The STRATOMASTER VEGA range instruments/indicators from MGL AVIONICS includes different 2 1/4" (57mm) microprocessor based color display instruments operating over a wide supply voltage range of 8 to 30V DC with with built in reverse and over voltage protection. They are non certified and only suitable for installation in experimental and sport  (LSA) aircraft. Using a high resolution color graphics display, these instruments/indicators provide excellent daylight readability with built in backlighting making them easy to read at night time. They include a rotary control plus 2 independent keys for easy menu navigation and to access specific instrument features. Sensors are also offered to enhance their functionality. The MGL AVIONICS STRATOMASTER VEGA Series instruments/Indicators include: Artificial Horizon & Magnetic Compass Display, Altimeter/VSI, ASI, ASI/VSI, Engine Monitoring System (EMS), Fuel Computer, Information Display, Manifold Pressure, Température, RPM, Hobbs, Universal Engine/Rotor RPM, Hobbs, 4-Channel Thermocouple (EGT/CHT), 4 Channel Universal Analog Input (Pressure/Temperature/Voltage/Current) and NAVCOM Control head for MGL N16 NAV/COMM or V16 COMM VHF.

The RCA 56 Series of electric turn and bank indicators by KELLY MFG (RC ALLEN) are an all volt instrument, with a power warning flag, a black or white ball inclinometer and either lighted or non-lighted. These rate-of-turn pointer controlled instruments are powered by an electrically driven DC precision gyro with an inclinometer providing the pilot with turn and bank information.  They meet or exceed requirements of FAA TSO C3b. Made in the USA. Weight: 1.9 lbs.

Dimensions: Length: 6 1/4 in. Max, Width: 3 3/8 in. Max, Height: 3 3/8 in. Max

Mating Connector: MS3106A10SL-3S.

Connector Pin Out: A: +11-30 VDC, B: Ground, C: Spare

KANARDIA INDU Series round altimeters are part of INDU diverse family of non-certified gauges for use in ultralight aeroplanes, autogyros and helicopters. They feature colour LCD display, one or two pointers  with possibility to personalise scales (in feet or meters) and LCD displays. They are offered as standalone (master) altimeters with internal pressure sensors or as slave instruments. The slave version requires some PFD like KANARDIA NESIS, EMSIS, AETOS or HORIS to be present on the CAN bus. KANARDIA INDU Series round altimeters are available for two standard panel hole diameters of 57 mm (2.25") with one pointer and 80 mm (3.15") with two pointers. They can also be ordered with integrated backup battery at additional cost. The backup battery can also handle and additional indicator, typically an airspeed indicator.

The smartPlane system by Guardian Avionics is an iOS-based Multifunction Display (MFD) and Flight Data Recorder (FDR) system with voice command capability for Part 23 FAA certified aircraft. It has been designed as a budget-friendly general aviation multifunction display option while collecting, storing, and displaying flight and performance data. smartLink 4 different units (554, 555. 650, and 851) can be used to connect select EFIS, GPS, and engine monitors for data collection & transmission to Guardian Avionics smartMFD iOS application by USB or Bluetooth.All smartPlane product line units additionaly feature Carbon Monoxide detection, Real-time Aircraft Tracking, Pilot Logbook, Aircraft Flight Logs, and Discrepancy Reports (squawk list). They are FAA approved  for installation in FAA Certified Part 23 aircraft under the NORSEE (Non-Required Safety Enhancing Equipment) authorization.

Guardian Avionics smartPlane EM100 Flight Engine Monitoring System can be remote mounted and integrates with smartLink 851 via RS-232 which in turn communicates with smartMFD iOS app through an iPad and/or iPhone via a USB connection. This results in iPad and iPhone becoming multifunction displays of rich flight and engine performance information which is also stored by the smartMFD app and can be shared with others, as required.

The EM100 includes 3 main connectors (J2 Female 37P DB, J3 Male 37P DB, J4 Female 15P HD) on the back of the unit. Every connector is defined to specific sensors for specifics engine measurements. Sensors are not included as part of EM100 unit and havee to be supplied separately. Engine parameters monitored by the EMS100 include: EGT, CHT, TIT, OAT, IAT, Oil Temperature (OT) & Pressure (OP), Fuel Pressure (FP),  Fuel Flow (FF) & Fuel Levels (FL), RPM, Manifold Pressure (MP), Voltage, and Amperage.

For additional information please refer to the Product Description section and the supplied documentation.

OMRON A3C series cylindrical pushbutton switches have the basic design as the M2C Series cylindrical indicators. They provide a high-intensity uniform surface lighting while they have a miniature size with excellent feeling of operation. They have a cylindrical 20-mmX12-dia. body making panel cutouts easier. These switches are offered in lighted and non lighted versions, different colors, display shapes, with LED or incandescent lamps and different socket units. Please consult the attached documentation for ordering.

