Machine screws are one of the more widely used products among dozens of standard fastener types. They can be either coarse-threaded or fine-threaded, and are usually available with a wide range of head types. Usually stronger than many other screw types, they are used for fastening metal parts and panels securely together in a range of construction and other applications including aerospace, machinery, vehicles, engines, tool assemblies, electronic devices, and large-scale industrial equipment.

Sourced from quality producers,  machine screws are offered as part of our own labelled (AVIATIONEU NEW ERA) product lines conforming to aerospace/military or industrial standards/specifications.  They come in different sizes, head types, materials and thread gradings.

AVIATIONEU NEW ERA AN526 series screws are mil spec truss-head non-structural machine screws made of carbon steel and cadmium plated. Minimum tensile strength 55,000 psi. Available in slot head or Phillips recessed head indicated by the letter "R" in the product part number. They are available in different sizes and lengths in inches and sold in packs. The number of screws per package is indicated after the letters "PK" in the product reference number (SKU). For more information, please refer to the individual product presentations, the supplied documentation or contact us.

National Aerospace Standard (NAS) machine bolts are commonly used in aircraft, space shuttles, military vehicles, drones, and other high-performance applications. They are offered in different series to meet application requirements.

Those of NAS 6203 through NAS 6220 series, superseding their NAS 11(xx) counterparts, are tension hexagon head high strength close tolerance short-thread alloy steel bolts with a minimum tensile strength of 160,000 psi and a minimum shear strength of 95,000 psi.

They are made from different steel alloys such as 4140 (UNS G41400) or  4340 (UNS G43406) with either Cadmium Plate  Type II, Class 2 or Chromium Plate on shank only with all other surfaces cadmium plated.

Depending on the series they come in different nominal diameters in inches (e.g. NAS 6203 0.1875" (3/16"), NAS 6204 0.25" (1/4"), NAS 6205  0.3125" (5/16"), NAS 6206 0.375" (3/8"), NAS 6208 0.500" 1/2") or NAS 6210 0.625" (5/8") grips (in 1/16” increments beginning at 1/16”), thread and overall fastener lengths. They can be supplied undrilled or with drilled head and/or thread and with or without locking elements (nylon or equivalent). Sourced from quality manufacturers, these bolts are listed according to their series, and offered either as OEM parts or as parts of our own labelled (AVIATIONEU NEW ERA) product lines (see the respective listings). Sold in pieces or packs of specified number of bolts per pack designated by the number after the letters "PK" in the product reference code (SKU).

The following letters after the basic part numbers specify the material, finish, drilling condition, and self-locking capability of these bolts.

No Finish Code for Cadmium II plated bolts

"C" for Chromium plated bolts (shank only)

"L" for Self-locking bolts

"P" for Self-locking bolts with patch type locking element only

Grip Dash Number indicating grip in .0625 increments

"D" after the grip dash number for drilled thread bolts

"H" after the grip dash number for bolts with drilled head

More than one code letters may be used in sequence.

PN Examples:

NAS6204-10 - NAS 6204 Series Bolt, .2500-28 Thread, .625 Grip, Undrilled, Non-locking, Alloy Steel Cadmium II Plated.

NAS6204-10D - Same bolt as above with Drilled Thread.

For more information, please refer to the supplied documentation or contact us.

AVIATIONEU NEW ERA high tensile stainless steel threaded bolts are manufactured from AISI 410 stainless steel and heat-treated and machined to minimum of 110-ksi or 760 Mpa tensile strength. They are dual ASTM & ASME certified (ASTM A193 B6: Class 1 Stainless Steel, ASME B1.1 2A/3A Inch Unified Threads and B1.13M 6h Metric Coarse Threads). In addition to their high tensile strength, they exhibit excellent resistance to corrosion, good dimensional stability, durability as well as a long functional work life. They can be used in different industries demanding high tensile strength and corrosion resistance like marine, chemical & petrochemical etc. Sold in in packs (pk) of 25 bolts/pk in different head, body diameters and thread lengths in inches with Minimum Order Quantity (MOQ) 10 packs. Please refer to the attached specifications table. Appearing price is for reference only and differentiates based on wanted bolt sizes. Please contact us for a quotation.

