drive for hydraulic governor & cover for sealing of governor flange and slipper clutch for reduction gearbox. The BRP-ROTAX® 912 UL S3 engine is the same as  912 UL S2 engine additionally with drive for hydraulic governor & cover for sealing of governor flange.

Different options are also available at additional cost. They can only be ordered at the time of ordering of the respective engine(s).

For additional information please refer to the supplied documentation.

ROTAX® aircraft  engines form part of the product portfolio  of BRP-Powertrain GmbH & Co. KG which develops and manufactures engines for snowmobiles, watercrafts, boats, roadsters, all-terrain and side-by-side vehicles, motorcycles, carts, and aircrafts.

BRP-ROTAX® product range includes certified and non certified internal combustion engines, parts and accessories for light and ultralight aircraft.

Different air filters are used in BRP-ROTAX® aircraft engines. They are offered as certified or non certified parts from the manufacturer. Non certified parts can be used in ultralights or other aircraft not requiring certification of parts for their installation. Certified parts are designated by the letters "CERT" in the product reference number (SKU).

Aircraft engine  parts are subject to changes from time to time. Some parts may be no longer available or replaced by others with different part numbers. Listed BRP-ROTAX® engine parts do not imply their current availability or suitability for your engine application. Always consult the most recent Illustrated Part Catalogs (IPCs) or other documentation available from the manufacturer for the correct part number before ordering.

BRP-ROTAX® product range includes certified and non certified internal combustion engines, parts and accessories for light and ultralight aircraft. They form part of  BRP-Powertrain GmbH & Co. KG product portfolio which also includes engines for snowmobiles, watercrafts, boats, roadsters, all-terrain and side-by-side vehicles, motorcycles & carts.

The BRP-ROTAX®  914 UL Series Aircraft Engines are non certified  turbo charged four cylinder engines. Certified models of this engine (914 F2  and 914 F3) are also offered (please refer to the respective 914 F Series product presentation).

ROTAX 914 UL Series are intended for use in ultralight and experimental aircraft. Engine model 914 UL2 is suitable for aircraft equipped with a fixed pitch propeller and it is offered with or without slipper clutch installed. Engine model 914 UL3  is the same as 914 UL2  with additionally a drive for hydraulic governor, a cover for sealing of governor flange and a slipper clutch for reduction gear box.

Different options are also available at additional cost. They can only be ordered at the time of ordering of the respective engine(s).

914 UL Series Engine Features:

Performance: 73,5 kw a 5500 1/min, 84,5 kw a 5800 1/min (max 5 min.)

Four cylinder engine

liquid cooled cylinder heads, aircooled cylinders

integrated reduction gearbox i = 2,43

electric starter standard + starter relay

electronic dual ignition system

ignition cover

R.F.I. suppression

regulator rectifier 965349

2 carburetors

turbocharger with electronic controlled wastegate

2 external electric 12V fuel pump 996 738

engine truss assembly (Assy) without silent block

stainless steel exhaust system

expansion tank 922666

oil filter, oil tank,without hoses

coolant pump and internal coolant hoses

2 sensor for cylinder head temperature 965531

1 sensor for oil temperature

1 oil pressure sensor 10 bar

airbox with drip tray set

without propeller cover disc and round neck nut set

drive for hydraulic governor (Model 914 UL3)

cover for sealing of governor flange (Model 914 UL3)

slipper clutch for reduction gear box (Model 914 UL3)

Available Options (supplied with the engine):

drive vacuum pump

electric starter large (HD- high duty)

mechanical tachometer pick-up

NOTE: Options are additionally charged and must be specified at the time of ordering. They can only be ordered with the respective engine(s). For pricing of options and overhaul kits please refer to those listed under 914 F Engine Series.

CONTINENTAL AEROSPACE TECHNOLOGIES™ (formerly Teledyne Continental Motors Inc. (TCM) designs and manufactures gasoline and Jet-A engines and related parts.