1-1/4 inch TSO'd Electronic Fuel Pressure Gauges from UMA INSTRUMENTS. Black & White dial marking. Available in different pressure (PSI) ranges. Case: Aluminum. Weight: 4.0 oz. UMA sensors are sold separately.

RAY ALLEN (RAC) R2S Rocker Switch provides a very positive snap action in 2 directions and returns to a center off position. It was designed specifically for Ray Allen trim systems. It is wired to connect both power leads to ground when the rocker is released. This eliminates motor coasting and allows very precise trimming. The RS2 switch is rated at 1amp. The faceplate measures 1.75" (44mm) x 1.0" (25mm) x 1.47" (37mm) deep. Self adhesive labels are not included. Sold separately.

The HONEYWELL BENDIX KING® KMT 112 is a Magnetic Azimuth Transmitter (aka Flux Detector or  Valve) which senses the direction of the earth’s magnetic field and continuously transmits this information through the slaving circuitry to a directional gyro (such as the HONEYWELL BENDIX KING® KG 102A or KSG 105 slaved directional gyros). This sensor is mounted remotely, usually in a wingtip, to eliminate the possibility of magnetic interference. The KMT 112 is typically used in HONEYWELL BENDIX KING® KCS 55A and KCS 305 compass systems. The KMT-112 flux valve is a sealed unit and cannot be serviced or have parts replaced. The unit must be replaced when/if it fails.

Like other KCS 55A compass system components, the  KMT 112 transmitter can be furnished in NEW condition or as USED in Serviceable or Overhauled conditions indicated respectively by the letters "SV" and "OH" in the product reference numbers (SKU and  accompanied by the relevant certification (e.g. yellow tag, 8130-3 form). They are also offered as exchanges / trade-ins  for returned customer owned units indicated by the letter "EX" in the SKU.  In the case of an exchange/trade-in option of a customer unit, the  full selling price of the ordered unit is charged and the core credit is refunded or credited towards future orders when our co-operating supplier verifies that the unit is in a reasonable, repairable condition. It is recommended that this option is selected by our customers mainly for upgrades and only in cases when their units are functioning properly at the time removal from the aircraft. In cases when customer units are found by our supplier to be non-repairable, the core deposit shall not be refunded and shipping charges shall apply if customers wish the return of these units to them.

Installation parts and manuals are sold separately.

For additional information and technical specifications please refer to the Product Desscription section, the product presentation of the HONEYWELL BENDIX KING® KCS 55A compass system or contact us.

HONEYWELL BENDIX KING® manufactures a range of TSO'd VOR/LOC/Glidescope indicators. These navigation instruments include VOR/LOC left-right needles, To-From indicator, VOR/LOC warning flag, glideslope deviation needle, glideslope warning flag and 30Hz OBS resolver. Depending on the model, the feature rectilinear instead of pendulum type meter movements for more precise indicator readings, 14/28 volt internal lighting, metal bezel with glass lens and course datum synchro for autopilot use.

These indicators are commonly used with BENDIX KING® remote mounted VOR/LOC converters such as KN-72 or KN-77, remote mounted Glideslope Receivers such as KN-73 or KN-75, KNS-80, KNS-81 nav systems and KX-155/KX-165 NAV/COMM transceivers.

The KI203 model features an internal VOR/ LOC converter and it is compatible with the BENDIX KING® KX155 transceiver. It has a rectilinear meter movement. Compatible with the BENDIX KING KX155 NAV/COMM transceiver.

The KI 204 VOR/LOC/Glideslope Indicator features a built-in VOR/LOC converter and scallop rejection filter, rectilinear needle movement and an optically coated glass lens. Requires input from external glideslope receiver. Compatible with the BENDIX KING® KX 155 or KX 155A NAV/COMMs. Requires input from external glideslope receiver.

The KI 206 VOR/LOC/Glideslope Indicator is rectilinear and internally lighted. It is used with the KNS 80/81 units, KX 165  transceiver and the KNR 634 VOR/LOC/GS/MB receiver. It is available with course datum synchro.

The KI208 model features a built-in VOR/ LOC converter and it is compatible with the BENDIX KING® KX 155 or KX 155A NAV/COMMs. It has a  pivoted needle action and a plastic lens.

The KI209 model features an internal VOR/ LOC converter and it is compatible with the BENDIX KING® KX155 transceiver. It features a pivot needle action.  The KI209 model includes GPS interface capability.

