Structural screws are made of alloy steel, are properly heat treated, and can be used as structural bolts. Those commonly used in aircraft applications are manufactured to aerospace/military standards/specifications. They are offered as part of our own branded (AVIATIONEU NEW ERA) product lines structured in different series based on the standard of their conformance. Some of the screws commonly used include NAS204 through NAS235 and AN509/AN525 series.

AN525/AN525R Series high-strength structural washer head (AN525) and cross-recessed (Phillips) head (AN525R) screws, fabricated from alloy steel per specification QQ-S-689. Tensile strength 125,000 PSI. Cadmium plated per QQ-P-416A, Type II, Class 3.

The AN525 washer head structural screws provide a large contact area. The AN509R (100° countersunk) Phillips head screws are used in countersunk holes where a flush surface is necessary. These have been replaced by MS24694 Series structural screws of the respective materials and finishes.

Structural screws have a definite grip and the same shear strength as a bolt of the same size. Shank tolerances are similar to AN hex head bolts, and the threads are National Fine. Structural screws are available with round, brazier, or countersunk heads. The recessed head screws are driven by either a Phillips or a Reed and Prince screwdriver. Sourced from quality suppliers, these structural screws are offered as part of our own labelled (AVIATIONEU NEW ERA) product lines in different thread sizes and lengths in inches and sold in pieces. For more information, please refer to the individual product presentations, the supplied documentation or contact us.

National Aerospace Standard (NAS) machine bolts are commonly used in aircraft, space shuttles, military vehicles, drones, and other high-performance applications. They are offered in different series to meet application requirements.

Those of NAS 6203 through NAS 6220 series, superseding their NAS 11(xx) counterparts, are tension hexagon head high strength close tolerance short-thread alloy steel bolts with a minimum tensile strength of 160,000 psi and a minimum shear strength of 95,000 psi.

They are made from different steel alloys such as 4140 (UNS G41400) or  4340 (UNS G43406) with either Cadmium Plate  Type II, Class 2 or Chromium Plate on shank only with all other surfaces cadmium plated.

Depending on the series they come in different nominal diameters in inches (e.g. NAS 6203 0.1875" (3/16"), NAS 6204 0.25" (1/4"), NAS 6205  0.3125" (5/16"), NAS 6206 0.375" (3/8"), NAS 6208 0.500" 1/2") or NAS 6210 0.625" (5/8") grips (in 1/16” increments beginning at 1/16”), thread and overall fastener lengths. They can be supplied undrilled or with drilled head and/or thread and with or without locking elements (nylon or equivalent). Sourced from quality manufacturers, these bolts are listed according to their series, and offered either as OEM parts or as parts of our own labelled (AVIATIONEU NEW ERA) product lines (see the respective listings). Sold in pieces or packs of specified number of bolts per pack designated by the number after the letters "PK" in the product reference code (SKU).

The following letters after the basic part numbers specify the material, finish, drilling condition, and self-locking capability of these bolts.

No Finish Code for Cadmium II plated bolts

"C" for Chromium plated bolts (shank only)

"L" for Self-locking bolts

"P" for Self-locking bolts with patch type locking element only

Grip Dash Number indicating grip in .0625 increments

"D" after the grip dash number for drilled thread bolts

"H" after the grip dash number for bolts with drilled head

More than one code letters may be used in sequence.

PN Examples:

NAS6204-10 - NAS 6204 Series Bolt, .2500-28 Thread, .625 Grip, Undrilled, Non-locking, Alloy Steel Cadmium II Plated.

NAS6204-10D - Same bolt as above with Drilled Thread.

For more information, please refer to the supplied documentation or contact us.

National Aerospace Standard (NAS) machine bolts are commonly used in aircraft, space shuttles, military vehicles, drones, and other high-performance applications. They are offered in different series to meet application requirements.

