Different screws used on Textron Aviation Cessna, Beechcraft and Hawker aircraft. Also available as FAA-PMA approved parts from other manufacturers.

Machine screws are one of the more widely used products among dozens of standard fastener types. They can be either coarse-threaded or fine-threaded, and are usually available with a wide range of head types. Usually stronger than many other screw types, they are used for fastening metal parts and panels securely together in a range of construction and other applications including aerospace, machinery, vehicles, engines, tool assemblies, electronic devices, and large-scale industrial equipment.

Sourced from quality producers,  machine screws are offered as part of our own labelled (AVIATIONEU NEW ERA) product lines conforming to aerospace/military or industrial standards/specifications.  They come in different sizes, head types, materials and thread gradings. NAS Standard Machine Screws meet aerospace standards and come in different types and sizes structured in different series including NAS1101, NAS1102, NAS1189, NAS1190, NAS1191, NAS1635, NAS1801, NAS1802, NAS220, NAS229, NAS333, NAS514, NAS517, NAS560, NAS583, NAS600, NAS623 and NAS662.

AVIATIONEU NEW ERA NAS1801/NAS1802 series of machine (non structural) screws are aeronautical standard fully threaded Phillips hexagon head screws replacing those of NAS1096 series of same sizes. NAS1801 screws are made from alloy steel per MIL-S-6049 with a Cadmium finish per QQ-P-416 Type II and feature a 160,000 - 185,000 psi tensile strength. NAS1802 screws are made from A-286 Corrosion Resisting Steel and are passivated per QQ-P-35. They are both offered in different thread sizes and lengths in inches and sold in pieces or packs of specified number of screws indicated after the letters "PK" in the product reference number (SKU). For more information, please refer to the supplied documentation or contact us.

National Aerospace Standard (NAS) bolts come in a large variance of lengths, thread types, head type, and materials. NAS bolts are suitable for high strength applications. They are the same as Army-Navy (AN) bolts, except they may be either raised or recessed.

NAS bolts are offered as part of our own labelled (AVIATIONEU NEW ERA) lines of fasteners. They are sourced from quality manufacturers and structured in different series.

AVIATIONEU NEW ERA NAS 428 series of machine (non structural) bolts are fully threaded, crowned hexagon head bolts made from cadmium plated steel or corrosion resistant steel (CRES). These bolts are offered with drilled or undrilled head or thread in different thread sizes, diameters and lengths in inches and sold in pieces. The number after NAS428 ( - ) denotes the thread size in 1/16th inch increments. The number after the last dash ( - ) is the overall length under the head. If this number is a single digit it is 1/8 of an inch. If it is a two digit number, the first is whole inches, the second is additional 1/8ths. For more information, please refer to the supplied documentation or contact us.

Close tolerance bolts, designed with a greater emphasis on measurement accuracy than other types of bolts, are commonly used in the aerospace manufacturing industry. They are threaded fasteners with a shank and head and a tolerance of just +0.000, -0.0005 inch as an acceptable range of variance. The shank is threaded, thus allowing them to be driven into a threaded hole. They intend to eliminate problems appearing when using traditional bolts which have a greater acceptable range of variance. Close tolerance bolts have closer shank tolerances than that of traditional bolts and fit more securely in threaded holes. For some fastening applications, traditional bolts may suffice. For sensitive fastening applications in which precision is required, close tolerance bolts are typically used. When selecting close tolerance instead of traditional bolts the drive type should be considered. Most close tolerance bolts have a recess within their head that supports a specific bit, such as a Phillips head bit. Regarding their threading, all close tolerance bolts, as well as traditional bolts, have threading. But the way in which the threading is designed may vary. Some bolts have more threading on their shank than others, and some bolts have finer threading than others.

Close tolerance bolts are offered in different materials with high-carbon steel being a common material used in their construction.

Army & Navy (AN) close tolerance bolts are offered as part of our own labelled (AVIATIONEU NEW ERA) lines of fasteners. They are sourced from quality manufacturers and structured in different series (AN 173/174/175/176/178/180).