CONTINENTAL® produces four series (200, 360, 470 & 500) of certified factory new and rebuilt AvGas engines, designed to meet the power and performance requirements of every GA pilot. Ranging from 100 HP to 375 HP, the gasoline engines are built in-house from parts manufactured on site. The Jet-A engines are world-class benchmarks in General Aviation favored by flight schools and specified by major OEMs including Tecnam®, Cessna®, Diamond® , Mooney® , Glasair® , Piper® , and Robin® . These Jet-A fueled engines operate on universally-available aviation fuel kerosene (Jet Fuel, Jet-A and other certified aviation Jet fuels). Each is certified to the requirements of FAA, EASA and a further 78 countries. Continental continues to develop the technologically advanced engine series which now includes engines ranging from 135 HP to 300 HP. Continuous improvements have increased TBO to to 2,100 hours for the CD-135, CD-155, and 2,000 hours for the CD-300 engines. Prime™ Certified Engines are designed specifically for high utilization, ideal for flight schools or fleet operators. Competitively priced they are offered with a power output ranging from 180 to 195 HP. Titan™ Experimental Engines are individually built to customer specifications providing better control over weight, displacement and power output with a choice from 4-cylinder engines in the range of 174–195 HP.

OEM and FAA-PMA parts for CONTINENTAL® are also offered (please see separate product presentation). Please consult the supplied documentation or contact us for additional information and a quotation.

These nuts are for use in Textron Lycoming aircraft engines. Supplied with our own Certificate of Conformance. If additional certification is required, please contact us as a respective charge may apply.

LORD manufactures a range of vibration and motion control products for General Aviation aircraft including elastomeric and non-elastomeric mounts, full structures, yokes and attachments. Their Dynafocal engine mounts are available for many aircraft, including the most produced general aviation fixed wing aircraft models, such as the Cessna 152, Cessna 172, Cessna 182, Piper PA-28 series, and more. For additional information please also refer to the attached Lord Catalog.

ROTAX® aircraft  engines form part of the product portfolio  of BRP-Powertrain GmbH & Co. KG which develops and manufactures engines for snowmobiles, watercrafts, boats, roadsters, all-terrain and side-by-side vehicles, motorcycles, carts, and aircrafts.

BRP-ROTAX® product range includes certified and non certified internal combustion engines, parts and accessories for light and ultralight aircraft.

Fuel pressure gauges are used in BRP-ROTAX® aircraft engines and offered as certified or non certified parts from their respective manufacturers. Non certified parts can be used in ultralights or other aircraft not requiring certification of parts for their installation.

Aircraft engine  parts are subject to changes from time to time. Some parts may be no longer available or replaced by others with different part numbers. Listed BRP-ROTAX® engine parts do not imply their current availability or suitability for your engine application. Always consult the most recent Illustrated Part Catalogs (IPCs) or other documentation available from the manufacturer for the correct part number before ordering.

Fuel pressure gauges are no longer offered as ROTAX Part Numbers. These part numbers are provided for reference only. For these gauges please refer to our product presentation on AVIASPORT Fuel Pressure Gauges or contact us.

ROTAX® aircraft  engines form part of the product portfolio  of BRP-Powertrain GmbH & Co. KG which develops and manufactures engines for snowmobiles, watercrafts, boats, roadsters, all-terrain and side-by-side vehicles, motorcycles, carts, and aircrafts.

BRP-ROTAX® product range includes certified and non certified internal combustion engines, parts and accessories for light and ultralight aircraft.

Different springs are used in BRP-ROTAX® aircraft engines. They are offered as certified or non certified parts from the manufacturer. Non certified parts can be used in ultralights or other aircraft not requiring certification of parts for their installation. Certified parts are designated by the letters "CERT" in the product reference number (SKU).

Aircraft engine  parts are subject to changes from time to time. Some parts may be no longer available or replaced by others with different part numbers. Listed BRP-ROTAX® engine parts do not imply their current availability or suitability for your engine application. Always consult the most recent Illustrated Part Catalogs (IPCs) or other documentation available from the manufacturer for the correct part number before ordering.

MWfly SPIRIT SKY LINE and RED LINE non certified Aeronautic Engines total 16 high performance models delivering from 100 to 160 horsepower and can be supplied with clockwise or anticlockwise rotation, both in tractor and pushing configurations.. They are 4-cylinder horizontally opposed (boxer type) liquid cooled motors manufactured to the highest standards to meet application requirements in a wide range of LSA and experimental single-engine or twin-engine airplanes and other aircraft (STOL, helicopters, gyrocopters, hang gliders, seaplanes and drones). SPIRIT engines come with many accessories as standard. Please refer to the respective engine presentations and comparison charts. Additional engine accessories for MWfly SPIRIT SKY LINE and RED LINE engines can be purchased separately or included in the order of any SPIRIT engine. For additional information please contact us for customized solutions to your projects.

