AVERY TOOLS (*) manufactures and supplies gauges for shop rivet heads and rivet lengths.

AVERY TOOLS rivet head gauges are offered as a set of four gauges for -3, -4, -5, & -6 rivets. Each gauge measures MINIMUM height and MINIMUM diameter of shop heads AFTER setting. Eliminates guessing if your rivets are properly set. Works for measuring both universal head and flush rivets. Precision machined to size from 2024 aluminum. Rivet size permanently stamped on each gauge. Color coded anodized finish.

A rivet length gauge is also available to check for proper length of rivets BEFORE setting and can be ordered separately or as kit with the head gauges.

(*) AVERY TOOLS aviation tools and products are now available only through retail suppliers.

MS20604 and MS20605 Standard pull-thru rivets are unique blind rivets typically used in nut plate applications. MS20604 and MS20605 series blind rivets are superseded by those of NASM20604 and NASM20605 respectively.They are both non structural blind rivets with universal head (MS20604) or 100 Deg. flush head (MS20605). These rivets are ideal in circumstances with very limited clearance while allowing for a secure set on both sides of the application. The symmetrical insertion allows for access and installation on either side while retaining its blind rivet capacity of one-sided installation. NASM/MS 20604 rivets come with a Universal Head, allowing for ease of installation while retaining strength and security.

Sourced from quality manufacturers, NASM20604/MS20604 and NASM20605/MS20605 blind rivets are offered either as part of our own label (AVIATIONEU NEW ERA) product lines or as OEM parts of PCC CHERRY® AEROSPACE and other manufacturers (separately listed). They are available in different mil-spec approved materials, such as 2117-T4 grade Aluminum or 5056 Grade Aluminum, finishes and sizes. They are sold in packs of specified number of rivets per pack indicated after the letters "PK" in the product reference code (SKU).

The rivet pin range by HI-SHEAR CORPORATION, subsidiary of LISI AEROSPACE, offers a versatile solution for most of structural assemblies. They consist a very common type of threaded fastener used for clearance, transition and low interference fit throughout the airframe (metallic and composite), from wings to fuselage, in engine fairings, and more. Easily installed from one side, by one person with conventional tooling.

HI-SHEAR rivet pin product portfolio includes the original HI-LOK™ (HL™) system, the latest HI-LITE™ (HST™) pins with an improved recess and HI-TIGUE™ (HLT™) pins with improved fatigue benefits. They can be used in shear and/or tension applications on plain or sloped surfaces and feature controlled preload, a wide range of sizes and variety of materials and coatings for installation in all structures.

Most fasteners are mainly loaded in shear. That should be the only way for rivets as their tension capability is relatively low. Whenever there is a substantial tension load in a fastener, a threaded bolt should be used.

HI-LOK™ (HL™) is the original and versatile solution, a simple two-part fastener for strong and reliable assemblies. HI-LOK™ pins are commonly used in applications requiring high tensile strength in extreme environments. Consistent torque on installed fasteners is achieved through the integrated functions of the system working together. A carefully regulated breakoff groove in the self-locking HI-LOK™ collar  (separately presented) provides uniform preload values by separating when the correct torque level is reached. This controlled preload of each HI-LOK™ in the structure improves the fatigue life of the airframe significantly when compared to other fastening systems, including swaged collar type. HI-LOK™ pins and HI-LOK™ collars offer extremely precise dimensions making these fasteners commonly used in space, military, and commercial aviation application. They are both threaded and require common installation tools making  HI-LOK™ fasteners easy to install and remove.

HI-LITE™ (HST™) rivet pins are direct descendants from their original HI-LOK™ series counterparts but significantly lighter as they are made from 6Al-4V Titanium alloy resulting in improved weight saving. Combined with HI-LITE™ nuts and collars (separately presented), they provide up to 13% weight saving compared to the previous HI-LOK™generation. Both HI-LOK™ and HI-LITE™ rivet pins are also available with ASTER improved recess (HSTR pins) that prevents failure during the assembly process,  especially suited for clearance fit assemblies of composite structures.

HI-TIGUE™ (HLT™) pin series has improved fatigue benefits by combining the hole-improvement qualities of the HI-TIGUE™ pins and the consistent preloading qualities of the HI-LOK™ collars.

Additional information is available in Product Description section and the supplied documentation.