NAS 6604 Series Steel Cadmium Plated Shear Hex Head Machine Bolts are offered as part of our own labelled (AVIATIONEU NEW ERA) lines of  fasteners. Sourced from quality manufacturers, AVIATIONEU NEW ERA NAS6604 series shear hexagon head bolts conform to the respective U.S. National Aerospace Standard of the Aerospace Industries' Association. They have a 1/4-28 thread and a nominal grip diameter of 0.2500 inch. NAS6604 series forms part of NAS family of bolts (NAS6603 through NAS6610 series) which includes hex head, close tolerance, alloy steel, long thread, self-locking & non-locking bolts. Their shearing feature is used to minimize damage to more critical components within the application. They are made from alloy steel with cadmium or chromium finishes and offered  in different grips and lengths in inches with undrilled or drilled head and/or shank. Used in applications where a premium-quality, high strength bolt is necessary. The following letters after the basic part numbers specify the material, finish and drilling condition of these bolts.

No Finish Code for cadmium plated bolts

"C" for chromium plated bolts

"D" for drilled shank bolts

"L" for self-locking bolts

"P" for self-locking bolt with patch type locking element

"H"for bolts with drilled head

More than one code letters may be used in sequence.

AVIATIONEU NEW ERA Hexagon Bolts are made of Stainless Steel 304/316 (depending on the P/N) with a bright surface treatment and a strength class of A2-70 for SS 304 bolts and A4-70 for SS 316 bolts. They are fully threaded, coarse type, and produced by certified manufacturers in accordance with DIN 933 standard. They are offered in competitive prices in different diameters ("M" designated), indicating the bolt's diameter in mm and lengths in mm. The thread pitch (the distance between threads measured along the length of the bolt) expressed in mm is indicated by the "P" designation in the P/N. Sold in packs of 250, 100 or  25 pieces depending on the selected product. The number of pieces included in each pack is mentioned after "PK" designation.

ROTAX® aircraft  engines form part of the product portfolio  of BRP-Powertrain GmbH & Co. KG which develops and manufactures engines for snowmobiles, watercrafts, boats, roadsters, all-terrain and side-by-side vehicles, motorcycles, carts, and aircrafts.

BRP-ROTAX® product range includes certified and non certified internal combustion engines, parts and accessories for light and ultralight aircraft.

Different screws, such as hexagonal, allen, fixation and others are used in BRP-ROTAX® aircraft engines (please refer to the respective product presentations). They come in various sizes (mostly Metric) and are offered as certified or non certified parts from the manufacturer. Non certified parts can be used in ultralights or other aircraft not requiring certification of parts for their installation. Certified parts are designated by the letters "CERT" after the part number in the product reference number (SKU).

Aircraft engine  parts are subject to changes from time to time. Some parts may be no longer available or replaced by others with different part numbers. Listed BRP-ROTAX® engine parts do not imply their current availability or suitability for your engine application. Always consult the most recent Illustrated Part Catalogs (IPCs) or other documentation available from the manufacturer for the correct part number before ordering.

European Standards (EN) and other deliverables are developed in a large number of sectors by the CEN National Standardization Bodies and CENELEC's National Committees (NCs) of the EU and EFTA countries. Together with the European Telecommunications Standards Institute (ETSI) they are the three European Standardisation Organisations operating under the Regulation (EU) No 1025/2012 to produce European harmonised standards in support of EU legislation and policies.

EN 6114 & EN 6115 Standards relate to short thread countersunk & protruding head bolts respectively for aerospace applications. EN6114 & EN 6115 Standard bolts are commonly used on Airbus commercial aircraft platforns such as A320, A330, A350 and A380. Airbus A320/ A330 aicraft commonly use the alloy steel versions of the EN6114 Standard bolts and those of the Titanium series indicated by the V and T surface coding. The Airbus A350 and A380 models incorporate those from INCONEL®  nickel-chromium-based superalloy. Several HLT, HST, NSA, and VL fasteners can be used as alternates to those of EN6114 Standard (see the supplied documentation).