AN hex head bolts in different series are offered under AVIATIONEU NEW ERA product series. Sourced from quality vendors, these bolts are manufactured to the US Army-Navy (AN) standard, predecessor to Mil-Spec (MS), superseded by the National Aerospace Standard (NAS). Commonly used in aviation for either tensile/shear load applications. Made from high-strength type 4037 or 8740 alloy steel or 431 Stainless Steel (CRES) and cadmium plated for superior corrosion resistance (compared to commercial grade zinc plated bolts) they are offered with shank drilled for cotter pin or undrilled for stop nut application, and with a drilled head for safety wire or without. Minimum Tensile Strength (Steel and CRES) - 125,000psi. The length of AN aircraft bolts is measured from under the head to the end of the shank. The "grip" is the unthreaded portion of the shank. Threads are pressed into the steel, not cut, thus maintaining strength throughout the entire shank. The surface under the head of AN bolts is designed to be a bearing surface to reduce non-uniform stress as the bolt is torqued thus reducing premature fatigue. The following letters are used in the product part  numbers.

"A" after the dash number for bolts with undrilled shank

"C"  for bolts made of 431 Stainless Steel (CRES)

"H" after the AN number for bolts with drilled head (eg. AN3H-15)

 AN3 through AN20 Series bolts are superseded by NASM3 through 20 Series. The part numbers in both series have not been changed.

Specification Details:

AN3 through AN20 (REV. 12), Military Specification Sheet: Bolt -Machine, Aircraft [superseded by NASM3 through 20]. This specification covers aircraft machine bolts part numbers, AN3, AN4, AN5, AN6, AN7, AN8, AN9, AN10, AN14, AN16, AN17, AN18, and AN20. AN3 THRU AN20  is canceled and superseded by NASM3 THRU NASM20. The Part Identification Number (PIN) for AN3 THRU AN20 REV. 12 and the part number for NASM3 THRU NASM20 are identical. The part numbers have not been changed.

ROTAX® aircraft  engines form part of the product portfolio  of BRP-Powertrain GmbH & Co. KG which develops and manufactures engines for snowmobiles, watercrafts, boats, roadsters, all-terrain and side-by-side vehicles, motorcycles, carts, and aircrafts.

BRP-ROTAX® product range includes certified and non certified internal combustion engines, parts and accessories for light and ultralight aircraft.

Different screws, such as hexagonal, allen, fixation and others are used in BRP-ROTAX® aircraft engines (please refer to the respective product presentations). They come in various sizes (mostly Metric) and are offered as certified or non certified parts from the manufacturer. Non certified parts can be used in ultralights or other aircraft not requiring certification of parts for their installation. Certified parts are designated by the letters "CERT" after the part number in the product reference number (SKU).

Aircraft engine  parts are subject to changes from time to time. Some parts may be no longer available or replaced by others with different part numbers. Listed BRP-ROTAX® engine parts do not imply their current availability or suitability for your engine application. Always consult the most recent Illustrated Part Catalogs (IPCs) or other documentation available from the manufacturer for the correct part number before ordering.

Different screws used on Textron Aviation Cessna, Beechcraft and Hawker aircraft. Also available as FAA-PMA approved parts from other manufacturers.

AN Clevis bolts are manufactured from nickel steel alloy, SAE 2330 and cadmium plated in same manner as AN3 - AN8 aircraft bolts.They are special-purpose bolts with a a slotted brazier type head and used where a large shearing stress occurs (never in tension). Minimum tensile strength 125,000 PSI. They are available with drilled or undrilled shank (designated by the letter "A" after the dash number for undrilled shank). For the AN12-AN23 bolts the second digit denotes the fine thread machine screw size (e.g. for AN21 the size is 6-40, for AN22 8-36 and for AN23 10-32). For the AN24-AN36 bolts the second digit denotes the diameter in 1/16 inch increments (AN25 has a diameter of 5/16 inch).