ATI® TOOLS 106A series flush swivel type rivets are manufactured from S2 high-grade shock-resistant steel and machined in accordance with MIL-STD GGG-R-425. They feature protection with plastic coating to prevent damage during shipment and storage, blended radius between cup and chamfer with no sharp edges, which coin or mar skin, highly polished precision cup, free of machine marks and ridges and chamfered corners. Rivet Type: Flush Swivel Type. Shank diameter 0.401".

USATCO C-Yoke riveters are available in single cylinder and tandem cylinder types, both in standard and high force versions. They cover different capacity requirements for use in aluminum and steel and feature quiet, easy operation, CE approval and swivel air inlets. Clamping force exceeds federal specifications. USATCO C-yokes are available for different mounting spacings and furnished with .187” or .250” set holes.

For additional information please refer to the attached documentation or contact us.

AICRAFT TOOL SUPPLY (ATS) is a manufacturer of tools and hardware for the aviation industry. ATS offers an extensive range of aircraft countersink cutters and piloted aircraft stop countersink cutters (aka Micro-Stop cutters or Microstop Countersinks) used to make precision countersinks to accept flush-head fasteners.

Our offered ATS countersinks include:

HSS 1/4-28 male threaded 3 cutting flute pilot cutters,

HSS 1/4-28 male threaded, 1/2” diameter zero flute pilot cutters,

HSS 1/4-28 male threaded removable pilot cutters with solid carbide tip (require 1500P pilot),

Hollow cutters designed to cut away swagged or threaded collars from fasteners,

Respective offered ATS Microstops include:

133-HD heavy duty Microstop Countersink with ball bearings for ultra smooth operation. The ball bearing design also makes it run much cooler than a standard microstop,

133-Mini Microstop Countersink for use  in tight areas that can’t be reached by a standard cage.

133-Slim Microstop Countersink packing all the features of a standard microstop in a slim design of only 11/16” in diameter.

 Complete kit is a great package deal featuring our 133

133 Microstop Countersink Kit which includes the Microstop and 4 pilot cutters (1000-100 series) in sizes #40, #30, #21, and #12. The kit is also offered with the countersink only.

For additional information please consult the supplied documentation or contact us.

For over 60 years, CHERRY® AEROSPACE Installation Tools have been specified and used by aircraft manufacturers and repair facilities throughout the world. Each CHERRY® AEROSPACE fastening system is combined with a full range of tools to provide an overall systems approach that ensures optimum compatibility and consistent installation performance. Used worldwide, Their tools are are manufactured to provide maximum service with minimum care. They are offered in a wide variety of hand, pneumatic and pneumatic/hydraulic versions, with optional accessories to permit their use in difficult and limited access areas. The size and type of fastener being installed dictates the type of tool to be used. All installation tools are manufactured at CHERRY® AEROSPACE's plant in Santa Ana, CA, USA.and they are CE Certified.

For additional information please refer to the supplied documentation or contact us.

Rivet cutters of different types are commonly used in Aerospace and many industrial applications. These quality heavy duty tools are made by different manufacturers mostly in hand-held but also in bench mounted versions and can be used for cutting rivets of aluminum and other materials od different diameters and lengths. Some of them are briefly presented below.

ATI® TOOLS 501 series aerospace heavy duty rivet cutters are designed to quickly and easily shear aluminum rivets. They are adjustable for 1/4˝ to 3/4˝ long rivets in 1/16˝ increments. Available in two models with standard handle (ATI 501R) and long handle (ATI 501S).

The RC-1 heavy-duty rivet cutter manufactured by LANCASTER PUMP is designed to mount onto a workbench (or held in vice), and will cut five (5) different diameter rivets, wire, and screws to any of seven (7) different lengths. It is made of hardened steel and the cutting surfaces are ground to exacting tolerances for consistently clean, distortion-free cuts. Accepts diameters: 1/16", 3/32", 1/8", 5/32", and 3/16". Cuts lengths: 5/32", 7/32", 9/32", 11/32", 13/32", 15/32", and 17/32". Shipping weight 3 lbs ( appr. 1.5kg).

For more information on these tools please consult the supplied documentation or contact us.