The following letters after the basic part numbers specify the material, finish and drilling condition of these bolts.

First Number after AN Basic designates the Diameter.

"-" for Steel, Cad II plated, no head hole

"C" in place of (-) for Corrosion Resistant Steel (CRES)

"H" in place of (-) or after (C) for bolts with a head hole

"A" In the end of the PN  for bolts with no shank hole

National Aerospace Standard (NAS) machine bolts are commonly used in aircraft, space shuttles, military vehicles, drones, and other high-performance applications. They are offered in different series to meet application requirements.

NAS 6603 Series Steel Cadmium Plated Shear Hex Head Machine Bolts are offered as part of our own labelled (AVIATIONEU NEW ERA) lines of  fasteners. Sourced from quality manufacturers, AVIATIONEU NEW ERA NAS6604 series shear hexagon head bolts conform to the respective U.S. National Aerospace Standard of the Aerospace Industries' Association. They have a 10-32 thread and a nominal grip diameter of 0.1900 inch. NAS6603 series forms part of NAS family of bolts (NAS6603 through NAS6610 series) which includes hex head, close tolerance, alloy steel, long thread, self-locking & non-locking bolts. Their shearing feature is used to minimize damage to more critical components within the application. They are made from alloy steel with cadmium or chromium finishes and offered  in different grips and lengths in inches with undrilled or drilled head and/or shank. Used in applications where a premium-quality, high strength bolt is necessary. The following letters after the basic part numbers specify the material, finish and drilling condition of these bolts.

No Finish Code for cadmium plated bolts

"C" for chromium plated bolts

"D" for drilled shank bolts

"L" for self-locking bolts

"P" for self-locking bolt with patch type locking element

"H" for bolts with drilled head

More than one code letters may be used in sequence.

Machine screws are one of the more widely used products among dozens of standard fastener types. They can be either coarse-threaded or fine-threaded, and are usually available with a wide range of head types. Usually stronger than many other screw types, they are used for fastening metal parts and panels securely together in a range of construction and other applications including aerospace, machinery, vehicles, engines, tool assemblies, electronic devices, and large-scale industrial equipment.

Sourced from quality producers,  machine screws are offered as part of our own labelled (AVIATIONEU NEW ERA) product lines conforming to aerospace/military or industrial standards/specifications.  They come in different sizes, head types, materials and thread gradings. Countersunk screws allow the head of the screw to sit flush with or below the surface of the surrounding material. They may also be used to remove the burr left from a drilling or tapping operation thereby improving the finish of the product and removing any hazardous sharp edges.

AVIATIONEU NEW ERA AN507 series screws are mil spec threaded 100 degree countersunk non structural screws with Phillips head. They have been replaced by the respective screws of MS24693 series of materials and finishes. These screws are made of carbon steel and cadmium plated, stainless steel unplated or brass with chemical black finish. They are sold in pieces and offered in different sizes in the following materials and finishes with the corresponding notations after MS24693 and before the size number:

Carbon Steel Cadmium plated (letter "S")

300 Series Stainless Steel unplated (letter "C")

Brass with chemical black finish, (letter "BB")

For more information, please refer to the individual product presentations, the supplied documentation or contact us.

Machine screws are one of the more widely used products among dozens of standard fastener types. They can be either coarse-threaded or fine-threaded, and are usually available with a wide range of head types. Usually stronger than many other screw types, they are used for fastening metal parts and panels securely together in a range of construction and other applications including aerospace, machinery, vehicles, engines, tool assemblies, electronic devices, and large-scale industrial equipment.

Sourced from quality producers,  machine screws are offered as part of our own labelled (AVIATIONEU NEW ERA) product lines conforming to aerospace/military or industrial standards/specifications. They come in different sizes, head types, materials and thread gradings.