The AVIASPORT indicators (gauges) are reliable, accurate and solid, combining the accumulated experience of more than twenty years with the latest technology  They have been designed for ROTAX engines and their display areas are divided into red, green and yellow zones in line with Rotax limits. They use a pointer that turns 240º or 320º, providing high resolution. AVIASPORT range of gauges includes CHT, EGT, tachometers, oil and fuel pressure, oil and coolant temperature, fuel level, voltmeters & ammeters and offered with casings of different sizes: 80mm; 57mm and 52mm.

AVIASPORT Oil Pressure indicators (gauges) are designed specifically for ROTAX 912/914 aircraft engines with painted red, green, and yellow gauge markings. are available in two sizes: 52 and 57 mm. They are offered in two unit versions for readings in PSI or Bars. They work with different pressure sensors depending on these installed in ROTAX 912/914 engines: the VDO sensor (Before September 2008) or the 4..20mA sensor (after 2008).

Range of special accessories by FRANZ AIRCRAFT ENGINES for use in BRP-ROTAX® aircraft engines and other applications.

BRP-ROTAX® product range includes certified and non certified internal combustion engines, parts and accessories for light and ultralight aircraft. They form part of  BRP-Powertrain GmbH & Co. KG product portfolio which also includes engines for snowmobiles, watercrafts, boats, roadsters, all-terrain and side-by-side vehicles, motorcycles & carts.

BRP-ROTAX® product range includes certified and non certified internal combustion engines, parts and accessories for light and ultralight aircraft.

BRP-ROTAX® 582 MOD. 99 (65 hp) is a two stroke non certified engine for experimental and ultralight aircraft with 300 hrs TBO. This engine is widely used and well accepted in the market for its robustness and easy maintenance.

For additional information please refer to the supplied documentation.

582 MOD. 99 Engine Features:

2 stroke non certified engine with dual independent breakerless, magneto capacitor discharge ignition (CDI) systems

with:

BING carburetor

fuel pump (big)

rewind starter

oil tank for rotary valve drive

exhaust system

integrated water pump

thermostat

hidro vibration damper

Options (supplied with the engines):

Gearbox Version E (with integrated electric starter) P/N:300005262-5003-5347-5004 for 503, 582

suitable for a mass moment of inertia of the propeller up to max 6000 kgcm2

reduction ratio i=2,62/3,0/3,47/4,0

Gearbox Version B P/N:300002258 for 447, 503, 582 (This option is no longer available)

suitable for a mass moment of inertia of the propeller up to max 3000 kgcm2

reduction ratio i=2,58

NOTE: Options are additionally charged and must be specified at the time of ordering. They can only be ordered with the respective engine(s).

The Viking Non-Certified aircraft engines  are based on used Mitsubishi and Honda automobile engines of recent production removed from cars that are uneconomical to repair. Their models come in multiple horsepower ranges (from 90 hp up to 195 hp). All engines are geared, liquid cooled with a fuel injection system.

Features of their Honda based engines include liquid cooling, Honda direct gasoline fuel injection system, 4 coil ignition system, lifetime chain camshaft drive, integral exhaust manifold cast into cylinder head, off-set crank shaft and friction reduction coating throughout the engine, variable valve lift and timing, Honda racing technology parts, 40 amp genuine Nippon Denso alternator, custom Mil-spec jacketed wire loom, 3 gear gearbox for Lycoming style propeller rotation and vertical engine orientation, forged, heat treated and ground helical gears, dual overhead camshafts, original Honda tuned intake system, 2.33:1 gearbox ratio.

The AVIASPORT indicators (gauges) are reliable, accurate and solid, combining the accumulated experience of more than twenty years with the latest technology  They have been designed for ROTAX engines and their display areas are divided into red, green and yellow zones in line with Rotax limits. They use a pointer that turns 240º or 320º, providing high resolution. AVIASPORT range of gauges includes CHT, EGT, tachometers, oil and fuel pressure, oil and coolant temperature, fuel level, voltmeters & ammeters and offered with casings of different sizes: 80mm; 57mm and 52mm.

The AVIASPORT fuel pressure gauges  have been designed especially to measure fuel pressure in Rotax® engines 912 and work both with 12V and 24V systems. Unlike mechanical gauges, the AVIASPORT ielectronic gauges use a high precision sensor to be installed close to the engine, preventing fuel lines in the cockpit. These gauges are sold without sending units or as kits with matching senders whenever specified.