AN 22 Series Clevis bolts are available in NEW SURPLUS condition. Availability till stock exhaustion. They are special-purpose bolts with a a slotted brazier type head and used where a large shearing stress occurs (never in tension). Available with drilled or undrilled shank (designated by the letter "A" after the dash number for undrilled shank).

AN hex head bolts in different series are offered under AVIATIONEU NEW ERA product series. Sourced from quality vendors, these bolts are manufactured to the US Army-Navy (AN) standard, predecessor to Mil-Spec (MS), superseded by the National Aerospace Standard (NAS). Commonly used in aviation for either tensile/shear load applications. Made from high-strength type 4037 or 8740 alloy steel or 431 Stainless Steel (CRES) and cadmium plated for superior corrosion resistance (compared to commercial grade zinc plated bolts) they are offered with shank drilled for cotter pin or undrilled for stop nut application, and with a drilled head for safety wire or without. Minimum Tensile Strength (Steel and CRES) - 125,000psi. The length of AN aircraft bolts is measured from under the head to the end of the shank. The "grip" is the unthreaded portion of the shank. Threads are pressed into the steel, not cut, thus maintaining strength throughout the entire shank. The surface under the head of AN bolts is designed to be a bearing surface to reduce non-uniform stress as the bolt is torqued thus reducing premature fatigue. The following letters are used in the product part  numbers.

"A" after the dash number for bolts with undrilled shank

"C"  for bolts made of 431 Stainless Steel (CRES)

"H" after the AN number for bolts with drilled head (eg. AN5H-15)

 AN3 through AN20 Series bolts are superseded by NASM3 through 20 Series. The part numbers in both series have not been changed.

Specification Details:

AN3 through AN20 (REV. 12), Military Specification Sheet: Bolt -Machine, Aircraft [superseded by NASM3 through 20]. This specification covers aircraft machine bolts part numbers, AN3, AN4, AN5, AN6, AN7, AN8, AN9, AN10, AN14, AN16, AN17, AN18, and AN20. AN3 THRU AN20  is canceled and superseded by NASM3 THRU NASM20. The Part Identification Number (PIN) for AN3 THRU AN20 REV. 12 and the part number for NASM3 THRU NASM20 are identical. The part numbers have not been changed.

Structural screws are made of alloy steel, are properly heat treated, and can be used as structural bolts. Those commonly used in aircraft applications are manufactured to aerospace/military standards/specifications. They are offered as part of our own branded (AVIATIONEU NEW ERA) product lines in different materials and finishes, structured in different series based on the standard of their conformance.

AVIATIONEU NEW ERA MS27039 Series structural machine screws are pan head cross recessed screws equivalent to those of NAS 220 Series. MS27039 Series screws are fabricated from Alloy Steel and Cadmium plated per specification QQ-P-416A, Type II, Class 3, Anodized Aluminum Alloy 2024 or Stainless Steel Unplated  to MIL-S-6050 or MIL-8695 specifications. Those from are designated by the letters "DD" and their counterparts from stainless steel  by the letter "C" respectively in the product part number after MS27039 and before the size number. These screws have 125,000 to 145,000 psi tensile strength. Sourced from quality suppliers, they are offered in different thread sizes and lengths in inches and sold in pieces or convenient packs of specified number of screws per pack indicated after the letters "PK" in the product reference number (SKU).

Other structural screws of NAS204 through NAS235 and AN509/AN525 series are also available (see individual product presentations).

For more information, please refer to the supplied documentation or contact us.

National Aerospace Standard (NAS) machine bolts are commonly used in aircraft, space shuttles, military vehicles, drones, and other high-performance applications. They are offered in different series to meet application requirements.

NAS 6604 Series Steel Cadmium Plated Shear Hex Head Machine Bolts are offered as part of our own labelled (AVIATIONEU NEW ERA) lines of  fasteners. Sourced from quality manufacturers, AVIATIONEU NEW ERA NAS6604 series shear hexagon head bolts conform to the respective U.S. National Aerospace Standard of the Aerospace Industries' Association. They have a 1/4-28 thread and a nominal grip diameter of 0.2500 inch. NAS6604 series forms part of NAS family of bolts (NAS6603 through NAS6610 series) which includes hex head, close tolerance, alloy steel, long thread, self-locking & non-locking bolts. Their shearing feature is used to minimize damage to more critical components within the application. They are made from alloy steel with cadmium or chromium finishes and offered  in different grips and lengths in inches with undrilled or drilled head and/or shank. Used in applications where a premium-quality, high strength bolt is necessary. The following letters after the basic part numbers specify the material, finish and drilling condition of these bolts.