The RCA 22 Series of vacuum artificial horizon are controlled by air driven precision gyros to present the pilot with pitch and roll information. The attractive color scheme of blue sky and brown ground presents a realistic spherical display of flight. Unless otherwise indicated all instruments have a  "standard" display (dark blue/brown display with fixed pointer) and are unlighted.

All R.C. Allen vacuum gyros run off of 4.5" Hg, erect time is 3 min. The instrument fits in a standard 3 1/8 panel cutout. A ¼ -18 NPTF nylon tube slip fitting is recommended for vacuum hose installation. A 1/8 – 27 NPTF nylon tube slip fitting is recommended for vacuum gauge installation.

Dimensions: H: 3-3/8", W: 3-3/8", L: 6"

Weight: 2.75 lbs.

Certification: Meet or exceed all requirements of FAA TSO C4c and Aeronautical Standard AS396B.

Made in the USA

NOTE: The RC Allen RCA22-7 Vacuum Horizon Gyro can be an alternate device for Cessna Gyro Horizon C661076-0101.

KELLY MANUFACTURING (RC ALLEN) RCA 15AK series are TSO'd 3-1/8" ( 80mm) electric directional gyros suitable for both fixed wing and rotor wing aircraft.

FLYBOX® EFC-P Electronic Flap Controller by MICROEL SRL allows selection of the desired position of the flaps of an aircraft. EFC-P Controllers are offered in Rectangular (P/N: EFC-P-102010) or Round (P/N: EFC57-P-103010) versions. They are intended for use in ultralight and experimental aircraft. The working mode consist in selecting one of the four positions previously stored by the user, then the EFC-P will automatically moves the flaps in the exact position. The LEDs show the current position of the flaps or, when in movement, the position that they are reaching. For further information please refer to the attached documentation.

HONEYWELL BENDIX KING® KA 51B is a slave meter used in the KCS 55A compass system. Displays slaving error between the KMT 112 flux valve and KI 525A pictorial navigation indicator by means of small meter movement.

AIRPATH certtified (FAA TSO) Magnetic Compasses are used in almost all production aircraft. They are offered in in different panel mount and pedestral models,  lighted or non lighted versions, black & white markings, black finish, and capabilities for operations in South or North Hemisphere.

AIRPATH C2300 panel mount magnetic compasses fit in a 2.25 in. hole and need 3 in. of clearance from behind the panel. Offered Models(*): C2300, C2300-SF, C2300-L4, C2300-L4-SF.Compass fluid is included inside the units and come with the mounting screws and nuts required for their installation. A compass deviation card and card holder can be ordered separately.

AIRPATH C2400 series pedestral magnetic compasses have been specifically designed for installation either for streamline-type bracket housing or a pedestal-type housing. Wire lead length, voltage, and lighting color are specified under each respective part number. Each model is provided with mounting hardware, deviation card, deviation card window and either an attached cardholder, deviation plate, or standard unattached cardholder depending on the application. All compasses in the C-2400 series meet FAA TSO-C7c requirements and are offered in different versions for operations in South or North Hemisphere. They fit in a 2.25 hole. Lighting: Red 12 VDC. Meet FAA TSO-C7c requirements.

(*) Letter “L” after the dash in the part number indicates a lighted version. Letters “SF” indicate South Hemisphere.

FALCON GAUGE Magnetic Compasses are non certified  2" compasses available in liquid (MCDN) and non-liquid (dry) types (MCVC). The Liquid Type compasses provide an accurate reading at a low cost. They are fluid damped and incorporate a thermal expansion chamber and compensating magnet. Available in Panel or Pedestal Mount versions with or without lighting. Different models available: MCDN-2, MCDS-2, MCDN-2L, MCDS-2L. They can be ordered for Northern or Southern Hemisphere.

These compasses are very similar to the Airpath C2300 & C2400 style compasses, but are priced more economically.

The FALCON GAUGE Vertical Card Compasses are of a non-liquid type.  They are designed with a different concept which eliminates the disadvantages experienced with a liquid compass, namely leaking and back and forth motion of the compass card.  These compasses look like directional gyros and offer superior visibility.  A second vertical rotating dial, which is compared with a fixed miniature airplane (lubber line), presents the magnetic heading of the aircraft at all times making heading information more natural.  The easy to read presentation allows the pilot to see the complete 360 degree dial.  They also feature an internal LED light and a universal mounting bracket.

VDO Fuel Level Gauges have always been known for the superb fit, finish, and appearance, as well as the wide range of styles VDO offers. VDO Fuel Level 10-180 ohm Gauges  are offered in 2" and 2-1/4'" diameters with matching Fuel Level Senders  (aka sensors or probes) for their operation. This 12/24 VDC Fuel Level Sender has a resistance rating of 10 ohms when the tank is empty and 180 ohms when full. The unit can be adjusted to read accurately in tanks from 6" to 23" deep. In the case of the 2" 33-240 ohm Fuel Gauge, the appropriate fuel sender is P/N 226-007.