Machine sccrews meeting National Aerospace Standards (NAS), developed and maintained by the US Aerospace Industries Association (AIA), come in different types and sizes structured in different series, including:

NAS 1101, 1102, 1189, 1190, 1191, 1635, 1801, 1802, 220, 229, 333,  514,  517, 560, 583, 600, 623 και NAS 662.

The NAS 583 series are non structural machine screws are flush head close tolerance machine screws made of aeronautical 100 deg. alloy steel and cadmium plated.  Offered in different thread sizes and lengths in inches as OEM parts of respective manufacturers or as parts of AVIATIONEU NEW ERA product lines. Sold mostly in packs with number of pieces per pack specified after the letters "PK" in the product reference number (SKU). For more information, please refer to the supplied documentation or contact us.

These bolts are for use in Textron Lycoming aircraft engines. Supplied with our own Certificate of Conformance. If additional certification is required, please contact us as a respective charge may apply.

AN hex head bolts in different series are offered under AVIATIONEU NEW ERA product series. Sourced from quality vendors, these bolts are manufactured to the US Army-Navy (AN) standard, predecessor to Mil-Spec (MS), superseded by the National Aerospace Standard (NAS). Commonly used in aviation for either tensile/shear load applications. Made from high-strength type 4037 or 8740 alloy steel or 431 Stainless Steel (CRES) and cadmium plated for superior corrosion resistance (compared to commercial grade zinc plated bolts) they are offered with shank drilled for cotter pin or undrilled for stop nut application, and with a drilled head for safety wire or without. Minimum Tensile Strength (Steel and CRES) - 125,000psi. The length of AN aircraft bolts is measured from under the head to the end of the shank. The "grip" is the unthreaded portion of the shank. Threads are pressed into the steel, not cut, thus maintaining strength throughout the entire shank. The surface under the head of AN bolts is designed to be a bearing surface to reduce non-uniform stress as the bolt is torqued thus reducing premature fatigue. The following letters are used in the product part  numbers.

"A" after the dash number for bolts with undrilled shank

"C"  for bolts made of 431 Stainless Steel (CRES)

"H" after the AN number for bolts with drilled head (eg. AN6H-15)

 AN3 through AN20 Series bolts are superseded by NASM3 through 20 Series. The part numbers in both series have not been changed.

Specification Details:

AN3 through AN20 (REV. 12), Military Specification Sheet: Bolt -Machine, Aircraft [superseded by NASM3 through 20]. This specification covers aircraft machine bolts part numbers, AN3, AN4, AN5, AN6, AN7, AN8, AN9, AN10, AN14, AN16, AN17, AN18, and AN20. AN3 THRU AN20  is canceled and superseded by NASM3 THRU NASM20. The Part Identification Number (PIN) for AN3 THRU AN20 REV. 12 and the part number for NASM3 THRU NASM20 are identical. The part numbers have not been changed.

AVIATIONEU NEW ERA Hexagon Socket Head Screws are made of Carbon Steel, Alloy Steel with a Black Oxide or Galvanized finish (depending on the P/N) and a strength class of 4.8 or other as specified by the letter "S" in the P/N. They are fully threaded, coarse type, and produced by certified manufacturers in accordance with DIN 7984 standard. They are offered in competitive prices in different diameters ("M" designated), indicating the screw's diameter in mm and lengths in mm. The thread pitch (the distance between threads measured along the length of the screw) expressed in mm is indicated by the "P" designation in the P/N. Sold in packs of 500, 250 or  50 pieces depending on the selected product. The number of pieces included in each pack is mentioned after "PK" designation.

Structural screws are made of alloy steel, are properly heat treated, and can be used as structural bolts. Those commonly used in aircraft applications are manufactured to aerospace/military standards/specifications. They are offered as part of our own branded (AVIATIONEU NEW ERA) product lines in different materials and finishes, structured in different series based on the standard of their conformance.