No Finish Code for cadmium plated bolts

"C" for chromium plated bolts

"D" for drilled shank bolts

"L" for self-locking bolts

"P" for self-locking bolt with patch type locking element

"H"for bolts with drilled head

More than one code letters may be used in sequence.

AN hex head bolts in different series are offered under AVIATIONEU NEW ERA product series. Sourced from quality vendors, these bolts are manufactured to the US Army-Navy (AN) standard, predecessor to Mil-Spec (MS), superseded by the National Aerospace Standard (NAS). Commonly used in aviation for either tensile/shear load applications. Made from high-strength type 4037 or 8740 alloy steel or 431 Stainless Steel (CRES) and cadmium plated for superior corrosion resistance (compared to commercial grade zinc plated bolts) they are offered with shank drilled for cotter pin or undrilled for stop nut application, and with a drilled head for safety wire or without. Minimum Tensile Strength (Steel and CRES) - 125,000psi. The length of AN aircraft bolts is measured from under the head to the end of the shank. The "grip" is the unthreaded portion of the shank. Threads are pressed into the steel, not cut, thus maintaining strength throughout the entire shank. The surface under the head of AN bolts is designed to be a bearing surface to reduce non-uniform stress as the bolt is torqued thus reducing premature fatigue.  AN3 through AN20 Series bolts are superseded by NASM3 through 20 Series. The part numbers in both series have not been changed. The following letters are used in the product part  numbers.

"A" after the dash number for bolts with undrilled shank

"C"  for bolts made of 431 Stainless Steel (CRES)

"H" after the AN number for bolts with drilled head (eg. AN10H-15)

AN10 bolts have a 5/8-18 thread with a 5/8" shank diameter. All AN10 bolts have a 0.955 thread length regardless of grip length. They can be torqued  to 92-108 lb-ft with AN365 or AN310 full-height nuts, or 50-65 lb-ft with AN364 or MS21042 half-height nuts. Indicated lengths are UHL: Under Head Length (aka Full Shank Length or Overall Length not including bolt head).

AVIATIONEU NEW ERA Hexagon Socket Head Screws are made of Carbon Steel, Alloy Steel with a Black Oxide or Galvanized finish (depending on the P/N) and a strength class of 4.8 or other as specified by the letter "S" in the P/N. They are fully threaded, coarse type, and produced by certified manufacturers in accordance with DIN 7984 standard. They are offered in competitive prices in different diameters ("M" designated), indicating the screw's diameter in mm and lengths in mm. The thread pitch (the distance between threads measured along the length of the screw) expressed in mm is indicated by the "P" designation in the P/N. Sold in packs of 500, 250 or  50 pieces depending on the selected product. The number of pieces included in each pack is mentioned after "PK" designation.

Close tolerance bolts, designed with a greater emphasis on measurement accuracy than other types of bolts, are commonly used in the aerospace manufacturing industry. They are threaded fasteners with a shank and head and a tolerance of just +0.000, -0.0005 inch as an acceptable range of variance. The shank is threaded, thus allowing them to be driven into a threaded hole. They intend to eliminate problems appearing when using traditional bolts which have a greater acceptable range of variance. Close tolerance bolts have closer shank tolerances than that of traditional bolts and fit more securely in threaded holes. For some fastening applications, traditional bolts may suffice. For sensitive fastening applications in which precision is required, close tolerance bolts are typically used. When selecting close tolerance instead of traditional bolts the drive type should be considered. Most close tolerance bolts have a recess within their head that supports a specific bit, such as a Phillips head bit. Regarding their threading, all close tolerance bolts, as well as traditional bolts, have threading. But the way in which the threading is designed may vary. Some bolts have more threading on their shank than others, and some bolts have finer threading than others.