Sourced from various manufacturers in different materials (steel, titanium or INCONEL® alloys), coatings and sizes, the EN 6114 & EN 6115 Standard bolts are offered as OEM parts of their respective suppliers or as part our own labelled (AVIATIONEU NEW ERA) product lines. Different material letter codes in the part number indicate the material used (e.g. " V" and "T" for Titanium or "L" and "M" for Inconel®). They are sold in packs with the number of bolts included in each pack designated after the letters "PK" in the product reference number (SKU). For additional information please refer to our brochure in our Attachment section

The NAS1630 Series screws are pan head, short thread, offset cruciform machine screws offered as part of our own branded (AVIATIONEU NEW ERA) product lines. These screws use PHILLIPS Screw-Torq-Set® drive system with significant benefits outlined below. Sourced from quality manufacturers they are offered in alloy steel or corrosion resistant steel (CRES) and different thread sizes and legths in inches. Sold in packs each containing a specified number of screws. The number of screws in each pack is specified after the letters "PK" in the product reference code (SKU).

PHILLIPS Screw-Torq-Set® Drive System Features & Benefits

Offset cruciform shape with straight wing walls for greater torque transfer.

Removal walls larger than drive walls. Facilitates disassembly without drill outs.

Specific driver for each diameter fastener. Assures optimum torque for each size and strong head configuration.

Compatible with standard PHILLIPS ACR® ribbed TORQ-SET® drivers. Allows use of ribbed tools with standard screws

PSC quality inspections. Assures global system quality and compatibility.

National Aerospace Standard (NAS) machine bolts are commonly used in aircraft, space shuttles, military vehicles, drones, and other high-performance applications. They are offered in different series to meet application requirements.

Those of NAS 6203 through NAS 6220 series, superseding their NAS 11(xx) counterparts, are tension hexagon head high strength close tolerance short-thread alloy steel bolts with a minimum tensile strength of 160,000 psi and a minimum shear strength of 95,000 psi.

They are made from different steel alloys such as 4140 (UNS G41400) or  4340 (UNS G43406) with either Cadmium Plate  Type II, Class 2 or Chromium Plate on shank only with all other surfaces cadmium plated.

Depending on the series they come in different nominal diameters in inches (e.g. NAS 6203 0.1875" (3/16"), NAS 6204 0.25" (1/4"), NAS 6205  0.3125" (5/16"), NAS 6206 0.375" (3/8"), NAS 6208 0.500" 1/2") or NAS 6210 0.625" (5/8") grips (in 1/16” increments beginning at 1/16”), thread and overall fastener lengths. They can be supplied undrilled or with drilled head and/or thread and with or without locking elements (nylon or equivalent). Sourced from quality manufacturers, these bolts are listed according to their series, and offered either as OEM parts or as parts of our own labelled (AVIATIONEU NEW ERA) product lines (see the respective listings). Sold in pieces or packs of specified number of bolts per pack designated by the number after the letters "PK" in the product reference code (SKU).

The following letters after the basic part numbers specify the material, finish, drilling condition, and self-locking capability of these bolts.

No Finish Code for Cadmium II plated bolts

"C" for Chromium plated bolts (shank only)

"L" for Self-locking bolts

"P" for Self-locking bolts with patch type locking element only

Grip Dash Number indicating grip in .0625 increments

"D" after the grip dash number for drilled thread bolts

"H" after the grip dash number for bolts with drilled head

More than one code letters may be used in sequence.

PN Examples:

NAS6204-10 - NAS 6204 Series Bolt, .2500-28 Thread, .625 Grip, Undrilled, Non-locking, Alloy Steel Cadmium II Plated.

NAS6204-10D - Same bolt as above with Drilled Thread.

For more information, please refer to the supplied documentation or contact us.

The NAS1581 Series screws  (also termed as bolts) are high strength, close tolerance, reduced (shear) head, countersunk screws offered as part of our own branded (AVIATIONEU NEW ERA) product lines. They come in different materials and finishes designated by the following letters in their product reference number (SKU) which is formed as a combination of the material, diameter, drive style, grip length and option of the screw:

Materials

(A) or (F) = Alloy Steel, 4140,4340 or 8740, Heat treated to 160-180ksi. Cad 2 plated. Material Code (A) has been superseded by Code (F)

(C) = Corrosion Resistant (A286) Steel, Heat treated to160-190ksi. Cad 2 (optional)

(V) = Titanium (6al-4v) Heat treated to 160-180ksi. No finish. Material Code (V) has been cancelled Dec.1991

Diameters: Numbers 3 to 10

Drive Styles

(R)= Offset Cruciform, (Torq-set) R, for diameters 3,4 & 5.