Νuts and collars by HI-SHEAR CORPORATION, subsidiary of LISI AEROSPACE, are designed to fit with their related HI-LOK™/HI-TIGUE™ and HI-LITE™ pins  (separately presented) forming the respective fastener system. HI-LOK™ nuts and collars are designed to fit HI-LOK™ & HI-TIGUE™ pins. HI-LITE™ nuts and collars are designed to fit HI-LITE™, PULL-IN™, PULL-STEM™ & TAPER HI-LITE™ pins.

With a wide range of shapes, materials and coatings, they are suited for most of structural assemblies and are commonly used in the aerospace industry in tension and shear applications. Collars’ wrenching element is designed to break-away at a controlled preload. It has been tested over time and has proven its reliability when installed with non-torque-controlled tools. Main features of nuts and collars include:

- controlled preload

- wide variety of materials and coatings for installation in all structures

- suitable for shear or tension applications, with captive washer, self-aligning or self-sealing options

- limited access installation, using conventional tooling

- designed with a counterbore to fit nominal and oversized pins

- nuts allow customized torque and preload & low height design for low access areas

Please refer to the supplied documentation for additional information.

ATI® TOOLS 100A series (straight drive) and 101A series (offset drive) AN470/MS20470 universal-head cup shaped  rivets are manufactured from S2 high-grade shock-resistant steel and machined in accordance with MIL-STD GGG-R-425. Respective flush head rivets of ATI® TOOLS 100A/101A series are designated by the letter "F" after the series number (i.e. 100AF/101AF respectively. They feature protection with plastic coating to prevent damage during shipment and storage, blended radius between cup and chamfer with no sharp edges, which coin or mar skin, highly polished precision cup, free of machine marks and ridges and chamfered corners. Shank diameter 0.401". Available in different rivet sizes, body diameters and lengths in inches.

Solid shank rivets are relatively low-cost,  permanently installed fasteners used as structural parts in aircraft and other applications where reliability and safety consist a priority.  These rivets are produced in accordance with military and other international standards such as US Army-Navy (AN) standard and Mil-Spec (MS) that followed. AN426/MS20426 and AN470/MS20470 Series rivets are solid aluminum rivets with countersunk head or universal head respectively. Sourced from quality suppliers they are offered as part of our own labelled (AVIATIONEU NEW ERA) product lines. They are  available in different diameters and lengths and sold by the pound (lb). Those designated by the letter "A" in their part numbers are "soft" rivets fabricated from 1100-grade aluminum with a tensile strength of 16,000 PSI while rivets designated by the letters "AD" are fabricated from 2117 aluminum and heat treated to the T4 condition. They have a shear strength of 26,000 PSI and a tensile strength of 38,000 PSI. For additional information please refer to the article on an overview of our fasteners, other supplied documentation, the individual product presentations or contact us.

Solid shank rivets are relatively low-cost,  permanently installed fasteners used as structural parts in aircraft and other applications where reliability and safety consist a priority.  These rivets are produced in accordance with military and other international standards such as US Army-Navy (AN) standard and Mil-Spec (MS) that followed. AN426/MS20426 and AN470/MS20470 Series rivets are solid aluminum rivets with countersunk head or universal head respectively. Sourced from quality suppliers they are offered as part of our own labelled (AVIATIONEU NEW ERA) product lines. They are  available in different diameters and lengths and sold by the pound (lb). Those designated by the letter "A" in their part numbers are "soft" rivets fabricated from 1100-grade aluminum with a tensile strength of 16,000 PSI while rivets designated by the letters "AD" are fabricated from 2117 aluminum and heat treated to the T4 condition. They have a shear strength of 26,000 PSI and a tensile strength of 38,000 PSI. For additional information please refer to the article on an overview of our fasteners, other supplied documentation, the individual product presentations or contact us.

GOEBEL® is leading manufacturer of high quality fasteners with product lines extending from blind Rivets, self-tapping/drilling screws, and sealing washers, to drill bits, nut drivers, toggle latches, hand & power tools, PPE equipment, and many more innovative specialty products. GOEBEL® blind rivets, much like other GOEBEL® fastening products, are widely recognized used by leading companies in nearly every industry including oil & gas, automotive, HVAC, railroad, aerospace, telecommunications, and construction.

Blind rivets are offered in different product families in different materials, finishes head styles and sizes to meet intended application requirements. They include Standard, Multi-Grip, Semi Structural & Structural, Tri-Folding & Load Spreading as well as Specialty blind rivets. More information on GOEBEL® Structural Blind Rivets is included in the Product Description. Additional information on GOEBEL® Blind Rivers is also available in the documentation in the Attachment section.