Close tolerance bolts are offered in different materials with high-carbon steel being a common material used in their construction.

Army & Navy (AN) close tolerance bolts are offered as part of our own labelled (AVIATIONEU NEW ERA) lines of fasteners. They are sourced from quality manufacturers and structured in different series (AN 173/174/175/176/178/180).

The following letters after the basic part numbers specify the material, finish and drilling condition of these bolts.

First Number after AN Basic designates the Diameter.

"-" for Steel, Cad II plated, no head hole

"C" in place of (-) for Corrosion Resistant Steel (CRES)

"H" in place of (-) or after (C) for bolts with a head hole

"A" In the end of the PN  for bolts with no shank hole

Machine screws are one of the more widely used products among dozens of standard fastener types. They can be either coarse-threaded or fine-threaded, and are usually available with a wide range of head types. Usually stronger than many other screw types, they are used for fastening metal parts and panels securely together in a range of construction and other applications including aerospace, machinery, vehicles, engines, tool assemblies, electronic devices, and large-scale industrial equipment.

Sourced from quality producers,  machine screws are offered as part of our own branded (AVIATIONEU NEW ERA) product lines conforming to aerospace/military or industrial standards/specifications.  They come in different sizes, head types, materials and thread gradings. NAS Standard Machine Screws meet aerospace standards and come in different types and sizes structured in different series including NAS1101, NAS1102, NAS1189, NAS1190, NAS1191, NAS1635, NAS1801, NAS1802, NAS220, NAS229, NAS333, NAS514, NAS517, NAS560, NAS583, NAS600, NAS623 and NAS662.

AVIATIONEU NEW ERA NAS333/NAS334 series of machine (non structural) screws (also termed as bolts) are aeronautical standard 100 Deg. standard flush head, shear close tolerance screws. They are made from alloy steel per MIL-S-6049 with a Cadmium finish per QQ-P-416 Type II. They are both offered in different thread sizes, grips and lengths in inches and sold in pieces. CPA indicates a plated Phillips recess. The length and grip of the screw are indicated by numbers after the last dash in the product part number. For more information, please refer to the supplied documentation or contact us.

AN 21 Series Clevis bolts are available in NEW SURPLUS condition. Availability till stock exhaustion. They are special-purpose bolts with a a slotted brazier type head and used where a large shearing stress occurs (never in tension). Available with drilled or undrilled shank (designated by the letter "A" after the dash number for undrilled shank).

Machine screws are one of the more widely used products among dozens of standard fastener types. They can be either coarse-threaded or fine-threaded, and are usually available with a wide range of head types. Usually stronger than many other screw types, they are used for fastening metal parts and panels securely together in a range of construction and other applications including aerospace, machinery, vehicles, engines, tool assemblies, electronic devices, and large-scale industrial equipment.

Sourced from quality producers,  machine screws are offered as part of our own branded (AVIATIONEU NEW ERA) product lines conforming to aerospace/military or industrial standards/specifications. They come in different sizes, head types, materials and thread gradings.

Machine sccrews meeting National Aerospace Standards (NAS), developed and maintained by the US Aerospace Industries Association (AIA), are offered in different series.

AVIATIONEU NEW ERA AIA NAS 623 Series are aeronautical standard non structural pan head cross recess short thread machine screws. They are made from alloy steels 4140 (UNS G41400)  per MIL-S-5626, 4340 (UNS G43400)  per MIL-S-5000 or 8740 (UNS G87400 per MIL-S-6049. They are cadmium plated per QQ-P-416 Type II, Class 2. Heat treatment 160,000 to 180,000 psi ultimate tensile streangth in accordance with SPEC-MIL-H-6875.They are offered in different thread sizes, grips and lengths in inches and sold in pieces or convenient packs of specified number of screws per pack indicated by the number after the letters "PK" in the product reference number (SKU).

For more information, please refer to the supplied documentation or contact us.

AVIATIONEU NEW ERA ASTM A324 Grade 10.9 Series high tensile hexagonal head threaded bolts are produced from medium carbon steel, medium carbon steel alloy and low carbon boron steel with heat treatment by both quenching and tempering.  They meet ASTM A324 Grade BD and SAE J429 standards. These bolds feature high tensile strength and good wear resistance and are used in automotive applications and for bolting large and forged parts.