(T) = Offset Cruciform, (Torq-set) R for diameters 6 and up.

(H) = Dovetail Slot

Grip Lengths

The grip length  for Countersunk Head Fasteners (T in the supplied table) includes the head and extends to the full cylindrical portion of the shank. The Grip Length for NAS1581 Series screws is measured in 1/16ths of an inch. + or - .010

AVIATIONEU NEW ERA NAS1581 Series screws are offered in pieces or kits for convenience and economy.

For more information, please refer to the supplied documentation or contact us.

Machine screws are one of the more widely used products among dozens of standard fastener types. They can be either coarse-threaded or fine-threaded, and are usually available with a wide range of head types. Usually stronger than many other screw types, they are used for fastening metal parts and panels securely together in a range of construction and other applications including aerospace, machinery, vehicles, engines, tool assemblies, electronic devices, and large-scale industrial equipment.

Sourced from quality producers,  machine screws are offered as part of our own branded (AVIATIONEU NEW ERA) product lines conforming to aerospace/military or industrial standards/specifications.  They come in different sizes, head types, materials and thread gradings. Countersunk screws allow the head of the screw to sit flush with or below the surface of the surrounding material. They may also be used to remove the burr left from a drilling or tapping operation thereby improving the finish of the product and removing any hazardous sharp edges.

AVIATIONEU NEW ERA MS35206 and MS35207 series of machine (non structural) screws are mil spec pan head cross recessed (Phillips) screws, manufactured from carbon steel and are cadmium plated to specification QQ-P-416, Type 2, Class 3. MS35206 series machine screws feature 60,000 psi min. tensile strength and can be used as replacements for AN526 truss head & AN515 round head screws. MS35207 series machine screws are fine threaded have a minimum tensile strength of 55,000 psi and replace the AN507R series. Both MS35206 and MS35207 series machine screws are offered in different diameters, thread sizes and lengths in inches and they are sold in pieces. For more information, please refer to the individual product presentations, the supplied documentation or contact us.

AN hex head bolts in different series are offered under AVIATIONEU NEW ERA product series. Sourced from quality vendors, these bolts are manufactured to the US Army-Navy (AN) standard, predecessor to Mil-Spec (MS), superseded by the National Aerospace Standard (NAS). Commonly used in aviation for either tensile/shear load applications. Made from high-strength type 4037 or 8740 alloy steel or 431 Stainless Steel (CRES) and cadmium plated for superior corrosion resistance (compared to commercial grade zinc plated bolts) they are offered with shank drilled for cotter pin or undrilled for stop nut application, and with a drilled head for safety wire or without. Minimum Tensile Strength (Steel and CRES) - 125,000psi. The length of AN aircraft bolts is measured from under the head to the end of the shank. The "grip" is the unthreaded portion of the shank. Threads are pressed into the steel, not cut, thus maintaining strength throughout the entire shank. The surface under the head of AN bolts is designed to be a bearing surface to reduce non-uniform stress as the bolt is torqued thus reducing premature fatigue. The following letters are used in the product part  numbers.

"A" after the dash number for bolts with undrilled shank

"C"  for bolts made of 431 Stainless Steel (CRES)

"H" after the AN number for bolts with drilled head (eg. AN6H-15)

 AN3 through AN20 Series bolts are superseded by NASM3 through 20 Series. The part numbers in both series have not been changed.