AVIATIONEU NEW ERA MS27039 Series structural machine screws are pan head cross recessed screws equivalent to those of NAS 220 Series. MS27039 Series screws are fabricated from Alloy Steel and Cadmium plated per specification QQ-P-416A, Type II, Class 3, Anodized Aluminum Alloy 2024 or Stainless Steel Unplated  to MIL-S-6050 or MIL-8695 specifications. Those from are designated by the letters "DD" and their counterparts from stainless steel  by the letter "C" respectively in the product part number after MS27039 and before the size number. These screws have 125,000 to 145,000 psi tensile strength. Sourced from quality suppliers, they are offered in different thread sizes and lengths in inches and sold in pieces or convenient packs of specified number of screws per pack indicated after the letters "PK" in the product reference number (SKU).

Other structural screws of NAS204 through NAS235 and AN509/AN525 series are also available (see individual product presentations).

For more information, please refer to the supplied documentation or contact us.

AN hex head bolts in different series are offered under AVIATIONEU NEW ERA product series. Sourced from quality vendors, these bolts are manufactured to the US Army-Navy (AN) standard, predecessor to Mil-Spec (MS), superseded by the National Aerospace Standard (NAS). Commonly used in aviation for either tensile/shear load applications. Made from high-strength type 4037 or 8740 alloy steel or 431 Stainless Steel (CRES) and cadmium plated for superior corrosion resistance (compared to commercial grade zinc plated bolts) they are offered with shank drilled for cotter pin or undrilled for stop nut application, and with a drilled head for safety wire or without. Minimum Tensile Strength (Steel and CRES) - 125,000psi. The length of AN aircraft bolts is measured from under the head to the end of the shank. The "grip" is the unthreaded portion of the shank. Threads are pressed into the steel, not cut, thus maintaining strength throughout the entire shank. The surface under the head of AN bolts is designed to be a bearing surface to reduce non-uniform stress as the bolt is torqued thus reducing premature fatigue. The following letters are used in the product part  numbers.

"A" after the dash number for bolts with undrilled shank

"C"  for bolts made of 431 Stainless Steel (CRES)

"H" after the AN number for bolts with drilled head (eg. AN5H-15)

 AN3 through AN20 Series bolts are superseded by NASM3 through 20 Series. The part numbers in both series have not been changed.

Specification Details:

AN3 through AN20 (REV. 12), Military Specification Sheet: Bolt -Machine, Aircraft [superseded by NASM3 through 20]. This specification covers aircraft machine bolts part numbers, AN3, AN4, AN5, AN6, AN7, AN8, AN9, AN10, AN14, AN16, AN17, AN18, and AN20. AN3 THRU AN20  is canceled and superseded by NASM3 THRU NASM20. The Part Identification Number (PIN) for AN3 THRU AN20 REV. 12 and the part number for NASM3 THRU NASM20 are identical. The part numbers have not been changed.

AVIATIONEU NEW ERA Screw Extraction Kit is intended for use as a removal tool of stuck or broken screws, bolts or studs.

The kit consists of a 6-piece standard screwdriver set and a T Type steel single sided ratchet wrench adjustable to handle fasteners of M3 to M8 sizes.

It is a high quality, versatile, convenient, efficient and long service life kit that can be used for home and professional applications in bikes, cars, electronics, household appliances, mobile repairs and other uses.

The 6-piece standard screwdriver set and the ratchet wrench can be bought separately although the kit provides a cost effective solution.

Machine screws are one of the more widely used products among dozens of standard fastener types. They can be either coarse-threaded or fine-threaded, and are usually available with a wide range of head types. Usually stronger than many other screw types, they are used for fastening metal parts and panels securely together in a range of construction and other applications including aerospace, machinery, vehicles, engines, tool assemblies, electronic devices, and large-scale industrial equipment.

Sourced from quality producers,  machine screws are offered as part of our own branded (AVIATIONEU NEW ERA) product lines conforming to aerospace/military or industrial standards/specifications.  They come in different sizes, head types, materials and thread gradings. NAS Standard Machine Screws meet aerospace standards and come in different types and sizes structured in different series including NAS1101, NAS1102, NAS1189, NAS1190, NAS1191, NAS1635, NAS1801, NAS1802, NAS220, NAS229, NAS333, NAS514, NAS517, NAS560, NAS583, NAS600, NAS623 and NAS662.