Nominal Tensile Strength: 1.000 Megapascal (MPa) or 1.000 N/sqr. mm , Yield Stress: 900 Megapascal (MPa) or 900 N/sqr. mm

They are offered in different finishes (zinc plated, plain or hot dip galvanised) and different standard, coarse and fine thread sizes (diameter M20 to M100 mm / 3/4" to 3.1/2").  Sold by the piece (pc.) in increments of 10 pieces with Minimum Order Quantity (MOQ) 100 pieces. Appearing price is for reference only and differentiates based on wanted bolt sizes. Please contact us for a quotation.

AN hex head bolts in different series are offered under AVIATIONEU NEW ERA product series. Sourced from quality vendors, these bolts are manufactured to the US Army-Navy (AN) standard, predecessor to Mil-Spec (MS), superseded by the National Aerospace Standard (NAS). Commonly used in aviation for either tensile/shear load applications. Made from high-strength type 4037 or 8740 alloy steel or 431 Stainless Steel (CRES) and cadmium plated for superior corrosion resistance (compared to commercial grade zinc plated bolts) they are offered with shank drilled for cotter pin or undrilled for stop nut application, and with a drilled head for safety wire or without. Minimum Tensile Strength (Steel and CRES) - 125,000psi. The length of AN aircraft bolts is measured from under the head to the end of the shank. The "grip" is the unthreaded portion of the shank. Threads are pressed into the steel, not cut, thus maintaining strength throughout the entire shank. The surface under the head of AN bolts is designed to be a bearing surface to reduce non-uniform stress as the bolt is torqued thus reducing premature fatigue. The following letters are used in the product part  numbers.

"A" after the dash number for bolts with undrilled shank

"C"  for bolts made of 431 Stainless Steel (CRES)

"H" after the AN number for bolts with drilled head (eg. AN4H-15)

 AN3 through AN20 Series bolts are superseded by NASM3 through 20 Series. The part numbers in both series have not been changed.

Specification Details:

AN3 through AN20 (REV. 12), Military Specification Sheet: Bolt -Machine, Aircraft [superseded by NASM3 through 20]. This specification covers aircraft machine bolts part numbers, AN3, AN4, AN5, AN6, AN7, AN8, AN9, AN10, AN14, AN16, AN17, AN18, and AN20. AN3 THRU AN20  is canceled and superseded by NASM3 THRU NASM20. The Part Identification Number (PIN) for AN3 THRU AN20 REV. 12 and the part number for NASM3 THRU NASM20 are identical. The part numbers have not been changed.

Structural screws are made of alloy steel, are properly heat treated, and can be used as structural bolts. Those commonly used in aircraft applications are manufactured to aerospace/military standards/specifications. They are offered as part of our own branded (AVIATIONEU NEW ERA) product lines structured in different series based on the standard of their conformance. Some of the screws commonly used include NAS204 through NAS235 and AN509/AN525 series.

AN525/AN525R Series high-strength structural washer head (AN525) and cross-recessed (Phillips) head (AN525R) screws, fabricated from alloy steel per specification QQ-S-689. Tensile strength 125,000 PSI. Cadmium plated per QQ-P-416A, Type II, Class 3.

The AN525 washer head structural screws provide a large contact area. The AN509R (100° countersunk) Phillips head screws are used in countersunk holes where a flush surface is necessary. These have been replaced by MS24694 Series structural screws of the respective materials and finishes.

Structural screws have a definite grip and the same shear strength as a bolt of the same size. Shank tolerances are similar to AN hex head bolts, and the threads are National Fine. Structural screws are available with round, brazier, or countersunk heads. The recessed head screws are driven by either a Phillips or a Reed and Prince screwdriver. Sourced from quality suppliers, these structural screws are offered as part of our own labelled (AVIATIONEU NEW ERA) product lines in different thread sizes and lengths in inches and sold in pieces. For more information, please refer to the individual product presentations, the supplied documentation or contact us.