The CHERRY® Nut-Plate family of fasteners offers an extensive range of head styles in a low cost, pull through style rivet. Rivet heads include the CCR/CCMR274, “Universal”, CCR/CCMR264, 100° Flush, and the CCR/CCMR244, 100° Reduced Flush head (NAS 1097). Sleeve materials include C1018 steel or A-286 CRES stainless steel. Single action installation tools are all that is required to complete this low cost fastening system. Recommended installation tools include the G29 hand tool, which is sold complete with pulling head, or the G902/G902-15 lightweight power tool with pulling heads sold separately.

For additional information please refer to the supplied documentation or contact us.

HSTOOLING (formerly HI-SHEAR TOOLING) is a brand of ZEPHYR Manufacturing Co., Inc. (aka Zephyr Tool Group) designing and manufacturing the highest quality aerospace and industrial assembly tools and tooling systems.

HSTOOLING product porfolio includes installation, assembly and repair tools for Aerospace (air drills, riveters, both conventional rivet hammers and compression riveters, specialty fastener installation and other tools and accessories).

HSTOOLING ULTRALITE® compression riveters include different models covering different capacity requirements for aluminum and steel.They are  offered in Alligator jaw and C-Yoke models and feature ergonomic design, weight reduction vs. comparable-force models, high-strength forged jaws and C-yokes, precison bearings and shafts.  The new 702 and 702T alligator models posess outstanding force-to-size ratios.

HSTOOLING Air Driver Assemblies are designed specifically for installing HI-SHEAR CORPORATION HI-LOK™ (*), HI-LITE™,  and HI-LOK™/HI-TIGUE™ pin and collar fastener combinations. They come in a variety of sizes and configurations, to drive fasteners in both open and restricted-access areas. Compact, lightweight, fast and reliable HSTOOLING tooling systems generate low noise compared with conventional riveting, require minimum employee training, and are designed to operate at a normal factory air pressure of 90 psi with 1/4 or 3/8 inch air lines.

Installation/removal tools for Hi-Lok™ or Hi-Lok™ style fasteners made by Jiffy Air Tool and USATCO are also offered. Pleae refer to the respective product presentations.

For additional information please refer to the supplied documentation or contact us.

(*) The HI-LOK™ fasteners from HI-SHEAR CORPORATION, subsidiary of LISI AEROSPACE, are the second most used fasteners in aircraft structural assembly after the solid rivets MS20470 and MS20426. The HI-LOK™ fastener system includes a rivet pin (similar to a screw but with additional advantages) and a collar (similar to a nut).

Blind Rivets are multi-piece rivet assemblies, capable of being installed from one side of the workpiece.Traditionally, blind rivets were used on aircraft leading edges, trailing edges, and close out areas which are limited to access to one side of the structure.  Current blind rivet usage has expanded to many additional areas of the aircraft in an effort to decrease labor expense and to address the ergonomic issues of solid riveting.

The CherryMAX® rivet by CHERRY® AEROSPACE is the most reliable, high strength structural fastener with visual inspectability in the world today.  It features the "Safe-lock" locking collar for more reliable joint integrity, and meets the requirements of PS-CMR-3000. CherryMAX® fasteners are currently available in 1/8" through 1/4" diameters in both nominal (CR3212 and CR3213 Series) and 1/64" oversize diameters (CR3242 and CR3243 Series).

Please refer to the supplied documentation and the Product Description section for detailed information on CherryMAX® rivet and other blind rivets manufactured by CHERRY® AEROSPACE.

Blind Rivets are multi-piece rivet assemblies, capable of being installed from one side of the workpiece.Traditionally, blind rivets were used on aircraft leading edges, trailing edges, and close out areas which are limited to access to one side of the structure.  Current blind rivet usage has expanded to many additional areas of the aircraft in an effort to decrease labor expense and to address the ergonomic issues of solid riveting.

The CherryLOCK® blind rivets by CHERRY® AEROSPACE come in below  mentioned types, and in different sizes, materials and strength levels. A complete range of recommended power tools, hand tools and pulling heads are also available.