Specification Details:

AN3 through AN20 (REV. 12), Military Specification Sheet: Bolt -Machine, Aircraft [superseded by NASM3 through 20]. This specification covers aircraft machine bolts part numbers, AN3, AN4, AN5, AN6, AN7, AN8, AN9, AN10, AN14, AN16, AN17, AN18, and AN20. AN3 THRU AN20  is canceled and superseded by NASM3 THRU NASM20. The Part Identification Number (PIN) for AN3 THRU AN20 REV. 12 and the part number for NASM3 THRU NASM20 are identical. The part numbers have not been changed.

AN hex head bolts in different series are offered under AVIATIONEU NEW ERA product series. Sourced from quality vendors, these bolts are manufactured to the US Army-Navy (AN) standard, predecessor to Mil-Spec (MS), superseded by the National Aerospace Standard (NAS). Commonly used in aviation for either tensile/shear load applications. Made from high-strength type 4037 or 8740 alloy steel or 431 Stainless Steel (CRES) and cadmium plated for superior corrosion resistance (compared to commercial grade zinc plated bolts) they are offered with shank drilled for cotter pin or undrilled for stop nut application, and with a drilled head for safety wire or without. Minimum Tensile Strength (Steel and CRES) - 125,000psi. The length of AN aircraft bolts is measured from under the head to the end of the shank. The "grip" is the unthreaded portion of the shank. Threads are pressed into the steel, not cut, thus maintaining strength throughout the entire shank. The surface under the head of AN bolts is designed to be a bearing surface to reduce non-uniform stress as the bolt is torqued thus reducing premature fatigue. The following letters are used in the product part  numbers.

"A" after the dash number for bolts with undrilled shank

"C"  for bolts made of 431 Stainless Steel (CRES)

"H" after the AN number for bolts with drilled head (eg. AN5H-15)

 AN3 through AN20 Series bolts are superseded by NASM3 through 20 Series. The part numbers in both series have not been changed.

Specification Details:

AN3 through AN20 (REV. 12), Military Specification Sheet: Bolt -Machine, Aircraft [superseded by NASM3 through 20]. This specification covers aircraft machine bolts part numbers, AN3, AN4, AN5, AN6, AN7, AN8, AN9, AN10, AN14, AN16, AN17, AN18, and AN20. AN3 THRU AN20  is canceled and superseded by NASM3 THRU NASM20. The Part Identification Number (PIN) for AN3 THRU AN20 REV. 12 and the part number for NASM3 THRU NASM20 are identical. The part numbers have not been changed.

AVIATIONEU NEW ERA ASTM A324 Grade 10.9 Series high tensile hexagonal head threaded bolts are produced from medium carbon steel, medium carbon steel alloy and low carbon boron steel with heat treatment by both quenching and tempering.  They meet ASTM A324 Grade BD and SAE J429 standards. These bolds feature high tensile strength and good wear resistance and are used in automotive applications and for bolting large and forged parts.

Nominal Tensile Strength: 1.000 Megapascal (MPa) or 1.000 N/sqr. mm , Yield Stress: 900 Megapascal (MPa) or 900 N/sqr. mm

They are offered in different finishes (zinc plated, plain or hot dip galvanised) and different standard, coarse and fine thread sizes (diameter M20 to M100 mm / 3/4" to 3.1/2").  Sold by the piece (pc.) in increments of 10 pieces with Minimum Order Quantity (MOQ) 100 pieces. Appearing price is for reference only and differentiates based on wanted bolt sizes. Please contact us for a quotation.

AN Clevis bolts are manufactured from nickel steel alloy, SAE 2330 and cadmium plated in same manner as AN3 - AN8 aircraft bolts.They are special-purpose bolts with a a slotted brazier type head and used where a large shearing stress occurs (never in tension). Minimum tensile strength 125,000 PSI. They are available with drilled or undrilled shank (designated by the letter "A" after the dash number for undrilled shank). For the AN12-AN23 bolts the second digit denotes the fine thread machine screw size (e.g. for AN21 the size is 6-40, for AN22 8-36 and for AN23 10-32). For the AN24-AN36 bolts the second digit denotes the diameter in 1/16 inch increments (AN25 has a diameter of 5/16 inch).