VDO product range also include Standard Tubular Level sensors mounted direct into the tank with different tube diameters and lengths from 200 mm to 650 mm and different resistances. They feature:

- Resistance output

- Compatibility to the VDO gauges 301-010-00X and X10-110-981-009  (adjustable to 60 to 90 Ohm at empty).

- M4 bolt and hexagon nut or 6,3 x 0,8 mm spade terminal

- Optional ground connector

- Optional warning contact

- Mounting bolt circle 54 mm dip tube fuel senders with different tube diameters and lengths.

For additional information please consult the supplied documentation or contact us.

MITCHELL AIRCRAFT PRODUCTS, Inc. is a well known manufacturer of tachometers, gauges, and instruments the general aviation industry, built under an FAA-approved quality system.

Their product range includes:

Mechanical 3-1/8″ Clockwise, & Counter-Clockwise, 2, 2-1/4″ Mechanical Recording & Electric Lighted Tachometers,

Electric Gauges (Ammeters, Cylinder Head Temperature, Exhaust Gas Temperature, Fuel Quantity Gauges, Outside Air Temperature, Pressure & Temperature Gauges, and Voltmeters,

Mechanical Pressure &Temperature Gauges

Modular Gauges (Ammeters, Blank, Fuel Quantity,Pressure, Temperature Gauges, and Voltmeters, Modular Gauge Frames. This line of FAA PMA  miniature square engine gauges is ideal for a wide variety of general aviation applications. They measure nearly 1-1/2″  and are stackable. The modular design allows them to be plugged from the front of the panel. The units are internally lighted. Complete standard panels are also available. If individual gauges are ordered, appropriate backplate with pigtail must be ordered to mount and connect the gauge. If more than one gauge are ordered to be mounted together, a special order clustering requires custom backplates.

Sending Units (CHT & EGT Thermocouples, Fuel Quantity & Pressure Senders, 1/8″ & 5/8″ Temperature Senders.

MITCHELL FAA PMA'd D1-211 Series  modular 1-1/2 " fuel quantity square  gauges can be stacked in horizontal and/or vertical rows in any position in the aircraft panel. These  modular gauges are internally lighted and are plug removable from the front of the panel for easy maintenance. Available in different sender resistances for the indication of fuel quantity in the aircraft's left or right fuel tank.

MITCHELL FAA PMA'd D1-211 Series  modular electric 12V (PN D1-211-5074) & 24V (P/N PE-111-4074) fuel quantity gauges are lighted and easily installed in a 2-1/4" panel hole. They feature a 2 year factory warranty.

The gauges and senders must be ordered separately.

For the 12V Fuel Quantity Gauge D1-211-5074 the matching sender is PS-211-8038, 10-180 Ohm. For 24V operation, P/N PE-111-4074  resistors for each instrument must be ordered.

MITCHELL Pressure Senders 80 PSI (PN PS-211-9002) and 150 PSI (PN PS-211-9040) are offered for use with D1-211-6089 and D1-211-6092 FAA PMA Pressure Gauges respectively. Both have 2 terminals (one terminal to be grounded).

MITCHELL EGT Gauge 0-1600 Deg. F, PN D1-211-6101 requires PN PS-211-8162 sender (probe).

These UMA new manufacture NON TSO'd electric ammeters offer accuracy, rugged construction, and contemporary styling. They are available in different  measurement ranges with a 270° sweep and are suitable for installation in 2-1/4" panel hole diameters. Made in U. S. A. and furnished with shunt.

WULTRAD INC. is a manufacturer of non-certified flight and engine instruments under FALCON GAUGE brand for experimental and homebuilt aircraft. Although their products are Non-TSO, they are made to TSO or MIL specifications for quality.

FALCON GAUGE  Electrical Turn Coordinator is used for displaying the angular rate and sideslip of turning in horizontal flying and turning. The inclinometer indicates the slip angle of the aircraft while in a turn. A power failure flag drops into view whenever the voltage drops below a level for proper operation. The Turn Coordinator incorporates a built-in voltage regulator so it can be used with either 14VDC or 28VDC power system. It is compact in size and light weight eliminating radio interference.

This small, lightweight unlighted turn coordinator is excellent for homebuilt aircraft. Works for 14 Volt or 28 Volt systems. Features, power out warning flag with a 0° Panel. Fits Standard 3-1/8" Cut Out, 3-3/4" long.