AVIATIONEU NEW ERA NAS517 series of machine (non structural) screws are aeronautical 100 deg. high strength cross recessed flush head close tolerance machine screws. They are made from alloy steel with a Cadmium finish per QQ-P-416 Type II and feature a 160 - 180 KSI tensile strength. They are both offered in different thread sizes and lengths in inches and sold in pieces. For more information, please refer to the supplied documentation or contact us.

AN hex head bolts in different series are offered under AVIATIONEU NEW ERA product series. Sourced from quality vendors, these bolts are manufactured to the US Army-Navy (AN) standard, predecessor to Mil-Spec (MS), superseded by the National Aerospace Standard (NAS). Commonly used in aviation for either tensile/shear load applications. Made from high-strength type 4037 or 8740 alloy steel or 431 Stainless Steel (CRES) and cadmium plated for superior corrosion resistance (compared to commercial grade zinc plated bolts) they are offered with shank drilled for cotter pin or undrilled for stop nut application, and with a drilled head for safety wire or without. Minimum Tensile Strength (Steel and CRES) - 125,000psi. The length of AN aircraft bolts is measured from under the head to the end of the shank. The "grip" is the unthreaded portion of the shank. Threads are pressed into the steel, not cut, thus maintaining strength throughout the entire shank. The surface under the head of AN bolts is designed to be a bearing surface to reduce non-uniform stress as the bolt is torqued thus reducing premature fatigue. The following letters are used in the product part  numbers.

"A" after the dash number for bolts with undrilled shank

"C"  for bolts made of 431 Stainless Steel (CRES)

"H" after the AN number for bolts with drilled head (eg. AN8H-15)

 AN3 through AN20 Series bolts are superseded by NASM3 through 20 Series. The part numbers in both series have not been changed.

Specification Details:

AN3 through AN20 (REV. 12), Military Specification Sheet: Bolt -Machine, Aircraft [superseded by NASM3 through 20]. This specification covers aircraft machine bolts part numbers, AN3, AN4, AN5, AN6, AN7, AN8, AN9, AN10, AN14, AN16, AN17, AN18, and AN20. AN3 THRU AN20  is canceled and superseded by NASM3 THRU NASM20. The Part Identification Number (PIN) for AN3 THRU AN20 REV. 12 and the part number for NASM3 THRU NASM20 are identical. The part numbers have not been changed.

Machine screws are one of the more widely used products among dozens of standard fastener types. They can be either coarse-threaded or fine-threaded, and are usually available with a wide range of head types. Usually stronger than many other screw types, they are used for fastening metal parts and panels securely together in a range of construction and other applications including aerospace, machinery, vehicles, engines, tool assemblies, electronic devices, and large-scale industrial equipment.

Sourced from quality producers,  machine screws are offered as part of our own branded (AVIATIONEU NEW ERA) product lines conforming to aerospace/military or industrial standards/specifications.  They come in different sizes, head types, materials and thread gradings. Countersunk screws allow the head of the screw to sit flush with or below the surface of the surrounding material. They may also be used to remove the burr left from a drilling or tapping operation thereby improving the finish of the product and removing any hazardous sharp edges.

AVIATIONEU NEW ERA MS35206 and MS35207 series of machine (non structural) screws are mil spec pan head cross recessed (Phillips) screws, manufactured from carbon steel and are cadmium plated to specification QQ-P-416, Type 2, Class 3. MS35206 series machine screws feature 60,000 psi min. tensile strength and can be used as replacements for AN526 truss head & AN515 round head screws. MS35207 series machine screws are fine threaded have a minimum tensile strength of 55,000 psi and replace the AN507R series. Both MS35206 and MS35207 series machine screws are offered in different diameters, thread sizes and lengths in inches and they are sold in pieces. For more information, please refer to the individual product presentations, the supplied documentation or contact us.