Machine screws are one of the more widely used products among dozens of standard fastener types. They can be either coarse-threaded or fine-threaded, and are usually available with a wide range of head types. Usually stronger than many other screw types, they are used for fastening metal parts and panels securely together in a range of construction and other applications including aerospace, machinery, vehicles, engines, tool assemblies, electronic devices, and large-scale industrial equipment.

Sourced from quality producers,  machine screws are offered as part of our own branded (AVIATIONEU NEW ERA) product lines conforming to aerospace/military or industrial standards/specifications.  They come in different sizes, head types, materials and thread gradings. NAS Standard Machine Screws meet aerospace standards and come in different types and sizes structured in different series including NAS1101, NAS1102, NAS1189, NAS1190, NAS1191, NAS1635, NAS1801, NAS1802, NAS220, NAS229, NAS333, NAS514, NAS517, NAS560, NAS583, NAS600, NAS623 and NAS662.

AVIATIONEU NEW ERA NAS333/NAS334 series of machine (non structural) screws (also termed as bolts) are aeronautical standard 100 Deg. standard flush head, shear close tolerance screws. They are made from alloy steel per MIL-S-6049 with a Cadmium finish per QQ-P-416 Type II. They are both offered in different thread sizes, grips and lengths in inches and sold in pieces. CPA indicates a plated Phillips recess. The length and grip of the screw are indicated by numbers after the last dash in the product part number. For more information, please refer to the supplied documentation or contact us.

Machine screws are one of the more widely used products among dozens of standard fastener types. They can be either coarse-threaded or fine-threaded, and are usually available with a wide range of head types. Usually stronger than many other screw types, they are used for fastening metal parts and panels securely together in a range of construction and other applications including aerospace, machinery, vehicles, engines, tool assemblies, electronic devices, and large-scale industrial equipment.

Sourced from quality producers,  machine screws are offered as part of our own labelled (AVIATIONEU NEW ERA) product lines conforming to aerospace/military or industrial standards/specifications. They come in different sizes, head types, materials and thread gradings.

Machine sccrews meeting National Aerospace Standards (NAS), developed and maintained by the US Aerospace Industries Association (AIA), come in different types and sizes structured in different series, including:

NAS 1101, 1102, 1189, 1190, 1191, 1635, 1801, 1802, 220, 229, 333,  514,  517, 560, 583, 600, 623 και NAS 662.

The NAS 584 series are non structural machine screws are flush head close tolerance machine screws made of aeronautical 100 deg. alloy steel and cadmium plated.  Offered in different thread sizes and lengths in inches as OEM parts of respective manufacturers or as parts of AVIATIONEU NEW ERA product lines. Sold mostly in packs with number of pieces per pack specified after the letters "PK" in the product reference number (SKU). For more information, please refer to the supplied documentation or contact us.

Machine screws are one of the more widely used products among dozens of standard fastener types. They can be either coarse-threaded or fine-threaded, and are usually available with a wide range of head types. Usually stronger than many other screw types, they are used for fastening metal parts and panels securely together in a range of construction and other applications including aerospace, machinery, vehicles, engines, tool assemblies, electronic devices, and large-scale industrial equipment.

Sourced from quality producers,  machine screws are offered as part of our own labelled (AVIATIONEU NEW ERA) product lines conforming to aerospace/military or industrial standards/specifications.  They come in different sizes, head types, materials and thread gradings. Countersunk screws allow the head of the screw to sit flush with or below the surface of the surrounding material. They may also be used to remove the burr left from a drilling or tapping operation thereby improving the finish of the product and removing any hazardous sharp edges.

AVIATIONEU NEW ERA AN507 series screws are mil spec threaded 100 degree countersunk non structural screws with Phillips head. They have been replaced by the respective screws of MS24693 series of materials and finishes. These screws are made of carbon steel and cadmium plated, stainless steel unplated or brass with chemical black finish. They are sold in pieces and offered in different sizes in the following materials and finishes with the corresponding notations after MS24693 and before the size number:

Carbon Steel Cadmium plated (letter "S")

300 Series Stainless Steel unplated (letter "C")

Brass with chemical black finish, (letter "BB")

For more information, please refer to the individual product presentations, the supplied documentation or contact us.