CherryLOCK® ‘A’ Code “non-shift”, self-plugging blind rivets

Single action, mechanically locked, wire-drawing fasteners providing excellent hole-fill and sheet take-up capability. They conform to the Procurement Specification NAS 1400 and Standards Pages NAS 1398 and NAS 1399.These rivets are offered in aluminum, monel and A-286 stainless steel materials in a wide variety of diameters and grip ranges. CherryLOCK® ‘A’ Code  "Wiredraw"  rivets are locked spindle flush fracturing structural rivets manufactured in 3/32", 1/8", 5/32", 3/16" and 1/4" diameters in 100° flush head and protruding head style configurations and offer grip ranges from .020 in the smaller diameters to 1.073 in the larger diameters. The 3/32" diameter rivet is available in A-286 only with grips ranging from .020 to .562. Rivets 1/8" diameter and larger have head markings to identify grip, material and manufacturer for ready inspection. The flush fracturing spindle eliminates the need for shaving and meets the flushness requirement of the NAS 1400 specification. These rivets are especially suited for sealing applications and joints requiring excellent sheet take-up and allow simple installation with a wide variety of Cherry® nonshifting and shifting tools.

Both CherryLOCK® ‘A’ & Wiredraw Rivets rivets are designed to provide strong, reliable fastening solutions, but the choice between them may depend on specific application requirements, such as material compatibility, strength needs, and installation conditions. Both offer a wide grip range, making them versatile for different thicknesses.

Bulbed CherryLOCK® locked spindle and flush fracturing structural rivets

They consist a complete shear fastening system.  Their features can be utilized for optimum strength and performance in both thick and thin sheets. They provide the highest possible design integrity, particularly in double dimple or thin backside sheet applications. CherryLOCK® hydroshift installation tool systems are required for installation. They conform to Procurement Specification NAS1740 and Standards Pages NAS1738 and NAS1739.

For additional information on CherryLOCK® rivets and other blind rivets manufactured by CHERRY® AEROSPACE (separately listed) please refer to the supplied documentation and the Product Description section.

ATS Pro-X rivet guns offer unmatched controllability when setting rivets of any type or size. They are used in aircraft manufacturing plants such as Boeing and Lockheed-Martin. With the improved variable power control, proper riveting can be accomplished with confidence.  Different models serve specification requirements (see attached table). 1/8" Aluminum (3/32" Steel) Rivet Capacity. These guns accept all .401 shank rivet sets and attachments. Non-slip Powder Coat Finish. 1/4" NPT Inlet. Lifetime ATS-Pro Warranty.

Rivet Pin Gauges from HI-SHEAR CORPORATION,  subsidiary of LISI AEROSPACE, can be used for inspection or measurement of correct grip length of HI-LITE™ / HI-LOK™ rivet pins. Different HI-SHEAR Pin Protrusion Gauges are offered for respective HI-LITE™ / HI-LOK™series pins. HI-SHEAR Grip Gauge Assemblies can be used to measure the “grip length” of HI-LOK™ and HI-LITE™ pins, shear lockbolts, structural screws and bolts. The HI-SHEAR 2-651 Grip Gauge Assembly includes one HI-SHEAR 2-612 Grip Gauge & one HI-SHEAR 2-615 Grip Gauge Slide. The 2-612 Grip Gauge measures in increments 1/16” to 3”(1 mm to 75 mm). Made from spring temper stainless steel, 3/4" x 6-1/4".

Structural screws are made of alloy steel, are properly heat treated, and can be used as structural bolts. Those commonly used in aircraft applications are manufactured to aerospace/military standards/specifications. They are offered as part of our own branded (AVIATIONEU NEW ERA) product lines structured in different series based on the standard of their conformance. Some of the screws commonly used include NAS204 through NAS235 and AN509/AN525 series.

MS24694 Series structural screws have a 100° countersunk Phillips head. They replace the respective AN509 series structural screws of materials and finishes. Minimum tensile strength for steel is 125,000 psi. They are fabricated from alloy steel and cadmium plated per specification QQ-P-416A, Type II, Class 3 or 300 Series Stainless Steel unplated designated by the letters "S" and "C" respectively in the product part number after MS24694 and before the size number.

Sourced from quality suppliers, AVIATIONEU NEW ERA MS24694 series structural screws are offered in different thread sizes and lengths in inches and sold in pieces or packs of specified number of screws designated after the letters "PK" in the product reference number (SKU). For more information, please refer to the individual product presentations, the supplied documentation or contact us.