AVIATIONEU NEW ERA ASTM A193 Grade B6 Series stainless steel stud bolts are manufactured from the ferritic grade AISI 410 stainless steel and can be heat-treated and machined to minimum of 110-ksi or 760 Mpa tensile strength. Like other fasteners in this seies, apart from their high tensile strength, they exhibit excellent resistance to corrosion, durability as well as a long functional work life. They can be used in different applications in industries that demand high tensile strength and corrosion resistance. Sourced by certified manufacturers they are competively priced and offered in different diameters and lengths. Sold by the piece (pc.) in increments of 10 pieces with Minimum Order Quantity (MOQ) 100 pieces. Appearing price is for reference only and differentiates based on wanted bolt sizes. Please contact us for a quotation.

National Aerospace Standard (NAS) machine bolts are commonly used in aircraft, space shuttles, military vehicles, drones, and other high-performance applications. They are offered in different series to meet application requirements.

Those of NAS 6203 through NAS 6220 series, superseding their NAS 11(xx) counterparts, are tension hexagon head high strength close tolerance short-thread alloy steel bolts with a minimum tensile strength of 160,000 psi and a minimum shear strength of 95,000 psi.

They are made from different steel alloys such as 4140 (UNS G41400) or  4340 (UNS G43406) with either Cadmium Plate  Type II, Class 2 or Chromium Plate on shank only with all other surfaces cadmium plated.

Depending on the series they come in different nominal diameters in inches (e.g. NAS 6203 0.1875" (3/16"), NAS 6204 0.25" (1/4"), NAS 6205  0.3125" (5/16"), NAS 6206 0.375" (3/8"), NAS 6208 0.500" 1/2") or NAS 6210 0.625" (5/8") grips (in 1/16” increments beginning at 1/16”), thread and overall fastener lengths. They can be supplied undrilled or with drilled head and/or thread and with or without locking elements (nylon or equivalent). Sourced from quality manufacturers, these bolts are listed according to their series, and offered either as OEM parts or as parts of our own labelled (AVIATIONEU NEW ERA) product lines (see the respective listings). Sold in pieces or packs of specified number of bolts per pack designated by the number after the letters "PK" in the product reference code (SKU).

The following letters after the basic part numbers specify the material, finish, drilling condition, and self-locking capability of these bolts.

No Finish Code for Cadmium II plated bolts

"C" for Chromium plated bolts (shank only)

"L" for Self-locking bolts

"P" for Self-locking bolts with patch type locking element only

Grip Dash Number indicating grip in .0625 increments

"D" after the grip dash number for drilled thread bolts

"H" after the grip dash number for bolts with drilled head

More than one code letters may be used in sequence.

PN Examples:

NAS6204-10 - NAS 6204 Series Bolt, .2500-28 Thread, .625 Grip, Undrilled, Non-locking, Alloy Steel Cadmium II Plated.

NAS6204-10D - Same bolt as above with Drilled Thread.

For more information, please refer to the supplied documentation or contact us.

AN Clevis bolts are manufactured from nickel steel alloy, SAE 2330 and cadmium plated in same manner as AN3 - AN8 aircraft bolts.They are special-purpose bolts with a a slotted brazier type head and used where a large shearing stress occurs (never in tension). Minimum tensile strength 125,000 PSI. They are available with drilled or undrilled shank (designated by the letter "A" after the dash number for undrilled shank). For the AN12-AN23 bolts the second digit denotes the fine thread machine screw size (e.g. for AN21 the size is 6-40, for AN22 8-36 and for AN23 10-32). For the AN24-AN36 bolts the second digit denotes the diameter in 1/16 inch increments (AN25 has a diameter of 5/16 inch).

AN 22 Series Clevis bolts are available in NEW SURPLUS condition. Availability till stock exhaustion. They are special-purpose bolts with a a slotted brazier type head and used where a large shearing stress occurs (never in tension). Available with drilled or undrilled shank (designated by the letter "A" after the dash number for undrilled shank).