Tapping screws eliminate the need for drilled holes, as they are designed to cut their own hole as it is screwed into the materials. They are commonly used  in cases when the material is too thin (e.g. sheet metals), there is no rear access for installation of  a nut or when disassembly is required at a later stage and therefore blind rivets can not be an alternative. Sourced from quality producers, tapping screws are offered as part of our own labelled (AVIATIONEU NEW ERA) product lines conforming to aerospace/military or industrial standards/specifications.

AVIATIONEU NEW ERA AN530 series screws are mil spec tapping screws offered in different sizes and sold in packs. Those with a Philips recessed head are indicated by the letter "R" in the product part number. Tapping screws conforming to ASME specifications are also available as part of AVIATIONEU NEW ERA product portfolio (see separate product presentation). The number of screws per package is indicated after the letters "PK" in the product reference number (SKU). For more information, please refer to the individual product presentations, the supplied documentation or contact us.

Structural screws are made of alloy steel, are properly heat treated, and can be used as structural bolts. Those commonly used in aircraft applications are manufactured to aerospace/military standards/specifications. They are offered as part of our own branded (AVIATIONEU NEW ERA) product lines structured in different series based on the standard of their conformance. Some of the screws commonly used include NAS204 through NAS235 and AN509/AN525 series.

MS24694 Series structural screws have a 100° countersunk Phillips head. They replace the respective AN509 series structural screws of materials and finishes. Minimum tensile strength for steel is 125,000 psi. They are fabricated from alloy steel and cadmium plated per specification QQ-P-416A, Type II, Class 3 or 300 Series Stainless Steel unplated designated by the letters "S" and "C" respectively in the product part number after MS24694 and before the size number.

Sourced from quality suppliers, AVIATIONEU NEW ERA MS24694 series structural screws are offered in different thread sizes and lengths in inches and sold in pieces or packs of specified number of screws designated after the letters "PK" in the product reference number (SKU). For more information, please refer to the individual product presentations, the supplied documentation or contact us.

AN hex head bolts in different series are offered under AVIATIONEU NEW ERA product series. Sourced from quality vendors, these bolts are manufactured to the US Army-Navy (AN) standard, predecessor to Mil-Spec (MS), superseded by the National Aerospace Standard (NAS). Commonly used in aviation for either tensile/shear load applications. Made from high-strength type 4037 or 8740 alloy steel or 431 Stainless Steel (CRES) and cadmium plated for superior corrosion resistance (compared to commercial grade zinc plated bolts) they are offered with shank drilled for cotter pin or undrilled for stop nut application, and with a drilled head for safety wire or without. Minimum Tensile Strength (Steel and CRES) - 125,000psi. The length of AN aircraft bolts is measured from under the head to the end of the shank. The "grip" is the unthreaded portion of the shank. Threads are pressed into the steel, not cut, thus maintaining strength throughout the entire shank. The surface under the head of AN bolts is designed to be a bearing surface to reduce non-uniform stress as the bolt is torqued thus reducing premature fatigue. The following letters are used in the product part  numbers.

"A" after the dash number for bolts with undrilled shank

"C"  for bolts made of 431 Stainless Steel (CRES)

"H" after the AN number for bolts with drilled head (eg. AN4H-15)

 AN3 through AN20 Series bolts are superseded by NASM3 through 20 Series. The part numbers in both series have not been changed.

Specification Details:

AN3 through AN20 (REV. 12), Military Specification Sheet: Bolt -Machine, Aircraft [superseded by NASM3 through 20]. This specification covers aircraft machine bolts part numbers, AN3, AN4, AN5, AN6, AN7, AN8, AN9, AN10, AN14, AN16, AN17, AN18, and AN20. AN3 THRU AN20  is canceled and superseded by NASM3 THRU NASM20. The Part Identification Number (PIN) for AN3 THRU AN20 REV. 12 and the part number for NASM3 THRU NASM20 are identical. The part numbers have not been changed.
